8 Application Architecture
8.1 Introduction
This chapter describes an abstract architecture for OPC UA applications with different layers having defined responsibilities regarding OPC UA functionality. Afterward the deliverables of the OPC Foundation and their features are listed and it is pointed out how these are reflected in the abstract architecture.
8.2 Architectural Overview
When you intend to develop an application based on OPC UA you first have to think about what it should do by specifying the requirements and the functionality. Having that in mind you normally start designing the architecture of your applica-tion. Thereby certain design goals (e.g., portability, performance, or security) have to be agreed upon before first architectural concepts are developed. In this chapter, we will take a look at OPC UA from the design perspective and introduce a poten-tial application scenario. We expect that this scenario will be applied by many application vendors. The main design goal thereby is the reuse of components and artifacts.
In this scenario, we assume that we have to develop an OPC UA client and a server. Both client and server will have application logic covering functionality tailored to concrete use cases. For example, the server has to access special data sources (e.g., data bases, devices, or other applications) or the client has to be integ-application logic covering common functionality like managing connections, cre-ating and processing OPC UA messages as well as securing them. Since we defined reuse as our main design goal it would make sense to separate use-case-specific and common functionality when designing the architecture. The common part can tions and processing Service messages and lower level functions like encoding, securing, and transmitting messages. The part providing the higher level functions can be considered as a Software Development Kit (SDK) and the part with the lower level functions can be represented by a protocol stack. The client and server applications are layered on top of the SDK. Based on these blocks we come to a very high level architecture shown in Fig. 8.1.
The above-described software layers are named as Application, SDK, and Stack and are described in more details in the following sections.
255
DOI: 10.1007/978-3-540-68899-0_8,be further divided into two parts: the higher level functions like managing connec-W. Mahnke et al., OPC Unified Architecture ,rated into another application (e.g., in a MES application). But they will also have ? Springer-Verlag Berlin Heidelberg 2009
Fig. 8.1 Architectural overview
8.3 Stack
As mentioned in Sect. 8.2, the Stack is a common part covering lower level func-tionality. In this section, we want to structure the Stack further into different parts
leading to a more detailed architectural view like the one shown in Fig. 8.2.
Fig. 8.2 Stack overview
8.3.1Interfaces
First of all, the layers above need somehow to access the Stack in order to send and receive messages. Both client and server can use the same stack since it pro-vides a lot of functionality that can be used for both sides such as encoding and securing messages. However, there are also functions specific to each side. For
8 Application Architecture
256
example the client is only sending requests and processing responses, whereas the server processes requests and sends responses. Therefore an access layer (i.e., interface) is needed for both the client- and the server-side (Client and Server API in the figure). They could, for example, offer methods for configuring the Stack, for managing the connection establishment, for sending OPC UA Service mes-sages, and for notifying the layers above when messages are received.
The encoding and the decoding of messages are processed in the Encoding Layer. Once data structures representing Service messages are provided from the API layer they are serialized according to the special rules defined by OPC UA and passed to the layer beneath for further processing. Service messages received from the Security Layer are deserialized and passed as arguments of callback functions registered by the upper layer.
8.3.3Security Layer
Encoded Service messages passed by the Encoding Layer to the Security Layer are then secured. Secured in this context means that depending on the configura-encrypted or only signed. In scenarios in which applications are running in iso-lated environments there must also be the possibility to disable message security by configuration. In addition, special security headers and footers are appended providing information for the receiver on how to decrypt the message and how to verify the signature of the message. The Security Layer of the receiver has to check the security headers and footers of incoming messages to know how they were secured. Depending on that messages are first decrypted and afterward the signature of the message is verified or only the signature is verified or none of these activities are done (in the case the message was not secured).
8.3.4Transport Layer
The Transport Layer is responsible for transmitting and receiving messages as well as for dealing with errors at Network Layer. Before transmitting messages special transport headers are appended containing special information for example about the type and the length of the message. The Transport Layer of the receiver verifies whether it is well-formed meaning whether the type can be identified or whether the message is not too long 1 before forwarding it to the Security Layer.
1In UA TCP, the maximum message lengths are negotiated and verified at Transport Level. 257
8.3 Stack 8.3.2Encoding Layer
tion of the Secure Channel (Sect. 7.5.2.1) outgoing messages are signed and
8.3.5Platform Layer The reuse factor of the Stack can be increased by adding an additional layer to this model – the Platform Layer. The basic idea thereby is that all other layers of the Stack are developed in platform-neutral manner. Only the Platform Layer contains for managing sockets, threads, or cryptographic operations (e.g., encrypting and signing messages). This means that only the Platform Layer has to be changed in order to port the Stack to another platform, the other parts of the code can be reused.
8.4 Software Development Toolkit
On top of the Stack, the SDK Layer is located covering the higher level function-ality. This layer can be in general composed of three parts which are illustrated in Fig. 8.3.
Fig. 8.3 SDK overview
8.4.1UA-Specific Functionality
The UA-specific part represents the implementation of the concepts and the Services specified in OPC UA. Note, that all the different aspects (like Sessions, Events, or Nodes) depicted in Fig. 8.3 have to be addressed by both the client and the server.
8 Application Architecture
258
However, the semantic of these aspects for client and server is different (e.g., Client creates a Session request and server processes the client’s Session request).
One important aspect is the management of OPC UA Sessions. As we learned the connection establishment of OPC UA includes creating a Secure Channel, establishing a Session, and activating the Session. The SecureChannel Services should be implemented in the Stack Layer to reduce the complexity in the SDK. Therefore, the Secure Channels should also be managed in that layer. The Session Services (i.e., CreateSession, ActivateSession, and CloseSession) are implemented in the present model in the SDK Layer. However, managing OPC UA Sessions does not only mean processing the Service requests and responses. There has also to be special logic behind like associating Sessions with the Secure Channel that secures the exchanged messages for that context. In addition, Sessions are run on behalf of users that have to be authenticated and authorized. Furthermore there are special Session parameters that have to be taken care of like the lifetime of the session or used locales. Such tasks are handled by a management class which can be called as a Session Manager.
Another important aspect is working with Nodes. Nodes are very essential to OPC UA and are used for organizing Address Spaces as well as for providing attribute values. Address Spaces in OPC UA reside on the server-side allowing clients to access and manipulate them via the NodeManagement and Attribute Service Sets. This means that on the server-side there has to be entities managing the Nodes (e.g., Node Manager) of the Address Space (i.e., Nodes and References) and the manipulation of the values contained in the Nodes (e.g., I/O Manager). Other concepts and Services like Subscriptions, Events, and History can be approached in a similar way.
OPC UA defines certain diagnostics information for Services and exposes it in the Address Space. It contains for example information about how often Services have been called. Managing this information is also a task for the SDK Layer since is also manages the Services of which the upper layer may not be aware of.
8.4.2Common Functionality
The second part of the SDK Layer covers more general functionality that has to be implemented by clients and servers.
OPC UA exchanges certificates in order to establish secure connections. Before using them it has to be verified whether a received certificate can be trusted or not. OPC UA specifies what part of a certificate has to be validated to be trusted, how-ever, it does not state how it has to be validated. Therefore common functionality has to be provided allowing the applications to validate certificates and accessing their associated certificate stores. An alternative to implementing that function-ality in the SDK is using the Stack for that purpose. Since the Stack is a common component that should be used for large range of applications it is assumed that all applications use the same way of validating certificates. In heterogeneous 259
8.4 Software Development Toolkit
environments, it sometimes can make more sense to implement that in SDK or even in the Application Layer when different sources for gathering certificates or certificate-related information (e.g., certificate revocation lists, private keys, or validation rules) have to be consumed.
Other important topics that belong to the common part are application configu-ration and logging.
8.4.3Interfaces
The last part of the SDK discussed in this context represents the interfaces to the Application Layer. Client interfaces are needed for sending requests to the server and for receiving responses from it (i.e., callback interfaces). On the server side some interfaces for initializing and configuring the SDK should be provided as well as for integrating underlying systems acting as data providers.
8.5 Application
The Application Layer includes in principle two kinds of applications: clients and servers. The way how the architectures of these applications look like differs very much depending on the concrete scenario.
8.5.1Client
One example for an OPC UA client application is a generic browser used for exploring and manipulating the Address Space provided by a server. The main tasks of the client is visualizing data provided by the SDK Layer and translating user interactions into calls to the SDK’s API. The design of such an application from the functionality point of view can be quite simple which is shown in Fig. 8.4.
Fig. 8.4 Example of a high-level client architecture
8 Application Architecture
260
8.5.2Server
In principle there are two kinds of server applications: one managing the whole address space in the main memory and another one accessing underlying systems for gathering Address Space information.
In the first case, the Address Space is stored in a special data source (e.g., data-base or XML file) and completely loaded into the main memory when the server starts up. This provides a fast access to information contained in the Address Space requested by clients.
In the second case, an OPC UA server facades an underlying system like a device, controller or DCS. In the last case, typically several sources are accessed, like a configuration database and several controllers. It is expected that many sys-tem vendors will first head such an approach in order to smoothly migrate existing applications to OPC UA. The main responsibilities of this layer are reading and writing data from the underlying system. A SDK could for example provide spe-cial callback interfaces for exchanging data in a simple way to reduce the complexity of the server implementation on top of the SDK. An example of that architecture is given in Fig. 8.5.
Fig. 8.5 Example of a high-level server architecture
8.6 Deliverables Provided by the OPC Foundation
The OPC Foundation provides a set of deliverables that can make your life easier when developing OPC UA applications. Some of the deliverables follow the archi-tecture described in Sect. 8.5. All of them are available in the so-called UA SDK. It contains thereby various Stacks, libraries, and sample applications.
261
8.6 Deliverables Provided by the OPC Foundation
8.6.1 Stacks
Both an ANSI-C-based and a C#-based Stack is provided with the UA SDK.
A Java-based Stack was under development at the time when this book was writ-ten. It is recommended to use the UA stacks provided by the OPC Foundation in order to ensure interoperability between applications implemented in different development environments.
The ANSI-C Stack is implemented according to the architecture depicted in Conversation for the Security Layer, and UA TCP for the Transport. For securing messages and validating certificates, the OpenSSL crypto library is applied and integrated in the platform-specific part of the Stack.
Alternatively there is also a .NET Stack written in C# which does not have a Platform Layer. Therefore the architecture is different to the one shown above. For the Encoding Layer it supports UA Binary and XML, UA-SecureConversation and WS-SecureConversation as Security Layer protocols, and the transport protocols UA TCP and SOAP/HTTP. However, only the following combinations of the pro-tocols (also named as Stack profiles or mappings schemes; see Chap. 6 for more details) can be used:
?
HTTP/SOAP, WS-SecureConversation, UA Binary ?
HTTP/SOAP, WS-SecureConversation, XML ?
HTTP/SOAP, WS-SecureConversation, UA Binary, and XML 8.6.2 SDKs
There are two C#-based libraries contained in the UA SDK: a client library and a server library. These libraries can be considered as the SDK Layer described ear-lier. Both are providing the base functionality for handling the UA protocol and for processing common tasks regarding logging, security, and configuration. The server library provides special interfaces that can be used to integrate underlying systems for example in order to read or write certain values. The client library implements a NodeCache for buffering Nodes and References. In addition to the client and server libraries, the SDK also provides a C#-based discovery server used by clients for identifying running endpoints of the server they can connect to. C++-based UA SDKs for clients and servers were developed by a group of early adopter companies and are available as commercial libraries from Unified Automation. They are using the ANSI-C stack and are providing platform layers for different operating systems. Similar to the .NET UA SDK, the C++ SDKs are implementing common UA functionality to reduce the development effort for UA applications and are defining interfaces to integrate the application-specific infor-mation with the SDK.
8 Application Architecture
262? UA TCP, UA-SecureConversation, UA Binary.
Fig. 8.2. It supports UA Binary encoding for the Encoding Layer, UA-Secure-
8.6.3 Applications
The OPC Foundation’s UA SDK provides both a sample client and server application written in C#. The client application is a generic OPC UA browser offering the base OPC UA functionality like browsing the Address Space, reading and writing Node attributes, subscribing for data changes and Events, and also more sophisti-cated concepts like calling Methods or using Views. Therefore, it is a powerful tool for learning and exploring the concepts of OPC UA. The server uses an in-memory Address Space including standard Nodes as well as an example describing a boiler and its components.
8.7 Summary
8.7.1 Key Messages
This chapter describes how the architecture of an OPC UA application typically looks like. The main design goal is thereby the reuse of artifacts (e.g., code and components). Therefore the following layers with certain responsibilities are defined: Application Layer, SDK Layer, and Stack Layer.
The Stack is responsible for the lower level functions like encoding and decod-ing messages, securing messages, as well as sending and receiving messages. In addition to that, it has a Platform Layer containing only platform-specific code whereas the other layers are written in platform neutral manner. This facilitates the portability of the Stack to other platforms.
The SDK contains higher level functionality covering UA-specific functions and common functions. The UA-specific part implements the OPC UA concepts and Services whereas the common part deals for example with configurations and logging. Additionally the server-side of the SDK provides interfaces in order to integrate other systems used as data providers.
The Application Layer covers the use-case-specific part of the functionality. Clients could, for example, process data received from the SDK in a special way in order expose it to the user. Servers could access underlying systems in order to expose its information via OPC UA to clients.
The OPC Foundation offers a set of OPC UA standard deliverables that system vendors can reuse. Some of the components already implement similar architec-ture as described in this chapter.
8.7.2 Where to Find More Information?
More information about the OPC UA standard deliverables can be found on the OPC Foundation Web site (https://www.doczj.com/doc/1f11650549.html,/). More information 263
8.7 Summary
2648 Application Architecture
about the C++ SDKs can be found at the Unified Automation Web site (http:// https://www.doczj.com/doc/1f11650549.html,). Finally, the Web site of the OPC programmers’ connection (https://www.doczj.com/doc/1f11650549.html,/) provides a section with SDKs that can a useful source when intending to implement OPC UA applications.
8.7.3 What’s Next?
In Chap. 8 – System Architecture – different variants of OPC UA client–server concepts are introduced like chained or aggregating server. In addition, some related concepts regarding redundancy, discovery, and auditing are introduced.
