TREX鼓性能
TREX响鼓的效果：采用直通设计理念，跟据车型排量及性能设计大小不同的消音管道设计，从而达到个性化要求，声音在90分贝左右，主要提升汽车的高转速马力。

TREX轻音鼓的效果：内部采用内回压设计理念，主要提高中低转速扭力，高转速马力也同样得到相应的提升，使用该产品使你的爱车起步快、爬坡有力，声音在3000转左右发出，声音清脆低沉，声音85分贝左右。

TREX静音鼓的效果：采用内部双次回压设计理念，根据不同车型的排量设专车专用鼓，声音在75分贝左右，声音静，提升中低转速扭力。

TREX HKS型---是直排带回压的，提升中低转速扭力和高转速马力。

声音比直排的小，比回压的大，是比较清脆的，在95分贝绝不扰人。

高转速时无共振声。

（有日本HKS的效果）设计原理：按气流沿壁走向的原理。

TREX J鼓回压鼓---提升马力和扭力的，音质也相当讲究，鼓身完全为了增加马力兼降低音量而设的，完全可以在行街与高速行走任选择，整段排气采用日本最流行的渐次放大的设计式样，更能发挥引擎的潜能，声音在90分贝左右，平衡了油耗加速反应，动力提升，街鼓成为了理想的街道行走之喉,。

随着汽车工业的高速发展，汽车已经成为人们日常生活中不可缺少的交通工具。

但与此同时，汽车尾气排放也成为城市空气污染的重要来源。

对车辆排放的限制，已成为政治、经济、决策的一个焦点。

改善发动机燃烧状况，降低油耗，减少污染物排放，或是开发清洁能源汽车，已经成为现代汽车工业的发展趋势。

电子控制缸内直喷+精确控制空燃比+三元催化器可使发动机能耗及排放大幅降低。

多气门技术、稀燃技术、连续气门正时及升程可变技术、分层充气、废弃再循环（EGR）与电控技术相结合，是目前车用汽油机的发展方向。

汽车排气系统属于相当成熟的行业，2013年全球汽车排气系统市场规模大约为317亿美元，比2012年微增1.3%。

主要原因包括欧盟市场疲弱，日元大幅度贬值，中国推迟柴油车国IV标准。

不过随着排放标准的进一步严格，排气系统的市场规模将稳步成长，尤其是柴油车（Diesel Vehicle)领域。

预计2014年汽车排气系统市场的规模可达330亿美元，增长4.1%。

目前中国汽车排气系统可以分欧系、美系、日系、韩系和本土系。

欧系：主要有Faurecia、Bosyen、Eberspacher。

Faurecia包揽大部分欧系中低端车型，包括一汽大众FAW、上海大众SVW、东风雪铁龙DCAD、东风标致DPAD、上海通用SGM、宝马奔驰的中低端车型。

高端车型由Bosyen和Eberspacher分享。

美系：主要有Tenneco、Katcon。

主要客户也是上海通用SGM。

Tenneco和Eberspacher 的合资厂分享部分FAW中高端车型市场。

日系：主要有Sango、Futuba、Yutaka、Hirotec。

Sango和Futuba主要客户是丰田，Yutaka主要客户是Honda，Hirotec主要客户是MAZDA。

韩系：只有Sejong。

包揽韩国现代所有车型的市场。

本土系：主要分两种方式；一种是内部In-house完成，如重庆长安、比亚迪和长城汽车；另一种由专业厂家来完成，这些专业厂家主要有无锡威孚力达催化净化器、重庆海特汽车排气系统、天津卡达克汽车等。
