常用模具零件中英文对照表
2005-12-19 14:51:17???中国注塑网
入水：gate
进入位：gate location
水口形式：gate type
大水口：edge gate
细水口： pin-point gate
水口大小：gate size
转水口：switching runner/gate
唧嘴口径：sprue diameter
二、流道: runner
热流道：hot runner,hot manifold
热嘴冷流道: hot sprue/cold runner
唧嘴直流: direct sprue gate
圆形流道：round(full/half runner
流道电脑分析：mold flow analysis :?[??n?l?s?s]
流道平衡:runner balance
热嘴：hot sprue
热流道板：hot manifold
发热管：cartridge heater
探针: thermocouples
插头：connector plug
插座： connector socket
密封/封料： seal
三、运水：water line
喉塞：line lpug
喉管：tube
塑胶管：plastic tube
快速接头：jiffy quick connector plug/socker
四、模具零件：mold components
三板模：3-plate mold
二板模：2-plate mold
边钉/导边：leader pin/guide pin
边司/导套：bushing/guide bushing
中托司：shoulder guide bushing
中托边：guide pin
顶针板：ejector retainer plate
托板：support plate
螺丝： screw
管钉：dowel pin ['da??l]
开模槽：ply bar scot
内模管位：core/cavity inter-lock
顶针：ejector pin
司筒：ejector sleeve
司筒针：ejector pin
推板：stripper plate ?[?str?p?r] 脱漆剂；脱衣舞演员；剥离剂；剥离器缩呵：movable core,return core core puller
扣机（尼龙拉勾）：nylon latch lock?['na?.lɑn]:
斜顶：lifter
模胚（架）： mold base
上内模：cavity insert
下内模：core insert
行位（滑块）： slide
镶件：insert
压座/斜鸡：wedge
耐磨板/油板：wedge wear plate
压条：plate
撑头: support pillar
唧嘴： sprue bushing
挡板：stop plate
定位圈：locating ring
锁扣：latch
扣鸡：parting lock set
推杆：push bar
栓打螺丝：
顶板：eracuretun
活动臂：lever arm
分流锥：spure sperader
水口司:bush
垃圾钉：stop pin
隔片：buffle
弹弓柱：spring rod
弹弓:die spring
中托司：ejector guide bush
中托边：ejector guide pin
镶针：pin
销子：dowel pin
波子弹弓：ball catch
喉塞:pipeplug
锁模块：lockplate
斜顶：anglefrompin
斜顶杆：angleejectorrod
尼龙拉勾：partinglocks
活动臂：leverarm
复位键、提前回杆：earlyreturnbar
气阀：valves
斜导边：anglepin
术语：terms
承压平面平衡：partingsurfacesupportbalance
模排气：partinglineventing
回针碰料位：returnpinandcavityinterference
模总高超出啤机规格：moldbaseshuthight
顶针碰运水：waterlineinterfereswithejectorpin
料位出上/下模：partfromcavith(core)side
模胚原身出料位：cavitydirectcutonA-plate,coredirectcutonB-plate.
不准用镶件：Donotuse(core/cavity)insert
用铍铜做镶件：useberylliumcopperinsert
初步（正式）模图设计：preliinary(final)molddesign
反呵：reversecore
弹弓压缩量：springcompressedlength
稳定性好：goodstability,stable
强度不够：insufficientrigidity
均匀冷却：evencooling
扣模：sticking
热膨胀：theroexpansion
公差：tolorance
铜公(电极）：copperelectrode
塑件模具相关英文词汇
出处：FanE『翻译中国』作者：(转载) FanE『翻译中国』 2005-12-16 20:41:59
electrical discharge machining (EDM) 电火花加工
15. electrical insulating property 电绝缘性能
16. electrochemical die-sinking machine 电解型腔加工机，电解型腔加工机床
17. electrochemical machine (ECM) 电解加工机床，电化学加工机床
18. electrochemical machining (ECM) 电解加工，电化学加工
19. electro-discharge cutting 电火花加工，电火花切割
20. electro-discharge cutting machine 电火花切割机
21. electro-discharge machine tool 电火花加工机床
22. Electro-discharge Machine 电火花加工机床
23. electro-discharge machining 电火花加工
24. electro-discharge machining process 电火花加工工艺，电火花加工工序
25. epoxy resin 环氧树脂
9. guide bushing 导套
10. guide pillar 导柱，导杆，导柱
11. guide pin 导向销，导杆
12. guide pin cover 导柱盖
13. guide plate 导料板，导板
14. guide plate blanking die 导板式冲裁模，导板式落料模
15. guide post 导柱，导柱
16. guide stock plate 挡料板
4. injection mold 注射模，注塑模
5. injection molding 注射成型，注塑成型
6. injection-molding machine 注塑机，注射机，注塑成形机
7. injection plunger 注射柱塞
8. in-line reciprocating screw 联机往复螺杆，串联往复螺杆，直线排列往复螺杆
9. inner ram 内滑块
10. inserting molding 嵌件成形
11. integrated manufacturing 集成制造
12. internal stress 内应力
13. intermediate platen 中间板，隔板
塑料成型模具的主要设计要素
脱模距 stripper distance
脱模斜度 draft
投影面积 projected area
最大开距 maximum daylight;open daylight
闭合高度 mould-shut height
抽芯距 core-pulling distance
抽芯力 core-pulling force
脱模力 ejector force
开模力 mould opening force
模内压力 internal mould pressure;cavity pressure
成型压力 moulding pressure
背压环 back-up ring
1 bar =
高压接头 bite type fitting
液压马达 hydraulic motor
冷却水流量计 waterflow regulator
打磨器材 abrasive material
打磨砂轮 grinding wheels
切割砂轮 cutting wheels
码模夹(注塑机使用) mould clamps; lifting clamps 小五金工具 piping tools
高压力软管 high pressure hose
风管,水软管 air .water hose
高压油表 pressure gauge
压力油喉 hydraulic hoses
光塑检测 photoelastic testing
吹塑模 plastic blow mould
注塑模 plastic injection mould
冲扎复合模 blank & form compound die
精密冲模 precision blanking die
熔料流动率 MFR=melt flow rate
熔料流动指数 MET=melt flow index
推板导柱 guide pin for ejector plater
座板 clamping plate
垫块 space block(plate)
推板 ejector block(plate)
afdek plate 档尘板
guide stripe 行位后板
cavity sub-insert 前模镶件
core sub-insert 后模镶件
sprue puller insert 扣针镶件
stage ejector 顶棍
spacer rock(risers) 间隔板
变形 distortion
弯曲 warp
拖花 drag marks
火花纹 EDM marks
困气 venting
烧黑 burns
表面缩水 shrinkage
料位过薄/砸穿 thin wall stock
走水不平行 uneven fill pattern
夹水纹/流纹 witness line;mismatch;stress marks 走水纹 knit lines
走水不齐 short shots
orifice 料口
nozzle seat 热嘴垫圈
nozzle plate 射嘴板
cross pin 十字头销
sled 射台
seal ring 封密圈
spacer rail 介子座
heater groove 发热管槽
heater cement 发热管的结合剂soak 浸泡
seat 垫圈
ream 铰大圆孔直径
grind 磨床
drill 钻床
mill 铣床
caliper 卡尺
G-caliper 分厘卡
Depth Gauge 深厚计
hardness tester 硬度计
angle gauge 角规
marble table 云台石
projector 投影仪
height gauge 高度仪
microscope 显微镜
plug gauge 塞规
leveller 水平器
R gauge R 规
Inter caliper 内分厘卡
surface 平面仪
item number 细目编码
catalog number 材料分类编码undercut lip 倒扣口
hot tip = hot drop = nozzle 热嘴blow-off strip 放气板
blow-off nozzle 吹风口
spiral hose 螺旋式的连接喉
rust solvent 除锈剂
shaft 曲轴
tensile strength 拉伸力
yield strength 屈服力
spark erosion 电火花蚀刻
etch(photo-etch) 电蚀
harden 淬硬
copper electrode 铜公
corrosion resistance 耐腐蚀anneal 退火
heat treatment 淬火
FEM(finite elemnet method) 有限元法preliminary tool design 初期模具设计图zone 热流道区域
reverse taper 倒啤把
clamp plate 码板
toggle clamp 快速夹
vacuum furnace 真空炉
cavity insert rounds 圆柱镶件
cavity insert b0locks 方柱镶件
tensile strength 抗张强度,抗拉强度Concept drawing 概念图
Assembly drawing 装配图
mismatch;witness line 夹纹
shut-off(n.) 枕位
venting valves 疏气阀
venting plug 疏气塞
valve casing 阀门罩
twist drill 旋钻
harden/nitride 碎硬
anneal 退火
temper 回火
stess crack 应力断裂
corrosion resistance 防腐,防锈
tensile strength 物】抗张强度,抗拉强度split mould (分离)组合式的模具
inclined plate 斜面
inclined bolt 斜栓
jaw (工具,机械等)夹住东西的部分,钳口step change of the P/L 分形面枕位的改变thin steel section 较薄的料位
clean-up 清理,清除,清扫
Mold Dating Insert 模具日志镶件
Hot Sprue Bushing 热浇口套
semi-automatic 半自动
quick disconnector 快速断开接头
full shot 足量注射
mismatch 夹痕;夹水纹
ejector mark 顶痕
screw boss 螺丝孔,螺丝基座
sink mark 缩坑
15% glass filled ABS 掺有15%玻璃的ABS spraying mold release 脱模剂
drag mark 拖痕
stress mark 应力痕
reinforcement rib 加强筋
slght stoning 轻度磨砂
soliid line 实线
dotted line 虚线
internal diameter 内径
external diameter 外径
nickel-plated 电镀的
handling hole;lifting hole 吊装孔
parallel 平行块
piston 活塞
plunger 柱塞
carrier 导轨
rest 支架
item number 项目编号
catalog item 商品目录编码
dimensional datum 尺寸基准
heat treatment certification 淬硬证明文件
back-up bushing 支撑导套
jacking screw 起重螺丝,千斤顶
tapped hole (带有螺旋角度的)螺丝孔
diagonal corner 成对角的角落
burn mark 烧痕
hot runner mainfold (热流道板)分流板
texuring 蚀纹
clamping screw (注塑机)码模螺丝
imperial 英制的
metric 公制的
puller bushing 水口套
puller bar 水口铁
drool bushing 防漏胶套筒
safety switch 限位制
water line connected internally or hard tubing 不可用胶喉连接运水lifter on square rod or locked from rotation 用方形柱或用管钉止转gate insert 入水镶件
gate shut-offs 流道开关配件
guided ejection 中托司
parting line shutoff 前后模接触面
waterlines clear tie bars. 运水喉咀接驳位要避开啤机呵林柱.
BGV=Balanced Gate Value 平衡入水值
spacer 垫块
pocket 挖槽
rough 粗加工
finish 精加工
plunge rate 进刀率
retract rate 提刀速率
splindle rate 主轴转速
coolant 冷却液
SPLIT RING 开口环(钥匙圈)
侧向抽芯力 side pulling-core force
转图
guide pin 边针
Tee slot cutter T形SLOT CUTTER
zigzag 双向切削
constant overlap spiral 等距环切
parallel spiral 环绕切削
parallel spiral clean corners 环切并清角morph spiral 依外形环绕
true spiral 螺旋切削
one way 单向
end mill 平铣刀
spher mill 球刀
bull mill 圆鼻刀
face mill 面铣刀
rad mill 圆角成型刀
chamfer mill 倒角刀
slot mill 槽刀
taper mill 推拔铣刀
dove mill 鸠尾铣刀
lot mill 棒状
drill 钻孔
reamer 纹刀
bore bar 搪刀
tap RH 右牙刀
Tap LH 左牙刀
ctr Drill 中心钻
spot drill 点钻
cntr bore 沉头孔刀
c. sink 鱼眼孔钻
loft surface 举升曲面
coons surface 昆氏曲面
ruled surface 直纹曲面
revolved surface 旋转曲面
swept surface 扫描曲面
draft surface 牵引曲面
grinding wheel 磨砂使用的轮子
quench steel 将...淬火,使冷却
stress relieving 应力消除
molten 熔热的
oxide film 氧化层
guide pin and sleeve, locating ring ,导边,司筒,定位圈
ejector ,ejector balde, ejector sleeve,顶针,扁顶针,顶针司筒, lifters, wear plate,horn pin,斜坊,磨损板,气顶针,
O ring, water baffle, water pipe plug,O形圈,隔片,运水管道塞, water line connector,wear plate ,运水管道转接头,耐磨板
air cylinder,hydraulic cylinder,氯压缸,液压缸
micro switch,oil nipple, spring,开关装置,油枪接头,弹弓
sprue bushing,early return system,浇口套,早期回撞装置, accelerated ejectors, slied holder,加速顶针,注塑周期计数器, cycle counter,date stamper，滑块固定板,生产日期铭牌,
hot runner system ，热流道系统
chemical composition 化学成份
thermal conductiivity 导热性能
thermal diffusivity 热扩散性能
dimensonal stablity 尺寸稳定性能
cooling effiency 冷却效率
easiler ejection 易于脱模
alloy insert 合金镶件
(cooling) duct 输送管;导管
maintenance cost 维护费用
ultrasonic testing 超声波检测
crack 断裂
direct gate 直接浇口
ring gate 环形浇口
disk gate;disphragm gate 盘形浇口
spoke gate;spider gate 轮辐浇口
pin-point gate 点浇口
edge gate 侧浇口
submarine gate;tunnel gate 潜伏浇口
fan gate 扇形浇口
tab gate 护耳浇口
runner plate 流道板(或冷或热)
secondary nozzle 二级喷嘴
torpedo;torpedo body assembly 鱼雷形组合体
catridge heater 管式加热器
heat pipe 热管
valve gate 阀式浇口
force plunger;pot plunger 柱塞
flash groove;spew groove 溢料槽
impression;cavity block;cavity plate 凹模
punch;force 凸模
movable insert;loose detail 活动镶件
cavity splits;core splits(凹模拼块) (型芯拼块) 拼块
side core 侧型芯
thread plug;threaded core 螺纹型芯
thread ring;threaded cavity 螺纹型环
cutting wheel 切割砂轮
grinding wheel 打磨砂轮
abrasive material 打磨器材
mould clamps;lifting clamp 砂模夹(注塑机使用)
air (water) hose 风管,水轮管
pressure gauge 高压油表
hydraulic hose 压力油喉
plastic blow mould 吹塑模
plastic injection mould 注塑模
blandk&form compound die 冲扎复合模
precisiion blanking die 精密冲模
MFR=melt flow rate 熔料流动率
MFT=melt flow index 熔料流动指数
handling hole 拉铃孔
stop plate 限位块
linder bush 衬套
spacer block(plate) 垫块,方铁
back-up ring 背位环
standoff 限位块
American Safety Hoist Rings. 英制安全吊装环
Mechanical Properties 机械性能
Tensile Strength(MPa) 抗拉强度
elongation 延伸率
hardness(Brinell) 硬度
shear stength(MPa) 剪切力
impact strength 冲韧性
Physical Properties 物理性能
solidification shrinkage 凝固收缩率
freezing range 凝固与熔范围
thermal expansion 热膨胀系数
specific heat 比热
thermal conductivity 热导率
electrical conductivity 电导率
micro-structure 金相分析
hot work tool steel 热作钢
circular motion 环形运动
variable 变数,参数
graphics window 图形窗口
45 degree entry and a zero degree exit. 进刀口45度,退刀口0度
runner stripper plate 脱料板
stripper plate 活动板
spacer rock(risers) 间隔板
stage ejector 顶棍
sprue puller insert 扣针导套
guide strip 行位后板
afdek plate 挡尘板
side gate 大水口
pinpoint gate 细水口
SHCS 杯头螺丝
FHCS 平头螺丝
set screw 无头螺丝
ball catch 波子螺丝
wedge 行位较杯
gib 线条,(撑鸡的导轨)
latch 拉杆
clamp 码仔
spring guide pin 弹弓导柱
steel pad disc 橙仔方
ejector cam insert 斜顶块
(screw) nut 螺母
taper 嗲把/ 斜度
taper interlock 嗲把锁
texture 花纹
toggle-lok 回撞装置
top clamping plate 顶码板
unified national coarse (UNC) 美制螺丝(粗牙) unified national fine (UNF) 美制螺丝(幼牙) set screw 喷头螺丝
side gate 大水口
slide retainer 行位管位
water junction 喉咀
spacer block 登仔
jiffy-matic socket 喉咀套
jiffy-tite plug 喉咀公
spring plunger 弹弓座
sprue puller 勾针/勾粒
spring washer 弹簧塑圈
stepped ejector pin 有托顶针
strippers plate 推板/细水口板submarine gate 潜水口
support pin 拉杆
support plate 暗板
surface finish 光洁度
alignment strip 斜锁
angle pin 斜针
fan gate 扇形入水
fillet 圆口
ball catch 弹弓波子
blade ejector 扁顶
bottom clamping plate 底码板
free length 自然长度
bridge piece 水口铁
helix spindle 锅杆
hose clip 水喉箍
bubbler 隔气运水
jiggle 斜顶
jiggle witness line 斜顶片位置
center distance (CRS) 山打距离(中心线距离)
clamp 码仔
contour 外形
leader pin 导针
location ring(flange) 法兰
counterbore 拔头,介子托
mock-up;prototype 手办
die cast 合金压铸
national pipe thread(NPT) 美制喉牙
overflow 垃圾位
ejection sleeve 司筒,顶套
epoxy 胶样
pin point gate 细水口
pressure plug 喉塞
pressure spring 压力弹簧
parting line flash 披锋
burned 烧黑
underfilled 缺料
insert mismatch 镶件夹口
ejector pins not flush 顶针有高低
ejector pins skid 顶针滑动
insert flash 镶件披锋
pressure transducer 压力探测头
hydraulic schematic 油积筒油路接驳图
jiffy connector recessed 安装喉嘴后不可突出模胚
knock out pullback stud -flush with clamp plate 顶棍镶件与底板有否空间safety switches 限位开关
stop block 限位块
safety strap 安全带
drool bushing 防漏胶套筒
insert mismatch 镶件夹口
EDM visible 明显火花纹
lifter scrapes 斜顶拖花
short shots 走水不齐
wall stock 料位厚薄
knit lines 走水纹
stress marks 夹水纹
uneven fill pattern 走水不平行
drag marks 拖花
sprue pretrusion 唧嘴突出高度
sprue orifice and radil size 唧嘴R尺寸sprue bushing-keyed 唧嘴有管钉
English Chinese
program name 产口名称
part name 零件名称
tool name 模具名称
tool source 模具来源
tool steel 模具钢材
resin 塑料
program number 产品编号
part number 零件编号
tool number 模具编号
customer 客户名称
No of cavities 内模编号
machine size 啤机吨数
drum miller 鼓形铣床
duplex horizontal miller 复式卧铣床face miller 端面铣床
grinding miller 研磨机
plain miller 平面铣床
planer-type miller 刨式铣床
rack miller 齿条铣床
slab miller 大型平面铣床
slot miller 键槽铣刀
spline miller 花键铣刀
thread miller 螺纹铣刀
vertical miller 立式铣刀,立辊,立辊轧机endmill 立铣刀
plastic mould steel 塑料模钢
cold work steel 冷作钢
hot work steel 热作钢
high speed steel 高速钢
electric magnetic clutch 电磁离合器
pad printer 移印机
screen printer 丝印机
hot stamper 烫印机
solid carbide slitting saw 钻石钢锯片
convex cutter 凸锣刀片
concave cutter 凹锣刀片
side&face cutters,staggered teeth 正侧双用镶钻石钢锣刀end-mill 锣刀
semi-rod 半圆刀
split double end 双头刀
single end 单头刀
2-flute 两辨
3-flute 三辨
4-flute 四辨
reamer 直拈
centre drill 中心钻
solid carbide drill 钻咀
zinc ingot 锌锭
aluminium ignot 铝锭
tin ignot 锡锭
heater cement 发热管的结合剂
heater groove 发热管槽
spacer rail 介子座
cross pin 十字头销
nozzle plate 射嘴板
nozzle seat 热嘴
addendum 齿冠
dedendum 齿根
air compressor 空气压缩机
air exhauster 抽气机
air intake 进气口
air seal 空气隔离层
塑胶模具类中英文对照专业术语工程部/ Design department: 1) Designer - 设计师。 2) Assembly drawing - 模具组装图。 3) Mold layout - 模具结构图。 4) 2D product drawing - 2D产品图。 5) 3D product data - 3D产品数据。 6) Part drawing - 散件图。 7) Insert molding - 镶件模。 8) 2 color mold / Double injection tool - 双色模。 9) Hydraulic system - 油/水压系统。 10) Parting line - 分模线。 11) Air venting - 排气槽。 12) Cooling system - 冷却系统。 13) Screw - 镙丝。 14) Hot runner system - 热流道。 15) Valve gate - 伐针入水口。 16) Fan gate - 扇型入水口。 17) Pin point gate - 针点进胶。 18) Moon gate / Banana gate - 香蕉，象牙入水口。 19) Submarine gate - 潜水口。 20) Injection machine tonnage - 注塑机吨数。 21) Number of cavity - 穴数。 22) Steel - 钢材。 23) Copper - 铜。 24) Tungsten copper - 钨铜。 25) Beryllium copper - 铍铜。 26) Hardening - 加硬/淬火。 27) Tempering - 回火。
模具方面的中英文对照【二】 2007-05-09 22:35 塑料成型模具的主要设计要素 脱模距 stripper distance 脱模斜度 draft 投影面积 projected area 最大开距 maximum daylight; open daylight 闭合高度 mould-shut height 抽芯距 core-pulling distance 抽芯力 core-pulling force 脱模力 ejector force 开模力 mould opening force 模内压力 internal mould pressure; cavity pressure 成型压力 moulding pressure 背压环 back-up ring 1 bar = 14.5psi 高压接头 bite type fitting 液压马达 hydraulic motor 冷却水流量计 waterflow regulator 打磨器材 abrasive material 打磨砂轮 grinding wheels 切割砂轮 cutting wheels 码模夹(注塑机使用) mould clamps; lifting clamps 小五金工具 piping tools 高压力软管 high pressure hose 风管,水软管 air .water hose 高压油表 pressure gauge 压力油喉 hydraulic hoses 光塑检测 photoelastic testing 吹塑模 plastic blow mould 注塑模 plastic injection mould 冲扎复合模 blank & form compound die 精密冲模 precision blanking die 熔料流动率 MFR=melt flow rate 熔料流动指数 MET=melt flow index 推板导柱 guide pin for ejector plater 座板 clamping plate 垫块 space block(plate) 推板 ejector block(plate) afdek plate 档尘板 guide stripe 行位后板 cavity sub-insert 前模镶件 core sub-insert 后模镶件 sprue puller insert 扣针镶件
AD-Diameter The tread diameter at the centerline of the tread (EU); also: "T-Diameter"(GT) AD直径：指胎面中心线直径（EU）。又叫T直径（GT） Auto-lock Ear A Lug on the cone ring used to mount the mold/container in the top half of a 60“ NRM Auto-lock press. 导环上的突缘，用于和60“ NRM Auto-lock 硫化机上半部连接。 Bead Ring The tire bead forming ring (also: toe ring) 钢圈，也称toe ring Bead Ring Register The landing and tapered seat that the bead ring fits into 钢圈配合：侧板上，和钢圈配合的平面及锥面 Bottom Container Plate The plate that the bottom sidewall plate is bolted to 模壳底座 Bottom Container Plate Lifting Lug A lug attached to the Bottom Container Plate with Horizontal holes used for lifting. 模壳底座吊耳：装配在底座上、有水平的孔，用来吊装的吊耳 Bottom Container Plate Dowel Pin Lug A lug attached to the Bottom Container Plate that supports the Dowel Pin Bushing. 装配在底座上，用来支承定位销套的突缘 Bottom Container Plate Hold Down A lug that is used to fix the Bottom Plate in the Press. 用来将底座装配在硫化机上的突缘 Breaker Hook A hook fixed to the bottom of the tread segment that catches the bottom container plate only when the segment will not release from the tire during de-molding. 分离钩：固定在花纹块底部的钩子，轮胎硫化完后若花纹块不能跟轮胎分离，就用此钩抓住模壳底座帮助花纹块和轮胎进行分离。
保留建筑EXISTING BUILDING 已建建筑AS-BUILT 新建建筑NEW BUILDING 道路ROADWAY 绿化LANDSCAPE 汽车流线CAR ACCESS 行人流线WALK ACCESS 消防车流线FIRE BRIGADE ACCESS 货车流线TRUCK ACCESS 自行车流线BICYCLE ACCESS 消防车道FIRE WAY 主出入口MAIN ENTRENCE 保安室NO.1 GUARD HOUSE 主出入口 1 EXIT 1 地下车库出口BASEMENT PARKING EXIT 自行车停车场BICYCLE PARKING 自行车停车位BICYCLE STAND 总停车位CAR PARK 其中INCLUDE 地上停车位AT-GRADE CAR PARK 地下停车位UNDERGROUND CAR PARK 空调管线AIR CONDITIONING 强电电缆LV 10KV 弱电电缆ELV 电缆10KV HV 供水管SUPPLY WATER 污水管WASTE WATER 雨水管RAIN WA TER 消防管线FIRE HYDRANT 西门子(中国)总部SIEMENS CENTER BEIJING 说明NOTE 1.本图依据城市道路高程及市政管线标高等 资料并结合场地排水、场地地形、土方平衡 等因素进行竖向设计。 1.THE DRAWING WITH "VERTICAL HEIGHT DESIGN" IS BASED ON CITY ROADWAY ENGINEERING WITH CITY BUREAU PIPELINE HEIGHT INDICATION DOCUMENT SITE DRAINAGE, SITE TOPOGRAPHY, AND SOIL BALANCE ARE INCORPORA TED INTO THE DESIGN. 2.本图所用坐标系统为北京市城市坐标系统， 所用高程为规划高程。 2.THE DRAWING INCORPORATES BEIJING CITY COORDINA TE SYSTEM. ALL THE INDICATIVE HEIGHTS ARE PLANNING HEIGHTS. 3.图中道路横坡按1.5%设计，最小纵坡为 0.2%。 3.ALL THE ROADWAY INDICATED ON THE DRAWING IS BASED ON 1.5%HORIZONTAL SLOPE.THE SMALLEST VERTICAL SLOPE IS 0.2%. 4.图中标注单位均为米。 4.BASIC UNIT OF MEASUREMENT IS METRIC. 保留建筑EXISTING BUILDING 已建建筑AS-BUILT 新建建筑NEW BUILDING 道路ROADWAY 绿化LANDSCAPE 地下车库入口BASEMENT PARKING ENTRANCE 坡道RAMP 消防车道FIRE WAY 紧急出口EMERGENCY EXIT 3 2#保安室NO.2 GUARD HOUSE 停车场PARKING 工程地点位置图SITE LOCATION 图例LEGEND 自行车停车场BASEMENT EXIT 1 BICYCLE PARKING H=4.8M 地下室出入口 2 BASEMENT EXIT 2 主出入口 4 PARKING EXIT 4 主出入口 1 EXIT 1 道路ROADWAY 实土绿化COMPACTED SOIL LANDSCAPE 敷土绿化DEPOSITED SOIL LANDSCAPE 通风井VENTILATION OUTLET 冷却塔(两组) COOLING TOWER(2 UNITS) 紧急通道EMERGENCY ACCESS 绿地LANDSCAPE 围挡BARRIER 停车场PARKING 地下车库出入口PARKING ENTRENCE 主出入口MAIN ENTRENCE 1#保安室NO.1 GUARD HOUSE 说明NOTE 1.图中所标注建筑尺寸为外墙皮尺寸. 1.DIMENSIONS INDICA TED ON THE PLAN ARE MEASURED TO EXTERNAL EDGE OF THE BUILDINGS. 2.建筑的坐标点为轴线交点坐标. 2.ARCHITECTURE COORDINATES = INTERSECTION OF THE BUILDINGS AXIS. 3.本图以米为单位,%%P0.000相当于绝对标 高37.75. 3.METRIC SYSTEMS ARE THE UNIT OF MEASUREMENT. 4.本项目对周边现状及规划建筑日照影响满 足相关法规及规范要求, 即日照时数满足大寒日最低2小时的日照要 求. 4.DESIGN COMPLIES WITH LOCAL REGULATION OF SUN SHADING TO NEIGHBORHOOD. 保留建筑面积EXISTING BUILDING 容 积率PLOT RATIO 建筑占地面积BUILDING COVERAGE 建筑密度BUILDING DENSITY 绿化面积GREEN AREA 绿地率GREEN RATIO 总人数TOTAL USERS 机动车停车位CAR PARK 地上其辆65 65 LOTS ABOVE GROUND 地下辆564 中INCLUDE UNDERGROUND 564 LOTS 200辆自行车停车位BICYCLE STAND 200 LOTS 地上辆200 200 LOTS ABOVE GROUND 服务中心SERVICE CENTRE 1号办公楼OFFICE 1 地上
碳钢弯头 Carbon Steel Elbow 不锈钢弯头 Stainless Steel Elbow 高压弯头 High-Pressure Elbow 同心异径管 Concentric Reducers 偏心异径管 Eccentric Reducers 高压异径管 High-pressure Reducers 不锈钢等径三通 Stainless Straight Tee 碳钢等径三通 Carbon Straight Tee 不锈钢等径四通 Stainless Straight Cross 高压三通 High-pressure Tee 锻制三通 Forged Tee 异径接头 Template 管帽 Caps 法兰flange 长径和短径弯头 long and short radius elbows 同心和偏心异径接头 concentric and eccentric reducers 等径和异径三通 straight and reducing outlet tees 大小头 CONCENTRIC REDUCER 相等的三通Tee Equal 等径三通Straight Tee 异径三通Reducing Tee 等径四通Straight Cross 90°短半径弯头90°SS Elbow(SR) U型管Return Bend
90°长半径弯头90°SS Elbow (LR) 高压厚壁弯头Thickness Elbow 盲法兰Blank Flange 弯管Bends 翻边stub ends 异径接头reducers 公称通径 nominal diameter 外径(mm) outside diameter 中心距至端面的距离 center to end 理论重量(kg/pcs) approx weight 类种description 标准Standard 类型Design 材质Material 双丝头 Nipple 同心异径短节 SWAGE Nipple 活接头 Union PLUG HEX HEAD六角管堵 PLUG HEX HEAD SCRD六角螺纹管堵 MPT螺纹 RC螺纹螺桩 stud SWAGE (CONC)同 心异径短节 单承口管箍 Half-Coupling 异径管箍Coupling, Reducing 盲板 Blind Flange 带双圈的盲板spectacle blind 偏心的Ecentric 等径直通equal coupling 内牙直通 female coupling 外牙直通 straight tube with outside 90等径弯头 90 equal elbow 45等径弯头 45 equal elbow
模具名词中英文对照表序号中文名英文名 1一、水口gate 2进水位gate location 3水口形式gate type 4大水口edge gate 5细水口pin-point gate 6水口大小gate size 7转水口switching gate 8唧嘴口径sprue diameter 9二、流道runner 10热流道hot runner 11冷流道cold runner 12唧嘴直流direct sprue gate 13圆形流道round runner 14模流分析mold flow analysis 15流道平衡runner balance 16热嘴hot sprue 17热流道板hot manifold 18发热管cartridge heater 19探针thermocouples 20插头connector plug 21插座connector socket 22密封/封料seal 23三、运水water line 24喉塞line pug 25喉管tube 26塑胶管plastic tube 27快速接头jiffy quick connector plug 28四、模具零件mold components 29三板模three-plate mold 模具名词中英文对照表 序号中文名英文名 30二板模two-plate mold 31边钉/ 导边leader pin /guide pin
32边司/ 导套bush in g/guide bush ing 33顶针板ejector retainer plate 34托板support plate 35螺丝screw 36管钉dowel pin 37开模槽ply bar score 38内模管位core/cavity inter-lock 39顶针ejector pin 40司筒ejector sleeve 41司筒针ejector pin 42推板stripper plate 43缩呵movable core 44扣机（尼龙拉勾）n yl on latch lock 45斜顶lifter 46模胚（架）mold base 47母模cavity in sert 48公模core insert 49行位（滑块）slide 50 镶件in sert 51压座/斜鸡wedge 52耐磨板/ 油板wedge wear plate 53压条plate 54撑头support pillar 55唧嘴sprue bushing 56挡板stop plate 57定位圈locating ring 58锁扣latch 模具名词中英文对照表 序号中文名英文名 59扣鸡parti ng lock set 60推杆push bar 61栓打螺丝S.H.S.B 62顶板ejector plate 63活动臂lever arm
dowel pin 定位梢 draft 拔模锥度 draw bead 张力调整杆 drive bearing 传动轴承 ejection pad 顶出衬垫 ejector 脱模器 ejector guide pin 顶出导梢 ejector leader busher 顶出导梢衬套ejector pad 顶出垫 ejector pin 顶出梢 ejector plate 顶出板 ejector rod 顶出杆 ejector sleeve 顶出衬套 ejector valve 顶出阀 eye bolt 环首螺栓 filling core 椿入蕊 film gate 薄膜形浇口 finger pin 指形梢 finish machined plate 角形模板 finish machined round plate 圆形模板fixed bolster plate 固定侧模板flanged pin 带凸缘销 flash gate 毛边形浇口 flask 上箱 floating punch 浮动冲头 gate 浇口 gate land 浇口面 gib 凹形拉紧楔 goose neck 鹅颈管
guide bushing 引导衬套 guide pin 导梢 guide post 引导柱 guide plate 导板 guide rail 导轨 head punch 顶头冲孔 headless punch 直柄冲头 heavily tapered solid 整体模蕊盒hose nippler 管接头 impact damper 缓冲器 injection ram 压射柱塞 inlay busher 嵌入衬套 inner plunger 内柱塞 inner punch 内冲头 insert 嵌件 insert pin 嵌件梢 king pin 转向梢 king pin bush 主梢 一、入水：gate 进入位：gate location 水口形式：gate type 大水口：edge gate 细水口： pin-point gate 水口大小：gate size 转水口：switching runner/gate 唧嘴口径：sprue diameter 二、流道: runner 热流道：hot runner, hot manifold 热嘴冷流道: hot sprue/cold runner
常用原材料英文缩写与中文名称对照表A 英文缩写全称 A/MMA 丙烯腈/甲基丙烯酸甲酯共聚物 AA 丙烯酸 AAS 丙烯酸酯-丙烯酸酯-苯乙烯共聚物 ABFN 偶氮(二)甲酰胺 ABN 偶氮(二)异丁腈 ABPS 壬基苯氧基丙烷磺酸钠 B 英文缩写全称 BAA 正丁醛苯胺缩合物 BAC 碱式氯化铝 BACN 新型阻燃剂 BAD 双水杨酸双酚A酯 BAL 2，3-巯(基)丙醇 BBP 邻苯二甲酸丁苄酯 BBS N-叔丁基-乙-苯并噻唑次磺酰胺 BC 叶酸 BCD β－环糊精 BCG 苯顺二醇 BCNU 氯化亚硝脲 BD 丁二烯 BE 丙烯酸乳胶外墙涂料 BEE 苯偶姻乙醚 BFRM 硼纤维增强塑料 BG 丁二醇 BGE 反应性稀释剂 BHA 特丁基-4羟基茴香醚 BHT 二丁基羟基甲苯 BL 丁内酯 BLE 丙酮-二苯胺高温缩合物 BLP 粉末涂料流平剂 BMA 甲基丙烯酸丁酯 BMC 团状模塑料 BMU 氨基树脂皮革鞣剂
BN 氮化硼 BNE 新型环氧树脂 BNS β－萘磺酸甲醛低缩合物 BOA 己二酸辛苄酯 BOP 邻苯二甲酰丁辛酯 BOPP 双轴向聚丙烯 BP 苯甲醇 BPA 双酚A BPBG 邻苯二甲酸丁(乙醇酸乙酯)酯 BPF 双酚F BPMC 2-仲丁基苯基-N-甲基氨基酸酯 BPO 过氧化苯甲酰 BPP 过氧化特戊酸特丁酯 BPPD 过氧化二碳酸二苯氧化酯 BPS 4，4’-硫代双(6-特丁基-3-甲基苯酚) BPTP 聚对苯二甲酸丁二醇酯 BR 丁二烯橡胶 BRN 青红光硫化黑 BROC 二溴(代)甲酚环氧丙基醚 BS 丁二烯-苯乙烯共聚物 BS-1S 新型密封胶 BSH 苯磺酰肼 BSU N，N’-双(三甲基硅烷)脲 BT 聚丁烯-1热塑性塑料 BTA 苯并三唑 BTX 苯-甲苯-二甲苯混合物 BX 渗透剂 BXA 己二酸二丁基二甘酯 BZ 二正丁基二硫代氨基甲酸锌 C 英文缩写全称 CA 醋酸纤维素 CAB 醋酸-丁酸纤维素 CAN 醋酸-硝酸纤维素 CAP 醋酸-丙酸纤维素 CBA 化学发泡剂
MENU 冷菜Cold Dish 白切鸡Boiled Chicken with Sauce 川北凉粉Clear Noodles in Chili Sauce 夫妻肺片Pork Lungs in Chili Sauce 酱香猪蹄Pig Feet Seasoned with Soy Sauce 老醋泡花生Peanuts Pickled in Aged Vinegar 泡椒凤爪Chicken Feet with Pickled Peppers 五香牛肉Spicy Roast Beef 盐焗鸡Baked Chicken in Salt 炸花生米Fried Peanuts 酱猪肘Pork Hock Seasoned with Soy Sauce 凉拌黄瓜Cucumber in Sauce 糖拌西红柿Tomato Slices with Sugar 糖蒜Sweet Garlic 热菜Hot Dishes 东坡方肉Braised Dongpo Pork 鱼香肉丝Yu-Shiang Shredded Pork 糖醋排骨Sweet and Sour Spare Ribs 毛家红烧肉Braised Pork，Mao’s Family Style 红烧狮子头Stewed Pork Ball in Brown Sauce 回锅肉片Sautéed Sliced Pork with Pepper and Chili 京酱肉丝Sautéed Shredded Pork in Sweet Bean Sauce 酸豆角肉沫Sautéed Sour Beans with Minced Pork 杭椒牛柳Sautéed Beef Filet with Hot Green Pepper 青椒肉丝Sautéed Shredded Pork with Green Pepper 水煮牛肉Poached Sliced Beef in Hot Chili Oil 葱爆羊肉Sautéed Lamb Slices with Scallion 红焖羊排Braised Lamb Chops with Carrots 烤羊腿Roast Lamb Leg 手扒羊排Grilled Lamb Chops 烤羔羊Roasted Lamb
LN3--PU/Phylon/Rubber Process Contents for these three sections of English Version PFC: ?Phylon Work Sheet PH数据表 ?Components Specification Sheet(Phylon) 部件明细单(Phylon)?Component Specification Sheet Set Up(Phylon) (此部分无中文) ?Phylon Midsole Specifications PH全插规格 ?Phylon Preform Specifications PH粗胚规格 ?Preform Drawing 粗胚图 ?Component Specification Sheet Set Up(PU) (此部分无中文) ?PU Midsole Specifications PU全插规格 ?PU Midsole Specifications II PU数据表 ?Components Specification Sheet(PU) 部件明细单(PU) ?PU Midsole Pouring Specification PU灌注明细 ?Outsole Color Schedule 本底颜色明细 ?Outsole Preform Specifications 本底粗胚规格 ?Outsole Pressing Process 本底压制流程 ?Outsole Degreasing Process 本底水洗流程 ********************************************************************* ΦPU Section ΦPU部分 ********************************************************************* air bag schedule 空气袋分段 specific instructions 特别说明 air bag diagram 空气袋图示 hardness(skin on) 硬度（带皮） density 密度 elongation 延伸率 tear 撕力 tensile 拉力 split tear 撕裂 painting 喷漆 MCS number 材料编号 mold release agent 脱模剂 polyurethane 聚安脂 polyester 聚脂 Density must be within NIKE spec and follow weight chart 密度必须符合NIKE要求及重量表 No dirty midsole sidewalls yellowing or poor cosmetics due to mold condition. 无因模具造成的边墙黄变及外观不良。 Correct molded or painted colors per NIKE confirmation. 根据NIKE的确认，成型材料及喷漆颜色正确。 Correct top/bottom edge trimming within 1mm width allowance. 正确修边上部及底部边缘，允许1mm余量。 No larger than 5mm diameter internal air voids.(checked by light table)
中英名詞對照 一.劃 一般商業用模座：Commercial die set 二.劃 V字形靠柵：V-gaging 三.劃 1.工作單：Operation sheet 2.三角形沖片：Triangular blank 3.小沖床沖模：Sub-press die 4.工作流程單：Route sheet 5.下驅動沖床：Underdrive press 6.三角形打料板：Knockout plate spider 7.工具校驗部門：Tool inspection depart 四.劃 1.分圓：Detail drawing 2.止動銷：Dutchman 3.雙行排列：Layout double-raw 4.分裝模體：Split die block 5.方頭駐螺：Square-head set screw 6.中心莰入件：Center insert 7.水硬工具鋼：Water hardening tool Steel 1.尺寸與注記：Dimensions and notes 2.六方埋頭螺絲：Socket cap screw 3.孔徑尺寸注記：Dimension of hole 4.手動定位裝置：Finger stop 5.雙排沖切設計（排列）：Double-raw layout 五道次沖切排列：Rive-station layout 五.劃 1.切圓：Cutting ring 2.切邊：Trimming 3.打料桿：Knockout rod 4.避位：Stiffening 5.半銅模座：Semi-steel die set 6.另件布置：Part layout 7.引伸沖模：Dies drawing 8.皮料加工：Finish of sheet 9.打料柱塞：Knockout plunger 10.打料裝置：Knockouts 11.可卸道筒：Demountable guide bushing 1.切斷沖模：Gutoff die 2.切邊裕度：Allowance or trimming 3.切邊沖模：Trimming die 4.平頭埋頭螺：Flat head screw socket 1.四道柱沖床：Four-post press 2.四道柱模座（沖模模座）：Four-post die sct 1.引伸零件展開：Development of drawn parts 1.半陰式定位銷：Semi-blind dowel 2.平行四邊形沖片：Parallelogram shaped blank 六.劃 1.沖扁（沖鍛）：Stamping 2.沖頭把：Punch shank 3.先道桿：Pilot 4.沖片毛邊：Burrside of blank 5.沖片加工：Blanking 6.沖片沖頭：Blanking 7.沖切長口：Slitting 8.沖孔沖床：Punch press 9.沖孔沖頭：Piercing punch 10.沖孔沖模：Die piercing 11.沖片沖模：Blanking die 12.沖片設計（安排）：Blank layout 13.沖片面積：Area of blank 14.沖床附件：Press accessories 15.沖床動力：Power for press 16.沖床構造：Press construction 17.自動沖床：Automated press 18.先道桿簧：Spring pilot 19.曲軸總成：Crankshaft assembly 20.沖模套筒：Die bushing 21.沖模間隙：Die Clearance 22.沖模截塊：Die section 23.沖模模座：Die set 24.沖彎公式：Bend formula
查看文章模具方面的中英文对照【二】2007-05-09 22:35 塑料成型模具的主要设计要素脱模距stripper distance 脱模斜度draft 投影面积projected area 最大开距maximum daylight;open daylight 闭合高度mould-shut height 抽芯距core-pulling distance 抽芯力core-pulling force 脱模力ejector force 开模力mould opening force 模内压力internal mould pressure;cavity pressure 成型压力moulding pressure 背压环back-up ring 1 bar = 14.5psi 高压接头bite type fitting 液压马达hydraulic motor 冷却水流量计waterflow regulator 打磨器材abrasive material 打磨砂轮grinding wheels 切割砂轮cutting wheels 码模夹（注塑机使用） mould clamps; lifting clamps 小五金工具piping tools 高压力软管high pressure hose 风管,水软管air .water hose 高压油表pressure gauge 压力油喉hydraulic hoses 光塑检测photoelastic testing 吹塑模plastic blow mould 注塑模plastic injection mould 冲扎复合模blank & form compound die 精密冲模precision blanking die 熔料流动率MFR=melt flow rate 熔料流动指数MET=melt flow index 推板导柱guide pin for ejector plater 座板clamping plate 垫块space block(plate) 推板ejector block(plate) afdek plate 档尘板guide stripe 行位后板cavity sub-insert 前模镶件core sub-insert 后模镶件sprue puller insert 扣针镶件 stage ejector 顶棍
"R，L Co.,Ltd" 模具常用术语中英文对照 模芯Parting Core 局部视图Partial View 冷料# Cold Slag 线切割 Wire 轮廊Contour 螺纹孔 Tapping Hole 连接件 Fittings 斜针Angle Pin 接合Engage 替换镶件Interchangeable Mold Inserts 指定吨位的注塑机Specific Press 水嘴接头Water Fittings 螺纹Eyebolt Thread 回针Stop Pin 二级顶出针Sub-Leaderd Pin 镶件Mold Insert 加硬Harden 唧嘴Sprue 设计筒图Design Preliminary 名称块表Title Block 版本标识Revision Level 材料清单Stock List 制模Build Mold 手动滑块Hand Slide 漏水测试Leak Test 流道排气Runner Vents 抛光Draw Polish 侧抽芯 Side Action 加强筋 Reinforcing
三角撑 Gusset 柱子Bossed 出模斜度Draft 外廊Contour 落单会议Kick-Off Meeting 装卸孔 Handling Hole 运输安全带Moldstrap 码模槽 Clamp Slot 撑头Support Pillar 螺牙1/2-13 Eye Bolt 1/2-13Tap 导柱位 Leader Pin Location 耐落胶 Teflon Paste 偏移量 Offset 水塞Water Line Plug 撬模脚 Ppy Slot 重新加工Reworked 配件Components 补偿Compensation 平面度 Parallel 倒角Chamfer 模胚Mold Base 热嘴Hotnozzle 火花机 Edm 熔接线 Weildline 压机Press 晒纹Texturing 梯形Trapezoid 凸缘、法兰Flange 方铁Spacer Block 顶针板Ejector Plate 顶针底板Ejector Retainer Plate 垫板Retainer Plate
handbag手提包 hatbox帽盒 cosmetics case 化妆箱 gloves手套 wrist watch手表 belt腰带 pendant项饰 necklace项链 neck scarf围巾 earrings耳环 sun glasses太阳镜 ring戒指 bracelet手链, 手镯 tie领带 cuff links袖扣 ascot宽领带 hair net发网 brush毛刷 nail polish指甲油 cream rinse营养发水 hair spray发胶 powder puff粉扑
face powder粉 compact带镜粉盒 astringent化妆水 perfume香水 skin milk乳液 cold cream油底霜 atomizer喷雾式香水 hand mirror手镜 bobby pin发夹 false eyelashes 假睫毛 lipstick口红 wig假发 tissue面纸 purse手包 brooch胸针 shawl披肩 neckerchief领巾 台湾是中国神圣领土不可分割的一部分Taiwan is an inalienable part of the inviolable territory of China. 〃台湾同胞Taiwan compatriots 〃台湾、香港、澳门保持原有的资本主义制度和生活方式长期
不变Taiwan, Hong Kong and Macao will retain the current capitalist system and way of life for a long time to come. 〃炭疽anthrax 〃踢皮球pass the buck 〃逃废银行债务evasion of repayment of bank loans 〃韬光养晦hide one’s capacities and bide one’s time 〃讨价还价wheel and deal 〃统筹兼顾make overall plans adn take all factors into consideration; overall planning and all-round consideration 〃同乡会an association of fellow provincials or townsmen 〃筒子楼tube-shaped apartment 〃团队精神team spirit; esprit de corps 〃团结就是力量Unity is strength. 〃退耕还林还草grain for green 〃退耕还林还牧convert the land for forestry and pasture 〃鸵鸟政策ostrich policy; ostrichism 〃脱贫致富?cast (shake, throw) off poverty and set out on a road to prosperity? 〃拖欠工资arrears of wage W 〃挖墙脚undermine the foundation of sth.; cut the ground
五金模具常用专业术语中英文对照表 上模座upper die set成型公form punch 脱料板stripper 垫板subplate/backup plate 下模座die plate滑块CAM slider 垫脚parallel 误检misfeeder 托板mounting plate顶料销kick off 初始管位first start pin带肩螺丝shoulder screw 两用销lifter pin氮气汽缸gas spring 弹簧护套spring cage 拔牙螺丝jack screw 侧冲组件cam section 导正装置guide equipment 漏废料孔slug hole刀口trim line 加强装置enhance equipment 入子insert 护套bushing 整形公restrike forming punch 止挡板stop plate 挂台head 扣位pocket of head 导柱guide post 导套guide bushing 油嘴oil nipple 接刀口mismatch/cookie bites 限位块stop block 挡块stopper 浮块lifter 压块keeper 靠块heel 对正块alignment block 简易模prototype tooling 检具gage/checking fixture 料带图strip layout 闭合高度shut hight 俯视图top view 料带strip 公差tolerance 正视图front view 走位travel 避位/空pocket 退磁demagnetization 间隙clearance 真空热外理vacuum heat treatment 镗孔mill hole 表面外理surface coasting 镀钛TD coasting 沉头counter sink 精锣finish mill 线割wire cutting 穿丝孔first wire hole 斜度taper 镭射laser-cut 上夹板/固定座holder/retainer 下模座lower die set 成刑母公forming die
DFM常用中英文对照 15、如果分型面此处，模具上会有尖角和刀口，对模具寿命有影响。 There are sharp edges if we set the parting line here, it will reduce the tool life. 16、此处料厚段差很大，成品表面会有应力痕，建议修改如图示。 The thickness is not equal and it will bring the stress lines on the surface, suggest to improve the part as the picture shown. 17、此大行位上有小行位，开模时小行位需先退，大行位做延时，合模时则相反。 The small slider is inside the big slider, when the mold open, the small slider need to recede first and the big slider have to postpone. When the mold close, it is contrary. 18、此处需做强顶。 This position need to force ejection. 19、由于此处没有足够空间下热咀，所以需做一个柱子进胶。 This position need to make a pole for gating because there have no enough space for hot sprue. 20、沾模， Stick 1.High shrinkage values could indicate sink marks or voids at gate location 高缩水率的产品容易产生缩印，但在浇口附近可以避 免。 2.Welding line on the cosmetic surface 熔接线在外表面 3.Two banana gate was to being confluent in the end of melt flow. 两个香蕉浇口在流动未端熔合。 4.Venting insert here has flash 排气镶件处有飞边 5.Venting gap between inserts is too big 镶件处的排气槽过大 6.Stress mark on the cosmetic surface 产品外表面上有压痕 7.Uneven thickness 不平均的产品壁厚 8.Unreasonable product structure 不合理的产品结构 9.Injection speed is high 注塑压力过高 10.There is black spot on the cosmetic surface 产品外表面上有黑色点 11.There is flash on the product 产品有飞边 12.there is sink mark on the cosmetic surface 产品外表面上有缩痕 13.Gate size is not reasonably 浇口尺寸不合理 14.There is argent spot 这里有亮点（银色斑点） 15.The plastic of first shot didn't meet high temperature. 塑料的第一胶不会有很高的温度。 16.Make sure the core float plate was closed before lifter completely return to correct position 确认lifter完全回位时core侧 浮动板已经复位 17.Make sure the ejector system is smooth 确认顶针系统移动平稳 18.Add early return structure to protect lifter return to correct position 增加先复位机构保护lifter回到正确位置。 19.Propose to add draft on slider side wall and draw polish. 建议增加slider的角度和抛光角度。 20.It is too thin and very difficult to inject fully, and weakness wall will have risk of the part function 该处壁厚过薄而造成很难去 填充完整，薄壁将会有产品功能上的风险。 21.These are will have sink marks due to uneven thickness, propose to reduce plastic. 壁厚不均匀容易产生缩印，建议在该处减胶。 22.These are will have sink marks due to ribs opposite. 正面的筋位易导致背面产生缩印。 23.Please confirm the 3D part thickness whether has including painting thickness or not? 请确认产品的设计是否考虑到油漆的厚 度。 24.Black paint on back side。背面喷黑漆处理。
