SPECIFICATION电源适配器规格书
FOR SWITCHING AC ADAPTER
PRODUCT 产品名称： AC-DC ADAPTER 电源适配器
发行行印印MODEL 产品型号：MTP051CC-0510E
PART NO 产品编号：C109-6234
REV 版本: A1
CUSTOMER 客户 :斯莱普
ISSUE DATE 发行日期： 2013-9-26
受
领
印
栏
*未签回而下订单即视同认可!
工程品管业务发
行
部核刘伟审黄弯经张鑫
署
栏准核办
SHENZHEN MOUNTPOWER INDUSTRY CO., LTD.
No 2, 2Road, XiaoShan Industrial Park, HuangPu, Shajing Town, Shenzhen City, China
TEL: +86- FAX: +86-
Website： NO:C109-6234 A1 PAGE 1 OF 13
3/27/2014
