海康威视网络高清红外智能球操作手册

8002红外智能球形摄像机说明书第一章：产品概述本红外智能球形摄像机是综合了多项高科技成果于一身的新一代监控产品。

本产品外观设计新颖精美；摄像机与红外灯采用分仓设计，彻底解决红外灯长时间开启产生的高温对摄像机的损坏，确保摄像机远距离监视的可靠性；红外灯仓及灯板采用全金属（铝），可靠的散发红外灯产生的热量；本产品采用全数码控制，编程灵活，使用精密电机，快速灵敏，定位准确，运行平稳，可设置摄像机自动适应环境明暗和目标远近的变化；大容量的预置位存储，可以设置多个巡视组；具有掉电记忆功能，自动恢复掉电前的工作状态，实现了真正意义上的全方位、全天候、高可靠、高清晰、智能化监视。

为了适合各种环境的安装使用，还有壁装、吊装等多种安装方式可供选择。

本产品适用于各行各业大面积、远距离的活动目标监视,如旅游景点、机场、电力部门、智能大厦、银行保安、学校监考、城市道路、车站监控等。

1.1产品认识①法兰连接柱②遮阳罩③装饰圈④灯仓前盖⑤灯仓⑥光敏电阻1.2产品外形尺寸1.3外出引线定义Q座：视频接线头电源插座：DC24V（内正外负）RS485：黄线 RS485 A+白线RS485 B-8、通电测试2、取出球机遮阳罩内部保护垫2.1安装流程注：如果订货时配有摄像机，可以省略灯仓前盖的拆卸。

请注意本说明书封底页上球机出厂配置。

2.2准备安装 2.2.1基本要求所有的电气工作都必须遵守使用最新的电气法规，防火法规以及其他相关法规。

检验随机物品是否齐全，确定该红外智能球形摄像机的应用场所和安装方式是否与所要求的吻合，若不吻合请与经销商联系。

2.2.2核查安装空间及安装地点构造的强度确认安装地点有容纳本产品及其安装结构件的足够空间。

确认安装球机的天花板、墙壁、支架的承载能力可支撑球机及其安装结构件的总重量。

要求具有4倍的安全系数。

1、打开包装，取出球机第二章：安装指南（检查产品在运输途中是否有损坏。

（否则影响球机通电时的正常运转）（详见第4页2.3摄像机机芯安装、拨码设置）（参照第7页e 安装灯仓前盖和装饰圈）（详见第8页2.4球机安装）2.3 摄像机机芯安装、拨码设置 2.3.1摄像机机芯安装a 、从包装箱中取出红外智能球形摄像机，将遮阳罩内部的球机保护垫（4块）取出，旋松装饰圈上的4颗自攻螺钉，取下装饰圈，再将灯仓前盖上的四个螺钉旋松，取下灯仓前盖。
