MOXA交换机使用说明教学内容一、简介MOXA交换机是一种高性能的工业以太网交换机，它能够满足工业环境中对网络可靠性和稳定性的要求。

MOXA交换机具有多个端口，支持各种网络协议，并具有多种网络管理和优化功能。

本教程将介绍如何正确使用MOXA交换机，并详细说明其各项功能。

二、安装与配置1.检查交换机是否损坏：确认交换机外观是否完好，是否有明显的损坏或缺陷。

2.连接电源：将交换机的电源插头插入电源插座，然后按下开关，确认交换机的指示灯是否亮起。

3.连接设备：使用网线将设备与交换机的端口相连。

4.配置网络参数：使用电脑连接至交换机的管理端口，通过浏览器登录交换机的配置界面，根据需要配置网络参数，如IP地址、子网掩码等。

5.网络测试：在配置完成后，使用网络测试工具对交换机进行测试，确认网络连接正常。

三、交换机配置1.VLAN配置：VLAN是一种将交换机端口划分为不同虚拟局域网的技术。

在交换机中配置VLAN，可以实现不同设备之间的隔离和通信。

2. QoS配置：QoS（Quality of Service）是一种网络优化技术，通过分配带宽和优先级，可以保证关键应用的网络传输质量。

3.静态路由配置：在交换机中配置静态路由，可以实现不同子网之间的通信。

4.端口管理：配置端口速率、全双工或半双工模式、流控等参数，以充分利用网络带宽和提高网络性能。

5.网络监控与诊断：通过交换机的网络监控功能，可以实时监测网络流量、连接状态和端口的状态，以及进行故障诊断和排除。

四、安全性配置1.密码设置：修改交换机的默认登录密码，以保护设备免受未经授权的访问。

2. 限制访问：通过配置ACL（Access Control List）或MAC过滤，限制特定IP地址或MAC地址的访问。

3.HTTPS加密：将交换机的管理界面配置为使用HTTPS加密协议，提高数据传输的安全性。

4.日志记录：开启日志记录功能，记录交换机的操作和事件，以便后续分析和审计。

Moxa一款产品两大功能一全千兆＋PoE＋工业交换机
无
【期刊名称】《自动化信息》
【年(卷),期】2012(000)007
【摘要】Moxa推出一款POE＋全千兆工业以太网交换机-EDS—G205A-4PoE，支持5个IEEE802．3af／atPoE＋全千兆以太网口。

EDS-G205A-4PoE具有千兆网口，可满足高带宽应用户需求；另外还具有PoE＋功能，每个端口最高可提供30W电源，兼容IEEE802．3af标准，可满足PoE应用的需求。

【总页数】1页(P16-16)
【作者】无
【作者单位】不详
【正文语种】中文
【中图分类】TP393.11
【相关文献】
1.红狮针对工业需求推出更多增强型千兆以太网供电（PoE＋）产品 [J], ;
2.Moxa发表PoE＋工业级以太网络交换机 [J],
3.MoxaEDS-510A千兆网管型冗余工业以太网交换机 [J], 无
4.Moxa EDS-G509千兆工业交换机荣膺大奖 [J], 无
5.红狮推出防护等级达IP67的工业管理型千兆以太网PoE＋交换机 [J],
因版权原因，仅展示原文概要，查看原文内容请购买。

EDS-G509Series9G-port full Gigabit managed EthernetswitchesFeatures and Benefits•410/100/1000BaseT(X)ports plus5combo(10/100/1000BaseT(X)or100/ 1000BaseSFP slot)Gigabit ports•Enhanced surge protection for serial,LAN,and power•TACACS+,SNMPv3,IEEE802.1X,HTTPS,and SSH to enhance network security•Easy network management by web browser,CLI,Telnet/serial console, Windows utility,and ABC-01•Supports MXstudio for easy,visualized industrial network managementCertificationsIntroductionThe EDS-G509Series is equipped with9Gigabit Ethernet ports and up to5fiber-optic ports,making it ideal for upgrading an existing network to Gigabit speed or building a new full Gigabit backbone.Gigabit transmission increases bandwidth for higher performance and transfers large amounts of video,voice,and data across a network quickly.Redundant Ethernet technologies Turbo Ring,Turbo Chain,RSTP/STP,and MSTP increase system reliability and the availability of your network backbone.The EDS-G509Series is designed especially for communication demanding applications,such as video and process monitoring, shipbuilding,ITS,and DCS systems,all of which can benefit from a scalable backbone construction.Additional Features and Benefits•Command line interface(CLI)for quickly configuring majormanaged functions•DHCP Option82for IP address assignment with different policies•Supports EtherNet/IP and Modbus TCP protocols for devicemanagement and monitoring•Compatible with PROFINET protocol for transparent datatransmission•IGMP snooping and GMRP for filtering multicast traffic•Compatible with the ABC-01(Automatic Backup Configurator)forsystem configuration backup•Port-based VLAN,IEEE802.1Q VLAN,and GVRP to ease networkplanning•QoS(IEEE802.1p/1Q and TOS/DiffServ)to increase determinism•Port Trunking for optimum bandwidth utilization•SNMPv1/v2c/v3for different levels of network management•RMON for proactive and efficient network monitoring•Bandwidth management to prevent unpredictable network status•Lock port function for blocking unauthorized access based on MACaddress•Port mirroring for online debugging•Automatic warning by exception through email and relay outputSpecificationsInput/Output InterfaceAlarm Contact Channels2,Relay output with current carrying capacity of1A@24VDCDigital Input Channels2Digital Inputs+13to+30V for state1-30to+3V for state0Max.input current:8mAEthernet Interface10/100/1000BaseT(X)Ports(RJ45connector)4Auto negotiation speedFull/Half duplex modeAuto MDI/MDI-X connectionCombo Ports(10/100/1000BaseT(X)or100/51000BaseSFP+)Standards IEEE802.1D-2004for Spanning Tree ProtocolIEEE802.1p for Class of ServiceIEEE802.1Q for VLAN TaggingIEEE802.1s for Multiple Spanning Tree ProtocolIEEE802.1w for Rapid Spanning Tree ProtocolIEEE802.1X for authenticationIEEE802.3for10BaseTIEEE802.3ab for1000BaseT(X)IEEE802.3ad for Port Trunk with LACPIEEE802.3u for100BaseT(X)IEEE802.3x for flow controlIEEE802.3z for1000BaseXEthernet Software FeaturesFilter802.1Q VLAN,GMRP,GVRP,IGMP v1/v2,Port-based VLANIndustrial Protocols EtherNet/IP,Modbus TCPManagement Back Pressure Flow Control,BOOTP,DDM,DHCP Option66/67/82,DHCP Server/Client,Flow control,IPv4/IPv6,LLDP,Port Mirror,RARP,RMON,SMTP,SNMP Inform,SNMPv1/v2c/v3,Syslog,Telnet,TFTPMIB Bridge MIB,Ethernet-like MIB,MIB-II,P-BRIDGE MIB,Q-BRIDGE MIB,RMON MIBGroups1,2,3,9,RSTP MIBRedundancy Protocols Link Aggregation,MSTP,RSTP,STP,Turbo Chain,Turbo Ring v1/v2Security Broadcast storm protection,HTTPS/SSL,Port Lock,RADIUS,SSH,TACACS+,SNMPv3 Time Management NTP Server/Client,SNTPSwitch PropertiesIGMP Groups256MAC Table Size8KMax.No.of VLANs64Packet Buffer Size1MbitsPriority Queues4VLAN ID Range VID1to4094LED InterfaceLED Indicators PWR1,PWR2,FAULT,10/100/1000M(TP port),100/1000M(SFP port),MSTR/HEAD,CPLR/TAILSerial InterfaceConsole Port RS-232(TxD,RxD,GND),8-pin RJ45(115200,n,8,1)DIP Switch ConfigurationDIP Switches Turbo Ring,Master,Coupler,ReservePower ParametersPower Connector2removable6-contact terminal block(s)Input Current0.69A@24VDCInput Voltage12/24/48VDC,Redundant dual inputsOperating Voltage9.6to60VDCOverload Current Protection SupportedReverse Polarity Protection SupportedPhysical CharacteristicsHousing MetalIP Rating IP30Dimensions87.1x135x107mm(3.43x5.31x4.21in)Weight1510g(3.33lb)Installation DIN-rail mounting,Wall mounting(with optional kit) Environmental LimitsOperating Temperature EDS-G509:0to60°C(32to140°F)EDS-G509-T:-40to75°C(-40to167°F)Storage Temperature(package included)-40to85°C(-40to185°F)Ambient Relative Humidity5to95%(non-condensing)Standards and CertificationsFreefall IEC60068-2-32EMC EN55032/24EMI CISPR32,FCC Part15B Class AEMS IEC61000-4-2ESD:Contact:6kV;Air:8kVIEC61000-4-3RS:80MHz to1GHz:10V/mIEC61000-4-4EFT:Power:2kV;Signal:1kVIEC61000-4-5Surge:Power:2kV;Signal:1kVIEC61000-4-6CS:10VIEC61000-4-8PFMFMaritime ABS,DNV-GL,LR,NKRailway EN50121-4Safety EN60950-1,UL508Shock IEC60068-2-27Vibration IEC60068-2-6MTBFTime598,659hrsStandards Telcordia(Bellcore),GBWarrantyWarranty Period5yearsDetails See /warrantyPackage ContentsDevice1x EDS-G509Series switchCable1x RJ45-to-DB9console cableInstallation Kit4x cap,plastic,for RJ45port5x cap,plastic,for SFP portDocumentation1x document and software CD1x product certificates of quality inspection,Simplified Chinese1x product notice,Simplified Chinese1x quick installation guide1x warranty cardNote SFP modules need to be purchased separately for use with this product. DimensionsOrdering InformationModel Name Layer Total No.of Ports 10/100/1000BaseT(X)PortsRJ45ConnectorCombo Ports10/100/1000BaseT(X)or100/1000BaseSFPOperating Temp.EDS-G5*******to60°C EDS-G509-T2945-40to75°C Accessories(sold separately)Storage KitsABC-01Configuration backup and restoration tool for managed Ethernet switches and AWK Series wirelessAPs/bridges/clients,0to60°C operating temperatureSFP ModulesSFP-1FELLC-T SFP module with1100Base single-mode with LC connector for80km transmission,-40to85°Coperating temperatureSFP-1FEMLC-T SFP module with1100Base multi-mode with LC connector for4km transmission,-40to85°Coperating temperatureSFP-1FESLC-T SFP module with1100Base single-mode with LC connector for40km transmission,-40to85°Coperating temperatureSFP-1G10ALC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for10km transmission;TX1310nm,RX1550nm,0to60°C operating temperatureSFP-1G10ALC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for10km transmission;TX1310nm,RX1550nm,-40to85°C operating temperatureSFP-1G10BLC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for10km transmission;TX1550nm,RX1310nm,0to60°C operating temperatureSFP-1G10BLC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for10km transmission;TX1550nm,RX1310nm,-40to85°C operating temperatureSFP-1G20ALC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for20km transmission;TX1310nm,RX1550nm,0to60°C operating temperatureSFP-1G20ALC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for20km transmission;TX1310nm,RX1550nm,-40to85°C operating temperatureSFP-1G20BLC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for20km transmission;TX1550nm,RX1310nm,0to60°C operating temperatureSFP-1G20BLC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for20km transmission;TX1550nm,RX1310nm,-40to85°C operating temperatureSFP-1G40ALC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for40km transmission;TX1310nm,RX1550nm,0to60°C operating temperatureSFP-1G40ALC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for40km transmission;TX1310nm,RX1550nm,-40to85°C operating temperatureSFP-1G40BLC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for40km transmission;TX1550nm,RX1310nm,0to60°C operating temperatureSFP-1G40BLC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for40km transmission;TX1550nm,RX1310nm,-40to85°C operating temperatureSFP-1GEZXLC SFP module with11000BaseEZX port with LC connector for110km transmission,0to60°C operatingtemperatureSFP-1GEZXLC-120SFP module with11000BaseEZX port with LC connector for120km transmission,0to60°C operatingtemperatureSFP-1GLHLC SFP module with11000BaseLH port with LC connector for30km transmission,0to60°C operatingtemperatureSFP-1GLHLC-T SFP module with11000BaseLH port with LC connector for30km transmission,-40to85°C operatingtemperatureSFP-1GLHXLC SFP module with11000BaseLHX port with LC connector for40km transmission,0to60°C operatingtemperatureSFP-1GLHXLC-T SFP module with11000BaseLHX port with LC connector for40km transmission,-40to85°Coperating temperatureSFP-1GLSXLC SFP module with11000BaseLSX port with LC connector for500m transmission,0to60°C operatingtemperatureSFP-1GLSXLC-T SFP module with11000BaseLSX port with LC connector for500m transmission,-40to85°Coperating temperatureSFP-1GLXLC SFP module with11000BaseLX port with LC connector for10km transmission,0to60°C operatingtemperatureSFP-1GLXLC-T SFP module with11000BaseLX port with LC connector for10km transmission,-40to85°C operatingtemperatureSFP-1GSXLC SFP module with11000BaseSX port with LC connector for300/550m transmission,0to60°Coperating temperatureSFP-1GSXLC-T SFP module with11000BaseSX port with LC connector for300/550m transmission,-40to85°Coperating temperatureSFP-1GZXLC SFP module with11000BaseZX port with LC connector for80km transmission,0to60°C operatingtemperatureSFP-1GZXLC-T SFP module with11000BaseZX port with LC connector for80km transmission,-40to85°C operatingtemperatureWall-Mounting KitsWK-46Wall-mounting kit,2plates,8screws,46.5x66.8x1mmSoftwareMXview-50Industrial network management software with a license for50nodes(by IP address)MXview-100Industrial network management software with a license for100nodes(by IP address)MXview-250Industrial network management software with a license for250nodes(by IP address)MXview-500Industrial network management software with a license for500nodes(by IP address)MXview-1000Industrial network management software with a license for1000nodes(by IP address)MXview-2000Industrial network management software with a license for2000nodes(by IP address)MXview Upgrade-50License expansion of MXview industrial network management software by50nodes(by IP address)©Moxa Inc.All rights reserved.Updated Aug06,2019.This document and any portion thereof may not be reproduced or used in any manner whatsoever without the express written permission of Moxa Inc.Product specifications subject to change without notice.Visit our website for the most up-to-date product information.。

如对您有帮助，请购买打赏，谢谢您！MOXA交换机环网配置说明（以EDS-508-MM-SC为例）1．打开MOXA edscfgui.exe配置工具，通过broadcast方式搜索网络中的所有MOXA网管型交换机。

2. 通过搜索框可查看到网路中的交换机相关信息。

3. 左键选中其中一台交换机，右边出现该台交换机的详细信息。

包括型号、名称、IP配置、物理地址、串列号、固件版本等。

当有多台交换机IP地址冲突时，每台交换机会按照接入网络的次序相应叠加，自动改变IP地址。

因此我们要对所有的交换机重新配置IP。

4. 选中某台交换机后，点击右键，进入弹出菜单中的Modify IP Address，可通过如下方式修改交换机IP。

如此配置好每台交换机IP并刷新显示列表。

5.有的时候我们可以通过firmware固件版本的升级，来更新交换机软件功能：选中某台交换机后，点击菜单栏Firmware->upgrade，选择firmware升级文件后确定。

6. 确定后系统开始更新该台交换机的firmware版本。

7. Progress信息栏显示OK，firmware升级完成。

8.接下来介绍页面配置。

可直接在IE浏览器中输入相应交换机IP地址访问，也可通过右键菜单中的Web Console进入配置页面。

9. 初次访问交换机时，默认用户名为admin,密码为空，直接点击login进入。

10.页面中上面为交换机信息，左半部分为交换机配置菜单，右边为子菜单内容。

进入Basic Settings的Network,右边显示交换机本身的网络配置。

可在此处更新IP，修改后必须点击Activate激活。

11．进入Communication Redundancy菜单，选择Turbo Ring环网方式或RSTP生成树网络结构。

点击Turbo Ring后，在下面选好Redundant Ports,即用于组环的两个交换机端口号。

(a)若该台交换机是这个环网中的master，则在Set as Master前打勾选中。

MOXA交换机配置
1.输入交换机的ip地址进入此界面，不用管用户明和密码，直接点Login进入。

2.进入到此项，再进入1，在2处为此交换机命名。

最后点击Activate 保存。

3.再点击1处进入此项，我们可以看到2处为开关该交换机端口，取消对应端口的对号，然后点击Activate保存，可关闭此端口。

4．再点击红框处进入环网配置页面。

5.如下1处配置，协议选择Turbo Ring V2.端口号选择光跳线所插的对应端口号。

6.下面为做两个环时（井下一个环，环上其中一台交换机与地面核心交换机一相连）所做的配置。

端口号为与核心交换机一相连的端口。

7. 下面为做两个环时（井下一个环，环上其中另一台交换机与地面核心交换机二相连）所做的配置。

端口号为与核心交换机二相连的端口。

结束。

8.附环网管理软件免费版。

限量20台交换机。

一、 测试网络拓扑IP 地址：192.168.100.0段子网掩码：255.255.255.0网关：192.168.100.1101P24P23P24P23P23P24网络拓扑描述：➢ 核心使用1台三层交换机IKS-G6824A ➢ 汇聚使用2台PT-7528交换机 ➢ 接入使用非网管型8口交换机。

➢ IKS-G6824A 和2PT-7528交换机均使用P23和P24端口组成千兆环网，各个产线中非网管型交换机互相级联后，接入至PT-7528.➢ 模拟现场设备划分4个网段：192.168.100.0、192.168.101.0、192.168.102.0、192.168.103.0。

➢ 服务器使用192.168.20.0网段。

要求：1. 服务器192.168.20.0网段要和现场的4个网段数据互通； 2. 现场4个网段之间数据互相隔离。

二、核心交换机IKS-G6824A配置步骤2.1.准备Moxa交换机默认IP地址为192.168.127.253默认用户：admin默认密码：moxa如果设备是新产品没有做过配置的话，先将PC 的有线网卡IP 地址修改成192.168.127.xxx（因为交换机默认的网段是192.168.127.0）2.2.进入交换机设置界面浏览器中输入交换机默认IP地址（192.168.127.253）进入配置界面。

假如不知道交换机当前的IP地址，使用“edscfgui”软件，可以搜索出交换机IP地址。

打开浏览器，输入交换机IP地址，进入交换机配置界面。

2.3.IP地址设置进入Home-→System--→Network--→IP Settings，进入IP地址设置选项IP Address 修改IP地址Subnet Mask 修改子网掩码Default Gateway 修改网关修改完成后，点击“Apply”进行保存。

保存后，请使用新的IP地址重新进入配置界面。

（此次测试核心交换机IP地址设置为192.168.127.1）修改完IP地址后，请使用新的IP地址重新进入配置界面。
