AC6901A杰理蓝牙方案开发说明
一、简介
AC6901A是杰理于2016年12月推出的一款单芯片的蓝牙解决方案,LQFP48封装的，支持MP3和WAV。
同时还支持无损格式FLAC、APE的解码，24位的DAC输出。
它集合了蓝牙+插卡+收音，蓝牙的版本为2.1+EDR，可以说这个芯片是一个功能强大，开发插卡蓝牙音箱的不二选择
二、杰理方案的分类说明
杰里的所有系列的芯片，都是一个晶圆，只是根据不同的需求，进行不同方式的封装，也就是说AC690N 系列里面SSOP24和LQFP48封装的晶圆是一样的。
注意，AC6901A芯片是可以反复烧录的，有想法的朋友可以自己摸索的
三、AC6901A的特点
●小型封装LQFP48。
四面出脚。
生产加工和调试不是很方便
●支持USB设备、TF卡、FM、AUX、蓝牙。
●支持遥控功能
●按键稳定支持10个[正常的产品，软件可设]，上一曲、下一曲。
可以随意扩展
●可以带显示的插卡方案，另外高达32个可用的GPIO，可以组成很多功能
1、AC6901A的管脚说明
2、芯片资源介绍
四、特别说明：
●芯片为可编程，由于程序是烧录在芯片内部的flash中，所以可以重复擦除
●感兴趣的朋友，可以自己开发，因为AC690N系列不需要开发板，不需要烧录器
●如果要自己开发的话，最好要买一个现成的板子，引出基本的gpio和串口、USB口就可以了。
