可编辑修改精选全文完整版1、DCS的控制机柜1.1、规格：2100*800*700mm、2260*800*700mm机柜样式为：前单开玻璃门，后双开门1.2 、DCS玻璃门控制机柜的正面主要安装控制器I/O模件、电源、隔离继电器和网络接口等设备。
1.3 、DCS玻璃门控制机柜背面两边布置两排竖排端子，用以连接现场热电阻、热电偶、模拟量信号以及开关量输入输出信号。
(附图)1.4、控制FCS机柜（远程柜）规格：1800*900*500mm、1300*900*500mm机柜样式为：前单开门现场总线控制机箱的材料为不锈钢、优质冷轧板，具有防水、防尘、防腐蚀功能，其防护等级为IP56，可以满足全露天布置环境。
(附图)1.5、箱主要安装控制器2500C、2500I/O模件,以及电源等设备。
1.6、左右布置有端子，用以连接现场热电阻、热电偶、模拟量信号以及开关量输入输出信号。
1.7、根据具体配置,每个现场总线控制机箱最多可布置四个2500控制器及相应的I/O模件。
通过Profibus或Modbus通讯电缆与DPU相连。
操作台1.8、操作员员站样式（附图）。
1.9、操作员站上可布置后备操按钮（紧急停炉、停机、汽包紧急放水门等）2、DCS的电源和接地2.1、 NETWORK6000系统中各分散处理站通常广泛的分布于全厂，除了非常小的系统，整个系统实现单点接地是不太实际。
但在大部分NETWORK6000的应用中，组成系统的分散站分布在全厂许多地区。
例如，分散站可以在控制室，计算机室、循泵房、制粉车间等。
通过在各个分散处理站之间建立“区域接地”可以实现单点接地。
所有数据高速公路的接地阻抗，必须遵循≤2欧姆的原则。
一般来说，把在半径为15米的圆形区域内的所有站定义为一个耦合站，对于接地来说，这一限制指的是从站的中心接地点到某个工作站的最大电缆长度。
藕合站内的各站点必须在离中心接地点15米的电缆长度范围内。
每个选定的藕合站位置中都应有一个相应的接地点或接地网，为保证系统的正常操作，所有藕合站接地时，应遵循以下规则：不要通过非NETWORK6000设备接地；不要接在高压设备使用的地线上；不要通过NETWORK6000部件对非NETWORK6000设备（除标准外设以外）进行接地；不要通过建筑构件接地,如工字梁等；在工作站簇内接地线不要超过15米。
