LED灯光产品介绍

led灯结构原理、用途介绍、具体照明科技目录1结构原理2用途介绍3具体特点4色温颜色5发展历史6应用介绍结构原理LED结构以及发光原理LED（Light Emitting Diode），发光二极管，是一种固态的半导体器件，它可以直接把电转化为光。

LED的心脏是一个半导体的晶片，晶片的一端附在一个支架上，一端是负极，另一端连接电源的正极，使整个晶片被环氧树脂封装起来。

半导体晶片由两部分组成，一部分是P型半导体，在它里面空穴占主导地位，另一端是N型半导体，在这边主要是电子。

但这两种半导体连接起来的时候，它们之间就形成一个P-N结。

当电流通过导线作用于这个晶片的时候，电子就会被推向P区，在P区里电子跟空穴复合，然后就会以光子的形式发出能量，这就是LED发光的原理。

而光的波长也就是光的颜色，是由形成P-N结的材料决定的。

最初LED用作仪器仪表的指示光源，后来各种光色的LED在交通信号灯和大面积显示屏中得到了广泛应用，产生了很好的经济效益和社会效益。

以12英寸的红色交通信号灯为例，在美国本来是采用长寿命，低光效的140瓦白炽灯作为光源，它产生2000流明的白光。

经红色滤光片后，光损失90%，只剩下200流明的红光。

而在新设计的灯中，Lumileds 公司采用了18个红色LED光源，包括电路损失在内，共耗电14瓦，即可产生同样的光效。

汽车信号灯也是LED光源应用的重要领域。

对于一般照明而言，人们更需要白色的光源。

1998年发白光的LED开发成功。

这种LED是将GaN芯片和钇铝石榴石（YAG）封装在一起做成。

GaN芯片发蓝光（λp=465nm，Wd=30nm），高温烧结制成的含Ce3+的YAG荧光粉受此蓝光激发后发出黄色光射，峰值550nm。

蓝光LED基片安装在碗形反射腔中，覆盖以混有YAG的树脂薄层，约200-500nm。

LED基片发出的蓝光部分被荧光粉吸收，另一部分蓝光与荧光粉发出的黄光混合，可以得到得白光。

舞台灯光大功率LED帕灯使用说明一、产品概述二、产品特点1.高亮度LED光源：LED帕灯采用了高亮度的LED灯珠作为光源，提供清晰明亮的光线，确保出色的照明效果。

2.调光性能优秀：LED帕灯具备广泛的调光范围，可实现从0-100%的无级调光，满足不同场景的照明要求。

3.色彩鲜艳丰富：帕灯内置了多个色温可调的光源，通过混色系统能够混合出丰富多样的色彩效果，满足不同灯光需求。

4.独立控制系统：帕灯配备了独立的控制系统，可通过DMX控制信号或手动控制面板进行调光、变色等操作，方便快捷。

5.节能环保：LED帕灯采用高效节能的LED光源，比传统灯光设备的能效提高80%以上，有效节省能源，减少对环境的污染。

三、产品安装1.确保安全：在安装之前，请确保帕灯周围没有易燃物品或其他危险物，以保证安全。

2.固定安装：将帕灯的底座固定在所需安装的位置上，确保帕灯稳固可靠。

3.连接电源：将帕灯的电源线连接到电源插座上，确保灯具能够正常供电。

4.设置调光器：如果需要通过调光信号控制帕灯的亮度，则需要配置相关调光设备，并进行相应的设置。

四、产品使用1.打开电源：将帕灯的电源开关打开，并确保电源指示灯亮起，表示帕灯已经正常通电。

2.控制方式选择：根据需要选择帕灯的控制方式，可以通过DMX信号控制，也可以通过手动控制面板进行控制。

3.调节亮度：通过控制设备，将帕灯的亮度调节到所需的亮度，可以逐渐调整到满意的效果。

4.调节颜色：如果需要调节帕灯的颜色，可以通过控制设备选择相应的色温灯珠或通过混色系统进行色彩混合。

5.设置场景：根据实际演出需求，可通过调节帕灯的位置、角度和光束形状等，在舞台上创造出理想的灯光效果。

五、注意事项1.使用环境：LED帕灯适用于室内使用，使用时避免长时间暴露在潮湿、高温或腐蚀性气体的环境中。

2.避免震动：帕灯在使用过程中需要避免剧烈震动，以免影响照明效果或损坏设备。

3.防水防尘：帕灯具备较好的防水性能，但仍需避免水或灰尘进入灯具内部，以免影响正常使用。

ADVANTAGES• 4 Lighting modes•CCT (Correlated Color Temperature) M ode allows for Bi-Color (Daylight to Tungsten) operation with the addition of plusand minus Green offset• Color Modes•HSI Color M ode allows for full color control over Hue, Saturation and Intensity•Gel Mode allows for a variety of Gels to be selected from the menu •RGBW mode allows independent adjustment of red, green, blue, and white•Effect Mode allows for a variety of cinematic lighting effects to be customized such as Emergency lights, Fire and TV•N o heavy external ballast or restrike period•F licker-free at any frame rate or shutter angle at any intensity level •A C/DC power with DC power via 3-pin XLR. No reduction in intensity•U ltra-smooth dimming from 100% to 0, with no color shift •Integrated DMX (5-pin XLR or RJ45) allows for remote dimming and color control•R obust lightweight metal frame and housing•Standard yoke with Jr Pin for easy mounting and positioning •Incredibly energy efficient, these fixtures draw only 325w nominal •Wireless control via optional Wireless DMX or Bluetooth •Master replica mode - connect multiple lights together and control them all together from one light as the master control 940-1301 US 940-1101 EU 940-1201 UK*Shown with Anton/Bauer Mobile power solution FEATURES•Flexible, modular concept•O ptional Bluetooth and wireless DMX modules allow thebrightness, color and cooling mode to be remote controlled•A bility to stack and gang lights together with optional hardware and yoke •Modern fixture design with integrated power supply•Intuitive and ergonomic controls for dimming, color and fixture set up• Aluminum core construction to provide maximum durability and superior thermal management•Barndoor/honeycomb accessory rails• Durable, industry standard PowerCon locking power connector with ability to daisy chain power•LCD screen displays vital setting and status•Six defined CCT presets plus six user programmable presets•T he Gemini allows for the user presets on Channel A which records color and intensity it also has factory presets on channel “B” with increments from2700K to 6000KIntroducing the Litepanels GeminiThe Litepanels Gemini is a 2x1 LED panel and providing a nice wide soft source of color accurate illumination. Staying true to the Litepanels legacy, the Gemini has accurate full spectrum Daylight and Tungsten lighting. The Gemini also allows for additional quick and easy adjustment by offering full featured 4 lighting modes full color with hue and saturation control all which allow for the intensity to be controlled anywhere from 100%-0 at all times. The Gemini is truly versatile with its manual and remote control via standard DMX 512 protocol or wirelessly with the option of wireless DMX or Bluetooth and can adapt to any lighting situation today’s Cinematographers and lighting professionals will find themselves in. The manual control knobs are sensitive to the speed of rotation and can either be finely tuned or when ramped up can adjust very quickly. With its light weight design, the Gemini allows for additional versatility with mobile power operation via 3pin XLR, making it a perfect location light.GEMINI SPECSSize:25 x 6.5 x 12.5” / 63.5 x 16.5 x 31.8 cmWeight:22.2 lbs / 10.1 kgPower Requirements:28V DC / 100-240VACMaximum Power Draw:325w nominal 350w MaxPower Supply: 28V DC Internal power supplyCRI/TLCI: 97 Daylight 99 TungstenIncludes: Fixture, Yoke, Internal Power Supply, PowerCon Power Cord GEMINI ACCESSORIES• 4-way Barndoors (900-3603)• 60° Honeycomb Grid (900-3602)• Snap Bag Softbox (900-0035)• direct fit 40° Snapgrid (900-0036)• 40° SnapGrid for snapbag soft box (900-0038)• Pole operated yoke (900-3616)• 3-pin XLR Battery Cable (410-0095)• PowerCon bare ends cord (411-0059)• Wireless DMX dongle (900-3601)• Bluetooth Dongle (MLLBTDONGLE) • Road case (900-3615)• Fixture Cover (900-3614)• Stacking Kits•Dual (900-3604)•Quad (900-3605)PHOTOMETRICS Beam Angle 93° / Field Angle 157°Gemini 2x1 Soft Panel (5600K): CCT=D5614 (-0.7)Gemini 2x1 Soft Panel (3200K): CCT=P3239 (-0.1)TLCI-2012 : 97(D5614)TLCI-2012 : 99(P3239)Close-up of the Gemini Manual controls and display。

创意灯光LED灯产品说明书一、产品概述创意灯光LED灯是一种高效节能的灯具，采用最新的LED技术，具有卓越的照明效果和创新的设计元素。

本产品说明书旨在向用户提供全面的产品信息，以便更好地了解和使用创意灯光LED灯。

二、产品特点1. 高亮度：创意灯光LED灯采用高亮度的LED芯片，具有出色的照明效果，能够提供明亮而均匀的光线。

2. 节能环保：LED技术具有低能耗、高光效、长寿命等特点，相比传统灯具，能够节省更多的能源并减少环境污染。

3. 多种灯具类型：创意灯光LED灯提供各种类型的灯具，包括吊灯、台灯、壁灯等，满足不同场所和需求的照明要求。

4. 创意设计：本产品注重设计，结合了时尚元素和个性化的创意，能够为用户创造出独特而舒适的照明环境。

5. 轻松安装：创意灯光LED灯采用简单的安装方式，用户可以方便地安装和拆卸灯具，节省时间和精力。

三、产品规格1. 光源参数：- LED类型：高亮度LED- 光色：暖白光、自然白光、冷白光（可选）- 色温范围：2700K-6500K2. 功率参数：- 功率：根据不同型号而定（具体参数请参照产品实物标识）3. 使用寿命：- 平均寿命：50000小时- 开关寿命：10000次4. 外观尺寸：- 根据不同灯具类型和设计风格，外观尺寸有所差异，请参照产品实物标识或咨询客服获取详细信息。

四、可选配件1. 遥控器：部分型号的创意灯光LED灯可选配遥控器，用户可以通过遥控器调节灯光亮度、色温和灯光效果。

五、使用注意事项1. 请勿将创意灯光LED灯安装在潮湿或易燃的场所。

2. 在安装和拆卸灯具时，请先断电操作，以确保安全。

3. 创意灯光LED灯为室内使用设计，避免在户外或潮湿环境下使用。

4. 清洁灯具时，请关闭电源并使用干布进行擦拭，避免使用含有腐蚀性物质的清洁剂。

六、售后服务1. 本产品提供1年质保服务，自购买日起计算。

2. 如在质保期内出现非人为损坏的质量问题，请联系我们的售后服务中心进行维修或更换。

Safe. Reliable. Efficient LED lighting solutions for harsh & heavy industrial areasSafe. Reliable.Efficient.LED solutions for harsh and heavy industrial environmentsPower generation. Food processing. Waste water treatment. Pulp and paper mills. Shipyards and ports. These arearound-the-clock operations where employee safety and zero downtime are criticalrequirements. Y ou need to maximize your efficiency and minimize the risk of damage to equipment or personnel. Y ou need a partner like Eaton.Eaton offers a large portfolio of innovative and reliable LED products for non-hazardous, industrial applications. We utilize more than 100 years of lighting expertise to optimize the benefits of LED technology to offer the safest and most reliable LED luminaires on the market today. These luminaires are engineered to thrive where vibration, corrosion, moisture, dust and extreme temperatures exist.With its Crouse-Hinds Series LED luminaires, Eaton can deliver a lighting solution that performs reliably in the worst operatingconditions, all the while reducing your energy, maintenance and man-power costs.3CROUSE-HINDS series LED lighting solutions † Operating temperature range may vary by lumen models within a product family. Refer to product catalog pages for complete temperature range details.AreaEquivalent lightExtreme Emergency PFME flood lightSelection guide – Harsh/heavy & light industrialDESIGN FEATURESAVersatile design -a wide range of mounting heights depending on model and light level requirement.BRugged heat sink -to +65°C and as low as -40°C. tough, rugged housing that keeps the internal driver and LED temperatures down.C High lumen output -DFull-frame yoke -mount bracket, making it ideal for retrofit or new installations (not available on 40L & 50L).EMultiple lens options -and diffused glass options available.FSmaller and lighter - model (3L ACEBDFPFMA3L – 25LIndustry-leading performance and reliability for outdoor area and site lighting in industrial locationsDESIGN FEATURESABuilt to last -Rated for 60,000+ hours of operation at 55ºC. Impact-resistant lens sealed from the outside environment provides ingress protection against water and dust.B High efficiency - Up to 116 lumens per watt.CRugged design - Engineered to perform in ambient temperatures from -40°C to +55°C. Die cast aluminum LED housing provides efficient thermal path to heat sink assembly, and vertical fin design facilitates air flow and dust shedding.DMultiple optic and lens options - Narrow and wide optics for ideal light output. Four lens styles provide flexibility for specific applications and customer preferences.ESimple installation -and new construction. Available with lever lock connectors.ACDEBSmaller footprint, lightweight design, and maintenance-free illumination in demanding environmentsACBDESIGN FEATURESA Rugged design - Engineered for durability in complex environments.BHigh efficiency - Up to 122 lm/W and custom optics to maximize light on the work plane.CEase of installation - Compact footprint with ceiling, pendant, wall or stanchion mount options and the ability to retrofit Crouse-Hinds series installed base.PMVL -3 – PMVL -13shown with optional uplight refractor lens and wire guardAModular design - This contractor-friendly design is ideal for both retrofit and new construction applications.BSafe, reliable heat transfer - Die cast aluminum housing provides safe and effective heat transfer from the LED assembly to the outside environment, ensuring low LED junction temperature, reliability and sustained lumen performance.CHigh efficiency drivers - Designed to provide reliable operation in even the harshest environments.DT ype 4X rated - The LED housing is constructed of durable die castaluminum, providing an efficient thermal path to the heat sink assembly. The impact-resistant lens is sealed from the outside environment and provides ingress protection against water and dust.ECustom optics and globe options -maximize light distribution and intensity. Optional Uplight refractor lens provides side and uplighting.FLever-lock connectors and 3-pole terminal block.Custom T ype I, III and V optics for better output, zero maintenance and reduced energy consumptionDESIGN FEATURESCBFDEAPVML -17 – PVML -25Up to 67% more energy efficient than aT5HO fluorescent light and 8 times the rated lifeDACBEDESIGN FEATURESA Best-in-class efficacy - Up to 134 lumens per watt.BCustom optics - Standard wide (120°) and narrow (80°) beam pattern for a wide variety of general and targeted lighting applications.C Built to last -resistant; 60,000 hour lifetime @ 55°C ambient.D Slim profile -mounting in confined or low height areas.E Quick & easy installation -brackets or hardware needed; five mounting options available.DESIGN FEATURESAInnovative and robust design -build-up. Withstands 1500 psi high pressure wash down, and food rated paint maintains safety.BHigh performance optics and drivers -highly efficient lighting. Rated life is up to 60,000 hours of maintenance-free and safe operation.Easily customized for application-specific performance -mounting options with a through feed design for simplified multiple fixture wiring.ABCCA non-metallic, corrosion-resistant LED A DESIGN FEATURESABuilt to last -provide excellent resistance to corrosion.Low-glare design -applications. Color LED options -emergency applications. Installation-friendly -feed. Emergency -power loss applications.DCEB C D E BCERTIFICATIONS & COMPLIANCES• UL1598• UL1598A Marine• cUL Listed to CSA Standard CSA C22.2 No. 250P3LM2DESIGN FEATURESADomeless reflector, low profile design -heights and confined spaces where incandescent and HID based luminaires are too large.BInstallation and replacement made simple -mounting modules as existing Eaton's Crouse-Hinds Vaporgard fixtures.CSafe, reliable heat transfer -effectively remove heat from the LED and driver, ensuring long product life and superior T DHigh power multi-die LED arrays -illumination in the harshest conditions, even when exposed to high, repeated vibration.watt incandescent and over 20 times the ACBDDBACDESIGN FEATURESA Energy efficient -B Built to last -polycarbonate lens and optics.C Custom optics -performance to key areas within an application.D Easy installation & maintenance -provide fast installation and maintenance.ACDEBDESIGN FEATURESA Increased efficiency - BMultiple mounting options -mount available.C Aluminum heat sinks for superior thermal management.DMultiple color temperature options -5000K cool white options available.DESIGN FEATURESA Increased efficiency - BMultiple mounting options -chain mounting.CAluminum heat sinks for superior thermal management.DMultiple lens options -and clear or diffused polycarbonate options available.EOptional occupancy sensor kit available.ACDEBV-SPRING ASimple vertical travel - multiple mounting heights and ensures safer installation.BEasy fixture rotation -positioning of lights or cameras.CFully assembled and wired -maximum environmental protectionCONDULET D Easy access -ESafer to install -no need to lean beyond handrail protectionIndustry standard sizing -accept V-Spring and other industry standard light polesACDEBEaton1000 Eaton Boulevard Cleveland, OH 44122 United States Crouse-Hinds Division 1201 Wolf Street Syracuse, NY 13208 © 2023 EatonAll Rights Reserved Printed in USA Publication No. BR403011EN October 2023Follow us on social media to get thelatest product and support information. Eaton is a registered trademark.All other trademarks are propertyof their respective owners.IEC Electrical (CEAG products)49 (0) 6271 806-500 FAX: 49 (0) 6271 806-476 *****************Haz Area Communications(MEDC, Hernis, Oxalis, FHF Sonix)44 (0) 1623 444400FAX: 44 (0) 1623 444531*******************Process instrumentation(MTL products)44 (0) 1582 723633FAX: 44 (0) 1582 422283********************Airport Lighting866-764-5454***************************Eaton Middle East9714-8066100 FAX: 9714-8894813CHBL*************Mexico/Latin America/Caribbean 52-555-804-4000FAX: 52-555-804-4020*************************CanadaToll Free: 800-265-0502 FAX: (800) 263-9504FAX Orders only: (866) 653-0645U.S. (global headquarters): Eaton’s Crouse-Hinds business 1201 Wolf Street Syracuse, NY 13208(866) 764-5454FAX: (315) 477-5179FAX Orders Only:(866) 653-0640***************************Eaton’s B-Line business509 West Monroe StreetHighland, IL 62249 800-851-7415FAX: 618-654-1917 /b-lineseriesAustralia61-2-8787-2777FAX: 61-2-9609-2342************************ China86-21-2899-3600FAX: 86-21-2899-4055******************。

54颗（防水）LED帕灯使用说明书使用前请仔细阅读说明书目录第1章产品概述 (2)1.技术参数 (2)2.灯具外形尺寸 (2)第2章注意事项与安装 (3)1.维护保养 (3)2.声明 (3)3.注意事项 (3)4.灯具安装 (4)第3章通道描述 (5)1.通道说明 (5)2.按键操作 (5)3.显示说明 (6)第1章产品概述1.技术参数输入电压：AC90-240V，50/60Hz额定功率：200W光源：54pcs RGBW LED色温：3200K-7800k灯珠寿命：60000小时频闪/调光：0-100%线性调节出光角度：8°15°，25°，45°（出光角度可供选择）控制方式：单机、主/从、声控、，自走效果、自动淡入淡出效果通道：4/8CH其他功能：RGBW(红、绿、蓝、白、)线性混色，内置宏功能，混色均匀，性能稳定；灯具采用具有PFC功率，因数校正的开关电源，PF﹥0.99效率高达90%，真正绿色环保。

LED采用静态恒流驱动方式，恒流精度高，无闪烁。

外壳：铸铝外壳，灯体黑色及白色。

防护等级：IP65应用环境：-20~+40℃散热：无风扇，自然散热灯体尺寸：340×210×295mm灯体重量：6kg2.灯具外形尺寸第2章注意事项与安装1.维护保养本灯具应保持干燥，避免在潮湿环境下工作。

间歇性的使用会有效地延长本灯具的寿命。

为了获得良好的通风效果和灯光效果，要注意经常清洁风扇和风扇网以及透镜。

请勿用酒精等有机溶剂擦试灯具外壳，以免造成损坏。

2.声明本产品在出厂进时，性能完好，包装完整。

所有使用者应严格遵守以上所陈述的警告事项和操作说明，任何因误用而导致的损坏不在本公司的保证之内，对忽视操作手册而导致的故障和问题亦不在经销商负责的范围内。

本手册如有技术改动，恕不另行通知。

3.注意事项该产品只适用于专业使用，不适用于其它用途，使用这种产品应注意火热电冲击，紫外线辐射，灯泡爆炸或脱落引起的严重或致命损伤。
