Data Acquisition Systems
Data acquisition systems are used to acquire process operating data and store it on，secondary storage devices for later analysis. Many or the data acquisition systems acquire this data at very high speeds and very little computer time is left to carry out any necessary, or desirable, data manipulations or reduction. All the data are stored on secondary storage devices and manipulated subsequently to derive the variables of
in-terest. It is very often necessary to design special purpose data acquisition systems and interfaces to acquire the high speed process data. This special purpose design can be an expensive proposition.
Powerful mini- and mainframe computers are used to combine the data acquisition with other functions such as comparisons between the actual output and the desirable output values, and to then decide on the control action which must be taken to ensure that the output variables lie within preset limits. The computing power required will depend upon the type of process control system implemented. Software requirements for carrying out proportional, ratio or three term control of process variables are relatively trivial, and microcomputers can be used to implement such process control systems. It would not be possible to use many of the currently available microcomputers for the implementation of high speed adaptive control systems which require the use of suitable process models and considerable online manipulation of data.
Microcomputer based data loggers are used to carry out intermediate functions such as data acquisition at comparatively low speeds, simple mathematical manipulations of raw data and some forms of data reduction. The first generation of data loggers, without any programmable computing facilities, was used simply for slow speed data acquisition from up to one hundred channels. All the acquired data could be punched out on paper tape or printed for subsequent analysis. Such hardwired data loggers are being replaced by the new generation of data loggers which incorporate microcomputers and can be programmed by the user. They offer an extremely good method of collecting the process data, using standardized interfaces, and subsequently performing the necessary manipulations to provide the information of interest to the process operator. The data acquired can be analyzed to establish correlations, if any, between process variables and to develop mathematical models necessary for adaptive and optimal process control.
The data acquisition function carried out by data loggers varies from one to 9 in system to another. Simple data logging systems acquire data from a few channels while complex systems can receive data from hundreds, or even thousands, of input channels distributed around one or more processes. The rudimentary data loggers scan the selected number of channels, connected to sensors or transducers, in a sequential manner and the data are recorded in a digital format. A data logger can be dedicated in the sense that it can only collect data from particular types of sensors and transducers. It is best to use a nondedicated data logger since any transducer or sensor can be connected to the channels via suitable interface circuitry. This facility requires the use of appropriate signal conditioning modules.
Microcomputer controlled data acquisition facilitates the scanning of a large number of sensors. The scanning rate depends upon the signal dynamics which means that some channels must be scanned at very high speeds in order to avoid aliasing errors while there is very little loss of information by scanning other channels at slower speeds. In some data logging applications the faster channels require sampling at speeds of up to 100 times per second while slow channels can be sampled once every five minutes. The conventional hardwired, non-programmable data loggers sample all the channels in a sequential manner and the sampling frequency of all the channels must be the same. This procedure results in the accumulation of very large amounts of data, some of which is unnecessary, and also slows down the overall effective sampling frequency. Microcomputer based data loggers can be used to scan some fast channels at a higher frequency than other slow speed channels.
The vast majority of the user programmable data loggers can be used to scan up to 1000 analog and 1000 digital input channels. A small number of data loggers, with a higher degree of sophistication, are suitable for acquiring data from up to 15, 000 analog and digital channels. The data from digital channels can be in the form of Transistor- Transistor Logic or contact closure signals. Analog data must be converted into digital format before it is recorded and requires the use of suitable analog to digital converters (ADC)．The characteristics of the ADC will define the resolution that can be achieved and the rate at which the various channels can be sampled. An in-crease in the number of bits used in the ADC improves the resolution capability. Successive approximation ADC's are
faster than integrating ADC's. Many microcomputer controlled data loggers include a facility to program the channel scanning rates. Typical scanning rates vary from 2 channels per second to 10, 000 channels per second.
Most data loggers have a resolution capability of ±0.01% or better, It is also pos-sible to achieve a resolution of 1 micro-volt. The resolution capability, in absolute terms, also depends upon the range of input signals, Standard input signal ranges are 0-10 volt, 0-50 volt and 0-100 volt. The lowest measurable signal varies form 1 t, volt to 50, volt. A higher degree of recording accuracy can be achieved by using modules which accept data in small, selectable ranges. An alternative is the auto ranging facil-ity available on some data loggers.
The accuracy with which the data are acquired and logged-on the appropriate storage device is extremely important. It is therefore necessary that the data acquisi-tion module should be able to reject common mode noise and common mode voltage. Typical common mode noise rejection capabilities lie in the range 110 dB to 150 dB. A decibel (dB) is a tern which defines the ratio of the power levels of two signals. Thus if the reference and actual signals have power levels of N, and Na respectively, they will have a ratio of n decibels, where
n＝10 Log10（Na /Nr）
Protection against maximum common mode voltages of 200 to 500 volt is available on typical microcomputer based data loggers.
The voltage input to an individual data logger channel is measured, scaled and linearised before any further data manipulations or comparisons are carried out.
In many situations, it becomes necessary to alter the frequency at which particu-lar channels are sampled depending upon the values of data signals received from a particular input sensor. Thus a channel might normally be sampled once every 10 minutes. If, however, the sensor signals approach the alarm limit, then it is obviously desirable to sample that channel once every minute or even faster so that the operators can be informed, thereby avoiding any catastrophes. Microcomputer controlled
intel-ligent data loggers may be programmed to alter the sampling frequencies depending upon the values of process signals. Other data loggers include self-scanning modules which can initiate sampling.
The conventional hardwired data loggers, without any programming facilities, simply record the instantaneous values of transducer outputs at a regular sampling
in-terval. This raw data often means very little to the typical user. To be meaningful, this data must be linearised and scaled, using a calibration curve, in order to determine the real value of the variable in appropriate engineering units. Prior to the availability of programmable data loggers, this function was usually carried out in the off-line mode on a mini- or mainframe computer. The raw data values had to be punched out on pa-per tape, in binary or octal code, to be input subsequently to the computer used for analysis purposes and converted to the engineering units. Paper tape punches are slow speed mechanical devices which reduce the speed at which channels can be scanned. An alternative was to print out the raw data values which further reduced the data scanning rate. It was not possible to carry out any limit comparisons or provide any alarm information. Every single value acquired by the data logger had to be recorded even
though it might not serve any useful purpose during subsequent analysis; many data values only need recording when they lie outside the pre-set low and high limits.
If the analog data must be transmitted over any distance, differences in ground potential between the signal source and final location can add noise in the interface design. In order to separate common-mode interference form the signal to be recorded or processed, devices designed for this purpose, such as instrumentation amplifiers, may be used. An instrumentation amplifier is characterized by good common-mode- rejection capability, a high input impedance, low drift, adjustable gain, and greater cost than operational amplifiers. They range from monolithic ICs to potted modules, and larger rack-mounted modules with manual scaling and null adjustments. When a very high common-mode voltage is present or the need for extremely-low
com-mon-mode leakage current exists（as in many medical-electronics applications），an isolation amplifier is required. Isolation amplifiers may use optical or transformer isolation.
Analog function circuits are special-purpose circuits that are used for a variety of signal conditioning operations on signals which are in analog form. When their accu-racy is adequate, they can relieve the microprocessor of time-consuming software and computations. Among the typical operations performed are multiplications, division, powers, roots, nonlinear functions such as for linearizing transducers, rims
measure-ments, computing vector sums, integration and differentiation, and
current-to-voltage or voltage- to-current conversion. Many of these operations can be purchased in available devices as multiplier/dividers, log/antilog amplifiers, and others.
When data from a number of independent signal sources must be processed by the same microcomputer or communications channel, a multiplexer is used to channel the input signals into the A/D converter.
Multiplexers are also used in reverse, as when a converter must distribute analog information to many different channels. The multiplexer is fed by a D／A converter which continually refreshes the output channels with new information.
In many systems, the analog signal varies during the time that the converter takes to digitize an input signal. The changes in this signal level during the conversion process can result in errors since the conversion period can be completed some time after the conversion command. The final value never represents the data at the instant when the conversion command is transmitted. Sample-hold circuits are used to make an acquisition of the varying analog signal and to hold this signal for the duration of the conversion process. Sample-hold circuits are common in multichannel distribution systems where they allow each channel to receive and hold the signal level.
In order to get the data in digital form as rapidly and as accurately as possible, we must use an analog/digital (A/D) converter, which might be a shaft encoder, a small module with digital outputs, or a high-resolution, high-speed panel instrument. These devices, which range form IC chips to rack-mounted instruments, convert ana-log input data, usually voltage, into an equivalent digital form. The characteristics of A/D converters include absolute and relative accuracy, linearity, monotonic, resolu-tion, conversion speed, and stability. A choice of input ranges, output codes, and other features are available. The successive-approximation technique is popular for a large number of
applications, with the most popular alternatives being the counter-comparator types, and dual-ramp approaches. The dual-ramp has been widely-used in digital voltmeters.
D/A converters convert a digital format into an equivalent analog representation. The basic converter consists of a circuit of weighted resistance values or ratios, each controlled by a particular level or weight of digital input data, which develops the output voltage or current in accordance with the digital input code. A special class of D/A converter exists which have the capability of handling variable reference sources. These devices are the multiplying DACs. Their output value is the product of the number represented by the digital input code and the analog reference voltage, which may vary form full scale to zero, and in some cases, to negative values.
Component Selection Criteria
In the past decade, data-acquisition hardware has changed radically due to ad-vances in semiconductors, and prices have come down too; what have not changed, however, are the fundamental system problems confronting the designer. Signals may be obscured by noise, rfi，ground loops, power-line pickup, and transients coupled into signal lines from machinery. Separating the signals from these effects becomes a matter for concern.
Data-acquisition systems may be separated into two basic categories:（1）those suited to favorable environments like laboratories -and（2）those required for hostile environments such as factories, vehicles, and military installations. The latter group includes industrial process control systems where temperature information may be gathered by sensors on tanks, boilers, wats, or pipelines that may be spread over miles of facilities. That data may then be sent to a central processor to provide real-time process control. The digital control of steel mills, automated chemical production, and machine tools is carried out in this kind of hostile environment. The vulnerability of the data signals leads to the requirement for isolation and other techniques.
At the other end of the spectrum-laboratory applications, such as test systems for gathering information on gas chromatographs, mass spectrometers, and other sophis-ticated instruments-the designer's problems are concerned with the performing of sen-sitive measurements under favorable conditions rather than with the problem of
pro-tecting the integrity of collected data under hostile conditions.
Systems in hostile environments might require components for wide tempera-tures, shielding, common-mode noise reduction, conversion at an early stage, redun-dant circuits for critical measurements, and preprocessing of the digital data to test its reliability. Laboratory systems, on the other hand, will have narrower temperature ranges and less ambient noise. But the higher accuracies require sensitive devices, and a major effort may be necessary for the required signal /noise ratios.
The choice of configuration and components in data-acquisition design depends on consideration of a number of factors:
1. Resolution and accuracy required in final format.
2. Number of analog sensors to be monitored.
3. Sampling rate desired.
4. Signal-conditioning requirement due to environment and accuracy.
5. Cost trade-offs.
Some of the choices for a basic data-acquisition configuration include：
1 ．Single-channel techniques.
A. Direct conversion.
B. Preamplification and direct conversion.
C. Sample-hold and conversion.
D. Preamplification, sample-hold, and conversion.
E. Preamplification, signal-conditioning, and direct conversion.
F. Preamplification, signal-conditioning, sample-hold, and conversion.
2. Multichannel techniques.
A. Multiplexing the outputs of single-channel converters.
B. Multiplexing the outputs of sample-holds.
C. Multiplexing the inputs of sample-holds.
D. Multiplexing low-level data.
E. More than one tier of multiplexers.
Signal-conditioning may include:
1. Radiometric conversion techniques.
B. Range biasing.
D. Logarithmic compression.
A. Analog filtering.
B. Integrating converters.
C. Digital data processing.
We shall consider these techniques later, but first we will examine some of the components used in these data-acquisition system configurations.
Multiplexers
When more than one channel requires analog-to-digital conversion, it is neces-sary to use time-division multiplexing in order to connect the analog inputs to a single converter, or to provide a converter for each input and then combine the converter outputs by digital multiplexing.
Analog Multiplexers
Analog multiplexer circuits allow the timesharing of analog-to-digital converters between a numbers of analog information channels. An analog multiplexer consists of a group of switches arranged with inputs connected to the individual analog channels and outputs connected in common（as shown in Fig. 1）．The switches may be ad-dressed by a digital input code.
Many alternative analog switches are available in electromechanical and solid-state forms. Electromechanical switch types include relays, stepper switches,
cross-bar switches, mercury-wetted switches, and dry-reed relay switches. The best switching speed is provided by reed relays（about 1 ms）．The mechanical switches provide high do isolation resistance, low contact resistance, and the capacity to handle voltages up to 1 KV, and they are usually inexpensive. Multiplexers using mechanical switches are suited to low-speed applications as well as those having high resolution requirements. They interface well with the slower A/D converters, like the integrating dual-slope types. Mechanical switches have a finite life, however, usually expressed in
number of operations. A reed relay might have a life of 109
operations, which would
allow a 3-year life at 10 operations/second.
Solid-state switch devices are capable of operation at 30 ns, and they have a life which exceeds most equipment requirements. Field-effect transistors（FETs）are used in most multiplexers. They have superseded bipolar transistors which can introduce large voltage offsets when used as switches.
FET devices have a leakage from drain to source in the off state and a leakage from gate or substrate to drain and source in both the on and off states. Gate leakage in MOS devices is small compared to other sources of leakage. When the device has a Zener-diode-protected gate, an additional leakage path exists between the gate and source.
Enhancement-mode MOS-FETs have the advantage that the switch turns off when power is removed from the MUX. Junction-FET multiplexers always turn on with the power off.
A more recent development, the CMOS-complementary MOS-switch has the advantage of being able to multiplex voltages up to and including the supply voltages. A±10-V signal can be handled with a ±10-V supply.
Trade-off Considerations for the Designer
Analog multiplexing has been the favored technique for achieving lowest system cost. The decreasing cost of A/D converters and the availability of low-cost, digital integrated circuits specifically designed for multiplexing provide an alternative with advantages for some applications. A decision on the technique to use for a given
sys-tem will hinge on trade-offs between the following factors:
1. Resolution. The cost of A/D converters rises steeply as the resolution increases due to the cost of precision elements. At the 8-bit level, the per-channel cost of an analog multiplexer may be a considerable proportion of the cost of a converter. At resolutions above 12 bits, the reverse is true, and analog multiplexing tends to be more economical.
2. Number of channels. This controls the size of the multiplexer required and the amount of wiring and interconnections. Digital multiplexing onto a common data bus reduces wiring to a minimum in many cases. Analog multiplexing is suited for 8 to 256 channels; beyond this number, the technique is unwieldy and analog errors be-come difficult to minimize. Analog and digital multiplexing is often combined in very large systems.
3. Speed of measurement, or throughput. High-speed A/D converters can add a considerable cost to the system. If analog multiplexing demands a high-speed
con-verter to achieve the desired sample rate, a slower converter for each channel with digital multiplexing can be less costly．
4. Signal level and conditioning. Wide dynamic ranges between channels can be difficult with analog multiplexing. Signals less than 1V generally require differential low-level analog multiplexing which is expensive, with programmable-gain amplifiers after the MUX operation. The alternative of fixed-gain converters on each channel, with signal-conditioning designed for the channel requirement, with digital multi-plexing may be more efficient.
5. Physical location of measurement points. Analog multiplexing is suited
for making measurements at distances up to a few hundred feet from the converter, since analog lines may suffer from losses, transmission-line reflections, and interference. Lines may range from twisted wire pairs to multiconductor shielded cable, depending on signal levels, distance, and noise environments. Digital multiplexing is operable to thousands of miles, with the proper transmission equipment, for digital transmission systems can offer the powerful noise-rejection characteristics that are required for
29 Data Acquisition Systems long-distance transmission.
Digital Multiplexing
For systems with small numbers of channels, medium-scale integrated digital multiplexers are available in TTL and MOS logic families. The 74151 is a typical example. Eight of these integrated circuits can be used to multiplex eight A/D con-verters of 8-bit resolution onto a common data bus.
This digital multiplexing example offers little advantages in wiring economy, but it is lowest in cost, and the high switching speed allows operation at sampling rates much faster than analog multiplexers. The A/D converters are required only to keep up with the channel sample rate, and not with the commutating rate. When large numbers of A/D converters are multiplexed, the data-bus technique reduces system interconnections. This alone may in many cases justify multiple A/D converters. Data can be bussed onto the lines in bit-parallel or bit-serial format, as many converters have both serial and parallel outputs. A variety of devices can be used to drive the bus, from open collector and tristate TTL gates to line drivers and optoelectronic isolators. Channel-selection decoders can be built from 1-of-16 decoders to the required size. This technique also allows additional reliability in that a failure of one A/D does not affect the other channels. An important requirement is that the multiplexer operate without introducing unacceptable errors at the sample-rate speed. For a digital MUX system, one can determine the speed from propagation delays and the time required to charge the bus capacitance.
Analog multiplexers can be more difficult to characterize. Their speed is a func-tion not only of internal parameters but also external parameters such as channel, source impedance, stray capacitance and the number of channels, and the circuit lay-out. The user must be aware of the limiting parameters in the system to judge their ef-fect on performance.
The nonideal transmission and open-circuit characteristics of analog multiplexers can introduce static and dynamic errors into the signal path. These errors include leakage through switches, coupling of control signals into the analog path, and inter-actions with sources and following amplifiers. Moreover, the circuit layout can com-pound these effects.
Since analog multiplexers may be connected directly to sources which may have little overload capacity or poor settling after overloads, the switches should have a break-before-make action to prevent the possibility of shorting channels together. It may be necessary to avoid shorted channels when power is removed and a chan-nels-off with power-down characteristic is desirable. In addition to the chan-nel-addressing lines, which are normally binary-coded, it is useful to have inhibited or enable lines to turn all switches off regardless of the channel being addressed. This simplifies the external logic necessary to cascade multiplexers and can also be useful in certain modes of channel
addressing. Another requirement for both analog and digital multiplexers is the tolerance of line transients and overload conditions, and the ability to absorb the transient energy and recover without damage.
数据采集系统
数据采集系统是用来获取数据处理和存储在二级存储设备，为后来的分析。许多或数据采集系统获得数据以很高的速度和非常小的计算机时间去进行任何必要的，或需要，数据操作或减少。所有的数据都存储在二级存储设备和操纵随后得出的变量的利益。这是很经常需要设计特殊用途的数据采集系统和接口获得高速过程数据。这一特殊目的的设计是一个昂贵的命题。
强大的小型和大型计算机结合使用的数据采集与其他职能，如比较实际输出与期望输出值，并决定对控制作用，必须采取确保输出变量躺在预设的限制。计算所需功率将取决于类型的过程控制系统的实施。软件需求进行比例，比率或三项控制的过程变量都比较琐碎，和微型计算机可以用来执行过程控制系统。它不可能使用许多现有微机实施高速度自适应控制系统，需要使用合适的过程模型和大量的在线数据处理。
微机数据记录仪是用来进行中间等功能的数据采集在较低的速度，简单的数学运算的数据和某些形式的数据约简。第一代的数据记录器，没有任何可编程计算机设施，使用简单的低速数据采集到一百频道。所有获得的数据可以被穿孔纸带或印刷为以后的分析。这种硬数据记录器，取而代之的是新一代数据记录器纳入微机和可编程的用户。他们提供了一个非常好的方法收集数据的过程中，使用标准接口，并随后执行必要的操作提供感兴趣的信息，经营者的过程。获得的数据可以分析，建立相关，如果有的话，变量之间的过程和发展的数学模型的必要的适应性和过程优化控制。
数据采集功能进行数据记录器不同从9到另一个系统。简单的数据记录系统获取的数据从几个渠道而复杂的系统，可以接收数据从数百，甚至数千，输入通道分布在一个
或多个进程。初步数据记录器扫描选定的通道，连接到传感器或传感器，在一个连续的方式，数据被记录在数字格式。数据记录仪能专注在这个意义上，它可以只收集数据从特定类型的传感器和传感器。最好的方法是使用一个专用数据记录仪，因为任何传感器或传感器可以连接到通道通过适当的接口电路。这个设备需要使用适当的信号调理模块。
微机控制的数据采集方便扫描大量传感器。扫描速度取决于信号的动态是指一些渠道必须扫描在非常高的速度，以避免混淆的错误而很少有损失的信息的扫描其它渠道以较慢的速度。在一些数据应用程序更快的渠道需要采样速度高达每秒100次而缓慢的渠道可以每五分钟采样一次。传统的硬，不可编程数据记录器样本的所有频道顺序和采样频率对所有通道必须是相同的。这个程序的结果积累的大量数据，其中一些是不必要的，而且也减慢了全面有效的取样频率。微机数据记录器可以用来扫描一些快速通道在更高的频率比其他速度慢通道。
绝大部分的用户可编程数据记录器可以用来扫描多达1000个模拟和1000个数字输入通道。少量数据记录器，具有更高的复杂程度，适用于从数据获取高达15，000模拟和数字通道。数据从数字频道的形式可以是晶体管-晶体管逻辑或接点闭合信号。模拟数据必须被转换成数字格式之前，它是记录和需要使用适当的模拟到数字转换器（模数转换器）。特色的模数转换器将确定的分辨率可以达到的速度在不同的渠道进行采样。一个能在使用的位数的提高分辨能力。逐次逼近模数转换器的速度比积分的。许多微机控制数据记录器包括一个设备编程通道扫描率。典型的扫描率从2通道每秒10，000通道每秒。
大多数数据记录器具有分辨能力±0.01%或更好，也有可能实现一个分辨率为1微伏。该决议的能力，绝对值，还取决于输入信号范围，标准输入信号范围为0 - 50- 100伏伏伏，和。最低可测信号的变化从1伏到50伏，。更高程度的记录精度可以达到使用模块接受数据量小，可选择的范围。另一种是自动测距设备可在某些数据记录器。
准确性与数据采集和登录的适当的存储设备是非常重要的。因此有必要的数据采集模块应该能够拒绝共模噪声和共模电压。典型的共模噪声抑制能力范围在110分贝至150分贝。分贝（分贝）是燕鸥定义比功率水平的信号。因此，如果参考和实际信号功率水平，和n分别，他们将有一个比的分贝，当
n＝10 Log10（Na /Nr）
防止最大共模电压为200到500伏特是典型的微机数据记录器。
电压输入个人数据记录仪测量信道，规模和线性化之前，任何进一步的数据操作或比较进行。
在许多情况下，有必要改变的频率在这项通道采样取决于价值的数据信号从收到一个特定的输入传感器。因此，渠道可能通常是每10分钟采样一次。如果，然而，传感器信号的警报限制，那么它显然是可取的样品通道每分钟或甚至更快，使运营商可以得知，从而避免任何灾难。微机控制智能数据记录器可以通过编程改变采样频率取决于价值的过程信号。其他数据记录器包括扫描模块，可以启动采样。
传统的硬数据记录器，无需任何编程，只记录瞬时值传感器的输出在采样间隔。这种原始数据通常是很小的典型用户。是有意义的，这个数据必须被线性化和规模，使用校准曲线，以确定真正价值的变量在适当的工程单位。之前的可用性可编程数据记录器，此功能通常在离线模式在小型或大型计算机。原始数据值是打了对纸胶带，在二进制或八进制代码，输入到随后的计算机用于分析的目的和转换为工程单位。纸带速度缓慢，机械设备，降低速度，通道可以扫描。另一个是打印出来的原始数据值，进一步减少了数据的扫描速度。这是不可能进行任何限制比较或提供任何报警信息。每一个单值获得的数据记录器已被记录，即使它可能没有任何用处在随后的分析；许多数据值只需要记录时，他们不在预先设定
