Two or more elements are in series （串联）if they are cascaded or connected sequentially （接顺序连接）and consequently carry the same current（流过相同电流）.
Two or more elements are in parallel （并联）if they are connected to the same two nodes and consequently
have the same voltage across them①.
Note:①：voltage across them表示关于两节点之间的电压， “them”指代“two nodes ”。
12
1.1 Introduction to Circuit Theory text
Elements may be connected in a way that they are either in series or in parallel. In the circuit shown in Fig.1.1, the voltage source and the 5Ω resistor are in series because the same current will flow through ①them.
Since the elements of an electric circuit can be
interconnected in several ways, we need to understand
some basic concepts of network topology. To differentiate between a circuit and ①a network,

Unit 1电气设备概述英文版

Unit 1电气设备概述英文版
Unit 1
Fundamentals of Power Plants and Substations
电厂和变电站基础
1
1 Introduction of Power Plants and Substations电 厂和变电站介绍
1.1 Power systems电力系统 Components of power systems电力系统的组成部分: • Power plants电厂 • Transmission lines 输电线路 • Substations变电站 • Electricity users电力用户 A simple power sythe principles of protection and control.
The secondary electrical connection for circuit breaker control in
a power plant is given here.
13
14
END OF UNIT 1
