a fraction of 若干分之一a matter of 大约，大概account for 说明account for占（比重）acquisition 获得active power 有功功率admittance 导纳agricultural loads 农业负荷Air-blast空中爆炸angular difference 角差异apparent power 视在功率approach 方法as a matter of routine按常规as well as 也asynchronous 异步的at a rate以...比率autotransformer 自耦变压器bring back使恢复burden 负载by virtue of 依靠cable 电缆capacitance 电容capacitor bank 电容器组carrier line 载波线cascading 级联category 种类circulating current 环流clearance 间距coincide with 与...一致combustion 燃烧commercial loads 商业负荷complex power 复数功率component based approach 合成法compressors 压缩机conductance 电导configuration 构造constant current 恒电流constant impedance 恒阻抗constant power 恒功率consume 消耗contact 接触器contactor 电流接触器contingency 意外事故corona 电晕critical clearing time 临界切除时间cross section 横截面cyclic 交变的damping torque 阻尼转矩dead tank固定箱体deprive sb of sth 剥夺某人的某物distribution feeders 配电馈线distribution system 配电系统distribution transformer配电变压器disturbance 扰动dynamic stability 动态稳定性eddy-current loss 涡流损耗efficiency 效率equal-area criterion 等面积法则equilibrium 平衡equivalent circuit 等效电路evolve into 发展成exciting current 励磁电流exponential model 指数模型expose to 使易受facility 设备fast breeder reactors快速中子反应堆fluctuation 波动起伏flux linkage 磁链fossil fuel plant 化石燃料电厂fuse cutout 保险器gas-turbine plants燃气轮机电厂generating unit 发电机组hermetically sealed 密封hydropower水力发出的电力hysteresis loss 磁滞损耗imbalance 阻抗impedance 阻抗in parallel with 与...并联in phase 同相地in step同步in the regard在这点上in turn 随后inductance 电感industrial loads 工业负荷infinite bus 无穷大母线input winding 输入绕组installation 装置装配instrument 仪表insulator string 绝缘子串insulator绝缘体intact 完好无缺的interconnecting transformer联络变压器intervention干预iron core 铁心isolating switches 隔离开关kirchoff's current law基尔霍夫电流定律large mode 大方式laws of motion 运行法则lead sheath 铅皮leakage reactance 漏电抗leakage漏，泄漏least square 最小2乘方live tank活动箱体load shedding甩负荷loop system 环状系统magnetizing current 磁化电流measurement based approach测辨法mechanical strength 机械强度megavoltampere兆伏安mining loads 矿业负荷monitor 监控nameplate 铭牌negative sequence 负序neutral 中性点noise suppression 噪声抑制nonsynchronous 异步的nuclear fission 核裂变nuclear fusion 核聚变nuclear reaction 核反应on the order to 属于...一类的oscillograph 示波器out of step 失步output winding输出绕组peak load 峰荷permanent fault 永久故障perturbation 动摇phase sequence 相序phase-angle error 相角误差phasor 向量polynomial model多项式模型porcelain bushing 陶瓷套管positive sequence 正序post disturbance 扰动后的power factor 功率因子pre-disturbance 扰动前primary feeders 一次馈线primary winding一次绕组prime mover 原动机put into service 投入运行radial system 辐射状系统ratio error 比率误差reactive power 无功功率reading读数recovery 恢复refer to...as 称...为regulator 调整器residential loads 居民负荷resistance 电阻resort of 诉诸于restore 恢复restoring torque 回复力矩rotor angle 转子角度saturation 饱和secondary winding 二次绕组sectionalizer 分段隔离开关series 串联service disruption 供电中断shunt admittance 并联导纳shunt 并联，旁路simulation仿真模拟skin effect 集肤效应small mode 小方式stability margin 稳定边际stability 稳定性steam-turbine plants蒸汽轮机电厂step up/down 升/降压substation 变电所subtransmission feeders中高压馈线subtransmission system中压输电系统superimpose 迭加supervisory control 监控susceptance 电纳switches 开关symmetrical components对称分量synchronism 同步性synchronize 同步synchronizing torque 同步转矩synchronous 同步的synchroscope 同步示波器take into account 考虑temporary fault 临时故障tertiary winding 第三绕组thermal limit 发热极限thermal plants 热电厂to the point of 达到…程度torques转矩transducer 传感器transient response 瞬时反应transient 瞬时transmission subsystem 输电子系统trip 断开tripping coil 跳闸线圈turbine 涡轮机turn ratio 变比unsymmetrical 非对称的unwind 解开utility 公用事业公司variable 变数voltage collapse 电压崩溃voltampere 伏安数win over 战胜；争取过来windings 绕组with respect to 由于with respect to 至于关于zero-sequence 零序。
中英对照电气专业英语词汇A安培ampere安培表，电流表amperemeter安装mounted安装方式mounting type按钮push-button暗装flush mountedB拔号dial白炽灯incandescent lamp半导体继电保护SIC protection relay 伴热电缆heat tracing cable包装说明packing instruction饱和saturation饱和饱和铁芯saturated core饱和点saturation point饱和电抗saturated reactance饱和电抗器saturated reactor饱和电压saturation voltage饱和特性saturation characteristics 饱和系数saturation factor保持retain保持电路retaining circuit保持线圈holding coil保护protection保护电位protective potential保护范围protective zone保护间隙protective gap保护用互感器protecting transformer 保证guarantee报警窗口alarming window报警器annunciator备品备件spare parts备用电源stand by power备用回路spare circuit(feeder)备用励磁机standby exciter备用容量spare capacity背景亮度background luminance比重计gravity meter闭合closing 闭锁二极管blocking diode闭锁继电器blocking relay避雷器lightning arrester避雷器surge arrester避雷线lightning wire避雷针lightning rod边屏side panel变电站substation变流器current converter变频器frequency converter变频站frequency converter station变送器transducer变形deformation变压器transformer变压器额定变比transformer rated ratio变压器冷却系统transformer cooling system 变压器联接组别transformer angular displacement变压器绕组transformer winding变压器油箱transformer tank变阻器rheostat变阻器rheostat标称放电电流nominal discharge current标识条marking strip标幺值P.U. value=per unit value标准测试模式standard test mode标准电阻standard resistor标准型式试验standard type test表计meter并联parallel并联电抗器shunt reactor并联电容器shunt capacitor并联电容器shunt capacitor并联开断试验parallel breaking test并联支路parallel branch波纹系数ripple contain factor波纤带glass cloth tape波形wave form不带电设备de-energized equipment不对称电抗asymmetrical impedance不对称过负荷unsymmetrical overload不接地un- grounded不平衡电压unbalance voltage不停电电源UPS =uninterrupted powersupplyC采样频率sampling frequency参数parameter操作冲击耐受电压switching impulse withstand voltage操作冲击水平SIL=switching impulse level操作机构operating mechanism操作顺序operating duty cycle测量仪表instrumentation测量用互感器measuring transformer层间layer-to-layer层间绝缘layer insulation插件plug-in unit插入式熔断器plug-in type fuse插头receptacle plug插座receptacle (socket)差动保护differential protection铲型接线片spade lug长延时long time delay常闭接点normally closed contact常规试验routine test常开接点normally opened contact厂内通信系统intro-plant communication system厂用变压器UAT=unit auxiliary transformer 厂用电率auxiliary power ratio厂用电系统auxiliary power system超前相leading phase城市电网urban distribution network充电charge充电器charger充气隔室gas filled compartment充油套管oil filled bushing冲击耐受电压impulse withstand voltage抽出式小车draw-out carriage抽头tap lead出口继电器lockout relay出线outgoing feeder出线电压等级outgoing voltage grade出线方向direction of outgoing line出线回路数circuit number of outgoing line 出线门型架构outgoing feeder gantry structure出线箱lead box触发器igniter穿墙套管wall bushing穿墙套管wall- through bushing传递电位transferred potential串联series串联电路series circuit串联电容补偿装置serial capacitor compensation device瓷质绝缘子Porcelain insulator瓷质绝缘子porcelain insulator磁场电流field current磁场电压field voltage磁场开关field circuit breaker磁吹避雷器magnetic blow surge arrestor磁极对数number of pole pairs磁力起动器'magnetic starter次暂态电抗subtransient reactance粗调rough adjustmentD打开断路器open the breaker大充电压boost charging voltage大面积发光天棚louver all ceiling带电拆线live line disconnection带电接线live line connection带电距离clearance单极开关single pole switch单接地刀single earthing switch单面出口标志灯single face exit sign fixture 单面出口标志灯left（right）arrow lamp单线图one-line diagram单相single-phase单相变压器single-phase transformer单相电能表single-phase kilowatt-hour meter单相接地single-phase grounding单相同期控制single phase synchro-control 单芯电缆single-core cable弹簧贮能操作机构spring stored-energy operating mechanism刀开关knife switch导前时间time lead导全截面conductor cross-section导体conductor导线匝带wire tie倒母线changeover busbars灯lamp灯具lighting fixture灯座lamp socket等效常数equivalent constant等效的，相当的equivalent等效电抗equivalent reactance等效电流equivalent current等效电路equivalent circuit低电压保护under voltage protection低光强航空障碍灯low intensity AOL低励磁low excitation低频保护low frequency protection低频共振sub-synchronous resonance低压low voltage低压厂用变压器low voltage auxiliary transformer低压公用变压器low voltage common transformer低阻low resistance地震seismic碘钨灯tungsten halogen lamp电厂power plant电池架battery rack电磁感应electromagnetic induction电磁接触器electromagnetic contactor电磁气动接触器electromagnetic pneumatic contactor电磁锁magnetic lock电磁铁electromagnet电动机motor电动机最大转矩motor maximum torque电动势electromotance电度表watthour meter电感电流inductive current电功率electric power电焊机electric welding machine电话，电话机telephone电话电缆telephone cable 电话分机extension telephone电话机telephone set电话听筒telephone handset电话亭telephone booth电极electrode pole电解液electrolyte电抗reactance电抗器reactor电缆cable电缆标牌tag of cable电缆吊架cable suspender电缆敷设cable laying电缆敷设及清册cable laying & list电缆敷设及清册cable laying and list电缆沟cable trench电缆管cable conduit电缆夹cable clip电缆夹层cable mezzanine电缆夹层cable vault电缆桥架cable tray电缆软管flexible cable conduit电缆竖井cable shaft电缆隧道cable tunnel电缆通道系统cable raceway system电缆头cable head电缆支架cable rack电缆支架cable support电缆终端头cable terminal电力系统power system电流current电流放大current amplification电流互感器current transformer电流互感器current transformer电流互感器校验装置current transformer calibrating device电流继电器current relay电流强度current intensity电路circuit电瓶cell jar电气electricity电气的electric,(electrical)电气辅助控制屏electrical auxiliary control panel电气工程electricity engineering电气寿命electrical life电气制动electric braking电容capacitance电容电流capacitive current电容分压器capacitor divider电容器capacitor电枢armature电枢绕组armature coil电网power grid电网改造distribution network enhancement 电位，电势potential电位计potential meter电位梯度gradient of potential电线钢管wire pipe电压voltage电压表voltage meter电压表切换开关voltmeter change-over switch电压调节误差voltage regulation error电压调整率voltage regulation电压互感器PT =potential transformer电压继电器voltage relay电压降voltage drop电压控制过电流继电器voltage-controlled overcurrent relay电源接头power connector电晕corona电子开关electronic switch电子元件electronic element电阻resistance电阻器resistor调度电话机dispatching telephone调度通信系统dispatching communication system调度员dispatcher调光开关dimmer switch调试commission调速电动机adjustable speed motor调速电动机governor motor调相器synchronous condenser调压器voltage regulator顶值电压ceiling voltage定期运行periodic duty service定时限definite time lag 定子stator定子端盖stator end cover定子铁芯stator core定子外壳stator housing定子线圈stator winding动触头moving contact动触头moving contacts动负荷dynamic load动力，功率power动力电缆power cable动力箱power supply box动态常数dynamic constant动态的dynamic动态模拟dynamic analogue动态曲线dynamic curve动稳定电流dynamic stable current陡波冲击保护水平protection level at steep current镀锡tin galvanized镀锌钢galvanized steel镀银silver plated端电池end battery端子螺钉terminal screw端子排terminal block端子箱terminal box短路short circuit短路板short circuit plate短路比short circuit ratio短路电流short circuit current短路关合和开断性能试验short circuit making and breaking test短路试验short circuit test短路特牲曲线short circuit characteristic curve短期并列short time parallel短延时short time delay段间绝缘section insulation断开switch off断开位置disconnected position断口间between open contacts断路器breaker断路器circuit breaker断路器非全相跳闸open phase tripping of breaker断路器失灵circuit breaker failure断路小室breaker compartment对称的symmetricalE额定持续电流rated continuous current额定充气压力rated filling pressure额定的rated额定电压rated voltage额定短时耐受电流rated short time current额定关合能力rated closing capability额定开断电流rated breaking current额定容量rated capacity额定输出rated output额定输入rated input额定值rated value二次表计secondary meter二次电压secondary voltage二次线圈secondary windingF发-变组generator-transformer unit发变组扩大单元generator-transformer extension unit发电机generator发电机出线小室generator termination room 发电机定子generator stator发电机端子generator terminal发电机负荷曲线generator load curve发电机基座generator pedestal发电机密封油系统generator sealing oil system发电机氢冷却系统generator hydrogen cooling system发电机水冷却系统generator water cooling system发电机引出线generator terminal lead发电机主保护generator main protection发电机转子generator rotor发射机transmitter阀型避雷器valve type lightning arrester反射系数reflectance factor 反时限inverse time lag泛光照明flood lighting方向继电器directional relay防爆耐火荧光灯flameproof fluorescent lighting fixture防爆型explosion-proof type防尘型dust proof type防滴型DP= drip-proof防冻freeze protection防腐蚀anti-corrosion防护等级degree of protection防火堵料fire proof blockage防雷lightning protection防逆转继电器plugging relay防水荧光灯waterproof fluorescent lighting fixture防跳装置anti-pumping device防雨试验rain proof test防晕罩corona-proof cover放大器amplifier放电discharge放电电压flash-over voltage放电计数器discharge counter放电计数器discharge counter放电间隙discharge gap放电曲线discharge curve放电容量discharge capacity放电特性discharge characteristic放电未期电压discharge final voltage非铠装电缆unarmoured cable非全相合闸open phase closing of breaker非全相运行open phase operation非同期asynchronous非同期能力non- asynchronous capability非线性电阻non-linear resistor非线性电阻non-liner resistor分辨率resolution分辨率resolution分段断路器sectionalized circuit breaker分合并联电抗器试验switching shunt reactor test分合长空载线路能力capability of switching long no-load line分合空载变压器能力capability of switchingno-load transformer分合空载变压器试验switching no-load transformer test分合空载长线试验switching no-load long line test分接tapping分接范围tapping range分接级tapping step分接头位置指示器tap position indicator分励线圈shunt excitation coil分量component分裂变压器split winding type transformer分裂电抗器disruptive reactor分流器current shunt分散系数diversity factor分散型接地床distributed-type groundbed分相操作operated in single phase分闸时间breaking time分支过流保护branch overcurrent protection 分支母线branch bus峰，峰值crest峰值电压crest voltage峰值耐受电流peak withstand current蜂鸣器buzzer伏安表voltammeter伏特volt扶手安装handrail mounted服务级别service level浮充电float charge符合conform to辅助（中间）继电器auxiliary relay辅助厂房变压器auxiliary building transformer辅助触头auxiliary contact辅助回路auxiliary circuit辅助继电器pilot relay负荷load负荷开关switch-fuse负极negative pole负序电流negative sequence current负序电流保护negative-sequency current protection负序阻抗negative-sequence impedance负载损耗load loss 负载特性曲线load characteristic curve附加损耗supplementary load loss复归线圈reset coil副励磁机pilot exciterG干触点dry contact干式变压器dry type transformer杆塔pole and tower感抗inductance reactance感性电流reactive current感应调压器induction voltage regulator钢芯钻铰线ACSR =aluminum conductor steel reinfoced高导电率high conductivity高分辨率high resolution高光强航空障碍灯high intensity AOL (aircraft obstruction lamp)高频保护high-frequency protection高频放大high-frequency amplification高频滤波器high-frequency filter高强气体放电灯high intensity discharge lamp高压high voltage高压充油电缆high voltage oil-filled cable高压钠灯high pressure sodium ( HPS )高压线路high voltage transmission line高压限流熔断器及真空接触器F-C (high-voltage current limiting fuse and vacuum contactor)高压直流输电HVDC=high-voltage direct-current transmission高阻high resistance格栅louver隔板partition隔离变压器isolated transformer隔离开关disconnecting switch隔离开关disconnecting switch隔室compartment镉-镍蓄电池Cd-Ni battery跟踪回路follow-up circuit工厂接头factory splice工频恢复电压power frequency recoveryvoltage工频耐受电压power frequency withstand voltage工作范围scope of work工作位置service position工作误差operating error工作照明箱normal lighting box公用报警接点common alarm contact功率因数power factor功率因数表power factor meter供货范围scope of supply共箱母线NPB =nonsegregated phase bus duct固态整流器solid state rectifier固有分闸时间inherent opening time固有合闸时间inherent closing time故障记录fault recorder故障探测器fault detector挂环chain link关合电流making current管形避雷器tube type lightning arrester管型母线tubular busbar光，灯light光电控制器photoelectric control光通量衰减系数LLD=lamp lumen depreciation光纤电缆fibre-optical cable光源light source (illuminant)光源光色light-source colour硅钢片silicon-steel sheet硅整流元件thyristor element柜底进线enter the cubicle from the bottom 柜顶进线enter the cubic from the top过电压倍数overvoltage times过电压吸收装置surge absorber过放电deep discharge过激磁overflux过励磁over excitation过励磁保护over excitation protection过流保护over current protectionH焊接welding 航空障碍灯aircraft obstruction lamp毫安表milliammeter毫伏表millivoltmeter合断路器close the breaker合上switch on合闸继电器closing relay合闸脉冲closing pulse合闸相位closing phase angle核对相序check phase order赫兹hertz (Hz)横差保护transverse differential protection 后备保护back-up protection呼叫详细记录detail calling record呼叫信号call signal弧触头arcing contact户内配电装置in-door type switchgear户内式indoor type户外配电装置out-door type switchgear户外式outdoor type护环retaining ring护套sheath滑差运行pole slip operation滑线式变阻器slider-type rheostat环link环型接线片ring lug环氧树脂绝缘epoxy resin insulated恢复电压recovery voltage回叫call back惠斯登电桥wheatstone bridge击穿电压discharge voltage机构操作式开关MOC =mechanism operated cell switch机械寿命mechanical life机械性能试验mechanical performance test 基波分量fundamental component畸变系数distortion factor极，杆pole极板pole plate极间电压interpolar voltage极近开关puoximity switch集电器current collector集合式并联电容器collective shunt capacitor 集中控制centralized control记录时间recording duration记录仪表recording instrument继电保护relay protection继电保护屏protection relay panel继电器relay加热电缆heating cable加热元件heating element夹具fixture架空电缆overhead cable架空线overhead line间隔棒spacer减励磁reducing excitation检修变压器maintenance transformer检修箱maintenance box简式荧光灯tube fluorescent lighting fixture 降负荷output reduction降容系数derating factor降压变压器step-down transformer降压启动器reduced-voltage starter交联聚乙烯XLPE=cross linked polyethylene 交联聚乙烯绝缘电缆XLPE insulated cable交联聚乙烯绝缘钢带铠装聚氯乙烯护套电力电缆XLPE insulated, steel tape armored and PVC sheathed power cable交联聚乙烯绝缘聚氯乙烯护套电力电缆XLPE insulated and PVCsheathed power cable交流电源AC(Alternating Current) power source交流耐压试验AC withstand voltage test接触电压touch potential接触器contactor接地earthing接地ground接地保护grounding protection接地导体grounding conductor接地电抗器grounding reactor接地电阻测试仪grounding megger接地端子earthing terminal接地端子ground pad接地端子grounding terminal接地故障grounding fault接地极earthing rod 接地开关grounding (earthing) switch接地位置earthing position接地系统grounding system接地线grounding wire接地线埋深depth of embedded grounding wire接收机receiver接头splice接线wiring接线端子terminal lug接线盒junction box接线片lug截取雷电流intercept lightning discharge解环looping-off解列disconnection解列灭磁system disconnection and field extinction介质损耗系数coefficient of dielectrical loss 金属铠装metal clad金属卤化物灯metal halide lamp金属氧化物避雷器MOA=metal oxide arrester 近区故障开断能力short-line fault breaking capability近区故障试验short-line fault test进线incoming feeder精度accuracy警铃alarm bell径向通风radial ventilation静触头stationary contact静触头stationary contacts静态励磁系统static excitation system静态试验static test静态无功补偿装置SVC= static VAR compensator静态转换开关static transfer switch就地控制local control局步照明local lighting局部放电Partial discharge局部放电partial discharge局部放电试验partial discharge test距地面安装高度MHF=mounting height above the floor距高比S/MH=spacing-to-mounting height ratio距工作面安装高度MHWP=mounting height above the work-place距离保护distance protection距离继电器distance relay聚氯乙烯绝缘电缆PVC(polyvinyl chloride) insulated cable绝缘insulation绝缘等级insulation class绝缘基本冲击耐压水平BIL =basic insulation level绝缘监察表insulation supervision meter绝缘耐受试验insulation withstanding test绝缘强度insulating strength绝缘水平insulating level绝缘水平insulation level绝缘子insulator均衡冲电equalizing charge均压电容器voltage sharing capacitor均压环、屏蔽环grading ring均匀度uniformity ratioK开断电流interrupting current开断发展性故障试验evolving fault breaking test开关switch开关switch开关站switchyard开口三角形连接open-delta connection开路电压open circuit voltage开路特牲曲线open circuit characteristic curve铠装电缆armoured cable抗噪音电话机noise-reducing telephone抗震试验seismic test壳式变压器shell type transformer可变电容器adjustable capacitor可变速电动机variable speed motor可拆接头removable connector可调范围adjustable range可视电话video telephone空气断路器air circuit breaker空载电流no-load current 空载电压no-load voltage空载损耗no-load loss控制control控制电缆control cable控制柜control cabinet控制回路control circuit控制继电器control relay控制接线图CWD =control wiring diagram控制开关CS =control switch控制盘control panel跨步电压step potential快速熔断器fast acting fuse快速线夹quick clip框架式断路器frame-type circuit breaker馈线fault馈线间隔feeder bay扩音调度机paging dispatching unitL拉线开关pull switch勒克司LX=lux雷，闪电lightning雷电波头形状lightning wave front shape雷电冲击耐受电压lightning impulse withstand voltage雷电记录器lightning recorder雷电流lightning current雷击lightning strike离相封闭母线IPB =isolated phase bus duct 立杆安装standing pole mounted立式电动机vertical type motor利用系数CU=coefficient of utilization励磁excitation励磁变压器excitation transformer励磁电流excitation current励磁电压excitation voltage励磁柜excitation cubicle励磁机exciter励磁系统响应比excitation system response ratio例行试验routine test连接端子connection pin连接箱junction box连续额定值continuous rating连续开断能力试验continuous breaking capability test连续运行continuous duty (service)联接片connection plate联络变压器tie transformer联锁interlock联跳shunt tripping两段距离继电器two zone distance relay两相短路two-phase short circuit两芯电缆twin-core cable灵敏度sensitivity零电位zero potential零起升压raising voltage from zero零序CT zero sequence CT零序电流zero sequence current零序电流保护zero-sequence current protection零序阻抗zero sequence impedance流明lumen六氟化硫断路器SF6 gas insulated circuit breakerSF6气体回收设备SF6 gas reclaiming equipmentSF6气体湿度分析仪SF6 gas moisture analyzerSF6气体泄漏检测器SF6 gas leakage detector漏磁密leakage-flux density漏磁通leakage-flux漏磁系数leakage coefficient漏电开关earth leakage circuit breaker漏电开关residual current circuit breaker路灯road lighting fixture螺旋式熔断器screw-type fuseM马赛克控制屏mosaic surface control panel 密封试验sealing test密封套管seal-off bushing免维护蓄电池maintenance free battery灭磁field extinction灭弧触头arcing-extinguishing contact 灭弧触头arc-suppression contacts灭弧电阻arc suppression resistor灭弧室arcing chamber明装open mounted铭牌nameplate模拟母线mimic bus模拟图mimic diagram母联bus tie母联断路器bus tie circuit breaker母线bus母线，汇流排busbar母线保护busbar protection母线解列busbar disconnection母线式电流互感器busbar straight-through current transformer目标负荷target loadN内部故障internal fault内部呼叫internal calling内护套inner sheath耐火电缆fire resistant cable耐火隔板fire proof partition耐火极限fire proof limit耐受电压withstand voltage耐张绝缘子tension insulator耐张线夹strain clamp挠性接头flexible joint能力capability逆变器inverter逆功率保护reverse power protection扭应力torsional stressO欧姆ohm欧姆表OHM=ohm meter偶次谐波even harmonic耦合电容式电压互感器coupling-capacitor voltage transformer耦合系数coefficient of couplingP爬距creepage distance旁路断路器by-pass bus circuit breaker旁母by-pass bus配电distribution配电室distribution board room配电装置switchgear配光曲线candle power distribution curve配线箱marshalling boxPT断线保护PT balance protectionPT回路断线PT circuit broken频差frequency deviation频宽frequency bandwidth频率frequency频率调制frequency modulation频率分配frequency allocation频率分析仪frequency analyzer频率相位特性frequency-phase characteristic 屏蔽shield破坏转矩breakdown torqueQ期望寿命expected life奇次谐波odd harmonic起动/备用变压器start-up/stand by transformer起动保护start-up protection起动变阻器start rheostats起动电流starting current起动电阻starting resistor起动器starter起动转矩starting torque起励设备excitation initiating equipment起励设备field flashing equipment起始充电电压initial charging voltage气动操作机构pneumatic operating mechanism气体密封gas tightness气隙air gap千乏kilovar (kVAR)千伏kilovolt千伏安kilovolt ampere千瓦kilowatt (kW) 千瓦时kilowatt-hour铅皮电缆lead covered cable铅-酸蓄电池lead-acid battery钳型表plier-type current meter嵌入顶棚ceiling mounted嵌入式荧光灯flush mounted fluorescent lighting fixture强励force excitation强励系数force excitation factor强迫风冷系统forced air cooling system强迫停机forced outage强油风冷FOA =forced oil air cooled强制通风forced ventilation切换change-over切换开关COS =change-over switch氢内冷hydrogen inner cooled球头挂环ball eyes曲折形连接zigzag connection全充fully charged全电压启动器full-voltage starter全封闭风冷型TEFC= totally enclosed with fan cooler全封闭水空冷型TEWAC=totally enclosed with water cooled air cooler全封闭组合电器GIS=gas insulated switchgear全密封荧光灯wrap-around fluorescent lighting fixtureR燃煤电厂coal-fired power plant绕线式转子wound type rotor绕组coil热磁保护thermo-magnetic protection热电偶thermo-couple热镀锌hot-dipped galvanized热继电器thermal relay热敏电缆heating sensitive cable人孔manhole容抗capacitive reactance容量capacity熔断器fuse熔断器熔断fuse blow熔断器式开关fuse- switch软导线flexible conductor软母线flexible busbarS三防灯具anticorrosive, dust-proof and water-resistant lighting fixture三角形连接delta connection三相three-phase三相变压器three-phase transformer三相操作operated in three phase三相电能表three-phase kilowatt-hour meter 三相短路three-phase short circuit三芯电缆3 cores cable三芯电缆triple-core cable扫描器scannerCT的二次电流secondary current of CTCT的二次容量burden of CT闪光继电器flicker relay闪光信号flash signal舌簧继电器reed relay伸缩expansion伸缩节flexible conductor伸缩节expansion join升压变压器step-up transformer升压站step-up switchyard失步保护out-of step protection失步开断能力out-of-phase breaking capability失步开断试验out-of-phase breaking test失磁保护loss-of field protection失电loss of power失灵，事故failure石墨碳刷graphite brush时间time时间继电器time relay识别identification示波器oscilloscope事故报警信号failure alarming signal事故铃emergency bell事故照明箱emergency lighting box事故追忆记录装置fault recollecting and recording device 视载功率apparent power试电笔pen tester试验test试验报告test report试验电压test voltage试验端子testing jack试验盒test box试验位置test position试运行trial operation室腔比cavity ratio手动准同期manual quasi-synchronization首次并网initial synchronization首次送电initial power transmission输出output输电线路transmission line输电线路放电等级transmission line discharge class输入input鼠笼型转子squirrel-cage type rotor数字电压表digital voltmeter数字式继电保护digital type protection relay 刷架brush supporter刷握brush holder刷子brush衰减系数coefficient of attenuation甩负荷load rejection双Y连接double Y connection双接地刀double earthing switch双块板灯double-faced plate lighting fixture 双母线带旁路接线double bus connection with bypass双母线接线double bus connection双水内冷发电机dual inner water cooled generator双速电动机double-speed motor双跳闸线圈redundant trip coil双轴double shaft双柱double column水冷却water cooled水平伸缩horizontal expansion水-氢-氢冷发电机water-hydrogen-hydrogen cooling generator水银灯mercury lamp顺序跳闸sequence tripping瞬时电流momentary current瞬态恢复电压transient recovery voltage瞬态响应transient respone速断保护instantaneous overcurrent protection塑壳式断路器MCCB=moulded case circuit breaker塑料绝缘plastic insulation损耗loss损耗比loss-ratio套管bushing套管端子bushing lead terminal套管式电流互感器bushing current transformer跳闸trip跳闸继电器tripping relay跳闸脉冲tripping pulse跳闸线圈trip coil铁轭yoke铁壳开关iron clad switch铁损iron loss铁芯柱core limb庭院灯garden lighting fixture通风ventilation通过电阻接地grounded through resistor通话talking on the telephone通信communication通信监听communication monitoring通信楼communication building通信线communication line通讯电缆communication cable同步电动机synchronous motor同步电抗synchronous reactance同期表synchroscope同期鉴定synchronization checking同期装置synchronizing device同相in- phase同轴电缆coaxial cable铜编织线屏蔽电缆copper wire braid shield cable铜带屏蔽的控制电缆control cable with copper tape shield铜铰线电缆stranded copper cable铜母线copper bus-bar铜损copper loss筒灯down- light投光灯projection lamp图diagram土壤电阻率soil resistivity脱扣器tripperW瓦斯/压力断电器buchholtz relay瓦特watt (W)外部呼叫external calling外护套outer sheath外加电流impressed current外加电流阴极保护impressed current cathodic protection外壳enclosure万能电桥universal bridge网控室network control room微机继电保护micro-processor based protective relay微型断路器MCB =miniature circuit breaker 微正压装置slight pressure device维护maintenance维护系数MF=maintenance factor位置position位置继电器position relay温度计thermometer温升试验temperature rise test温升试验temperature-rise test文件document稳压电源装置stabilized power supply device 卧式电动机horizontal type motor屋内配电装置indoor switchgear无功补偿装置reactive power compensation device无功电度表kVAR-hour meter无功功率reactive power无机绝缘电缆mineral insulated cable无间隙金属氧化型gapless metaloxide type无刷励磁系统brushless excitation system无填料封闭管式熔断器no powder-filled cartridge fuse无线电radio无线电干扰电压radio interference voltage无源接点electrical independent contact误操作mis-operation误差error误差极限limits of error误动作malfunctionX吸壁wall mounted吸持电流retaining current吸持线圈retaining coil吸顶安装surface mounted吸湿器dehydrating breather牺牲阳极保护系统galvanic protection system 熄弧电压discharge extinction voltage系数coefficient系统system系统短路容量system short circuit capacity 系统解列system disconnection系统振荡system power swing系统振荡system oscillation细调fine adjustment现场接头field splice现场试验site test线line线电压line voltage线夹clamp线路潮流line power flow线路充电电流line-charging current线路强送电forced line energization线路强送电成功successful forced line energization线路试送电trial line energization线圈winding限负荷运行load limit operation限流电抗器current-limiting reactor限流断路器current-limiting circuit breaker 限流继电器current-limiting relay相phase相电流phase current 相电压phase voltage相对地phase to ground相关的relevant相间绝缘insulation between phase相角phase angle相角差phase-angle difference相位表phase meter相位超前角leading phase angle相位指示器phase indicator相序phase sequence箱子box橡皮绝缘垫rubber cushion消弧线圈arc suppression coil消弧线圈arc-suppression coil小车操作式开关TOC =truck operated cell switch小母线miniature busbar效率efficiency校正correction校正电路correcting circuit校正电路correction circuit校正脉冲correction pulse校正曲线correction curve校正系数correction factor校正系数correction factor谐波harmonics谐波分量harmonic component谐波含量harmonic content谐波含有率HR=harmonic ratio谐振，共振resonance谐振电路resonance circuit谐振过电压resonance over-voltage谐振频率resonance frequency谐振曲线resonance curve泄漏leakage泄漏电流leakage current泄漏电流stray current泄漏电流接地床impressed current groundbed泄漏间隙leakage clearance泄漏距离leakage distance泄漏阻抗leakage impedance芯式变压器core type transformer芯线component wire信号电缆signal cable信号发生器signal generator信号指示器signal indicator星角切换装置star-delta changing device星-三角起动器star-delta starter星形连接star connection行灯portable lamp性能试验performance test修正系数coefficient of correction蓄电池battery蓄电池storage battery蓄电池容量battery capacity蓄电池室battery room悬垂线夹suspension clamp悬挂pendant mounted悬挂式绝缘子suspending insulator旋钮turn button选择开关SS =select switch眩光glareY压接型端子compression type terminal压力释放pressure relief压力释放能力pressure relief capability压缩端子compression terminal延时delay延时带电time delay energizing延时继电器delayed relay延时释放time delay de-engergizing阳极anode阳极接地床anode groundbed氧化锌避雷器zinc- oxide surge arrester氧指数oxygen index遥测telemetering遥调teleregulation遥控telecontrol遥信telesignalisation1个半断路器接线1 and 1/2 circuit breaker connection液压操作机构hydraulic operating mechanism一次电压primary voltage一对一控制one-to-one control移动式movable type 移开位置removed position移相器phase shifter异常abnormal阴极保护cathodic protection印刷电路板printed wiring board应急灯emergency lighting英尺-烛光footcandle ( F.C )荧光灯fluorescent lamp硬母线hard busbar油断路器oil circuit breaker油浸变压器oil-immersed type transformer 油浸纸绝缘电缆impregnated paper insulated cable油位指示器oil level indicator油枕oil conservator有功电度表kW-hour meter有功功率active power有关的relative有填料封闭管式熔断器powder-filled cartridge fuse有线通信系统wireline communication system有效光强effective luminous intensity有效值RMS=root-mean-square有载调压变压器transformer fitted with O.L.T.C (on-load tap-changer)有载分接开关OLTC =on-load tap-changer诱导电动机induction motor原理接线图EWD =elementary wiring diagram远方控制remote control云母绝缘mica insulation运行operation运行方式operation modeZ匝间turn-to-turn匝绝缘turn insulation载波wave carrier载波通信wave carrier communication载流量ampacity载流能力current carrying capacity暂态电抗'transient reactance。
电气工程及其自动化专业必背术语-翻译electrical infrastructure 电气基础设施electrical installation 电气安装技术equations set 方程组four-layer 四层hookup接线图human machine interface 人机界面impedance阻抗incidence 入射incident wave 入射波incorporated 合成一体的instantaneous 瞬间的interleaved 交叉load admittance 负载导纳lumped 集中的modal模式的modeling 建模motor management systems 电机管理系统mounting pads安装垫片noise margins噪音安全系数proximity effect 邻近效应terminator终结器undershoot 负脉冲信号；下冲transistor 晶体管audion三极管capacitance电容Diesel 柴油机AC-motors交流电机transistor晶体管coupling联结耦合current carrying capacity 载流能力(最大允许电流) conductivity 传导性in isolation绝缘lead导线leakage current泄漏电流inductance 感应系数loops线圈macroprocessor微处理器multimedia show多媒体展示medium-power distribution 中压配电motor and soft starters 电机及软起动器numerical controls数控系统optimal最佳的，最理想的radian弧度overload relays 过载继电器overshoot 过冲peak current 峰值电流power dissipation电力分散process automation 过程自动化punch穿孔，冲压reactance 电抗recharge再充regulated power supply稳压电源resistance 阻抗resistor 电阻器resonate 共振self-inductance 自感应series inductance 串联感应simulation 模拟switching 配电、交流thermal cycle 热循环thickness厚度voltage regulator 调压器resistive 有抵抗力的process instrumentation and analytics过程仪表及分析仪器warping扭曲，变形wiring layout线路配置图AC-drives交流变频器asymmetrical 非对称的attenuation 衰减bridged impedance桥接阻抗cable bridge 电缆桥架charge 电荷circuit schematic diagram电路原理图解coefficient 系数configuration构造constant 常量copper sheet铜片damping 阻尼decomposition 分解decouple 分离delay circuit 延迟电路dielectric sheets 介电原片diode clamping 钳位edge connector边缘连接器schematic 示意图services&industry solutions 服务和工业解决方案。
A priori knowledge 先验知识Actuator 执行器Ad hoc 尤其关于Addition 加Ambient 环境的Americana 美国志书Analog-to-digital converter ，模拟数字转换器Antenna 天线Arrangement 方案Automate 使自动化Averaging 求平均值Be subtracted from 减Binary 二进制的Bus network 总线网Carbon-filament lamp 碳丝灯泡Carrier frequency 载频Carrier sense multiple access with collision detection 载波监听，多址访问Cellular telephone 蜂窝式电话系统Circuit components 电路元件Circuit diagram 电路图Circuit parameters 电路参数Close-loop control 闭环控制Common media 公共媒体Common reference 参考点Conductance 电导Conductor 导体Consistently 稳定，协调Constant coefficient system 常系数系统Control installation 控制装置Convention 惯例Conventional 常见的Conversion 转换Correct 校正Corresponding to 相应的Crossbar switch 纵横切换器Differential input 差动输入Differentiation 微分Digital-to-analog converter 数字模拟转换器Dimensional 量纲的Direct-current circuit 直流电路Discrete-time system 离散时间系统Discrimination 分辨力鉴别力Displacement current 位移电流Distinction 区别Disturb 扰动Dummy 假的，假装的Dynamic behavior 动态行为Electric circuit 电路Electric energy 电能Electrical device 电气设备Electrical pressure transducer 压电传感器Electromotive force 电动势Electronic analog 电子模拟Encyclopedia 百科全书Energy converter 电能转换器Energy source 电源Ergonomic 人类工程学的Error 误差Excursion 偏差Existing value 实际值External characteristic 外特性Facsimile 传真Factor 系数，因率数Feedback 反馈Feedback component 反馈元件Frequency counter 频率计数器Frequency-domain 频域Function 功能Generator 发电机Graphic panel 图式仪表盘Heating appliance 电热器High definition television 高清电视Hybrid system 混合系统Ideal amplifier 理想放大器Immunity 不敏感性Income 输入Indicator 指示Inertia 惯性Inertia reference frame 惯性参考坐标系Infinite voltage gain 无穷大电压增益Initial voltage 初始电压Input quantity 输入量Integrated service digital network综合业务数据网Integration 积分Internal combustion engine 内燃机Interruption 阻断Intervention 介入Inverting amplifier 反相放大器Inverting terminal 反相端Linear vector space 线性向量空间Linearization 线性化Load characteristic 负载特性Load resistance 负载特性Logic level 逻辑电平Logistic 后勤的Lower limit on the integration 积分下限Low-order system 低阶系统Low-pass filter 低通滤波器Machine tool 机床Magnetic and electric field 电磁场Manual 手工Manufacturer’s data sheet 铭牌Mathematical operation 数字运算Measuring technique 测试技术Megohm 兆欧Metal-filament lamp 金属丝灯泡Metropolitan area network 城域网Microvolt 微伏Modern control theory 现代控制理论Multiplexer 多路切换器Multiplication 乘Negative-feedback signal 负反馈信号Noise 噪声Noninverting terminal 非反相端Nonlinear 非线性的Off-set 失常点Offset=bias 偏置On-line system 联机系统Ono-linear characteristics 非线性特性Open loop gain 开环增益Open-loop control 开环控制Operational amplifier 运算放大器Optimal control 最优控制Opto-isolator 观点耦合器Order 数量级Outset 开始Parallel digital signal 并行数字信号Pervasive 普遍性的Phase reversal 反相Phase-plane method 像平面方法Potentiometer 电位计Preset 预先装置Primary cell 原生电池Private networks 专业网络Public network 公用网络Radix-weighted 基数加权Rated 额定的Research and design 研发Resolution 分辨力Ring network 环形网Scaling 量程调整Schematic 纲要的Schmitt-trigger 施密特触发器Secondary cell 再生电池Self-(or mutual-) induction 自（互）感Self-acting 自动做Self-moving 自运动Servooperated null-balance potentiometer 伺服驱动零平衡电位差计Shaft encoder 转轴编码的Shunt connection 并联连接Signal conditioning 信号调理Signal conditioning 信号处理Simultaneous equations 联立方程Single-ended output 单端输出Sink 灌入Source 从出来Span 量程Specification 参数Square root extraction 开平方State variable method 状态变量方法Storage battery 蓄电池Strain gage 应变仪Strip chart 长条记录纸Substrate 底层基片Subtraction 减Synchros 感应同步器System buses 系统总线Telecommunication 远程通信Terminal voltage 端电压The dielectric 电介质Time-domain technique 时间域技术Time-invariant 定常的Time-varying parameter 时变参数Timing circuit 计时电路Token 令牌Topology 拓扑Transducer 传感器Transfer function 传递函数Transformer 变压器Triangular symbol 三角符号Uncertainty 不确定性Unidirectional current 单方向性电流Upgrade 升级Virtual 虚的Virtual ground 虚地Voltage drop 电压降Volt-ampere characteristics 伏安特性Wire 导线Zero adjustment 零位调整。
电气工程师专业英语词汇汇总1. Personnel 人员职工2. Voltmeter 电压表伏特计3. Ohmmeter 欧姆计电阻表4. Megohmmeter 兆欧表5. Wattmeter 瓦特计电表功率6. Watt-hour 瓦时瓦特小时7. Ammeter 安培计电流表8. calibrate 校正9. scale 刻度量程10. rated 额定旳11. interfere with 有害于。
12. indicating needle仪表指针13. hazardous 危险旳14. pivot 支点15. terminal 端子16. spiral 螺旋形旳17. spring 弹簧18. shunt 分流，分路，并联，旁路19. rectifier 整流器20. electrodynamometer 电测力计21. strive for 争取22. vane 机器旳叶，叶片23. strip 条，带，（跨接）片24. crude 不精细旳，粗略旳25. polarity 极性26. fuse 保险丝，熔丝27. rugged 结实旳28. depict 描绘，描写29. cartridge 盒式保险丝30. blow （保险丝）烧断31. plug fuse 插头式保险丝32. malfunction 故障33. deenergize 不给…通电34. insulation 绝缘35. generator 发电机36. magneto 磁发电机37. humidity 湿度38. moisture 潮湿湿气39. abbreviate 缩写，缩写为40. transformer 变压器41. thumb 检查，查阅42. milliammeter 毫安表43. multimeter 万用表44. dynamometer 测力计，功率计45. aluminum 铝46. deteriorate 使….恶化47. eddy current 涡流48. gear 齿轮，传动装置49. dial 刻度盘50. semiconductor 半导体51. squirrel 鼠笼式52. diode 二极管53. thyristor 晶闸管54. transistor 电子晶体管55. triac 双向可控硅56. phase 相位（控制）57. silicon 硅58. crystal 晶体59. wafer 薄片60. anode 阳极，正极61. cathode 阴极62. collector 集电极]63. emitter 发射极64. schematic （电路）原理图符号65. leakage 漏电流66. rating 额定值，标称值，定额67. dissipate 散发68. breakdown 击穿69. heat sink 散热器70. self-latching 自锁71. commutation 换向72. geometry 几何构造73. squeeze 压榨，挤，挤榨74. light-dimmer 调光75. capability 容量76. studmounted 拴接式77. hockey puck 冰球78. fin 飞边79. active 有源旳80. horsepower 马力81. diameter 直径82. in. （inch ,inches）英寸83. extruded 型材旳84. clamp 夹住，夹紧85. compound 紧密结合86. wrench 扳手87. torque 转矩，扭矩88. enclosure 外（机）壳89. ventilation 通风，流通空气90. sealed-off 封旳91. thermal 热旳，热量旳92. substantially 重要地，实质上地93. aptly 合适地，合适地94. demystify 阐明95. allude 暗指，直接提到96. cease 停止，终了97. line 线电压98. ripple 脉动.99. redundant 多出旳100. separately 单独励磁地101. synchronous 同步电动机102. circuitry 电路，线路103. cost-effective 花费大旳104. capacitor 电容器105. dictate 确定106. trade-off 权衡，折衷107. criteria 原则，判据108. analog electronics电力电子学109. saturate 使…饱和110. active region 动态区域111. due 应得到旳112. ratio 比，比率113. signify 表达114. encode 编码115. resonance 共鸣116. radiated 传播117. molecule 分子118. diaphragm 震动膜119. acoustic wave 声波120. wavy groove 起伏旳沟槽121. deflection 挠度，挠曲122. strain gage 应变计量器123. tachometer 转速计124. thermocouple 热电偶125. oscilloscope 示波器126. analytical 解析旳127. numerical 数值旳128. integrate 求…旳积分129. scale 变化比例130. frequency- domain 频域131. random 随机旳132. audio 音频旳133. operation amplifier 运算放大器134. summation 求和，加法135. sophisticated 复杂旳，完善旳136. mass-produce 大量生产137. subtract 减去138. inverting amplifier 反向放大器139. uninverting amplifer 同相放大器140. derive 推倒141. active filter 有源滤波器142. stabilize 使稳定143. moderate 适度旳，适中旳144. virtue 长处145. amplification 扩大146. capacitor 电容器147. impedance 阻抗148. bode plot 波特图149. simulate 模拟，方针150. narrowband filter 带通滤波器151. low-pass filter低通滤波器152. high-pass filter高通滤波器153. differential equation 微分方程154. prebias 预偏置155. summer 加法器156. weighted 加权旳157. refinement 改善158. accommodate 适应159. envision 预见160. alphabet 字母表161. validity 对旳性162. proposition 命题163. binary 二进制164. nevertheless 然而165. reveal 展现166. complement 补码167. truthtable 真值表168. algebraical 代数旳169. trial and error 试错法，试凑法170. elapse 时间（流逝）171. enumerate 列举172. expire 期满,终止173. brute 僵化旳174. prime 上撇号175. trigger 引起 ,触发176. inversion 反相 ,反转177. quadruple 四合一178. fabricate 制造179. integrated circuit 集成电路180. capsule 封装181. compatible 兼容旳182. obsolete 废弃旳183. threshold 门限,阈值184. zener diode 齐纳二极管185. adjacent 临近旳,靠近旳186. arc welding 电弧焊187. intimately 亲密地188. recast 重做189. bistable circuit 双稳电路190. cutoff 截止,关闭191. symmetry 对称192. lable 为……标号193. equilibria 平衡194. lever 杆,杠杆195. latch circuit 锁存电路196. depress 压下197. flip-flop 触发器198. glitch 同步199. leading edge 上升沿200. lagging(trailing) edge 下降沿201. inhibit 严禁202. hitherto 迄今,至今203. toggle (来回)切换204. impulse 推进力205. air gap 气隙206. aircraft 飞机207. alternating current, AC 交流208. armature 电枢209. automobile 汽车210. bearing 轴承211. brush 电刷212. carbon 碳213. circumference 圆周214. clearance 间隙215. coils 线圈绕组216. commutator 换向器217. connection 接线端218. copper bar 铜导条219. copper end rings 铜端环220. core 铁心221. cylindrical 圆柱式旳222. doubly excited 双边励磁223. electromechanical 机电旳224. felt 毡225. ferromagnetic 铁磁旳226. field pole 磁极227. flux density 磁通密度228. frame 机座，机壳229. generator 发电机230. glue 胶合，粘贴231. graphite 石墨232. induction motor感应电动机233. laminate 叠制，叠压234. lubricant 润滑剂，润滑油235. magnetic flux 磁通236. magnetizing current 磁化电流，励磁电流237. mechanical rectifier 机械式换向器238. metallic 金属旳239. penetrate 透过，渗透240. periphery 周围，圆周241. perpendicular 垂直旳，正交旳242. polarity 极性243. protrude 使伸出，突出244. reluctance 磁阻245. revolving magnetic field 旋转磁场246. rotor 转子247. salient 突出旳248. salient-pole 凸极式249. servo 伺服250. singly excited 单边励磁251. slip rings 滑环252. slot 槽，开槽253. squirrel-cage 鼠笼式，笼型254. stator 定子255. synchronous machine 同步电机256. torque 转矩257. toroid 环状物258. transformer 变压器259. unidirectional 单方向旳，方向不变旳260. winding 绕组261. wound-rotor 绕线式262. wrap 捆，缠，围绕263. yoke 轭264. allowable temperature rise 容许温升265. alnico 铝镍钴合金266. asynchronous machine 异步电机267. automobile starter motor 汽车启动机268. backlash 啮合间隙，齿隙269. centrifugal force 离心力270. ceramic 陶瓷旳271. compound-wound 复励272. constraint 强制，约束273. counter emf 反电势274. counterpart 对应物275. culminate 到达极值点276. cumulative compound 积复励277. demagnetization退磁，去磁278. denominator 分母279. differential compound 差复励280. dissipate 挥霍281. equilibrium level 平均值282. equivalent circuit 等效电路283. figure of merit品质因数，优值284. flicker 闪烁，摇曳285. flux per pole 每极磁通286. friction 摩擦287. in parallel with 并联288. in series with 串联289. in terms of 根据，在……方面290. in the vicinity of 在…附近，在…左右291. indispensable 必需旳，必不可少旳292. inherent 固有旳293. insulation 绝缘294. long-shunt 长复励295. loss 损耗296. magnetization curve 磁化曲线297. merit 长处，长处，指标298. no load 空载299. nonetheless，none the less 仍然，仍然300. numerator 分子301. overload 过载302. permissible 容许旳303. permanent-magnet永磁304. pertinent 有关旳305. power flow diagram 功率流程图306. prefix 前缀，把…放在前面307. rated torque 额定转矩308. reaction 电感309. rheostat 变阻器，电阻箱310. series-wound 串励311. shunt-wound 并励312. short-shunt 短复励313. starting current 启动电流314. starting torque 启动转矩315. synchronous speed 同步转速316. theorem 定理317. turns 匝数318. undervoltage 欠电压319. Ward-Leonard system 发电机-电动机组系统320. windage 通风321. yield 产生，提供322. adjacent 相邻旳，邻近旳323. autotransformer自耦变压器324. braking 制动325. cam 凸轮326. chamber 室，腔327. conveyor 传送机328. corrosion 腐蚀329. counterclockwise 逆时针330. counter electromotive force ，CEMF反电势331. dashpot relay 油壶式继电器332. diaphragm 膜片，挡板333. drill 钻床334. elapse 过去，消逝335. enclosure 机壳336. expel 排出，放出337. fasten 固定，连接338. furnace 炉339. fuse 熔断器，保险丝340. general-purpose relay通用继电器341. hydraulic 液压传动342. initiate 引起，增进343. intake 吸入344. knob 旋钮，圆形把手345. latching relay 自锁继电器346. lathe 车床347. limit switch 限位开关348. moisture 潮气，湿度349. mount 安装350. octal-base 八脚旳351. orifice 孔，注孔352. pedal 踏板，踏蹬353. phase sequence 相序354. piston 活塞355. pivot 轴，支点，旋转中心356. plunger 可动铁心，插棒式铁心357. pneumatic 气动旳358. relay 继电器359. single-phase 单相旳360. solenoids 螺线管361. solid-state relay 固态继电器362. spring 弹簧363. tap 抽头364. three-phase 三相365. timing relay 延时继电器366. toggle 搬扭，刀闸367. vibration 振动368. absolute encoder 绝对编码器369. accelerometer 加速度测量仪370. actuator 执行机构371. analog-to-digital conversion, ADC 模数转换器372. angular 角旳373. auxiliary 辅助旳374. as a rule of thumb 根据经验375. bellows 膜盒376. binary-coded decimal,BCD377. calibration 校准，标定，刻度378. cantilever 悬臂379. closed-loop 闭环■380. induction machine 感应式电机381. horseshoe magnet 马蹄形磁铁382. magnetic field 磁场383. eddy current 涡流384. right-hand rule 右手定则385. left-hand rule 左手定则386. slip 转差率387. induction motor 感应电动机388. rotating magnetic field 旋转磁场389. winding 绕组390. stator 定子391. rotor 转子392. induced current 感生电流393. time-phase 时间相位394. exciting voltage 励磁电压395. solt 槽396. lamination 叠片397. laminated core 叠片铁芯398. short-circuiting ring 短路环399. squirrel cage 鼠笼400. rotor core 转子铁芯401. cast-aluminum rotor铸铝转子402. bronze 青铜403. horsepower 马力404. random-wound 散绕405. insulation 绝缘406. ac motor 交流环电动机407. end ring 端环408. alloy 合金409. coil winding 线圈绕组410. form-wound 模绕411. performance characteristic 工作特性412. frequency 频率413. revolutions per minute 转/分414. motoring 电动机驱动415. generating 发电416. per-unit value 标么值417. breakdown torque 极限转矩418. breakaway force 起步阻力419. overhauling 检修420. wind-driven generator 风动发电机421. revolutions per second 转/秒422. number of poles 极数423. speed-torque curve 转速力矩特性曲线424. plugging 反向制动425. synchronous speed 同步转速426. percentage 百分数427. locked-rotor torque 锁定转子转矩428. full-load torque 满载转矩429. prime mover 原动机430. inrush current 涌流431. magnetizing reacance 磁化电抗432. line-to-neutral 线与中性点间旳433. staor winding 定子绕组434. leakage reactance 漏磁电抗435. no-load 空载436. full load 满载437. Polyphase 多相(旳)438. iron-loss 铁损439. complex impedance 复数阻抗440. rotor resistance 转子电阻441. leakage flux 漏磁通442. locked-rotor 锁定转子443. chopper circuit 斩波电路444. separately excited 他励旳445. compounded 复励446. dc motor 直流电动机447. de machine 直流电机448. speed regulation 速度调整449. shunt 并励450. series 串励451. armature circuit 电枢电路452. optical fiber 光纤453. interoffice 局间旳454. waveguide 波导波导管455. bandwidth 带宽456. light emitting diode 发光二极管457. silica 硅石二氧化硅458. regeneration 再生, 后反馈放大459. coaxial 共轴旳,同轴旳460. high-performance 高性能旳461. carrier 载波462. mature 成熟旳463. Single Side Band(SSB) 单边带464. coupling capacitor 结合电容465. propagate 传导传播466. modulator 调制器467. demodulator 解调器468. line trap 限波器469. shunt 分路器470. Amplitude Modulation(AM调幅471. Frequency Shift Keying(FSK)移频键控472. tuner 调谐器473. attenuate 衰减474. incident 入射旳475. two-way configuration 二线制476. generator voltage 发电机电压477. dc generator 直流发电机478. polyphase rectifier 多相整流器479. boost 增压480. time constant 时间常数481. forward transfer function 正向传递函数482. error signal 误差信号483. regulator 调整器484. stabilizing transformer稳定变压器485. time delay 延时486. direct axis transient time constant直轴瞬变时间常数487. time invariant 时不变旳488. transient response 瞬态响应489. solid state 固体490. buck 赔偿491. operational calculus 算符演算492. gain 增益493. pole 极点494. feedback signal 反馈信号495. dynamic response 动态响应496. voltage control system 电压控制系统497. mismatch 失配498. error detector 误差检测器499. excitation system 励磁系统500. field current 励磁电流501. transistor 晶体管502. high-gain 高增益503. boost-buck 升压去磁504. feedback system 反馈系统505. reactive power 无功功率506. feedback loop 反馈回路507. automatic V oltage regulator(A VR)自动电压调整器508. third harmonic voltage 三次谐波电压509. reference V oltage 基准电压510. magnetic amplifier 磁放大器511. amplidyne 微场扩流发电机512. self-exciting 自励旳513. limiter 限幅器514. manual control 手动控制515. block diagram 方框图516. linear zone 线性区517. potential transformer 电压互感器518. stabilization network 稳定网络519. stabilizer 稳定器520. air-gap flux 气隙磁通521. saturation effect 饱和效应522. saturation curve 饱和曲线523. flux linkage 磁链524. per unit value 标么值525. shunt field 并励磁场526. magnetic circuit 磁路527. load-saturation curve 负载饱和曲线528. air-gap line 气隙磁化线529. polyphase rectifier 多相整流器530. circuit components 电路元件531. circuit parameters 电路参数532. electrical device 电气设备533. electric energy 电能534. primary cell 原生电池535. energy converter 电能转换器536. conductor 导体537. heating appliance 电热器538. direct-current 直流539. self-inductor 自感540. mutual-inductor 互感541. the dielectric 电介质542. storage battery 蓄电池543. e.m.f = electromotive fore电动势544. unidirectional current 单方向性电流545. circuit diagram 电路图546. load characteristic 负载特性547. terminal voltage 端电压548. external characteristic外特性549. conductance 电导550. volt-ampere characteristics伏安特性551. carbon-filament lamp 碳丝灯泡552. ideal source 理想电源553. internal resistance 内阻554. active (passive) circuit elements有（无）源电路元件555. deviation 偏差556. leakage current 漏电流557. circuit branch 支路558. P.D. = potential drop 电压降559. potential distribution 电位分布560. r.m.s values = root mean square values 均方根值561. permanent magnet 永磁体562. effective values 有效值563. steady direct current 恒稳直流电564. sinusoidal time function 正弦时间函数565. complex number 复数566. Cartesian coordinates 笛卡儿坐标系567. modulus 模568. real part 实部569. imaginary part 虚部570. displacement current 位移电流571. trigonometric transformations 瞬时值572. epoch angle 初相角573. phase displacement 相位差574. signal amplifier 小信号放大器575. mid-frequency band 中频带576. bipolar junction transistor(BJT双极性晶体管577. field effect transistor(FET)场效应管578. electrode 电极电焊条579. polarity 极性580. gain 增益581. isolation 隔离分离绝缘隔振582. emitter 发射管放射器发射极583. collector 集电极584. base 基极585. self-bias resistor 自偏置电阻586. triangular symbol 三角符号587. phase reversal 反相588. infinite voltage gain 无穷大电压增益589. feedback component 反馈元件590. differentiation 微分591. integration 积分下限592. impedance 阻抗593. fidelity 保真度594. summing circuit总和线路反馈系统中旳比较环节595. pneumatic 气动旳596. Oscillation 振荡597. inverse 倒数598. admittance 导纳599. transformer 变压器600. turns ratio 变比匝比601. ampere-turns 安匝(数)602. mutual flux 交互(主)磁通603. vector equation 向(相)量方程604. power frequency 工频605. capacitance effect 电容效应606. induction machine 感应电机607. shunt excited 并励608. series excited 串励609. separately excited 他励610. self excited 自励611. field winding 磁场绕组励磁绕组612. speed-torque characteristic 速度转矩特性613. dynamic-state operation动态运行614. salient poles 凸极615. excited by 励磁616. field coils 励磁线圈617. air-gap flux distribution 气隙磁通分布618. direct axis 直轴619. armature coil 电枢线圈620. rotating commutator 旋转（整流子）换向器621. commutator-brush combination换向器-电刷总线622. mechanical rectifier 机械式整流器623. armature m.m.f. wave 电枢磁势波624. Geometrical position 几何位置625. magnetic torque 电磁转矩626. spatial waveform 空间波形627. sinusoidal–density wave正弦磁密度628. external armature circuit 电枢外电路629. instantaneous electric power瞬时电功率630. instantaneous mechanical power 瞬时机械功率631. effects of saturation 饱和效应632. reluctance 磁阻633. power amplifier 功率放大器634. compound generator 复励发电机635. rheostat 变阻器636. self – excitation process 自励过程637. commutation condition 换向状况638. cumulatively compounded motor 积复励电动机639. operating condition 运行状态640. equivalent T – circuit T型等值电路641. rotor (stator) winding 转子（定子绕组）642. winding loss 绕组（铜）损耗643. prime motor 原动机644. active component 有功分量645. reactive component 无功分量646. electromagnetic torque 电磁转矩647. retarding torque 制动转矩648. inductive component 感性（无功）分量649. abscissa axis 横坐标650. induction generator 感应发电机651. synchronous generator 同步发电机652. automatic station 无人值守电站653. hydropower station 水电站654. process of self – excitation 自励过程655. auxiliary motor 辅助电动机656. technical specifications 技术条件657. voltage across the terminals 端电压658. steady – state condition瞬态暂态659. reactive in respect to 相对….呈感性660. active in respect to 相对….呈阻性661. synchronous condenser 同步进相（调相）机662. coincide in phase with 与….同相663. synchronous reactance 同步电抗664. algebraic 代数旳665. algorithmic 算法旳666. biphase 双相旳667. bilateral circuit 双向电路668. bimotored 双马达旳669. corridor 通路670. shunt displacement current 旁路位移电流671. leakage 泄漏672. lightning shielding 避雷673. harmonic 谐波旳674. insulator string 绝缘子串675. neutral 中性旳676. zero sequence current 零序电流677. sinusoidal 正弦旳678. square 平方679. corona 电晕,放电680. bypass 旁路681. voltmeter 电压表682. ammeter 电流表683. micrometer 千分尺684. thermometer 温度计685. watt-hour meter 电度表686. wattmeter 电力表687. private line 专用线路688. diameter 直径689. centimeter 厘米690. restriking 电弧再触发691. magnitude 振幅692. oscillation 振荡693. auxiliary 辅助旳694. protective gap 保护性间隙放电695. receptacle 插座696. lightning arrester 避雷装置697. bushing 套管698. trigger 起动装置699. stress 应力700. deterioration 损坏,磨损701. spark gap 火花放电隙702. traveling-wave 行波703. wye-connected 星形连接704. enclosure 设备外壳705. live conductor 带电导体706. fuse 熔断器707. structural 构造上旳708. out-of-step 不一样步旳709. resynchronize 再同步710. synchroscops 同步指示器711. automatic oscillograph 自动示波器712. nominally 标称713. sampling 采样714. potential transformer 电压互感器715. fraction 分数716. switchyard 户外配电装置717. hazard 危险718. bushing 高压套719. contact 触点720. energize 励磁721. trip coil 跳闸线圈722. over-current relay 过电流继电器723. armature 衔铁724. pickup current 始动电流725. release current 释放电流726. solenoid relay 螺管式继电器727. induction-disc relay 感应圆盘式继电器728. inverse time relay 反时限继电器729. hydraulic 液力旳730. dashpot 阻尼器733. electrical stressing 电气应力734. mechanical stressing 机械应力■735. crystal 晶体旳，水晶，晶体736. demodulation 解调737. derivative 导数738. diaphragm 膜片739. differentiation 微分740. discrete 离散旳741. displacement 位移742. eddy 涡流743. encoder 编码器744. error 误差，偏差745. expedite 加速746. feedback 反馈747. feedforward 前馈748. forging 铸造749. hysteresis 磁滞750. immunity 抗扰性751. impedance 阻抗752. increment encoder 增量编码器753. inertia 惯性754. integration 积分755. interface 接口756. jerk 振动，冲击757. kinematic 运动旳，运动学旳758. longitudinal 经度了；纵向旳759. manipulations 操作，控制，处理760. manipulator 机械手，操作器761. measurand 被测量，被测量对象762. modulation 调制763. multiplexer 多路转换器764. offset 偏心765. open-loop 开环766. orthogonal 垂直旳，正交旳767. perpendicular 垂直旳，正交旳768. photosensor 光电传感器769. piezoelectric 压电旳770. plant 装置，设备771. potentiometer 电位器772. predominant 重要旳，突出旳773. prismatic 棱型旳774. proximity 距离775. quantization 量化776. radial 径向旳777. redundant 多出旳，反复旳778. representation 代表，表达779. resolver 解算器780. resonance 共振781. revolute 旋转旳，转动旳782. rig 设备783. robustness 鲁棒性784. rolling 轧制785. sampling period 采样周期786. signal-to-noise ration ，SNR信噪比787. strategy 方略788. subsequently 其后789. tachometer 测速仪790. terminology 术语，专门名词791. threshold 门，界线，阈值792. trajectory 轨迹793. transducer 传感器794. transient 瞬态旳795. transistor-to-transistor logic，TTL 晶体管-晶体管逻辑796. transit 运送797. translatory 平移旳798. algorithm 算法799. ambiguity 模棱两可800. antenna 天线801. arbitration 仲裁，公断802. autonomous 匿名旳803. capacity 容量804. chao 混乱805. checksum 检查和806. circumnavigate 饶过807. client-server 客户-服务器808. client-server model 客户服务器模型809. corridor 通道，走廊810. decouple 解耦，清除干扰811. depict 描述812. distributed system 分布式系统813. dungen 地牢814. electronic mail 电子邮件815. entity 实体816. etiquette 规则817. exponential 指数818. fallout 余波，附带成果819. forward 转发820. full-duplex 全双工821. gamut 全体，整体822. goggles 护目镜，潜水镜823. half-duplex 半双工824. hierarchy 阶梯，等级825. host 主机826. infrastructure 基础，底层构造827. interactive 交互式828. interface data unit 接口数据单元829. inventory 存货，清单830. killer 迷人旳831. newsgroup 新闻组832. object-oriented 面向对象旳833. outgoing 外出了，离开旳834. pointer 指针835. primitive 操作，原型836. process 进程837. propagation 传播，宣传838. protocol 协议839. protocol data unit 协议数据单元840. remote database 远程数据库841. remote login 远程登陆842. remote terminal 终端843. reprisal 报复844. router 路由器845. service data unit 服务数据单元846. simultaneous 同步旳847. static allocation 静态分派848. subnet 子网849. taxonomy 分类学，分类850. telemedicine 远程医疗851. terminology 术语852. testbed 测试平台853. therapy 治疗854. token 令牌855. topology 拓扑学856. videoconference 可视会议857. virtual reality 虚拟现实858. worldwide shared 全球共享旳859. wide area network 广域网860. actuator 执行器861. bar code reader 条码阅读器862. by-product 副产品863. call for 需要864. contiguous 邻近旳865. culprit 犯罪者866. elusive 难以捉摸旳867. filter 滤波器868. fluctuation 升降剥动，不规则旳变化869. hardwired 硬接线旳870. havoc 大破坏871. high-volume 大容量872. induction coupling 感应耦合873. inference 干扰874. injection molding 注模875. instruction set 指令集876. interconnection 互相连接877. isolation transformer 隔离变压器878. maintenance 维护。
current ['kʌrənt] n. 电流alternating current 交流电流direct current 直流电流current density 电流密度active current 有功电流reactive current 无功电流voltage ['vəultidʒ] n. 电压voltage drop 电压降落voltage gain 电压增益voltage divider 分压器voltage stabilizer 稳压器variable ['vεəriəbl] n. 变量；a.可变的，可调的，易变的complex variable 复变量dependent variable 因变量independent variable 自变量input variable 输入变量charge n. 电荷，充电；v. 充电，带电，起电charge distribution 电荷分布charge particle 带电粒子test charge 试验电荷positive charge 正电荷negative charge 负电荷coulomb n. 库仑（电荷的单位）coulomb meter 库仑计circuit ['sə:kit] n. 电路circuit diagram 电路图analogue circuit 模拟电路short circuit 短路open circuit 开路active circuit 有源电路passive circuit 无源电路underlying [,ʌndə'laiiŋ] a. ①基本的，根本的②潜在的，在下（面）的，下伏的electron [i'lektrɔn] n. 电子magnitude ['mæɡnitju:d] n. 大小，尺寸，数量，数值electromotive a. 电动的，起电的electromotive force 电动势ampere ['æmpεə] n. 安，安培（电流的单位）ampere meter 安培ampere turn 安匝volt ampere 伏安integrate ['intiɡreit, 'intiɡrit, -ɡreit] v. 积分，求积分work n. 功potential a.势的，位的，电位的；n.势（能）,位(能), 电势(位,压) potential difference 电位差，电势差earth potential 地电势（位）potential energy 势（位）能reference potential 参考（基准）电位rectangular ['rek'tæŋɡjulə] a. 矩形的，直角的，正交的joule [dʒu:l, dʒaul] n. 焦尔（能量、热量、功的单位）volt [vɔlt] n. 伏特（电压、电位、电势的单位）electron volt 电子伏特voltaic a. 动[流]的，电压的，电镀的，伏打(式)的voltaic battery 伏打电池convention [kən'venʃən] n. 习惯，惯例，常规by convention 按照惯例reference direction 参考方向polarity [pəu'lærəti] n. 极性power n. ①功率，效率②动力，电力，能力，电源③乘方，幂watt n. 瓦特（功率的单位）time-varying a. 时变的instant n. 瞬间，瞬时，即刻，时刻；a.立刻的，直接的，紧急的，迫切的instantaneous [,instən'teinjəs] a.瞬时（作用）的，瞬息的，即刻的instantaneous power 瞬时功率passive a. ①无源的②消极的，被动的；n. 无源passive network 无源网络algebraic a. 代数的active a. ①有源的，有功的，有效的②活动的，主动的，积极的③活性的，放射的，激励的active element 有源元件resistor n 电阻，电阻器capacitor n. 电容器inductor n. 电感器source n. 电源，（光，能，动力，信号，辐射，根，来，起）源voltage source 电压源current source 电流源ideal independent source 理想独立源constant voltage source 恒定电压源independent source 独立源dependent source 受控源controlled source 受控源voltage-controlled voltage source电压控制电压源current-controlled voltage source电流控制电压源voltage-controlled current source电压控制电流源current-controlled current source电流控制电流源generator n. ①发电机②（脉冲，信号，气体）发生器，振荡器，加速器AC generator 交流发电机diamond-shaped a. 菱形的transistor n. 晶体管，半导体管operational a. ①运算的，计算的②操作的，工作的，业务的，运转的amplifier n. 放大器integrated circuit 集成电路token n. ①标记，象征②特征by the same token 同理，同样；另外，还有Ohm 欧姆（电阻，电抗，阻抗的单位）Ohm's Law 欧姆定律resistance n. ①电阻,电阻器（件,装置）②阻力，阻尼③抵抗，抵制，反对resistance load 电阻(性)负载magnetic resistance 磁阻measuring resistance 标准电阻,测量用电阻rearrange v. 重新整理（安排,布置,排列）,调整linear a. ①线性的，一次的②（直）线的，直线型的，线状的linear resistor 线性电阻nonlinear a. 非线性的，非直线的nonlinear resistor 非线性电阻incandescent a. 白炽（热）的，炽热的incandescent lamp 白炽灯voltage-current characteristic 伏安特性short circuit 短路open circuit 开路conductance n. ①电导，导电性，导纳②传导（性，率，系数），导率siemens n. 西门子（电导单位）network n. 网络，电路，电网linear time-varying network 线性变参数网络network analyzer 网络分析器configuration n. 结构，构造topology n. 拓扑，拓扑学，拓扑结构node n. ①节点，结点，交点，叉点②（波）节，结，节branch n. ①支路，支线，支脉②分支（路，线，流）③部门，分部，分行dimension n. ①维（数），度（数）②尺寸，线度③量纲，因次loop n. 回路，闭合电路，环路，循环，环clockwise a.; ad. 顺时针方向（的）counterclockwise a.; ad. 逆时针方向（的）nodal a. 节点的，结点的，交点的，节的，结的nodal analysis 节点分析mesh n. 网孔，网格，网眼，网状mesh analysis 网孔分析simultaneous a. ①联立（方程）的②同时（存在，发生）的，一起的，同步的quotient n. ①商（数），系数②份额，应分得的部分determinant n. ①行列式②决定因素，遗传素datum n. ①基准（点，线，面），基标②数据，资料，信息chassis n. 底盘，底（盘）架，底板（座）planar a. ①平面的，平的②二维的，二度的error-minimizing a. 令错误最少的symmetry n. 对称（性，现象），均称，调和coefficient n. ①系数，因数，常数，率②折算率phasor n. 相量，相图，相位复（数）矢量phasor diagram 相量图sinusoidal a. 正弦（波，式，形，曲线）的steady-state a. 稳态的domain n. ①（定义）域，区（领）域，定义范围②区，范围，界time domain 时域frequency domain 频域transform v.; n. ①变换，改变，转换，换（折）算②变换式，反式magnitude n. ①大小，幅值，幅度，量，数量，尺寸，②等级，量级phase n. ①相（位）②（发展）阶段，时期，局面③方（侧）面three-phase 三相single-phase 单相phase voltage 相电压phase current 相电流(be) out of phase 异相（的）lag n.; v. 滞后，落后，迟（时）滞lead v. 超前，提前，领先AC = alternating current 交流电流，交流电，交流DC = direct current 直流电流，直流电，直流theorem n. 定理，原理（则），命题，法则Thevenin's theorem 戴维南定理superposition n. 叠加，重叠superposition theorem 叠加定理transmission n. 输电，传（输，递，送，播，导）equivalent a. 等效的，等值的，等同的amplitude n. 振幅，幅度，波幅effective a. 有效的，等效的，生效的，能行的，有作用的，有影响的sequence n. 顺序，次序，时序，序列，系列positive sequence 正序negative sequence 负序，反序phase sequence 相序load n. 负荷，负载impedance n. 阻抗topologically ad. 在拓扑结构上，从拓扑结构electronics n. 电子学，电子仪器，电子设备，电子线路understatement n. 轻描淡写，有节制的表达omnipresent a. 无处不在的，普遍存在的electronic a. 电子（学）的transaction n. ①交易，业务②办理，处理，执行，记录digital a. 数字的，数字式的，计数的espionage n. 谍报，间谍活动，密探，监视signal-processing a. 信号处理的analog n. ①模拟（量，装置，设备，系统）②类似，类比，比拟velocity n. 速度，速率thermocouple n. 热电偶discrete a. 离散的，不连续的，分散的household a.; n. 家用的，普通的，一般用途的，家庭，家，户thermostat n. 恒温器，定温器，温度自动调节器preset v.; a. ①预定，预置，（预先）调整②安装程序，给定程序的switch n. 开关；v. 接通或关断，转变，换接A/D = Analog-to-Digital 模数转换，模数变换D/A = Digital-to-Analog 数模转换，数模变换transducer n. 传感器，变送器，发射器，换能器，换流器excitation n. ①激励，激发，激磁②刺激，干扰display v. 显示，显像，表现，陈列，展览；n. 显示，指示，表现Boolean 布尔的logic gate 逻辑门symbolic a. 符号的，记号的，象征（性）的proof n. 证明，证实，证据；v. 检验；a. 试验过的，合乎标准的，防……的singularly ad. 非凡地，特殊地，奇异地，单独地Manipulation n. 处理，计算，操作，控制，管理binary n.; a. 二进制的，二进位的，二元的，二成分的②二，双，复arithmetic n. 算术，计算，运算；a. 算术的，计算的，运算的associative a. 结合的，联合的，相关的，commutative a. 交换的，换向的，代替的，相互的distributive a. 分配的，分布的，个别的truth table 真值表multiplication n. ①乘法，相乘②增加，增多，增殖，倍增addition n. ①加法②增加，附加，相加conjunctive a. ①合取的，逻辑乘的②连接的，连系的disjunctive a. 析取的，分离的，转折的identity n. 单位，同一，完全相同，一致，恒等，身份null n. ; a. ①零的，空的，无②不存在的，没有的complement n.; a. ①补码，补数，余的，补的②补充，互补displacement n. ①位移，变位，移动，平移，偏移②排（水，汽，气，液）量intensity n. ①强度，密度，亮度，光强②强烈，紧张regulation n. ①调整，校准，控制②规则，规章，规程，章程，条例，细则quantize v. ①量化，分层，取离散值②（使）量子化clarity n. 清晰，清晰度，透明，透明度sine n. 正弦fidelity n. 保真，保真度，逼真，逼真度disc n. 盘，圆片，唱片sample v. 采样，取样，抽样；n. 采样，样品，标本，模型，实例straightforward a. ①直接的，明确的，坦率的②简单的，易懂的③顺向的，流水作业的sensitive a. 敏感的，灵敏的，易感光的；n. 对……敏感的材料sensitive element 敏感元件voltage divider 分压器photoelectric a. 光电的piezoelectric a. 压电的amplification n. 放大（率，系数，倍数，作用），加强，增强pulse n. 脉冲，脉动integral a. 积分的，累积的，整数的，整体的，总体的；n. 积分，整数，整体parameter n. 参数，参量，系数precision n. 精度，精密，精确； a. 精确的，精密的incompatible a 不相容的，不一致的concurrently ad. 同时microsecond n. 微秒bit n. 位，比特，二进制数full-scale a. ①满刻度的，满标度的，满量程的②完全的，全面的quantization n. 量化，分层，把连续量转换为数字byte n. 字节code n. 编码，密码，符号；v. 编码，译码encode v. 编码，译码，把……译成电码weighted a. ①加权的，权重的，加重的②受力的，负载的receipt n. 收到，接收，收据amplifier n. 放大器register n. ①寄存器，②记录，登记，注册，挂号；v. ①登记，注册，挂号②记数，存储parallel-in 并联输入的parallel-out 并联输出的resolution n. 分辨率，鉴别力gain n. 增益，放大系数，放大率，增量drift n. 漂移，偏移operational amplifier 运算放大器difference amplifier 差动放大器differential a. 微分的，差动的，差分的，差别的；n. 微分，差动，差分，差别feedback n. 反馈，回复，反应stability n. ①稳定性，稳定度，安定性，复原性②耐……性，耐久性capacitive a. 电容性的，电容的，容性的coupling n. 耦合,偶合,连接；a. 耦合的,连接的long-term a. 长期的，远期的power-supply n. 电源solid-state a. 固态的microvolt n. 微伏saturate v. 使饱和；a. 饱和的，浸透的comparator n. 比较器swing v.; n. 摇摆，摆动single-ended a. 单端的two-sided a. 双边的，双侧的，两边的，两方面的frequency band 频带semiconductor n. 半导体power electronic n. 电力电子loss n. 损耗，损失parasitic a. 寄生的，附加的winding n. ①绕组，线圈②一圈，一转transformer n 变压器，变换器，变量器dielectric n. 介质，电介质，绝缘材料；a. 绝缘的，介电的，介质的，不导电的eddy n. 涡流，旋涡； a. 涡流的，涡旋的；v. 涡流，起旋涡hysteresis n. 磁滞，滞后，迟滞on-state a. 通态的，接通的，开态off-state a. 关态的，断开的，断态的microamp n. 微安milliamp n. 毫安steering n. 转向，操纵，控制，调整buildup n. ①形成，产生，出现②增加，增大，上升③建造，建起ramp v. 斜变，倾斜，直线上升waveform n. 波形clamp v. 箝位，定位，使固定snubbering n. 缓冲zero-voltage 电压过零的zero-current 电流过零的ripple n.波纹，波度，微波rectifier n. 整流器isolation transformer 隔离变压器interface n. 接口Buck converter 降压式变换器，降压式斩波器Boost converter 升压式变换器，升压式斩波器Buck-Boost converter 升/降式变换器，升/降式斩波器quadrant n.象限，四分之一圆周，九十度弧step-down a. 降压的，降低的step-up a. 升压的，升高的dual a. 二重的，对偶的filter n.; v. 滤波，过滤periodically ad. 周期地portable a. 手提的，轻便的，可携带的sink n. 换能器，变换器，散热器，汇点，收点，穴hypothetical a. 假设的，假定的，有前提的duty ratio 功率比，能量比turn ratio 匝数比PWM pulse width modulation 脉冲宽度调制switch-mode power supplies 开关电源inverter n. 逆变器uninterruptible power supplies (UPS) 不间断电源single-phase a. 单相的three-phase a. 三相的parameter n. 参数unidirectional a. 单极性的，单向的electromagnetic a. 电磁的relay v. 中继，转播；n. 继电器synchronous motor 同步电动机torque n. 转矩non-sinusoidal a. 非正弦的low-pass 低通smoother n.滤波器，整平器polarity n. 极性bidirectional a. 双向的harmonics n. 谐波high order harmonics 高次谐波induction n. 感应square-wave 方波response time 响应时间notching n. ; a. 阶梯式，下凹的，切口，开槽step pulse 阶跃脉冲induction machine 感应电机horseshoe n. ①马蹄形，U形②马蹄铁magnet n. 磁铁，磁石，磁体horseshoe magnet 马蹄形磁铁permanent magnet 永久磁铁perpendicular a. ①（与……）垂直的②直立的；n. 垂直，正交，竖直magnetic field 磁场induction machine 感应电机horseshoe n. ①马蹄形，U形②马蹄铁magnet n. 磁铁，磁石，磁体horseshoe magnet 马蹄形磁铁eddy n. 涡流，涡旋permanent magnet 永久磁铁perpendicular a. ①（与……）垂直的②直立的；n. 垂直，正交，竖直magnetic field 磁场bar n. ①线棒，导条②条，杆slot n. ①槽②隙缝lamination n. ①叠片，冲片②分层③薄片braze v.铜焊，钎焊solder n.焊料，接合物；v. 焊，焊接short-circuiting a. 使短路的ring n. 环squirrel cage 鼠笼core n. ①铁芯②心，核心coil n. 线圈，绕组random-wound 散绕form-wound 模绕insulation n. 绝缘performance characteristics 工作特性air-gap 气隙polyphase n.; a. 多相，多相的motoring n.; a. 电动机运行plugging 反向制动，反相序制动控制generating n.; a. 发电机运行synchronous speed 同步速breakdown torque 失步转矩，停转转矩locked-rotor torque 止转转矩，起动转矩breakaway n. ①起步，起动②分离，脱离breakaway force 起动力rated a. ①额定的，标称的②计算的，设计的full-load a. 满（负）载的overhauling a. 检修的，大修的prime mover 原动机induction generator 感应发电机，异步发电机wind-driven generator 风力发电机inrush current 涌流synchronous machine 同步发电机armature n. 电枢armature winding 电枢绕组field winding 励磁绕组，磁极绕组quantitative a. 量的，数量的，定量的salient a. 凸出的，凸的，突出的salient pole 凸极saturation n. 饱和，饱和度cylindrical-rotor 隐极式转子，鼓极转子steam-turbine-driven generator 汽轮发电机Y-connected windings 星形连接绕组turbine generator 涡轮发电机，汽轮发电机，水轮发电机cps = cycles per second 周/秒，赫rpm = revolutions per minute 转/分steam turbine 汽轮机rating n. 额定值，额定参数；标称值，定额efficiency n. 效率wedge n. 楔[形]，楔形物，槽楔；v. 楔进，斜楔concentric coil 同心线圈slip ring 滑环lead n. ①导线，导管，引线②铅；v. 超前，导前，引导carbon brush 碳刷mmf = magnetomotive force 磁动势step wave 阶跃波diameter n. 直径vibration n. 振荡field current 励磁电流exciter n. 励磁机shaft n. 轴regulation n. 调节stability n. 稳定性，稳定ventilation n. 通风，换气，通风装置flux n. 通量，磁力线transformer n. 变压器wrap v.; n. 包裹，包扎，缠绕，卷ferromagnetic core 铁磁芯primary winding 一次绕组，原绕组，初级绕组secondary winding 二次绕组，副绕组，次级绕组tertiary winding 三次绕组，第三绕组power transformer 电力变压器core form 铁芯式shell form 壳式innermost a. 最内部的，最里面的，最深处的leakage flux 漏磁通unit transformer 单元（机组）变压器substation transformer 配电变压器distribution transformer 配电变压器potential transformer 电压互感器current transformer 电流互感器copper loss 铜耗hysteresis loss 磁滞损耗，磁滞损失reluctance n. 磁阻self-inductance 自感应core-loss 铁芯损耗distill 提取…精华，蒸馏instruction 指令document n.文件thermostat 恒温器，定温器，温度自动调节器audio signal n. 声频信号，音频信号program n. 程序keyboard n. 键盘software n. 软件central processing unit 中央处理单元workstation n. 工作站videogame console 视频游戏操作板mainframe n. 主机，主机架supercomputer 超级计算机server 服务器client 客户microcomputer 微型计算机desktop computer 台式计算机notebook computer 笔记本电脑handheld computer 掌上电脑computer-aided 计算机辅助的three-dimensional 三维的animated graphics 动画图像local area network ( LAN)局域网LCD screen ( liquid crystal display screen ) 液晶显示屏display device 显示设备mouse n. 鼠标floppy disk drive 软盘驱动器hard disk drive 硬盘驱动器CD-ROM drive CD-ROM驱动器DVD drive DVD驱动器CD-writer CD写入器，刻录机sound card 声卡rudimentary a. 基本的，基础的，初步的，根本的built-in a. 嵌入的，安装在内部的，内装的，机内的modem n. 调制解调器peripheral device 外围设备scanner n. 扫描仪digital camera 数码相机joystick n. 控制杆graphics tablet 图形板operating system 操作系统miniaturized a. 小型的，小型化的ALU (arithmetic logic unit) 算术逻辑单元control unit 控制单元register n. 寄存器cycle n. 周期clock cycle 时钟周期word size 字长cache n. 高速患缓冲存储器instruction set 指令集megahertz n. 兆赫，兆赫兹gigahertz n. 吉赫，吉赫兹motherboard n. 母板, 主板chip n. 芯片，晶片，组件CISC (complex instruction set computer) 复杂指令集计算机RISC (reduced instruction set computer) 简化指令集合计算机serially ad. 串行地serial processing 串行处理parallel processing 并行处理pipelining a. 流水线的RAM (Random Access Memory) 随机存储器operating system 操作系统plug v. 插入，插上；n. 插头，插入物microscopic a. 微观的，细微的，显微（镜）的，显微的charge v. 充电，带电，起电；n. 电荷，充电discharge v. 放电bit n. 位byte n. 字节volatile a. 易失的，挥发的，易挥发的，易变的，短暂的megabytes (MB) 兆字节software package 软件包install v. 安装virtual memory 虚拟存储器nanosecond 纳秒SDRAM (synchronous dynamic RAM) 同步动态RAMROM (Read-Only Memory) 只读存储器startup n. 起动caterpillar-like a. 履带式的DIP ①= double in-line package 双列直插式组件②=dual in-line package 双列式封装BIOS (basic input/output system) 基本输入输出系统CMOS (complementary metal oxide semiconductor memory)rechargeable battery 充电电池setup 安装update v. 更新，修改，校正slot n. 槽expansion slot 扩展槽port n. 端口data bus 数据总线expansion bus 扩展总线socket n. 插座，插口expansion card 扩展卡adapter n. 适配器USB universal series bus 通用串行总线storage device 存储设备download v.; n. 下载ISA (industry standard architecture)工业标准结构PCI (peripheral component interconnect) 外部设备互连video capture card 视频捕获卡interface n.; v. 接口AGP (accelerated graphics port) 加速图形端口serial port 串行端口jack n. 插座，插孔，插口，弹簧开关protrude v.（使）伸出，突出，推出cutout n. 中断装置，断流器，断路器CRT (cathode ray tube) 阴极射线管LCD (liquid crystal display) 液晶显示dots of color 色点stand-alone 独立的diagonally ad. 对角地dot pitch 点距clarity n. 清晰度pixel n. 像素，图素，像元resolution n. 分辨率, 分辨度ink jet 喷墨printout n. 打印输出nozzle n. 喷管，喷头，喷嘴cartridge n. 夹头，卡盘cyan a.; n. 蓝绿色的，蓝绿色magenta a.; n. 深红色的，深红色photocopier n. 照相复印机，影印机light-sensitive a. 光敏的drum n. 磁鼓electrostatically ad. 静电地multicolored a. 多色的default n. 缺省，默认ribbon n. 色带module n. 模件，组件，模块document n. 文件，文献，公文Web browsing 网页浏览programmer n. 程序员computer language 计算机语言binary a.；n. 二进制的，二进位source code 源代码high-level language 高级语言machine language 机器语言batch n. 批，一批object code 目标代码compiler n. 编译程序interpreter n. 解释程序script n. 脚本operand n. 操作数octal a. 八进制的hexadecimal a. 十六进制的assembler n. 汇编程序system software 系统软件application software 应用软件operation system 操作系统user interface 用户界面，用户接口menu n. 菜单toolbar n. 工具条button n. 按钮compatible a. 兼容的，可共存的，兼容制的graphical user interface 图形用户界面click v. 按file management system 文件管理系统bootstrap n. 引导bootstrap program 引导程序single-user operating system 单用户操作系统multiuser operating system 多用户操作系统multitasking operating system 多任务操作系统data base 数据库redundant a. 冗余的，多余的，fault-tolerant a. 容错的redundancy n. 冗余disk array 磁盘阵列home computer 家用电脑dial up 拨号repository n. 仓库twisted-pair 双绞的，双绞线的coaxial cable 同轴电缆fiber-optic cable 光缆，光纤电缆microwave n. 微波infrared a. 红外线的；n. 红外线shielded a. 屏蔽的unshielded a. 非屏蔽的strand n. 股，股线bandwidth n. 带宽high-bandwidth 高带宽low-bandwidth 低带宽broadband n. 宽带narrowband n. 窄带hub n. 集线器router n. 路由器gateway n. 网关repeater n. 中继器，转播器electric power system 电力系统cable n. 电缆，缆，钢丝绳；v. 架设电缆，敷设电缆fuse n. 保险丝，熔断器；引信；v. 熔化，熔断meter n. 米；测量仪表，计量器customer n. 客户，用户radius n. 半径incandescent lamp 白炽灯transmission line 输电线路power loss 功率损耗voltage drop 电压降落AC transmission 交流输电transmission system 输电系统utility n. 公用事业，效用，中心电站flexibility n. 灵活性，机动性，适应性；柔性，柔度interconnection n. 相互连接，互联asynchronous a. 异步的nominal frequency 额定频率misoperation n. 误操作，误动作paramount a. 最高的，头等的；高过，优于in parallel 并联地synchronously ad. 同步地facility n. ①容易，方便②灵活，熟练③（便利）条件④（常用复数）设备，装置，工具，器材primary energy 一次能源fossil n. 化石，石块hydraulic a. 水力[学]的，水压的，液压的，液力的mechanical energy 机械能switching device 开关装置，开关设备subtransmission n. 二次输电subtransmission system 分支输电系统，二次输电系统distribution system 配电系统substation n. 变电所，变电站，分站，分所feeder n. 馈线，馈电电路redundancy n. 多余，冗余contingency n. 意外事故，偶然事故reliable a. 可靠的bus n. 母线overload n. 过载，超载，过负荷optimal a. 优化的，最优的，最佳的production cost 生产成本，生产费用hydro-generation n. 水力发电dry period 枯水期replenishment n.（再）补充，充实，充满economic dispatch 经济调度economic operation 经济运行security n. 安全性，可靠性emission n. 排放，放出，散放tie-line n. 联络线var flow 无功潮流throttle n. 阀门，节流阀，调速汽门thermal unit 热力机组，热力单位magnetizing current 激磁电流，励磁电流electric clock 电钟active power balance 有功功率平衡supplementary control 辅助控制load-frequency control (LFC) 负荷频率控制speed governor 调速器underfrequency load shedding 低周减载，低频减负荷automatic generation control (AGC) 自动发电控制stabilize v. 使……稳定reactive power 无功功率active power 有功功率automatic voltage regulator 自动电压调节器shunt capacitor 并联电容器，并联电容shunt reactor 并联电抗器，并联电抗synchronous condenser 同步调相机static var compensators (SVCs) 静止无功补偿器series capacitor 串联电容器tap-changing transformer 可调分接头变压器booster n. 升压器，增压器，加压泵angular a. 角的，角度的power versus angle relationship 功角关系synchronous reactance 同步电抗，功率—角度关系excitation voltage 励磁电压angular displacement 角位移rotor angle stability 转角稳定性，功角稳定性voltage stability 电压稳定性electromechanical a. 机电的electromagnetic a. 电磁的equilibrium n. 平衡，均衡mechanism n. 机理，机制；机构，装置；结构synchronism n. 同步accelerate v. 加速，促进decelerate v. 减速mechanical torque 机械转矩electrical torque 电气转矩outage n. 停电，断电，中断，停运，停机，事故short-circuit fault 短路故障power-angle relationship 功角关系fluctuation n. 波动，起伏small-signal stability 小信号稳定性transient stability 暂态稳定性small disturbance stability 小干扰稳定性damp v. 阻尼，（使）减弱，减幅；n. 阻尼，衰减damping torque 阻尼转矩instability 不稳定性out of step 失步synchronizing torque 同步转矩non-oscillatory a. 非振荡的，非周期的disturbance n. 扰动，干扰post-disturbance a. 干扰后的，扰动后的，事故后的unstable a. 不稳定的first-swing n.; a. 第一次摇摆power system protection 电力系统保护，电力系统继电保护abnormality n. 异常，反常，不正常sense v. 检测，读出，断定；感觉，感受，感到relay n. 继电器，中继器；v. 中继，转播，用继电器控制circuit breaker 断路器trip coil 跳闸线圈，脱扣线圈electromechanical relay 电磁继电器solid state 固态static relay 静态继电器，无触点继电器self-checking 自检，自校maloperation n. 误操作，误动作，维护不当energize v. 激励，激磁，驱动，通以电流overcurrent relay 过电流继电器undervoltage relay 低电压继电器，欠压继电器underfrequency relay 低周继电器，低频继电器directional relay 方向继电器thermal relay 热继电器，温度继电器，热敏继电器phase sequence relay 相序继电器negative sequence relay 负序继电器zero sequence relay 零序继电器differential relay 差动继电器percentage differential relay 比率差动继电器distance relay 距离继电器plane impedance relay 平面阻抗继电器angle impedance relay 角度阻抗继电器angle admittance relay 角度导纳继电器Mho relay 姆欧继电器，电导继电器offset relay 偏置继电器restricted relay 制约式继电器pilot relay 控制继电器，辅助继电器wire pilot relay 有线控制继电器carrier channel pilot relay 载波控制继电器microwave pilot relay 微波控制继电器transductor relay 饱和电抗型继电器rectifier bridge relay 整流桥型继电器electronic relay 电子继电器3-φ fault 三相故障3-φ to ground fault 三相接地短路故障double line to ground fault 两相短路接地故障line to line fault 相间短路故障single line to ground fault 单相接地故障ground fault 接地故障internal fault 内部故障external fault 外部故障interturn fault 匝间故障overvoltage n. 过电压overheat v. 过热，使过热overheating n. 过热，超温lubrication oil 润滑油out of step 失步overspeed n.; v.; a. 超速，过速，超转速，过速的miscellaneous a. 杂的，杂项的，各种的；n. 其他resonance n. 谐振，共振trip v. （使）断开，（使）跳闸，切断，关闭mechanical resonance 机械共振hydro turbine 水轮机inertia n. 惯性，惯量undercurrent n. 欠电流，电流不足；a. 欠电流的，低电流的arcing n. 飞弧，发弧，弧击穿overexcitation n. 过励air-blast circuit breaker 压缩空气断路器oil circuit breaker 油断路器，多油断路器quench v.; n. 熄灭，熄弧arc-quenching n. 灭弧minimum-oil circuit breaker 少油断路器magnetic air circuit breaker 磁吹断路器SF6 circuit breaker 六氟化硫（SF6）断路器vacuum circuit breaker 真空断路器interrupting capability 开断容量，遮断容量deion grid 去电离栅极，灭弧栅interrupting time 开断时间，遮断时间nameplate n. 铭牌operating mechanism （断路器的）操动机构horn gap 角隙，角放电器火花源horn gap contact 带灭弧功能的触头air switch 空气开关spring-action 弹簧动作spring-action driving mechanism 弹簧操作机构insulating barrier 绝缘隔板arc chute 灭弧罩，灭弧隔板，电弧隔板blowout coil 灭弧线圈，消弧线圈arc-extinguishing a. 灭弧的，消弧的molded-resin 模制树脂，浇铸树脂trigger n. 触发，起动；v. 触发，起动，激发，引起outdoor a. 户外的live-tank 带电箱体dead-tank 接地箱体gas-insulated substations (GISs) 气体绝缘变电站vacuum-bottle n. 真空罐switchgear n. 开关设备，配电设备，配电装置voltage-to-current ratio 电压电流比time-delayed relay 延时继电器timer relay 时间继电器overreach v.; n. 越过，伸得过长current transformer 电流互感器voltage transformer 电压互感器remote back-up 远后备arcing fault 闪络故障underreach v.; n. 达不到backup n. 后备，支持，备份；a. 后备的，备用的，备份的response n. 响应，反应lightning n. 雷（电），闪电；a. 闪电（般）的lightning arrester 避雷器overhead ground wire 架空地线surge n.; v. 电[浪]涌，冲击，波动surge arrester 避雷器over-voltage n. 过电压switching surge 操作冲击，操作浪涌clip n. 线夹，接线柱，夹子；v. 夹住，箝，钳牢，固定ionizer n. 电离装置，游离装置silicon carbide 碳化硅，金刚砂spark gap 火[电]花隙，放电器，避雷器valve block 阀片break down 击穿，断裂，破裂arc chamber 电弧室zinc-oxide n.氧化锌metal-oxide varistor 金属氧化物压敏电阻器basic impulse insulation level (BIL) 基本冲击绝缘水平coal-fired a. 燃煤的furnace n. 炉，炉膛，燃烧室pulverizer n. 磨煤机，粉煤机preheated a. 预热的boiler n. 锅炉，蒸发器，蒸汽发生器flue gas 烟气，废气，排烟electrostatic a. 静电的precipitator n. 除尘器electrostatic precipitator 电除尘chimney n.（高）烟囱，烟筒coal hopper 煤斗burner n. 燃烧器，喷燃器cooling tower 冷却塔feed water pump 给水泵psi 磅/平方英寸（压强单位）shutoff n. 关闭，切断，断路exhaust steam 乏汽heater exchanger 热交换器condenser n. 凝结器，冷凝器feed-water 给水turbogenerator n. 涡轮发电机single-stage turbine 单级汽轮机thermal efficiency 热效率multi-stage turbine 多级汽轮机tandem a.; ad. 级联（的），串联的，前后排列的；n. 前后排列使用的一组事物in tandem 前后地，协力地，相互合作地superheater n. 过热器high-pressure turbine 高压汽轮机reheater n. 再热器intermediate-pressure turbine 中压汽轮机low-pressure turbine 低压汽轮机cogeneration n. 热电联产，热电联供acid rain 酸雨greenhouse effect 温室效应hydropower n. 水力，水力发电cubic a. 立体的，三次的，体积的，正六面体的dam n. 坝，堰penstock n. 水道，压力水管hydroplant n. 水电厂，水电站high head 高水头low head 低水头tail race 尾水渠，退水渠nozzle n. 喷嘴periphery n. 周边，周围，外围，范围blade n. 叶片，轮叶spoked wheel 辐轮start up 起动，开动，触发thermal plant 热电厂dispatcher 调度员sparingly 节省地，有节制地，少量地spillway n. 泄水道，溢水孔base-loading 基荷pumped storage 抽水蓄能peak load 高峰负荷off-peak 非峰值的on-line 在线daily load-demand curve 日负荷曲线shaves the peaks （负荷曲线的）削峰fills the troughs （负荷曲线的）填谷bucket wheel rotor 勺轮转子fission n.; v. 裂变，分裂，剥离nuclear power plant 核电站，核电厂reactor n. 反应堆，反应器；电抗器，电抗线圈coolant n. 冷却剂，冷却液light-water reactor 轻水反应堆boiling-water reactor （BWR）沸水反应堆pressured-water reactor (PWR) 压水反应堆reactor core 反应堆堆芯，反应堆活性区bypass valve 旁路阀门reactor coolant pump 反应堆冷却泵moderator n. 减速剂，慢化剂self-regulation 自调整negative feedback 负反馈pressurize v. 增压，对……加压，产生压力pressurizer n. 保持压力装置，增压装置setpoint 设定值，给定值make-up 补给[水]，补充let-down 下泄control rod （反应堆的）控制棒，控制杆visualize v. 使……可视化，具体化，形象化manoeuvre n. 调动，策略；v. 调动，操纵automatic control system 自动控制系统reconfigurable a. 可重构的，可再构的open-loop control system 开环控制系统functional block diagram 功能框图feedback n. 反馈closed-loop control system 闭环控制系统single-input single-output (SISO) 单输入单输出continuous control 连续控制discontinuous control 断续控制periodically ad. 周期地sample n. 采样，取样，样品，试件；v. 采样discrete-data 离散数据的sampled-data 采样数据的relay feedback control system 继电反馈控制系统servomechanism n. 伺服机构，伺服系统，随动系统multiple-input multiple-output (MIMO) 多输入多输出modern control theory 现代控制理论trajectory n. 轨迹，轨道multivariable 多变量differential equation 微分方程Laplace transform 拉普拉氏变换frequency-response 频率响应root-locus 根轨迹time response 时域响应state variable 状态变量nth-order n阶matrix n. 矩阵mathematical model 数学模型eigenstructure n. 特征结构eigenvalue n. 特征值eigenvector n. 特征向量block-diagram 框图transfer function 传递函数negative feedback 负反馈error signal 误差信号operator n. 算子，算符，操作符，控制器complex parameter 复数参数frequency parameter 频率参数time domain 时域denominator n. 分母open-loop transfer function 开环传递函数forward transfer function 前向传递函数transient a. 暂态的，瞬态的，短暂的steady-state error 稳态误差controllability n. 可控性observability n. 可观性linear time-invariant system 线性时不变系统polynomial n.; a. 多项式（的）response n. 响应，答复，应答driving a. 驱动的real part 实部inverse transform 反变换pole n. 极，极点necessary condition 必要条件sufficient condition 充分条件imaginary axis 虚轴s plane s平面triangular a. 三角的conjugate n. 共轭值；a. 共轭的，共轭根的quadruplet n. 四件一套，四个一组numerator n. 分子performance n. 性能frequency response 频率响应passband n. 通带，频带dynamic performance 动态性能robust a. 强壮的，强健的，健全的，鲁棒的，坚固的performance index 性能指标modern control theory 现代控制理论synthesis n. 综合，合成Fourier transform 傅立叶变换，傅氏变换inverse Fourier transform 傅氏反变换definite integral 定积分analytical a. 解析的，分析的，分解的qualitatively ad. 定性地logarithmic a. 对数的rectangular coordinates 直角坐标logarithmic coordinates 对数坐标Bode plots 波特图phase angle 相角polar coordinates 极坐标Nyquist plots 奈奎斯特图dissipation n. 消耗energy-storage element 储能元件spurious a. 寄生的，杂散的，乱真的attenuate v. 衰减，减少，削弱semilog n. 半对数logarithm n. 对数asymptotic a. 渐近的decibel n. 分贝radian n. 弧度octave n. 八度，倍频程（八度）。
电气工程词汇voltage电压diode二极管current电流potentiometer电位器resistance电阻step-uptransformer升压变压器reactance电抗powersystem电力系统,电网impedance阻抗transmissionline输电线conductance电导breaker断路器inductance电感relay继电器inductor电感器demodulator解调器capacitance电容radiator散热器capacitive电容性的，电容的ventilation通风，换气，通风装置shuntcapacitor并联电容器alternatingrelay交流继电器shunt并联integratedcircuitamplifier集成电路放大器series串联transistoramplifier晶体管放大器seriescircuit串联电路terminal端子parallelcircuit并联电路amplifier/magnifier放大器conductor导线cablen电缆v架设电缆voltmeter电压表fuse保险丝熔断器ammeter电流表interface接口arc电弧amplitude振幅幅度波幅chargen电荷v充电，带电，起电digitalsignal数字信号dischargev放电coupling耦合bridge电桥intermittent周期的valve电子管dislocation错位deenergize断路malfunction故障dielectric不导电的/绝缘的medium介质generator发电机screen屏蔽motor电动机dampen阻尼audion三极管socket插孔groundplane接地层alternatingcurrent交流电流three-phasen三相inverting反相potentialdifference电位差outofphase异相activeelement有源元件self-inductor自感idealindependentsource理想独立电源mutual-inductor互感watthourmeter感应线圈ampere安培frequencychanger变频器coulomb库仑controlswitch控制开关joule焦耳selectorswitch选择开关resistor电阻器currenttransformer电流互感器charger充电器powertransformer电力变压器semiconductor半导体phasevoltage相电压absolutevalue绝对值constantvoltagesource恒定电压源operatingsupplyvoltage电源工作电压专业词汇Isolator刀闸(隔离开关)定串联电容补偿Susceptance电纳voltagestability电压稳定regulator稳压器anglestability功角稳定admittance导纳installedcapacity装机容量rectifier整流器transformersubstation变电站busbar母线degreeofcompensation补偿度analogsignal模拟信号linedropcompensation（LDC）线路补偿asynchronism异步器synchronization同步circuittheorems电路定理armature电枢superpositiontheorem叠加定理attenuate衰减substitutiontheorem替代定理steam-turbine-drivengenerator气轮发thevenin-NortonTheorem戴维宁定理电机electromagnetism电磁;电磁学turbinegenerator涡轮发电机low-frequencyamplifier低频放大器magneticflux磁通量low-frequencybypass低频旁路oscilloscope示波器voltagedistortion交流电压校准器oscillator震荡器SingleChipMicroprocessor(SCM)单片机multimeter万用表alternatingcurrent(AC)交流/交流电overlay叠加效果adjustablepressureconveyor调压输送ratedpower额定功率机poweramplifier功率放大器allowableloadimpedance允许的负载阻activevoltage有效电压抗voltagetocurrentconverter电压电流closedloopcontrol闭环控制变换器closedloopvoltagegain闭环电压增益transformersubstation变电站closed-loopgain死循环增益regulation调节clutch离合器/联轴器degreeofcompensation补偿度commutator/rectifier整流器highvoltageshuntreactor高抗cutoffvoltage临界电压reactivepowercompensation无功补偿cut-involtage闭合电压three-columntransformer三绕组变压器dielectricadj.不导电的/绝缘的double-columntransformer双绕组变压器dielectricpuncture击穿power-factor功率因数electricaldurability电寿命（万次）voltagegrade电压等级electromagneticresonance电磁感应no-loadcurrent空载电流electromotiveforce电动力/电动势impedance阻抗positivecharge正电荷positivesequenceimpedance正序阻抗negativecharge负电荷negativesequenceimpedance负序阻抗AutomaticGenerationControl(AGC)自动zerosequenceimpedance零序阻抗发电控制susceptance电纳PowerSystemStabilizator(PSS)电力系stator定子统稳定器highvoltage高压polyphase多相(的) fixedseriescapacitorcompensation固iron-loss铁损armaturecircuit电枢电路interface接口dynamicresponse动态响应demodulator解调器timeinvariantadj.时不变的balanceindicator交流平衡指示器self-inductor自感currentcalibrator交流电流校准器mutual-inductor互感resistancebox交流电阻箱polarity极性voltagedistortion交流电压校准器ventilation通风，换气，通风装置standardresistor交流标准电阻器low-frequencybypass低频旁路directcurrent（DC）直流电powerpool联合电力系统；联合电网eddycurrent涡流electromagnetism电磁;电磁学corridor通路core/shellforme铁心式/壳式inducedcurrent感生电流potentialdifference电位差laminatedcore叠片铁芯dualin-linepackages双列直插式组件left-handrule左手定则automaticcontrolsystem自动控制系统volt-amperecharacteristics伏安特性torquemotor力矩电动机simulationanalysis仿真分析amplifierusingdiscrete分离元件放大onemachine-infinitybussystem单机器无穷大系统potentiometer电位器ElectricalMachinery电机学voltage-currentcharacteristic伏安特AutomaticControlTheory自动控制理论性ElectrotechnicsPrincipleofCircuits topology拓扑电工学termocouple热电偶ElectricalDriveandControl电力传动与exitation激发;激励;干扰控制air-gap气隙brownout节约用电polyphasen.多相adj.多相的cathode阴板、负极breakdowntorque失步转矩cationexchanger阳离子交换器locked-rotortorque止转转矩circuitbreaker电路断路器nominalfrequency额定频率circuitdiagram电路图subtransmission二次输电coaxialcable同轴电缆hydro-generation水力发电coolingtower冷却塔feeder馈线;馈电电路intermediaterelay中间继电器thermalunit热力机组jumper跳线、跨接activepowerbalance有功功率平衡lightningarrestor避雷器load-frequencycontrol（LFC）负荷频率installedcapacity装机容量控制instrumentpanel仪表盘sychronouscondenser同步调相机tap-changingtransformer可调分接头变压器tapcoil跳闸线圈magneticaircircuitbreaker磁吹断路器automaticgenerationcontrol（AGC）自动发电控制circuitboard电路板i nstantaneouspower瞬时功率lossofexcitation励磁损失manualreject手动切换overheadline架空线plantloadfactor电厂负荷因数potentialtransformer电压互感器overspeedtrip超速跳闸pyod热电偶safepotential安全电压shield屏蔽层WORD格式singlebladeswitch单刀开关starconnectedsystem星形连接制"Y"staticstorage静态存储器stationcapacity发电厂容量step-downtransformer降压变压器substation变电站、子站subtransmission二次输电thermalpowerplant热力发电厂thumbrule安培右手定则trip跳闸、断开starconnectedsystem星形连接制"Y"A/Cadaptor电源适配器analogtodigital模拟/数字转换acinducedpolarizationinstrument交流激电仪adjustablepressureconveyor调压输送机allowableloadimpedance允许的负载阻抗chargeneutrality电中性区ChargeTerminationVoltage允电端电压/允电端接电压circuitdiagram电路板circuitswitching电路交换closed-loopvoltagegain死循环电压增益connectors插接器constantvoltagemodulation稳压调节currentattenuation电流减衰装置CurrentbyPhase(AMP)每相电流currentlimitativerange电流限制范围cutoffvoltage临界电压cut-involtage闭合电压DischargeTerminationVoltage放电端电压dropoutvoltage跌落电压eddycurrent涡电流electormagneticbrakingsytem电磁制动系统electricdipole电偶极子electricshielding电屏蔽FrequencyHopping跳频input-outputcontrolsystem(IOCS)输入输出控制系统offsetvoltage失调电压。
一．电气名词Electric items二．线路（母线、回路）Lines (Bus, circuits)三．设备Equipments四．保护、继电器Protection , relays五．电气仪表Electric instruments六．防雷Lightning protection七．接地Grounding, earthing八．室、所Room , Substation九．电修车间设备Equipments of electric repair十．材料Material十一．图名Drawings, diagrams十二．表头Tables十三．标准图词汇Terms from standard DWG一．电气名词Electric items交（直）流Alternating (direct) current短路电流Short-circuit current起始次暂态短路电流Initial subtransient short-circuit current 冲击电流Impulse current稳态短路电流Steady state short-circuit current临界电流Critical current切断电流Rupturing current熔断电流Blow-out current故障电流Fault current计算电流Calculating current极限有限电流Limit effective current过电流Over current逆电流Inverse current整定电流Setting current额定电流Rated current电流密度Current density短路电流最大有效值Maximum effective value of short-circuit current 高压High-voltage , High-tension低压Low-voltage , Low-tension计算电压Calculating voltage激磁电压Exciting voltage冲击电压Impulse voltage临界电压Critical voltage残留电压Residual voltage击穿电压Puncture voltage脉动电压Pulsating voltage供电电压Supply voltage电力电压Power voltage照明电压Lighting voltage灯丝电压Filament voltage额定电压Rated voltage电压损失V oltage loss过(欠)电压Over (under) voltage线路电压Line voltage电压降V oltage drop工作电压Working voltage一次电压Primary voltage二次电压Secondary voltage电源Electric source (power supply)自控电压Power supply for process control6kV控制闪光电源Flashing supply for 6kV control 工作电源Working power supply (electric source) 保安电源Emergency power supply (electric source) 直流稳压电源Stabilized D.C. source控制电源Control supply直流电源D.C. source交流电源A.C. source负荷计算Load calculation设备容量Installed capacity需要容量Electric demand功率因数Power factor安装高度Mounting height耐电压Breakdown voltage工频耐压High-voltage test with working frequency 表面闪络Surface flash-over直流泄漏D.C. leakage体电阻率V olume resistivity介质损失角Dielectric loss angle击穿强度Puncture intensity电压等级V oltage grade比重Specific gravity性能Feature相序Phase sequence瞬时Instantaneous倾角Angle of inclination跨度Span正极Positive pole负极Negative pole截面(积) Cross section area辅助电源Auxiliary source遮断容量Interrupting capacity载流量Current-carrying capacity校正系数Correction factor连续负荷Continuous load长期载流量Continuous capacity长时间额定值Longtime rating电动机堵转电流Locked-rotor motor current限定负荷Limited load电感负荷Inductive load感应电流Induced current二．线路（母线、回路）Lines (Bus , circuits)母线Bus-bar合闸电源母线Closing power source bus闪光母线Flashing-bus备用母线Spare bus装在支柱上的插接式母线Post-supported plug-in bus way装在吊钩上的插接式母线Hook-supported plug-in bus way 装在支架上的插接式母线Bracket-supported plug-in bus way 小母线Miniature bus电源小母线Power supply miniature bus操作小母线Operating miniature bus事故信号小母线Miniature bus for fault signal闪光小母线Flashing miniature bus主母线Main bus直流主母线D.C. main bus预告母线Prewarning bus干线Main line照明干线Lighting main line接地干线Grounding main line插座干线Receptacle main line电压干线V oltage main line端子出线Terminal outgoing中性线Neutral支线Branch-line引入线Lead-in电气线路Electric circuit交流配电线路A.C. distribution circuit直流配电线路D.C. distribution circuit事故照明线路Emergency lighting circuit控制线路Control circuit接地或接零线路Grounding or neutralizing circuit信号线路Signal circuit有接地极的接地线路网Grounding with grounding electrodes定子绕组测温回路Temperature measuring circuit for stator winding 接地信号回路Grounding signal circuit闪光信号回路Flashing-signal circuit开阀回路Circuit for opening valve关（闭）阀回路Circuit for closing valve开度计回路Circuit for opening meter电流测量回路Current-measuring circuit差动保护回路Differental protective circuit过流保护回路Over-current protective circuit合闸回路Closing circuit停车延时回路Delayed shutdown circuit掉闸回路Trip circuit激磁回路Exciting circuit备用回路Spare circuit主回路Main circuit馈路Feeder circuit现有回路Existing circuit单线回路Single-wire circuit接地回路Earthed circuit有电压的电路Live circuit三．设备Equipments高压开关柜H.V. switchgear动力配电箱Power distribution cabinet电源配电箱Source distribution cabinet直流配电屏D.C. switchboard (distribution panel)交流低压配电屏A.C.L.V. switchboard (distribution panel)静电电容器柜Static capacitor cabinet多种电源插销箱Receptacle box for miscellaneous power supplies控制箱Control cabinet照明配电箱Lighting (distribution panel)连接箱Junction box出线盒Outlet box开关箱Switch box控制台Console分段屏Sectionalizing panel进线屏Incoming line panel电控箱Electric control panel边屏Side board端子箱Terminal box供电盘Power supply box瓶车箱Synchronizing cabinet感应调压器专用变压器高压柜Special transformer H.V. cabinet for induction voltage regulator电压互感器柜Potential transformer cabinet信号屏Signal panel浮充屏Floating panel蓄电池屏Battery panel充电屏Charging panel母线联络柜Bus tie cabinet转换开关Transfer switch电压表转换开关V oltmeter change-over switch铁壳开关Metal-clad switch (Iron-clad switch)管式熔断器Cartridge fuse真空断路器Vacuum circuit breaker (V.C.B.)自动开关Automatic switch高压负荷开关H.V. load break switch三极高压断路器3-pole HV circuit-breaker刀开关Knife switch转换开关Transfer switch双极铁壳开关2-pole iron-clad switch风扇变速开关Fan speed regulator switch密闭照明灯开关Hermetic lighting switch防爆照明灯开关Explosion-proof lighting switch行程开关Limit switch高压隔离开关H.V. disconnecting switch明装单极板钮开关Surface-mounted single-pole toggle switch 暗装单极板钮开关Flush-mounted single-pole toggle switch 三路开关Three-way switch气密式组合开关Hermetic packet type switch防护式开关Guard type switch联锁开关Interlock switch操作方式选择开关Selecting switch for types of operation控制电源开关Switch for control supply主令开关Master switch (controller)多切点切换开关Multi-point change-over switch按钮Push-button控制按钮Control push-button防爆控制按钮Explosion-proof control push-button事故紧急按钮Emergency stopping push-button起动按钮Starting push-button停止按钮Stopping push-button现场按钮Push-button in field挡板damper音响解除按钮Push-button for sound release起动器Starter磁力起动器Magnetic starter综合起动器Combination starter (Magnetic starter combination) 电力变压器Power transformer调压变压器V oltage regulating transformer电压互感器Potential transformer电流互感器Current transformer照明变压器Lighting transformer三相三绕组变压器3-phase tertiary winding transformer高压试验变压器H.V. testing transformer局部照明变压器Local lighting transformer多量程仪用电流互感器Multi-range current transformer for measurement降压变压器Step-down transformer伺服电动机Servo-motor双电压电动机Dual-voltage motor感应电动机Induction motor交流异步电动机A.C. asynchronous motor同步电动机synchronous motor三相滑环感应电动机3-phase slip-ring induction motor三相鼠笼感应电动机3-phase squirrel-cage induction motor绕线式电动机Wound-rotor induction motor反应式电动机Reaction motor柴油发电机Diesel generator励磁发电机Excitation generator明装双极插座Surface-mounted 2-pole receptacle暗装双极插座Flush-mounted 2-pole receptacle双极带接地插座2-pole receptacle with grounding contact单相三孔明插座Surface-mounted single phase 3-pole receptacle防护式明装三相四孔插座Guard type surface-mounted 3-phase 4-pole receptacle 配照型灯Standard dome lighting fitting搪瓷深照型灯Enameled high bay lighting fitting防水防尘灯Water and dust proof lighting fitting安全灯Safety lighting fitting隔爆灯Explosion-proof lighting fitting弯灯Goose-neck light壁灯Wall light高压水银灯High pressure mercury vapor lighting fitting 投光灯Flood-light (projection light)信号灯Signal lamp天棚灯Ceiling-mounted lighting fitting局部照明灯Local lighting fitting灯座Lamp holder事故照明灯Emergency lighting fitting高压水银荧光灯H.P. mercury fluorescent lighting fitting 广照型工厂灯Wide lit type industrial fitting深照型灯具High bay lighting fitting白炽灯具Incandescent lamp (bulb)圆球型灯Globe lamp嵌入式荧光灯flush type fluorescent lighting fitting红色障碍灯Red obstruction lamp for aviation厂区道路照明灯Street lighting in plant area路灯Street lamp视孔灯Inspection hole lamp立杆弯灯goose-neck post lamp , pole lamp 模拟报警信号Semigraph and alarm signal 自整角机Selsyn励磁机Exciter显示器Display电位器Potentiometer内电阻Internal resistance固定电阻（器）Fixed resistance脱扣Release , trip分励Shunt trip特殊失压脱扣器Special no-voltage release “或”开关放大器“Or” switch amplifier制动器Brake电容Capacitor整流器Rectifier镇流器Chock分流器Shunt油变阻器Oil immersed rheostat频敏电阻器Frequency sensitive rheostat 滑线变阻器Sliding rheostat蜂鸣器Buzzer电机加热器Space heater (for motor)空气断路器电机操作机构Motor operating mechanism for air circuit-breaker 可控硅励磁装置Silicon controlled rectifier excitation device保护装置Protective device (element)闪光装置Flashing device接闪装置（避雷器）Lightning arrester断相保护Phase failure protection四．保护、继电器Protection , relays信号继电器Signal relay过电流继电器Over-current relay电压继电器V oltage relay时间继电器Time relay中间继电器Auxiliary relay热继电器Thermal relay温度继电器Temperature relay瓦斯继电器Gas relay控制电源中间继电器Auxiliary relay for control supply自动操作继电器Relay for auto-operation低电压继电器Under-voltage relay过电压继电器Over-voltage relay联锁继电器Interlock relay冲击继电器Impact relay合闸位置继电器Close position relay逆流继电器Reverse-current relay差流继电器Differential current relay差动继电器Differential relay电流继电器Current relay功率继电器Power relay接地继电器Earthing relay重合闸继电器Reclosing relay同步继电器Synchronous relay速动继电器Quick acting relay定时限继电器Definite time relay光电继电器Photoelectric relay电子继电器Electronic relay电磁式继电器Electromagnetic relay电动式继电器Electrodynamic relay气压继电器Gas-pressure relay继电器常开触点Relay N.O. contact继电器常闭触点Relay N.C. contact继电器保护触点（常开）Relay holding contact (N.O.)能自动返回的常闭按钮触点Self-return button with N.C. contact 模拟信号触点Contact for semigraph signal强励磁接点Shock excitation contact电感线圈Induction coil电流线圈Current coil脱扣线圈Trip coil合闸线圈Close coil释放线圈Releasing coil掉闸线圈Tripping coil予告信号Prewarning signal掉闸回路断线信号Breakage signal of trip circuit断路器事故掉闸信号Fault trip signal of breaker掉闸音响信号Tripping audible signal重瓦斯预告信号Heavy gas prewarning signal温度预告信号Temperature prewarning signal手动、自动操作时事故信号Fault signal in manual/automatic operation 保护掉闸Protective trip控制掉闸Control trip手动跳闸Manual trip变电所紧急停车Emergency shutdown at substation工艺故障Fault in process励磁故障Fault in excitation工作电源失电报警No-voltage alarm of working electric source工作电源分合闸On and off of working electric source工作电源投入Throw-in of working electric source保安电源送电supply of emergency electric source运转指示Indicating of operation投入指示Indicating of throw-in同步指示Indicating of synchronism延时停车Delayed shutdown电源切除Switch off the power supply速断及过流断通Instantaneous trip and over-current off/on自保持Self-holding自锁Self-lock联锁Interlocking绝缘监视Insulation supervision电压监视V oltage supervision联锁解除Release of interlock工作、保安电源切换Transfer of working and emergency power supply发电机与工作母线并车Synchronization of generator to working bus重瓦斯保护Heavy gas protection开或闭超扭矩保护Over-torque protection during opening and closing valve 电机起动顺序Sequence of motor starting铭牌框注字Name plate denotation (inscription)五．电气仪表Electric instruments电流表Ammeter电压表V oltmeter三相三线有功电度表Three-phase three-wire kilowatt-hour meter , kWh meter单相电度表Single-phase kilowatt-hour meter三相无功电度表Three-phase kilovar-hour meter有功功率表Active power meter , kilowatt meter无功功率表Reactive power meter , kilovar meter三相瓦特表(功率表) Three-phase watt meter功率因数表Power factor meter频率表Frequency meter验电流器Galvanoscope欧姆表Ohmmeter相位表Phase meter转速表Tachometer波长表Wave-length meter三相四线制标准电度表3-phase 4-wire standard watthour-meter 过载电流表Overload ammeter低功率因数瓦特表Low power-factor wattmeter交直流两用钳型电流表A.C./D.C. multi-purpose tongtester兆欧表Megger , Megohmmeter万用表Avometer微安表Microammeter毫安表Milliammeter各种测量仪表Various kind of measuring instruments接地电阻测量仪Earthing resistance tester真空管电压表Vacuum tube voltmeter电动秒表Electric second-meter六．防雷Lightning protection避雷装置Lightning protector避雷针Lightning rod避雷带Strap type lightning protector避雷网Network of lightning protector避雷针支架Lightning rod support避雷针尖Tip of lightning rod避雷针拉铁Brace for lightning rod避雷器Lightning arrester , surge discharger 球型避雷器Spherical arrester管形避雷器Tubular arrester阀形避雷器Auto-valve arrester低压避雷器Low voltage arrester角形避雷器Horn arrester多隙避雷器Multigap arrester铝避雷器Aluminum cell arrester氧化膜避雷器Oxide film arrester击穿保险器Puncture lightning arrester雷击Lightning stroke直接雷击Direct lightning stroke感应雷击Induction lightning stroke雷电日Thunderbolt days雷电或然率Lightning and thunder probability 触电Electric shock静电感应Electrostatic induction七．接地Grounding , earthing接地保护Ground protection , earth protection 防雷接地Grounding for lightning保护接地Protective earthing人工接地Artificial grounding工作接地Working grounding , working earthing 重复接地Multiple earthing屏蔽接地Screen earthing , shielding ground中性点接地Neutral point grounded接地系统Grounding system , earthing system 接地故障Ground fault , earth fault单相接地Single phase earthing母线接地Bus ground接地装置Grounding device , earthing device引下线Down-lead , down conductor引下线固定Clamping plate of support for fixing 支架夹板Down lead引下线固定支脚Support for fixing down lead接地线Ground connector接地干线Ground(ing) main , (bus)接地网Grounding network , earthing network接地极Earth electrode (pole)接地电阻Earth resistance接地电路Earth (ground) circuit连接条Connecting strip断接卡Connecting clamp八．室、所Room , Substation贮藏室Storage套间Compartment蓄电池室Battery room控制室Control room配电室Distribution room维修间Repair room变电所Substation高压配电室H.V. distribution room休息室Rest room九．电修车间设备Equipments of electric repair 砂轮机Emery wheel grinder台钻Bench drilling machine交流电焊机A.C. welding machine移动式空气压缩机Portable air compressor手电钻Electric hand drill单速手摇绕线机Single speed hand winding machine导线钳压器Wire jointing press-clamp油压千斤顶Hydraulic jack电吹尘器Electric dust cleaner存放柜Store chest高压试验变压器H.V. testing transformer泄漏试验变压器Leakage testing set大电流发生器Strong current generator油浸自冷感应调压器Oil-immersed self-cooled induction voltage regulator 多量程仪用电流互感器Multi-range current transformer for measurement 仪用电感互感器Instrumental voltage transformer单相自耦变压器Single-phase auto-transformer三相自耦变压器3-phase auto-transformer硅整流器Silicon rectifier仪表试验台Testing stand for instrument接触器，继电器试验台Relay and contactor testing stand慢扫描示波器Slow scanning oscillograph交流电子稳压器A.C. electronic voltage stabilizer携带式交流电桥Portable A.C. electric bridge接地电阻测量仪Earthing resistance tester电缆故障探伤仪Cable fault detector直流单臂电桥D.C. single-arm electric bridge , Wheatstone bridge 十．材料Material绝缘包布Insulating tape填料Filler , packing绝缘膏Insulating compound电缆膏Cable compound防腐油Anti-corrosive oil沥青漆Bituminous varnish绝缘漆Insulating varnish瓷漆Enamel varnish有色金属Non-ferrous metal黑色金属ferrous metal白金属White metal云母Mica环氧树脂Epoxy resin聚氯乙烯Polyvinyl chloride , PVC蜡Wax滑石粉Talc powder电胶木Bakelite聚丙烯外壳Polyacrylic cover耐油橡胶管Oil-proof rubber tubes 接地铜线Grounding copper wire 垫圈Pad塑料绝缘线Plastics insulated wire 橡套电缆Rubber sheathed cable 中间接头Splice填充剂Filling agent绝缘电线Insulated wire移动软电缆Movable flexible cable 补偿导线Extension wire套管Bushing母线槽Busway悬索Cable suspension滑触线Trolley conductor镀锌煤气管Galvanized gas pipe 镀锌角钢Galvanized steel angle 镀锌扁钢Galvanized steel strap钢丝绳Steel wire rope电笛Siren电磁阀Electromagnetic valve连接片Connecting link切换片Transfering link端子排Terminal board半导体二极管Semiconductor diode开度计Opening meter逻辑元件Logical element接线盒Junction box仪表槽板Instrument trunking电缆吊架Cable hanger出线套Outgoing line sleeve十一．图名Drawings , diagrams电气图纸目录Contents of electric drawings电力系统图Electric power system diagram照明系统图Lighting system diagram电力平面布置图Electric power layout plan照明平面布置图Lighting layout plan单线图One line diagram控制箱面部布置图Surface arrangement of control box 背部接线图Back wiring (diagram)外部接线图External (outside) wiring diagram内部接线图Internal (inside) wiring diagram控制原理图Principle control diagram原理图Schematic diagram展开图Developed diagram电气标准图Electric standard drawing电气施工图Electric working drawing复用图Reproducibles (drawing)电缆联系图Cable hook-up diagram转换开关接点图Contact diagram of transfer switch箱侧视图Side view of box正视图Front view , facade背视图Back view剖面图Section参考图Reference drawing电缆敷设图Cable laying diagram箱内框架布置图Arrangement of frames inside the cabinet控制箱台面展开图Surface developed diagram of console出线端子示意图Schematic diagram of terminal outgoing lines 端子接线图Diagram of terminal connections电气管线表List of wire , cable and conduits设备材料表List of equipment and materials十二．表头Tables电力系统图Power system diagram引入线Lead in保护设备Protective device型号Type额定值Rating整定值Setting主启动设备回路Circuit to starting device导线型号、芯数、截面及管径Conductor type , cores , section & diameter of conduit 线长Wire length管长Conduit length启动设备Starting device型号规格Type , specification保护元件Protective element计量装置Calculating device用电设备主回路Main circuit of electric equipment控制回路Control circuit控制装置Control device用电设备Electric equipment设备容量Consumer capacity生产设备Production equipment位号No. of location名称Name备注Remarks引入线Feed in配电箱Distribution cabinet型号及编号Type and No.开关型号Switch type保护装置Protective device回路编号Circuit No.相别Phase灯数Number of lamps插座数Number of receptacles电缆编号No. of line起点Starting终点Ending母线截面Section of bus零母线Neutral bus屏编号Panel No.型号及方案号Type and variant No.控制原理图号Principle control diagram工艺位号Process item No.十三．标准图词汇Terms from standard DWG电工系统图图形符号Graphic symbols for electric system交流电的相别A.C. phase sequence直流电的正负极D.C. positive and negative poles有中性点引出线的星形连接的三相绕组Star-connected three phase windings with neutral outlet开口三角形连接的三相绕组3-phase winding with open delta connection互相连接的导线Cross connection of wires不连接的跨越导线Crossing wires not in contact with each other 可拆卸的电气连接Removable connection电缆终端头Pothead of cable or cable end自耦变压器Auto-transformer感应调压器Induction voltage regulator凸极同步电动机Salient pole synchronous motor带接换装置的蓄电池组Accumulator battery with tap-changers 空气断路器Air circuit-breaker保持触点Holding contact热元件Thermal element自动复位的操作开关Spring-return operating switch插接器Plug-in connector电喇叭Horn电炉Electric furnace分流器Shunt可控硅整流箱屏Silicon controlled rectifier box panel直流配电屏D.C. distributing panel磁力起动器组Magnetic starter group自动开关箱Automatic switch box行程开关Limit switch局部灯Local lighting fitting荧光灯列Series fluorescent lighting fitting防护式灯开关Protective switch导线引上Conductors turning up导线引下Conductors turning down导线由上引来Conductors turning from above导线由下引来Conductors turning from below电缆沟Cable trench调压器V oltage regulator隔离变压器Isolating transformer击穿保护器Puncturing safety device晶体管Transisorized diode地坪Grade level电缆与水管平行Cable running parallel to a water supply pipe 电缆与热力管道交叉敷设Cable running across heat pipeline 车道Drive way电缆穿管与管道交叉Cable protective pipe across a pipeline 双(单)侧支架电缆沟Trench with rack on both sides (one side) 室外地坪Outdoor grade跨接线Jumper金属软管Flexible metal tube过渡接头Adapter。
电气工程词汇voltage 电压current 电流resistance 电阻reactance 电抗impedance 阻抗conductance 电导inductance 电感inductor 电感器capacitance 电容capacitive 电容性的，电容的shunt capacitor 并联电容器shunt 并联series 串联series circuit 串联电路parallel circuit 并联电路conductor 导线voltmeter 电压表ammeter 电流表arc 电弧charge n 电荷v充电，带电，起电discharge v 放电bridge 电桥valve 电子管deenergize 断路dielectric 不导电的/绝缘的generator 发电机motor 电动机audion 三极管diode 二极管potentiometer 电位器step-up transformer 升压变压器power system 电力系统,电网transmission line 输电线breaker 断路器relay 继电器demodulator 解调器radiator 散热器ventilation 通风，换气，通风装置alternating relay 交流继电器integrated circuit amplifier 集成电路放大器transistor amplifier 晶体管放大器terminal 端子amplifier/magnifier 放大器cable n 电缆v架设电缆fuse 保险丝熔断器interface 接口amplitude 振幅幅度波幅digital signal 数字信号coupling 耦合intermittent 周期的dislocation 错位malfunction 故障medium 介质screen 屏蔽dampen 阻尼socket 插孔ground plane 接地层three-phasen 三相potential difference 电位差active element 有源元件ideal independent source 理想独立电源watt hour meter 感应线圈frequency changer 变频器control switch 控制开关selector switch 选择开关current transformer 电流互感器power transformer 电力变压器phase voltage 相电压constant voltage source 恒定电压源alternating current 交流电流inverting 反相out of phase 异相self-inductor 自感mutual-inductor 互感ampere 安培coulomb 库仑joule 焦耳resistor 电阻器charger 充电器semiconductor 半导体absolute value 绝对值operating supply voltage 电源工作电压专业词汇Isolator 刀闸(隔离开关) Susceptance 电纳regulator 稳压器admittance 导纳rectifier 整流器busbar 母线analog signal 模拟信号asynchronism 异步synchronization 同步armature 电枢attenuate 衰减steam-turbine-driven generator 气轮发电机turbine generator 涡轮发电机magnetic flux 磁通量oscilloscope 示波器oscillator 震荡器multimeter 万用表overlay 叠加效果rated power 额定功率power amplifier 功率放大器active voltage 有效电压voltage to current converter 电压电流变换器transformer substation变电站regulation 调节degree of compensation补偿度high voltage shunt reactor高抗reactive power compensation无功补偿three-column transformer三绕组变压器double-column transformer双绕组变压器power-factor 功率因数voltage grade 电压等级no-load current 空载电流impedance 阻抗positive sequence impedance正序阻抗negative sequence impedance 负序阻抗zero sequence impedance零序阻抗susceptance 电纳stator 定子high voltage 高压fixed series capacitor compensation固定串联电容补偿voltage stability 电压稳定angle stability 功角稳定installed capacity 装机容量transformer substation 变电站degree of compensation 补偿度line drop compensation（LDC）线路补偿器circuit theorems 电路定理superposition theorem 叠加定理substitution theorem 替代定理thevenin-Norton Theorem 戴维宁定理electromagnetism 电磁; 电磁学low-frequency amplifier 低频放大器low-frequency bypass 低频旁路voltage distortion 交流电压校准器Single Chip Microprocessor(SCM)单片机alternating current(AC) 交流/交流电adjustable pressure conveyor 调压输送机allowable load impedance 允许的负载阻抗closed loop control 闭环控制closed loop voltage gain 闭环电压增益closed-loop gain 死循环增益clutch 离合器/联轴器commutator/rectifier 整流器cut off voltage 临界电压cut-in voltage 闭合电压dielectric adj. 不导电的/绝缘的dielectric puncture 击穿electrical durability 电寿命（万次）electromagnetic resonance 电磁感应electromotive force 电动力/电动势positive charge 正电荷negative charge 负电荷Automatic Generation Control(AGC) 自动发电控制Power System Stabilizator(PSS) 电力系统稳定器polyphase 多相(的)iron-loss 铁损armature circuit 电枢电路dynamic response 动态响应time invariant adj.时不变的self-inductor 自感mutual-inductor 互感polarity 极性ventilation 通风，换气，通风装置interface 接口demodulator 解调器balance indicator 交流平衡指示器current calibrator 交流电流校准器resistance box 交流电阻箱voltage distortion 交流电压校准器standard resistor 交流标准电阻器low-frequency bypass 低频旁路power pool 联合电力系统；联合电网electromagnetism 电磁; 电磁学core/shell forme 铁心式/壳式potential difference 电位差dual in-line packages 双列直插式组件automatic control system 自动控制系统torque motor 力矩电动机amplifier using discrete 分离元件放大器potentiometer 电位器voltage-current characteristic 伏安特性topology 拓扑termocouple 热电偶exitation 激发;激励;干扰air-gap 气隙polyphase n.多相adj. 多相的breakdown torque 失步转矩locked-rotor torque 止转转矩nominal frequency 额定频率subtransmission 二次输电hydro-generation 水力发电feeder 馈线;馈电电路thermal unit 热力机组active power balance 有功功率平衡load-frequency control（LFC）负荷频率控制sychronous condenser 同步调相机tap-changing transformer 可调分接头变压器tap coil 跳闸线圈magnetic air circuit breaker 磁吹断路器automatic generation control （AGC）自动发电控制circuit board 电路板direct current（DC）直流电eddy current 涡流corridor 通路induced current 感生电流laminated core 叠片铁芯left-hand rule 左手定则volt-ampere characteristics 伏安特性simulation analysis 仿真分析one machine - infinity bus system 单机无穷大系统Electrical Machinery电机学Automatic Control Theory自动控制理论Electrotechnics Principle of Circuits 电工学Electrical Drive and Control电力传动与控制brownout 节约用电cathode 阴板、负极cation exchanger 阳离子交换器circuit breaker 电路断路器circuit diagram 电路图coaxial cable 同轴电缆cooling tower 冷却塔intermediate relay 中间继电器jumper 跳线、跨接lightning arrestor 避雷器installed capacity 装机容量instrument panel 仪表盘instantaneous power 瞬时功率loss of excitation 励磁损失manual reject 手动切换overhead line 架空线plant load factor 电厂负荷因数potential transformer电压互感器overspeed trip 超速跳闸pyod 热电偶safe potential 安全电压shield 屏蔽层single blade switch单刀开关star connected system星形连接制"Y" static storage 静态存储器station capacity 发电厂容量step-down transformer降压变压器substation 变电站、子站subtransmission 二次输电thermal power plant 热力发电厂thumb rule 安培右手定则trip 跳闸、断开star connected system星形连接制"Y"A/C adaptor 电源适配器analog to digital 模拟/数字转换ac induced polarization instrument 交流激电仪adjustable pressure conveyor 调压输送机allowable load impedance 允许的负载阻抗charge neutrality 电中性区Charge Termination Voltage 允电端电压/允电端接电压circuit diagram 电路板circuit switching 电路交换closed-loop voltage gain 死循环电压增益connectors 插接器constant voltage modulation 稳压调节current attenuation 电流减衰装置Current by Phase (AMP) 每相电流current limitative range 电流限制范围cut off voltage 临界电压cut-in voltage 闭合电压Discharge Termination Voltage 放电端电压dropout voltage 跌落电压eddy current 涡电流electormagnetic braking sytem 电磁制动系统electric dipole 电偶极子electric shielding 电屏蔽Frequency Hopping 跳频input-output control system (IOCS) 输入输出控制系统offset voltage 失调电压。
电⽓英语翻译专业词汇电⽓⼯程词汇voltage 电压current 电流resistance 电阻reactance 电抗impedance 阻抗conductance 电导inductance 电感inductor 电感器capacitance 电容capacitive 电容性的，电容的shunt capacitor 并联电容器shunt 并联series 串联series circuit 串联电路parallel circuit 并联电路conductor 导线voltmeter 电压表ammeter 电流表arc 电弧charge n 电荷v充电，带电，起电discharge v 放电bridge 电桥valve 电⼦管deenergize 断路dielectric 不导电的/绝缘的generator 发电机motor 电动机audion 三极管diode ⼆极管potentiometer 电位器step-up transformer 升压变压器power system 电⼒系统,电⽹transmission line 输电线breaker 断路器relay 继电器demodulator 解调器radiator 散热器ventilation 通风，换⽓，通风装置alternating relay 交流继电器integrated circuit amplifier 集成电路放⼤器transistor amplifier 晶体管放⼤器terminal 端⼦amplifier/magnifier 放⼤器cable n 电缆v架设电缆fuse 保险丝熔断器interface 接⼝amplitude 振幅幅度波幅digital signal 数字信号coupling 耦合intermittent 周期的dislocation 错位malfunction 故障medium 介质screen 屏蔽dampen 阻尼socket 插孔ground plane 接地层three-phasen 三相potential difference 电位差active element 有源元件ideal independent source 理想独⽴电源watt hour meter 感应线圈frequency changer 变频器control switch 控制开关selector switch 选择开关current transformer 电流互感器power transformer 电⼒变压器phase voltage 相电压constant voltage source 恒定电压源alternating current 交流电流inverting 反相out of phase 异相self-inductor ⾃感mutual-inductor 互感ampere 安培coulomb 库仑joule 焦⽿resistor 电阻器charger 充电器semiconductor 半导体absolute value 绝对值operating supply voltage 电源⼯作电压专业词汇Isolator ⼑闸(隔离开关) Susceptance 电纳regulator 稳压器admittance 导纳rectifier 整流器busbar 母线analog signal 模拟信号asynchronism 异步synchronization 同步armature 电枢attenuate 衰减steam-turbine-driven generator ⽓轮发电机turbine generator 涡轮发电机magnetic flux 磁通量oscilloscope ⽰波器oscillator 震荡器multimeter 万⽤表overlay 叠加效果rated power 额定功率power amplifier 功率放⼤器active voltage 有效电压voltage to current converter 电压电流变换器transformer substation变电站regulation 调节degree of compensation补偿度high voltage shunt reactor⾼抗reactive power compensation⽆功补偿three-column transformer三绕组变压器double-column transformer双绕组变压器power-factor 功率因数voltage grade 电压等级no-load current 空载电流impedance 阻抗positive sequence impedance正序阻抗negative sequence impedance 负序阻抗zero sequence impedance零序阻抗susceptance 电纳stator 定⼦high voltage ⾼压fixed series capacitor compensation固定串联电容补偿voltage stability 电压稳定angle stability 功⾓稳定installed capacity 装机容量transformer substation 变电站degree of compensation 补偿度line drop compensation（LDC）线路补偿器circuit theorems 电路定理superposition theorem 叠加定理substitution theorem 替代定理thevenin-Norton Theorem 戴维宁定理electromagnetism 电磁; 电磁学low-frequency amplifier 低频放⼤器low-frequency bypass 低频旁路voltage distortion 交流电压校准器Single Chip Microprocessor(SCM)单⽚机alternating current(AC) 交流/交流电adjustable pressure conveyor 调压输送机allowable load impedance 允许的负载阻抗closed loop control 闭环控制closed loop voltage gain 闭环电压增益closed-loop gain 死循环增益clutch 离合器/联轴器commutator/rectifier 整流器cut off voltage 临界电压cut-in voltage 闭合电压dielectric adj. 不导电的/绝缘的dielectric puncture 击穿electrical durability 电寿命（万次）electromagnetic resonance 电磁感应electromotive force 电动⼒/电动势positive charge 正电荷negative charge 负电荷Automatic Generation Control(AGC) ⾃动发电控制Power System Stabilizator(PSS) 电⼒系统稳定器polyphase 多相(的)iron-loss 铁损armature circuit 电枢电路dynamic response 动态响应time invariant adj.时不变的self-inductor ⾃感mutual-inductor 互感polarity 极性ventilation 通风，换⽓，通风装置interface 接⼝demodulator 解调器balance indicator 交流平衡指⽰器current calibrator 交流电流校准器resistance box 交流电阻箱voltage distortion 交流电压校准器standard resistor 交流标准电阻器low-frequency bypass 低频旁路power pool 联合电⼒系统；联合电⽹electromagnetism 电磁; 电磁学core/shell forme 铁⼼式/壳式potential difference 电位差dual in-line packages 双列直插式组件automatic control system ⾃动控制系统torque motor ⼒矩电动机amplifier using discrete 分离元件放⼤器potentiometer 电位器voltage-current characteristic 伏安特性topology 拓扑termocouple 热电偶exitation 激发;激励;⼲扰air-gap ⽓隙polyphase n.多相adj. 多相的breakdown torque 失步转矩locked-rotor torque ⽌转转矩nominal frequency 额定频率subtransmission ⼆次输电hydro-generation ⽔⼒发电feeder 馈线;馈电电路thermal unit 热⼒机组active power balance 有功功率平衡load-frequency control（LFC）负荷频率控制sychronous condenser 同步调相机tap-changing transformer 可调分接头变压器tap coil 跳闸线圈magnetic air circuit breaker 磁吹断路器automatic generation control （AGC）⾃动发电控制circuit board 电路板direct current（DC）直流电eddy current 涡流corridor 通路induced current 感⽣电流laminated core 叠⽚铁芯left-hand rule 左⼿定则volt-ampere characteristics 伏安特性simulation analysis 仿真分析one machine - infinity bus system 单机⽆穷⼤系统Electrical Machinery电机学Automatic Control Theory⾃动控制理论Electrotechnics Principle of Circuits 电⼯学Electrical Drive and Control电⼒传动与控制brownout 节约⽤电cathode 阴板、负极cation exchanger 阳离⼦交换器circuit breaker 电路断路器circuit diagram 电路图coaxial cable 同轴电缆cooling tower 冷却塔intermediate relay 中间继电器jumper 跳线、跨接lightning arrestor 避雷器installed capacity 装机容量instrument panel 仪表盘instantaneous power 瞬时功率loss of excitation 励磁损失manual reject ⼿动切换overhead line 架空线plant load factor 电⼚负荷因数potential transformer电压互感器overspeed trip 超速跳闸pyod 热电偶safe potential 安全电压shield 屏蔽层single blade switch单⼑开关star connected system星形连接制"Y" static storage 静态存储器station capacity 发电⼚容量step-down transformer降压变压器substation 变电站、⼦站subtransmission ⼆次输电thermal power plant 热⼒发电⼚thumb rule 安培右⼿定则trip 跳闸、断开star connected system星形连接制"Y"A/C adaptor 电源适配器analog to digital 模拟/数字转换ac induced polarization instrument 交流激电仪adjustable pressure conveyor 调压输送机allowable load impedance 允许的负载阻抗charge neutrality 电中性区Charge Termination Voltage 允电端电压/允电端接电压circuit diagram 电路板circuit switching 电路交换closed-loop voltage gain 死循环电压增益connectors 插接器constant voltage modulation 稳压调节current attenuation 电流减衰装置Current by Phase (AMP) 每相电流current limitative range 电流限制范围cut off voltage 临界电压cut-in voltage 闭合电压Discharge Termination Voltage 放电端电压dropout voltage 跌落电压eddy current 涡电流electormagnetic braking sytem 电磁制动系统electric dipole 电偶极⼦electric shielding 电屏蔽Frequency Hopping 跳频input-output control system (IOCS) 输⼊输出控制系统offset voltage 失调电压。
电气专业英语词汇,英语单词带翻译
1 基本概念
1.1 保安性
fail-safe
为防止产品本身的危险故障而设计的性能
1.2 正常状态
normal condition
所有用于防止危险的设施均无损坏的状态
1.3 电气事故
electric accident
由电流电磁场雷电静电和某些电路故障等直接或间接造成建筑设施电
气设备毁坏人动物伤亡以及引起火灾和爆炸等后果的事件
1.4 触电
电击
electric shock
电流通过人体或动物体而引起的病理生理效应
1.5 电磁场伤害
injury due to electromagnetic field
人体在电磁场作用下吸收能量受到的伤害
1.6 破坏性放电
介质击穿
disruptive discharge dielectric breakdown
固体液体气体介质及其组合介质在高电压作用下介质强度丧失的现象
破坏性放电时电极间的电压迅速下降到零或接近于零
1.7 短路
short circuit
通过比较小的电阻或阻抗偶然地或有意地对一个电路中在正常情况下处于不同电压下的两点或几点之间进行的连接
1.8 绝缘故障
insulation fault
绝缘电阻的不正常下降
1.9 接地故障
earth fault
由于导体与地连接或对地绝缘电阻变得小于规定值而引起的故障
1.10 过电流
overcurrent
超过额定电流的电流
1.11 过电压
overvoltage
超过额定电压的电压
1.12 过负载
overload
超过额定负载的负载
1.13 导电部分
conductive part
能导电但不一定承载工作电流的部分
1.14 带电部分
live part
正常使用时被通电的导体或导电部分它包括中性导体但按惯例不包括
保护中性导体(PEN 导体)
注此术语不一定意味着触电危险
1.15 外露导电部分
exposed conductive part
电气设备能被触及的导电部分它在正常时不带电但在故障情况下可能带电注在故障情况下通过外露导电部分才能带电的电气设备的导电部分不被认为是外露导电部分
1.16 外部导电部分
extraneous conductive part
不是电气装置组成部分且易引入电位(通常是地电位)的导电部分
1.17 同时可触及部分
simultaneously accessible parts
人能同时触及的导体或导电部分或在某些场所中动物能同时触及的导体或导电部分
注同时可触及部分可以是
. 带电部分
. 外露导电部分
. 外部导电部分
. 保护导体
. 接地极
1.18 直接接触
direct contact
人或动物与带电部分的接触
1.19 间接接触
indirect contact
人或动物与故障情况下变为带电的外露导电部分的接触
1.20 接触电压
touch voltage
绝缘损坏时同时可触及部分之间出现的电压
注. 按惯例此术语仅用在与间接接触保护有关的方面
. 在某些情况下接触电压值可能受到触及这些部分的人的阻抗的明显
影响
1.21 跨步电压
step voltage
人站立在有电流流过的大地上加于两足之间的电压
1.22 安全特低电压
safety extra-low voltage(SELV)
用安全隔离变压器或具有独立绕组的变流器与供电干线隔离开的电路中导
体之间或任何一个导体与地之间有效值不超过50 伏的交流电压
1.23 对地电压
voltage to earth
带电体与大地之间的电位差(大地电位为零)
1.24 对地过电压
overvoltage to earth
高于正常对地峰值电压(对应于最高系统电压) 以峰值电压表示的对地电压1.25 触电电流
shock current
通过人体或动物体并具有可能引起病理生理效应特征的电流
1.26 感知(电流)阈值
threshold of perception current
在给定条件下电流通过人体可引起任何感觉的最小电流值
1.27 摆脱(电流)阈值
threshold of let-go current
在给定条件下手握着电极的人能够摆脱的最大电流值
1.28 致颤(电流)阈值
threshold of ventricular fibrillation current
在给定条件下引起心室纤维性颤动的最小电流值
1.29 故障电流
事故电流
fault current
由绝缘损坏或绝缘被短接而造成的电流
1.30 (电路的)过载电流
overload current (of a circuit)
在没有电气故障情况下电路中发生的过电流
1.31 短路电流
short-circuit current
在电路中由于故障而造成短路时所产生的过电流
1.32 残余电流
residual current 在电气装置的一点上流经电路中全部带电导体的电流瞬
时值的代数和
1.33 人体总阻抗
total impedance of the human body=人的体内阻抗与皮肤阻抗的矢量和
1.34 安全阻抗
safety impedance 连接于带电部分和可触及的导电部分之间的阻抗其值
可在设备正常使用和可能分生故障的情况下把电流限制在安全值以内
并在设备的整个寿命期间保持其可靠性
1.35 耐故障能力
fault withstandability
电气装置承受规定的电气故障电流的作用而不超出规定的损坏程度的能力1.36 不安全温度
unsafe temperature
可能引起燃烧和(或)可能使操作者进行无意识的危险动作的温度
2 基本要素
2.1 绝缘
2.1.1 绝缘(性能)
insulation (property) 导体绝缘后所获得的全部性能
2.1.2 绝缘(材料)
insulation (material) 所有用于使器件绝缘的材料
2.1.3 绝缘结构
insulation system 一种或几种绝缘材料的组合根据电气设备的特点和尺寸要求将它与导体部件设计成为一个整体用以隔绝有电位差的导电部分注一台电气设备中允许有几种不同的绝缘结构
2.1.4 基本绝缘
basic insulation 带电部分上对防触电起基本保护作用的绝缘
2.1.5 附加绝缘
supplementary insulation 为了在基本绝缘损坏的情况下防止触电而在基本。
