FUNCTIONS● Implementation of the entire sound system to provide a standardized,secure and automatic control of power start and shut down.● Effectively to prevent the start and shut down of the equipment which caused the impact and damage to the overall power and speakers.● Control circuits adopt high reliability & digital design, high current relay in output stage and low power-consumption.● 1U and the standard AC power outlet, it's easy to use.FRONT PANEL1. POWER SWITCHPreventing the machine can not be used due to some reason, once press down this switch, all of the power output would be open.2. SEQUENCE CONTROLLER DISPLAYWhen output is connected, the corresponding front code of led lights would be light.3. POWER LIGHTWhen the machine connected to power source, the light would be light.4. ON-OFF SWITCHWhen switch turns on, outputs will be connected from CH1 to CH8, when switch turns off, The output will be disconnected from CH8 to CH1.REAR PANEL1. POWER CORDThe power source of the machine.2. DOWN-LINE PORTTwo or more sets of products could be used through the series connection of this port.3. UP-LINE PORTExpand access interface(function same as down-line port).4. POWER OUTPUTS8-way power output, connect to other device.1. SINGLE DEVICE CONNECTIONUsing one standard CAT-5 cable connects device to computer. Setting computer's IP address 192.168.1.250, Subnet mask's IP address 255.255.255.0; then open PC control software, it will finding new device, click on ”connection”, Once it became to green meaning connected! See shown below.PC SOFTWARE SETTINGS AND MANAGEMENT2. MODIFY IP ADDRESS AND DEVICE NAMEDouble click the device which do want to modification, see picture shown below. Once IP address modified, MAC address will be change automatically. Then click OK, power off the device, then powered up device again.OPERATION1. STARTAfter each inspection confirmed, then connection the power cord to power source, insert the key then clockwise one time, output could be connected from CH1 to CH8, at the same time, the corresponding 8 led light of the front panel will light on in turn.2. SHUTInserting the key and counterclockwise rotation one time, the output will close in turn from CH8 to CH1, at the same time, the corresponding 8 led light of the back panel will off in turn.3. CONTROL PANEL INTRODUCTION(1). Channel testing: Any channels can turn on or off by click on channel number button.(2). Setting for output when powered up:Once selected the output channels with” √” , then click” Submit ”, those channels will be keeping its status at next time of power up. If user wants to modify it, just change the channel # and ” Submit ” again.4. LINK(1). In case of end user wants to having more output channels, then using Link function. It supported maximal 16 device connection together. From first device's RS485(A/B phoenix) to next device, Set host device's toggle switch to “NET” position. Once link is done, PC software will show linked device's ID. See below picture to show three devices worked at link mode. host device's ID was 0, three other devices were 0,1,2.(2). If user wants to monitor each device, using CAT-5 cable connection to HUB, HUB connects to computer, then user choosing any device he wanted, then can monitoring it!(3). Setting for toggle switch of Linked deviceFour digit switch as the ID number for device. ID= 0 means host device, ID > 0 means auxiliary device. Toggle switch at lower position means “1 or ON”, upper position means”0 or OFF”. See examples below:ID (0000)(0001)(0010)(0011)(0100)(0101)(0110)(0111)(1000)(1001)(1010)(1011)(1100)(1101)(1110)(1111)5. EXTERNAL RELAY CONTROLPin 3&4 of phoenix connector supports other equipments controlling by relay function.6. PROTOCOL No ModePort Description UDP 12O1MAIN CONTROLLER12ALL_OPEN<CR>ALL_CLOSE<CR>34EMG_CLOSE<CR>CH_ON [ID=01][1]<CR>CH_OFF [ID=01][1]<CR>5GET_STATUS [ID=01]<CR>RETURE TEXT :[ID=01]:1,1,1,1,0,0,0,0<CR>NoAPPLICATIONSOrder Description ALL OPEN ALL CLOSE EMERGENCY CLOSE SINGLE CHANNEL CONTROL(NEED DEVICES’S ID)GETTING DEVICES’SCHANNEL STATUSEXAMPLE:1.ALL_OPEN<CR>Hexadecimal system：41 4C 4C 5F 4F 50 45 4E 0D 0A.2.ALL_CLOSE<CR>Hexadecimal system：41 4C 4C 5F 43 4C 4F 53 45 OD OA.3.EMG_CLOSE<CR>Hexadecimal system：45 4D 47 5F 43 4C 4F 53 45 0D 0A.4.SINGLE CHANNEL OPEN ORDER(NEED TO KNOW ID OF DEVICE).Example: ID=00, Open channel 1: CH_ON [ID=00][1]<CR>.Hexadecimal system：43 48 5F 4F 4E 20 5B 49 44 3D 30 30 5D 5B 31 5D 0D 0A.5.SINGLE CHANNEL CLOSE ORDER(NEED TO KNOW ID OF DEVICE)Example: ID=00, Close Channel 1: CH_OFF [ID=00][1]<CR>Hexadecimal system：43 48 5F 4F 46 46 20 5B 49 44 3D 30 30 5D 5B 31 5D 0D 0A.6.GETTING CHANNEL STATUS: GET_STATUS [ID=00]<CR>Example: ID=00, getting [ID=00]:[0,0,0,0,0,0,0,0], meaning 8 channels all at closed status, if getting [ID=00]:[1,1,1,1,1,1,1,1], meaning 8 channels all at open status.SPECIFICATIONSOutput ----------------------------------------------------------------------------------------------8 channels Maximum output current of each channel ------------------------------------------------------------- 15A AC input ---------------------------------------------------------------------------------------- 180V-260V AC The time of each channel delay connection or separation --------------------------------------------1S Insulation resistance --------------------------------------------------------------------------------------20MATTACHMENTPlease keep device attaches the user’s manual and power switch’s key. In case of returning to repair or test, please using the original package.SAFETY ADVISEDo not attempt to remove the panel or screws, there is no user parts inside.Please keep far away the source of giving off heat, otherwise that will cause this machine radiation bad.Please using the unit in a dry place and pay attention against moistly, guarantee ventilates good, surrounding non-corrosiveness gas and electric conduction dust.It should be on earth safety and reliable, and make sure the user safety.Please prevent the object or liquid falls into the product, do not put the goods on AC power and equipment that might overflow the liquid.If unit can’t work or other abnormal phenomenon, please refer to the service information. MAINTENANCEWe are responsibility to repair the machine caused by design or bad materials usage in one year, any incorrect operations or else caused damage is not including.This pledge is effective to all our product.The producer retains to this service final right to interpret.OUT OF MAINTENANCEBecause of the accident, the improper using, the mistaken installment or the negligence cause the product damage.Repaired or revised the product without authorization.The series number is unclear, changed or tear up.MEETS THE MAINTENANCE CONDITION:Whatever you are a initial purchase user or second-hand user, so long as in maintenance time, and conforme the maintenance scope, then enjoyed this service.SERVICEWhen you found that your product can not working normally, please refer the user manual to make sure all settings right or not. If you still can not have an answer, please contact the agent which you purchased.IMPORTANT NOTICEIf you are not using the original packages to pack the unit or packing incorrectly, caused damage in trip of return, we are not responsibility to service the unit. Thanks.此产品可以通过网线连接PC软件控制。
