HD74LS02Quadruple 2-Input Positive NOR GatesREJ03D0389–0200Rev.2.00Feb.18.2005 Features• Ordering InformationPart Name Package Type Package Code(Previous Code)PackageAbbreviationTaping Abbreviation(Quantity)HD74LS02P DILP-14pin PRDP0014AB-B(DP-14AV)P —HD74LS02FPEL SOP-14 pin (JEITA) PRSP0014DF-B(FP-14DAV)FP EL (2,000 pcs/reel)HD74LS02RPEL SOP-14 pin (JEDEC) PRSP0014DE-A(FP-14DNV)RP EL (2,500 pcs/reel)Note: Please consult the sales office for the above package availability. Pin ArrangementCircuit Schematic (1/4)Absolute Maximum RatingsUnitRatingsItem SymbolSupply voltage V CC Note 7 VInput voltage V IN 7 V Power dissipation P T 400 mW Storage temperature Tstg –65 to +150 °CNote: Voltage value, unless otherwise noted, are with respect to network ground terminal.Recommended Operating ConditionsUnitMaxItem SymbolMinTypSupply voltage V CC 4.75 5.00 5.25 VI OH — — –400 µAOutput currentI OL — — 8 mA°C7525–20Operating temperature ToprElectrical Characteristics(Ta = –20 to +75 °C)ItemSymbol min. typ.* max. Unit Condition V IH 2.0 — — V Input voltageV IL — — 0.8 V V OH 2.7 — — V V CC = 4.75 V, V IL = 0.8 V, I OH = –400 µA— — 0.5 I OL = 8 mAOutput voltageV OL— — 0.4 V I OL = 4 mAV CC = 4.75 V, V IH = 2 V I IH — — 20 µA V CC = 5.25 V, V I = 2.7 V I IL — — –0.4 mA V CC = 5.25 V, V I = 0.4 VInput current I I — — 0.1 mA V CC = 5.25 V, V I = 7 V Short-circuit outputcurrent I OS –20— –100 mA V CC = 5.25 V I CCH — 1.6 3.2 mA V CC = 5.25 VSupply currentI CCL — 2.8 5.4 mA V CC = 5.25 VInput clamp voltage V IK — — –1.5 V V CC = 4.75 V, I IN = –18 mA Note: * V CC = 5 V, Ta = 25°CSwitching Characteristics(V CC = 5 V, Ta = 25°C)Item Symbol min. typ. max. Unit Conditiont PLH — 10 15 nsPropagation delay time t PHL — 10 15 ns C L = 15 pF, R L = 2 k ΩNote: Refer to Test Circuit and Waveform of the Common Item "TTL Common Matter (Document No.: REJ27D0005-0100)".Package Dimensions RENESAS SALES OFFICESRefer to "/en/network" for the latest and detailed information.Renesas Technology America, Inc.450 Holger Way, San Jose, CA 95134-1368, U.S.ATel: <1> (408) 382-7500, Fax: <1> (408) 382-7501Renesas Technology Europe LimitedDukes Meadow, Millboard Road, Bourne End, Buckinghamshire, SL8 5FH, U.K.Tel: <44> (1628) 585-100, Fax: <44> (1628) 585-900Renesas Technology Hong Kong Ltd.7th Floor, North Tower, World Finance Centre, Harbour City, 1 Canton Road, Tsimshatsui, Kowloon, Hong KongTel: <852> 2265-6688, Fax: <852> 2730-6071Renesas Technology Taiwan Co., Ltd.10th Floor, No.99, Fushing North Road, Taipei, TaiwanTel: <886> (2) 2715-2888, Fax: <886> (2) 2713-2999Renesas Technology (Shanghai) Co., Ltd.Unit2607 Ruijing Building, No.205 Maoming Road (S), Shanghai 200020, ChinaTel: <86> (21) 6472-1001, Fax: <86> (21) 6415-2952Renesas Technology Singapore Pte. Ltd.1 Harbour Front Avenue, #06-10, Keppel Bay Tower, Singapore 098632Tel: <65> 6213-0200, Fax: <65> 6278-8001。

HD74LS04 / HD74LS05Hex Inverters / Hex Inverters (with Open Collector Outputs)REJ03D0391–0300Rev.3.00Jul.13.2005 Features• Ordering Information• HD74LS04Part Name Package Type Package Code(Previous Code)PackageAbbreviationTaping Abbreviation(Quantity)HD74LS04P DILP-14pin PRDP0014AB-B(DP-14AV)P —HD74LS04FPEL SOP-14 pin (JEITA) PRSP0014DF-B(FP-14DAV)FP EL (2,000 pcs/reel)HD74LS04RPEL SOP-14 pin (JEDEC) PRSP0014DE-A(FP-14DNV)RP EL (2,500 pcs/reel)• HD74LS05Part Name Package Type Package Code(Previous Code)PackageAbbreviationTaping Abbreviation(Quantity)HD74LS05P DILP-14pin PRDP0014AB-B(DP-14AV)P —HD74LS05FPEL SOP-14 pin (JEITA) PRSP0014DF-B(FP-14DAV)FP EL (2,000 pcs/reel)HD74LS05RPEL SOP-14 pin (JEDEC) PRSP0014DE-A(FP-14DNV)RP EL (2,500 pcs/reel)Note: Please consult the sales office for the above package availability. Pin ArrangementCircuit Schematic (1/6)Absolute Maximum RatingsUnitRatingsItem SymbolSupply voltage V CC Note 7 VInput voltage V IN 7 V Power dissipation P T 400 mW Storage temperature Tstg –65 to +150 °CNote: Voltage value, unless otherwise noted, are with respect to network ground terminal.Recommended Operating Conditions• HD74LS04MaxUnitMinTypItem SymbolSupply voltage V CC 4.75 5.00 5.25 VI OH — — –400 µAOutput currentI OL — — 8 mA°C2575Operating temperature Topr–20• HD74LS05MaxUnitTypMinItem SymbolSupply voltage V CC 4.75 5.00 5.25 VOutput voltage V OH — — 5.5 VOutput current I OL — — 8 mA°C7525–20Operating temperature ToprElectrical Characteristics• HD74LS04(Ta = –20 to +75 °C)ItemSymbol min. typ.* max. Unit Condition V IH 2.0 — — V Input voltageV IL — — 0.8 V V OH 2.7 — — V V CC = 4.75 V, V IL = 0.8 V, I OH = –400 µA— — 0.5 I OL = 8 mAOutput voltageV OL— — 0.4 V I OL = 4 mAV CC = 4.75 V, V IH = 2 V I IH — — 20 µA V CC = 5.25 V, V I = 2.7 V I IL — — –0.4 mA V CC = 5.25 V, V I = 0.4 VInput current I I — — 0.1 mA V CC = 5.25 V, V I = 7 V Short-circuit outputcurrent I OS –20— –100 mA V CC = 5.25 V I CCH — 1.2 2.4 mA V CC = 5.25 VSupply currentI CCL — 3.6 6.6 mA V CC = 5.25 VInput clamp voltage V IK — — –1.5 V V CC = 4.75 V, I IN = –18 mA Note: * V CC = 5 V, Ta = 25°C• HD74LS05(Ta = –20 to +75 °C)ItemSymbol min. typ.* max. Unit Condition V IH 2.0 — — VInput voltageV IL — — 0.8 V— — 0.5 I OL = 8 mAOutput voltage V OL — — 0.4 V I OL = 4 mAV CC = 4.75 V, V IH = 2 VOutput current I OH — — 100 µA V CC = 4.75 V, V IL = 0.8 V, V OA = 5.5 VI IH — — 20 µA V CC = 5.25 V, V I = 2.7 VI IL — — –0.4 mA V CC = 5.25 V, V I = 0.4 VInput current I I —— 0.1 mA V CC = 5.25 V, V I = 7 V I CCH — 1.2 2.4 mA V CC = 5.25 VSupply currentI CCL —3.6 6.6 mA V CC = 5.25 V Input clamp voltage V IK — — –1.5 V V CC =4.75 V, I IN = –18 mA Note: * V CC = 5 V, Ta = 25°CSwitching Characteristics• HD74LS04(V CC = 5 V, Ta = 25°C)Item Symbol min. typ. max. Unit Conditiont PLH — 9 15 nsPropagation delay timet PHL — 10 15 ns C L = 15 pF, R L = 2 k Ω• HD74LS05(V CC = 5 V, Ta = 25°C)Item Symbol min. typ. max. Unit Conditiont PLH — 17 32 nsPropagation delay time t PHL — 15 28 nsC L = 15 pF, R L = 2 k ΩNote: Refer to Test Circuit and Waveform of the Common Item "TTL Common Matter (Document No.: REJ27D0005-0100)".Package Dimensions RENESAS SALES OFFICESRefer to "/en/network" for the latest and detailed information.Renesas Technology America, Inc.450 Holger Way, San Jose, CA 95134-1368, U.S.ATel: <1> (408) 382-7500, Fax: <1> (408) 382-7501Renesas Technology Europe LimitedDukes Meadow, Millboard Road, Bourne End, Buckinghamshire, SL8 5FH, U.K.Tel: <44> (1628) 585-100, Fax: <44> (1628) 585-900Renesas Technology Hong Kong Ltd.7th Floor, North Tower, World Finance Centre, Harbour City, 1 Canton Road, Tsimshatsui, Kowloon, Hong KongTel: <852> 2265-6688, Fax: <852> 2730-6071Renesas Technology Taiwan Co., Ltd.10th Floor, No.99, Fushing North Road, Taipei, TaiwanTel: <886> (2) 2715-2888, Fax: <886> (2) 2713-2999Renesas Technology (Shanghai) Co., Ltd.Unit2607 Ruijing Building, No.205 Maoming Road (S), Shanghai 200020, ChinaTel: <86> (21) 6472-1001, Fax: <86> (21) 6415-2952Renesas Technology Singapore Pte. Ltd.1 Harbour Front Avenue, #06-10, Keppel Bay Tower, Singapore 098632Tel: <65> 6213-0200, Fax: <65> 6278-8001Renesas Technology Korea Co., Ltd.Kukje Center Bldg. 18th Fl., 191, 2-ka, Hangang-ro, Yongsan-ku, Seoul 140-702, KoreaTel: <82> 2-796-3115, Fax: <82> 2-796-2145Renesas Technology Malaysia Sdn. Bhd.Unit 906, Block B, Menara Amcorp, Amcorp Trade Centre, No.18, Jalan Persiaran Barat, 46050 Petaling Jaya, Selangor Darul Ehsan, MalaysiaTel: <603> 7955-9390, Fax: <603> 7955-9510。

PACKAGING INFORMATIONOrderable Device Status(1)PackageType PackageDrawingPins PackageQtyEco Plan(2)Lead/Ball Finish MSL Peak Temp(3)SN74LV244ADBLE OBSOLETE SSOP DB20TBD Call TI Call TISN74LV244ADBR ACTIVE SSOP DB202000Green(RoHS&no Sb/Br)CU NIPDAU Level-1-260C-UNLIMSN74LV244ADBRE4ACTIVE SSOP DB202000Green(RoHS&no Sb/Br)CU NIPDAU Level-1-260C-UNLIMSN74LV244ADGVR ACTIVE TVSOP DGV202000Green(RoHS&no Sb/Br)CU NIPDAU Level-1-260C-UNLIMSN74LV244ADGVRE4ACTIVE TVSOP DGV202000Green(RoHS&no Sb/Br)CU NIPDAU Level-1-260C-UNLIMSN74LV244ADW ACTIVE SOIC DW2025Green(RoHS&no Sb/Br)CU NIPDAU Level-1-260C-UNLIMSN74LV244ADWE4ACTIVE SOIC DW2025Green(RoHS&no Sb/Br)CU NIPDAU Level-1-260C-UNLIMSN74LV244ADWR ACTIVE SOIC DW202000Green(RoHS&no Sb/Br)CU NIPDAU Level-1-260C-UNLIMSN74LV244ANSR ACTIVE SO NS202000Green(RoHS&no Sb/Br)CU NIPDAU Level-1-260C-UNLIMSN74LV244ANSRE4ACTIVE SO NS202000Green(RoHS&no Sb/Br)CU NIPDAU Level-1-260C-UNLIMSN74LV244ANSRG4ACTIVE SO NS202000Green(RoHS&no Sb/Br)CU NIPDAU Level-1-260C-UNLIMSN74LV244APW ACTIVE TSSOP PW2070Green(RoHS&no Sb/Br)CU NIPDAU Level-1-260C-UNLIMSN74LV244APWE4ACTIVE TSSOP PW2070Green(RoHS&no Sb/Br)CU NIPDAU Level-1-260C-UNLIMSN74LV244APWG4ACTIVE TSSOP PW2070Green(RoHS&no Sb/Br)CU NIPDAU Level-1-260C-UNLIM SN74LV244APWLE OBSOLETE TSSOP PW20TBD Call TI Call TISN74LV244APWR ACTIVE TSSOP PW202000Green(RoHS&no Sb/Br)CU NIPDAU Level-1-260C-UNLIMSN74LV244APWRE4ACTIVE TSSOP PW202000Green(RoHS&no Sb/Br)CU NIPDAU Level-1-260C-UNLIMSN74LV244APWRG4ACTIVE TSSOP PW202000Green(RoHS&no Sb/Br)CU NIPDAU Level-1-260C-UNLIMSN74LV244APWT ACTIVE TSSOP PW20250Green(RoHS&no Sb/Br)CU NIPDAU Level-1-260C-UNLIMSN74LV244APWTE4ACTIVE TSSOP PW20250Green(RoHS&no Sb/Br)CU NIPDAU Level-1-260C-UNLIMSN74LV244ARGYR ACTIVE QFN RGY201000Green(RoHS&no Sb/Br)CU NIPDAU Level-2-260C-1YEAR SN74LV244ARGYRG4ACTIVE QFN RGY20TBD Call TI Call TI(1)The marketing status values are defined as follows:ACTIVE:Product device recommended for new designs.LIFEBUY:TI has announced that the device will be discontinued,and a lifetime-buy period is in effect.NRND:Not recommended for new designs.Device is in production to support existing customers,but TI does not recommend using this part in a new design.PREVIEW:Device has been announced but is not in production.Samples may or may not be available.OBSOLETE:TI has discontinued the production of the device.(2)Eco Plan-The planned eco-friendly classification:Pb-Free(RoHS),Pb-Free(RoHS Exempt),or Green(RoHS&no Sb/Br)-please check /productcontent for the latest availability information and additional product content details.TBD:The Pb-Free/Green conversion plan has not been defined.Pb-Free(RoHS):TI's terms"Lead-Free"or"Pb-Free"mean semiconductor products that are compatible with the current RoHS requirements for all6substances,including the requirement that lead not exceed0.1%by weight in homogeneous materials.Where designed to be soldered at high temperatures,TI Pb-Free products are suitable for use in specified lead-free processes.Pb-Free(RoHS Exempt):This component has a RoHS exemption for either1)lead-based flip-chip solder bumps used between the die and package,or2)lead-based die adhesive used between the die and leadframe.The component is otherwise considered Pb-Free(RoHS compatible)as defined above.Green(RoHS&no Sb/Br):TI defines"Green"to mean Pb-Free(RoHS compatible),and free of Bromine(Br)and Antimony(Sb)based flame retardants(Br or Sb do not exceed0.1%by weight in homogeneous material)(3)MSL,Peak Temp.--The Moisture Sensitivity Level rating according to the JEDEC industry standard classifications,and peak solder temperature.Important Information and Disclaimer:The information provided on this page represents TI's knowledge and belief as of the date that it is provided.TI bases its knowledge and belief on information provided by third parties,and makes no representation or warranty as to the accuracy of such information.Efforts are underway to better integrate information from third parties.TI has taken and continues to take reasonable steps to provide representative and accurate information but may not have conducted destructive testing or chemical analysis on incoming materials and chemicals.TI and TI suppliers consider certain information to be proprietary,and thus CAS numbers and other limited information may not be available for release.In no event shall TI's liability arising out of such information exceed the total purchase price of the TI part(s)at issue in this document sold by TI to Customer on an annual basis.元器件交易网IMPORTANT NOTICETexas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications,enhancements, improvements, and other changes to its products and services at any time and todiscontinue any product or service without notice. Customers should obtain the latest relevant informationbefore placing orders and should verify that such information is current and complete. All products are soldsubject to TI’s terms and conditions of sale supplied at the time of order acknowledgment.TI warrants performance of its hardware products to the specifications applicable at the time of sale inaccordance with TI’s standard warranty. Testing and other quality control techniques are used to the extentTI deems necessary to support this warranty. Except where mandated by government requirements, testingof all parameters of each product is not necessarily performed.TI assumes no liability for applications assistance or customer product design. Customers are responsiblefor their products and applications using TI components. To minimize the risks associated with customerproducts and applications, customers should provide adequate design and operating safeguards.TI does not warrant or represent that any license, either express or implied, is granted under any TI patentright, copyright, mask work right, or other TI intellectual property right relating to any combination, machine,or process in which TI products or services are used. Information published by TI regarding third-partyproducts or services does not constitute a license from TI to use such products or services or a warranty orendorsement thereof. Use of such information may require a license from a third party under the patents orother intellectual property of the third party, or a license from TI under the patents or other intellectualproperty of TI.Reproduction of information in TI data books or data sheets is permissible only if reproduction is withoutalteration and is accompanied by all associated warranties, conditions, limitations, and notices.Reproduction of this information with alteration is an unfair and deceptive business practice. TI is notresponsible or liable for such altered documentation.Resale of TI products or services with statements different from or beyond the parameters stated by TI forthat product or service voids all express and any implied warranties for the associated TI product or serviceand is an unfair and deceptive business practice. TI is not responsible or liable for any such statements.Following are URLs where you can obtain information on other Texas Instruments products and applicationsolutions:Products ApplicationsAmplifiers Audio /audioData Converters Automotive /automotive/broadband DSP BroadbandControl /digitalcontrolDigitalInterface Logic Military /military Power Mgmt Optical Networking /opticalnetworkSecurity /securityMicrocontrollers Low Power Wireless /lpw Telephony /telephonyVideo & Imaging /videoWireless/wirelessMailing Address: Texas InstrumentsPost Office Box 655303 Dallas, Texas 75265Copyright © 2007, Texas Instruments Incorporated。

16DC FIL TERINGPACKAGINGSelf-extinguishing plastic case (V0 = in accordance with UL 94)filled thermosetting resin.Self-extinguishing thermosetting resin (V0= in accordance with UL 94; I3F1 = inaccordance with NF F 16-101).GENERAL DESCRIPTIONThe FFVE for low voltage DC filtering are polyester dielectric capacitors.Working temperature -40°C to +105°C (according to the power to be dissipated)Capacitance range 12µF to 400µF Capacitance tolerance ±10%Rated DC voltage300 to 1900 VT est voltage between terminals @ 25°C 1.5 x V n dc 10s (1.25 V ndc – 10s for FFVI)Insulation voltage between shorted terminals and earth7 kVrms/60sec/50HzThe FFV capacitor is specifically designed for DC filtering, low reactive power.The series uses a non-impregnated metallized polypropylene or polyester dielectric, which features a controlled self-healing process, specially treated to have a very high dielectric strength in operating conditions up to 105°C.The FFV special design gives this series a very low level of stray inductance (18 nH to 40 nH).Furthermore, the performance levels of the FFVE capacitor makes them a very interesting alternative to electrolytic technology, because they can withstand much higher levels of surge voltage, very high rms current ratings, and longer lifetimes.FFVE capacitors meet the Level 2 requirement of the fire behavior standard NF F 16-102.Frequency (kHz)K Rs(f) vs FREQUENCYFor frequency higher than 1 kHzuse following curveELECTRICAL CHARACTERISTICS17D C F I L TE R I N G*Change “K--” to “KJE” for female connectors M5 x 7.5mm*Change “KJ7” to “K7X” for female connectors M5 x 7.5mmLIFETIME EXPECTANCY FFVE POLYESTER50°C60°C 70°C 85°C95°C 105°C V w /V n d c1.51.41.31.21.11.00.40.50.60.70.80.9100100010000Lifetime Expectancy (hour s )1000001000000V w : permanent working or operating DC voltage.18DC FIL TERINGLIFETIME EXPECTANCY FOR FFVE POLYPROPYLENELIFETIME EXPECTANCY FOR FFVIV w : permanent working or operating DC-voltage.50°C70°C 85°C 95°C 105°C V w /V n d c1.61.81.41.21.00.80.6100100010000Lifetime Expectancy (hour s )1000001000000V w : permanent working or operating DC-voltage.50°C70°C85°C 95°C 105°C V w /V n d c1.21.11.00.90.80.70.60.5100100010000Lifetime Expectancy (hour s )100000HOT SPOT CALCULATIONθhot spot = θcase + (P d + P t ) x R thwith P d (Dielectric losses) = Q x tg δ0⇒ [ 1⁄2x C n x (V peak to peak )2x f ] x tg δ0(see tg δ0 vs dielectric pages 2 and 3)P t (Thermal losses) = R s x (I rms )2where C n in Farad I rms in Ampere f in HertzV in Volt R s in Ohmθin °C R th in °C/W R th hot spot/bottom case θcase = bottom middle caseK-- and KJEV w : permanent working or operating DC-voltage.70°C85°C95°C 105°C100°C 50°CV w /V n d c1.61.51.41.31.21.11.00.60.70.80.9100100010000Lifetime Expectancy (hour s )1000001000000KJ7 and K7X。

Data Sheet, V1.2, February 2004Boost ControllerTDA4863-2Power Factor ControllerIC for High Power Factorand Low THD/pfcPower Management & SupplyEdition 2004-02Published by Infineon Technologies AG,St.-Martin-Strasse 53,81669 München, Germany© Infineon Technologies AG 2002.All Rights Reserved.Attention please!The information herein is given to describe certain components and shall not be considered as warranted characteristics.Terms of delivery and rights to technical change reserved.We hereby disclaim any and all warranties, including but not limited to warranties of non-infringement, regarding circuits, descriptions and charts stated herein.Infineon Technologies is an approved CECC rmationFor further information on technology, delivery terms and conditions and prices please contact your nearest Infineon Technologies Office in Germany or our Infineon Technologies Representatives worldwide.WarningsDue to technical requirements components may contain dangerous substances. For information on the types in question please contact your nearest Infineon Technologies Office.Infineon Technologies Components may only be used in life-support devices or systems with the express written approval of Infineon Technologies, if a failure of such components can reasonably be expected to cause the failure of that life-support device or system, or to affect the safety or effectiveness of that device or system. Life-support devices or systems are intended to be implanted in the human body, or to support and/or maintain and sustain and/or protect human life. If they fail, it is reasonable to assume that the health of the user or other persons may be endangered.For questions on technology, delivery and prices please contact the Infineon Technologies Offices in Germany or the Infineon Technologies Companies and Representatives worldwide: see our webpage at .TDA4863-2Revision History:2004-02V1.2Previous Version:PageSubjects (major changes since last revision)Change footnote in Section 3.2 Electrical Characteristics: February 2004Change layout: February 2004TDA4863-2 1Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 1.1Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 1.2Improvements Compared to TDA 4862 and TDA4863 . . . . . . . . . . . . . . . . 4 1.3Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 1.4Pin Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 1.5Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 2Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 2.1Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 2.2IC Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 2.3Voltage Amplifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 2.4Overvoltage Regulator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 2.5Multiplier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 2.6Current Sense Comparator, LEB and RS Flip-Flop . . . . . . . . . . . . . . . . . . 10 2.7Zero Current Detector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 2.8Restart Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 2.9Undervoltage Lockout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 2.10Gate Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 2.11Signal Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 3Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 3.1Absolute Maximum Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 3.2Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 3.3Electrical Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 4Application Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 4.1Results of THD Measurements with Application Board P out=110W . . . . 22 5Package Outlines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25Type Ordering Code Package TDA4863-2Q67040-S4620P-DIP-8-4TDA4863-2GQ67040-S4621P-DSO-8-3Power Factor Controller IC for High Power Factor and Low THD TDA4863-2Final DataBoost ControllerP-DIP-8-4P-DSO-8-31Overview1.1Features•IC for sinusoidal line-current consumption •Power factor achieves nearly 1•Controls boost converter as active harmonic filter for low THD•Start up with low current consumption •Zero current detector for discontinuous operation mode•Output overvoltage protection •Output undervoltage lockout •Internal start up timer•Totem pole output with active shut down •Internal leading edge blanking LEB1.2Improvements Compared to TDA 4862 andTDA4863•Suitable for universal input applications with low THD at low load conditions •Very low start up current•Accurate OVR and V ISENSEmax threshold •Competition compatible V CC thresholds •Enable threshold referred to V VSENSE•Compared to TDA4863 a bigger MOS Transistor can be driven (see 2.10)Figure1Typical application1.3DescriptionThe TDA4863-2 IC controls a boost converter in a way that sinusoidal current is taken from the single phase line supply and stabilized DC voltage is available at the output. This active harmonic filter limits the harmonic currents resulting from the capacitor pulsed charge currents during rectification. The power factor which describes the ratio between active and apparent power is almost one. Line voltage fluctuations can be compensated very efficiently.1.4Pin ConfigurationFigure2Pin Configuration of TDA4863-2Pin Definitions and FunctionsPin Symbol Description1VSENSE Voltage Amplifier Inverting InputVSENSE is connected via a resistive divider to the boost converteroutput. With a capacitor connected to VAOUT the internal erroramplifier acts as an integrator.2VAOUT Voltage Amplifier OutputV VAOUT is connected internally to the first multiplier input. To preventovershoot the input voltage is clamped internally at 5V. If V VAOUT isless than 2.2V the gate driver is inhibited. If the current flowing intothis pin exceeds an internal threshold the multiplier output voltage isreduced to prevent the MOSFET from overvoltage damage.3MULTIN Multiplier InputMULTIN is the second multiplier input and is connected via a resistivedivider to the rectifier output voltage.4ISENSE Current Sense InputISENSE is connected to a sense resistor controlling the MOSFETsource current. The input is internally clamped at -0.3V to preventnegative input voltage interaction. A leading edge blanking circuitrysuppresses voltage spikes when turning the MOSFET on.5DETIN Zero Current Detector InputDETIN is connected to an auxiliary winding and monitors the zerocrossing of the inductor current.6GND Ground7GTDRV Gate Driver OutputGTDRV is the output of a totem-pole circuitry for direct driving aMOSFET. Compared with TDA4863 the TDA4863-2 can drive 20AMOSFETS. To achieve this the gate output voltage V GTL at I GT=0A hasbeen set to 0.85 V. An active shutdown circuitry ensures that GTDRVis set to low if the IC is switched off.8VCC Positive Voltage SupplyIf V CC exceeds the turn-on threshold the IC is switched on. When V CCfalls below the turn-off threshold the IC is switched off. In switch offmode power consumption is very low. Two capacitors should beconnected to VCC. An electrolytic capacitor and 100nF ceramiccapacitor which is used to absorb fast supply current spikes. Makesure that the electrolytic capacitor is discharged before the IC isplugged into the application board.1.5Block DiagramFigure3Internal Bolck Diagram2Functional Description2.1IntroductionConventional electronic ballasts and switch mode power supplies are designed with a bridge rectifier and a bulk capacitor. Their disadvantage is that the circuit draws power from the line when the instantaneous AC voltage exceeds the capacitors voltage. This occurs near the line voltage peak and causes a high charge current spike with following characteristics: The apparent power is higher than the real power that means low power factor condition, the current spikes are non sinusoidal with a high content of harmonics causing line noise, the rectified voltage depends on load condition and requires a large bulk capacitor, special efforts in noise suppression are necessary.With the TDA4863-2 preconverter a sinusoidal current is achieved which varies in direct instantaneous proportional to the input voltage half sine wave and so provides a power factor near 1. This is due to the appearance of almost any complex load like a resistive one at the AC line. The harmonic distortions are reduced and comply with the IEC555 standard requirements.2.2IC DescriptionThe TDA4863-2 contains a wide bandwidth voltage amplifier used in a feedback loop, an overvoltage regulator, an one quadrant multiplier with a wide linear operating range, a current sense comparator, a zero current detector, a PWM and logic circuitry, a totem-pole MOSFET driver, an internal trimmed voltage reference, a restart timer and an undervoltage lockout circuitry.2.3Voltage AmplifierWith an external capacitor between the pins VSENSE and VAOUT the voltage amplifier acts like an integrator. The integrator monitors the average output voltage over several line cycles. Typically the integrator´s bandwidth is set below 20Hz in order to suppress the 100Hz ripple of the rectified line voltage. The voltage amplifier is internally compensated and has a gain bandwidth of 5MHz (typ.) and a phase margin of 80 degrees. The non-inverting input is biased internally to 2.5V. The output is directly connected to the multiplier input.The gate drive is disabled when VSENSE voltage is less than 0.2V or VAOUT voltage is less than 2.2V.If the MOSFET is placed nearby the controller switching interferences have to be taken into account. The output of the voltage amplifier is designed in a way to minimize these inteferences.2.4Overvoltage RegulatorBecause of the integrator´s low bandwidth fast changes of the output voltage can’t be regulated within an adequate time. Fast output changes occur during initial start-up, sudden load removal, or output arcing. While the integrator´s differential input voltage remains zero during this fast changes a peak current is flowing through the external capacitor into pin VAOUT. If this current exceeds an internal defined margin the overvoltage regulator circuitry reduces the multiplier output voltage. As a result the on time of the MOSFET is reduced.2.5MultiplierThe one quadrant multiplier regulates the gate driver with respect of the DC output voltage and the AC half wave rectified input voltage. Both inputs are designed to achieve good linearity over a wide dynamic range to represent an AC line free from distortion. Special efforts have been made to assure universal line applications with respect to a 90 to 270V AC range.The multiplier output is internally clamped to1.3V. So the MOSFET is protected against critical operating during start up.2.6Current Sense Comparator, LEB and RS Flip-FlopThe source current of the MOS transistor is transferred into a sense voltage via the external sense resistor. The multiplier output voltage is compared with this sense voltage. Switch on time of the MOS transistor is determined by the comparision result To protect the current comparator input from negative pulses a current source is inserted which sends current out of the ISENSE pin every time when V ISENSE-signal is falling below ground potential. An internal RC-filter is connected at the ISENSE pin which smoothes the switch-on current spike.The remaining switch-on current spike is blanked out via a leading edge blanking circuit with a blanking time of typ. 200ns.The RS Flip-Flop ensures that only one single switch-on and switch-off pulse appears at the gate drive output during a given cycle (double pulse suppression).2.7Zero Current DetectorThe zero current detector senses the inductor current via an auxiliary winding and ensures that the next on-time of the MOSFET is initiated immediately when the inductor current has reached zero. This reduces the reverse recovery losses of the boost converter diode to a minimum. The MOSFET is switched off when the voltage drop of the shunt resistor exceeds the voltage level of the multiplier output. So the boost current waveform has a triangular shape and there are no deadtime gaps between the cycles. This leads to a continuous AC line current limiting the peak current to twice of the average current.To prevent false tripping the zero current detector is designed as a Schmitt-Trigger with a hysteresis of 0.5V. An internal 5V clamp protects the input from overvoltage breakdown, a 0.6V clamp prevents substrate injection. An external resistor has to be used in series with the auxiliary winding to limit the current through the clamps.2.8Restart TimerThe restart timer function eliminates the need of an oscillator. The timer starts or restarts the TDA4863-2 when the driver output has been off for more than 150µs after the inductor current reaches zero.2.9Undervoltage LockoutAn undervoltage lockout circuitry switches the IC on when V CC reaches the upper threshold V CCH and switches the IC off when V CC is falling below the lower threshold V CCL. During start up the supply current is less then 100µA.An internal voltage clamp has been added to protect the IC from V CC overvoltage condition. When using this clamp special care must be taken on power dissipation. Start up current is provided by an external start up resistor which is connected from the AC line to the input supply voltage V CC and a storage capacitor which is connected from V CC to ground. Be aware that this capacitor is discharged before the IC is plugged into the application board. Otherwise the IC can be destroyed due to the high capacitor voltage.Bootstrap power supply is created with the previous mentioned auxiliary winding and a diode (see “Application Circuit” on Page21).2.10Gate DriveThe TDA4863-2 totem pole output stage is MOSFET compatible. An internal protection ciruitry is activated when V CC is within the start up phase and ensures that the MOSFET is turned off. The totem pole output has been optimized to achieve minimized cross conduction current during high speed operation.Compared to TDA4863 a bigger MOS Transistor can be driven by the TDA4863-2. When a big MOSFET is used in applications with TDA4863, for example SPP20N60C3, the falling edge of the gate drive voltage can swing under GND and can cause false triggering of the IC. To prevent false triggering the gate drive voltage of theTDA 4863-2 at low state and gate current I GT= 0mA is set to V GTL= 0.85V (TDA4863: V GTL=0.25V). The difference between TDA4863-2 and TDA4863 is also depicted in diagramm: gate drive voltage low state on page 20.2.11Signal DiagramsFigure4Typical signals3Electrical Characteristics3.1Absolute Maximum RatingsParameter Symbol Limit Values Unit Remarksmin.max.Supply + Zener Current ICCH + IZ20mASupply Voltage VCC -0.3VZV VZ= ZenerVoltageI CC+I Z = 20mAVoltage at Pin 1,3,4-0.3 6.5Current into Pin 2I VAOUT-1040mA V VAOUT=4V,V VSENSE=2.8VV VAOUT=0V,V VSENSE=2.3Vt<1msCurrent into Pin 5I DETIN-1010DETIN>6VDETIN<0.4Vt<1msCurrent into Pin 7I GTDRV-500500t<1msESD Protection2000V MIL STD 883Cmethod 3015.6,100pF,1500ΩStorage Temperature T stg-50150°COperating Junction Temperature T J-40150Thermal Resistance Junction-Ambient R thJA100180K/W P-DIP-8-4P-DSO-8-33.2CharacteristicsUnless otherwise stated, -40°C < Tj < 150°C, VCC= 14.5VParameter Symbol Limit Values Unit Test Conditionmin.typ.max.Start-Up circuitZener Voltage V Z182022V I CC+I Z=20mA Start-up Supply Current I CCL20100µA V CC=V CCON-0.5V Operating Supply Current I CCH46mA Output lowV CC Turn-ON Threshold V CCON1212.513VV CC Turn-OFF Threshold V CCOFF9.51010. 5V CC Hysteresis V CCHY 2.5Voltage AmplifierVoltage feedback InputThresholdV FB 2.45 2.5 2.55VLine Regulation V FBLR5mV V CC=12V to 16V Open Loop Voltage Gain1)G V100dBUnity Gain Bandwidth1)B W5MHzPhase Margin1)M80DegrBias Current VSENSE I BVSENSE-1.0-0.3µAEnable Threshold VVSENSE0.170.20.25VInhibit Threshold Voltage V VAOUTI 2.1 2.2 2.3V ISENSE=-0.38V Inhibit Time Delay t dVA3µs V ISENSE=-0.38V Output Current Source I VAOUTH-6mA V VAOUT=0VV VSENSE=2.3V,t<1msOutput Current Sink I VAOUTL35V VAOUT=4VV VSENSE=2.8V,t<1msUpper Clamp Voltage V VAOUTH 4.8 5.4 6.0V V VSENSE=2.3V,I VAOUT=-0.2mA Lower Clamp Voltage V VAOUTL0.8 1.1 1.4V V VSENSE=2.8V,I VAOUT=0.5mA1)not subject to production - verified by characterizationOvervoltage RegulatorThreshold Current I OVR354045µA T j=25°C ,V VAOUT = 3.5 V Current ComparatorInput Bias Current I BISENSE-1-0.21µA V ISENSE=0VInput Offset Voltage (T j = 25 °C)V ISENSEO25mV V VAOUT=2.7VV MULTIN = 0 VMax Threshold Voltage V ISENSEM0.95 1.0 1.05VThreshold at OVR VISENOVR 0.05IOVR=50µALeading Edge Blanking t LEB100200300nsShut Down Delay t dISG80130DetectorUpper Threshold Voltage V DETINU 1.5 1.6VLower Threshold Voltage V DETINL0.95 1.1Hysteresis VDETINHY0.250.40.55Input Current I BDETIN-1-0.21µA V DETIN=2V Input Clamp VoltageHigh State Low State V DETINHCV DETINLC4.50.14.90.45.40.7VI DETIN=5mAI DETIN=-5mAMultiplierInput bias current I BMULTIN-1-0.21µA V MULTIN=0V Dynamic voltage rangeMULTINV MULTIN0 to 4V V VAOUT=2.75VDynamic voltage range VAOUT V VAOUT V FB toV FB+1.5V MULTIN=1VMultiplier Gain KlowK high 0.30.7V VAOUT<3V,V MULTIN=1VV VAOUT>3.5V,V MULTIN=1VK=delta VISENSE /delta VVAOUTat VMULTIN=constant3.2Characteristics (cont’d)Unless otherwise stated, -40°C < Tj < 150°C, VCC= 14.5VParameter Symbol Limit Values Unit Test Conditionmin.typ.max.Restart Timer Restart time t RES100160250µsGate DriveGate drive voltage low stateV GTL 0.85I GT =0mA V GTL 1.0VI GT =2mA 1.7I GT =20mA 2.2I GT =200mA Gate drive voltage high state V GTH10.8I GT =-5mA,see “Gate Drive Voltage High State versus V cc ” on Page 20Gate drive voltage active shut down V GTSD 1 1.25I GT =20mA, V CC =9V Rise time t rise 80130nsC GT = 4.7nF V GT =2 (8V)Fall timet fall551303.2Characteristics (cont’d)Unless otherwise stated, -40°C < T j < 150°C, V CC = 14.5VParameterSymbolLimit Values UnitTest Conditionmin.typ.max.3.3Electrical DiagramsI cc versus V ccI ccl versus V ccV CCON/OFF versus TemperatureI CCL versus Temperature, V CC = 10V00,511,522,533,544,5505101520Vcc/VI c c / m A051015202530354045500246810121416Vcc / VI c c l / uA7891011121314-404080120160Tj / °CV c c / V05101520253035404550-404080120160Tj / °CI C C L / u AVFB versus Temperature (pin1 connected to pin2)Overvoltage Regulator V ISENSE versus Threshold VoltageOpen Loop Gain and Phase versus FrequencyLeading Edge Blanking versus Temperature2,452,462,472,482,492,52,512,522,532,542,55-404080120160Tj / °CV F B / V00,20,40,60,811,2353739414345Iovp / uAV I S E N S E / V020406080100120f/kHz20406080100120140160180Phi/deg G V /dB 050100150200250300-4004080120160Tj / °CL E B / n sRestart Time versus Temperature1234V MULTIN / V 100120140160180200220-404080120160Tj / °Ct r s t / u s2,533,544,5V VAOUT / VGate Drive Rise Time and Fall Time versus TemperatureGate Drive Voltage High State versus V cc020*********120140-4004080120160Tj / °Cr i s e t i m e / n s88,599,51010,51111,512111315Vcc / VV G T H / V4Application CircuitFigure5P out = 110 W, Universal Input V in = 90-270V AC4.1Results of THD Measurements with Application Board P out=110W (Measurements according to IEC61000-3-2.150% limit (red line): Momentary measured value must be below this limit.100% limit (blue line): Average of measured values must be below this limit.The worst measured momentary value is shown in the diagrams.)Figure6THD Class C:P max=110W, V inac=90V, I out=250mA, V out=420V, PF=0.998Figure7THD Class C:P max=110W, V inac=220V, I out=250mA, V aout=420V, PF=0.992Figure8THD Class C:P max=110W, V inac=270V, I out=250mA, V aout=420V, PF=0.978Figure9THD Class C:P max=110W, V inac=90V, I out=140mA, V aout=420V, PF=0.999Figure10THD Class C:P max=110W, V inac=220V, I out=140mA, V aout=420V, PF=0.975Figure11THD Class C:P max=110W, V inac=270V, I out=140mA, V aout=420V, PF=0.8835Package OutlinesFigure12Figure13You can find all of our packages, sorts of packing and others in ourInfineon Internet Page “Products”: /products.Dimensions in mmInfineon goes for Business Excellence “Business excellence means intelligent approaches and clearly defined processes, which are both constantly under review and ultimately lead to good operating results.Better operating results and business excellence mean less idleness and wastefulness for all of us, more professional success, more accurate information, a better overview and, thereby, less frustration and more satisfaction.”Dr. Ulrich Schumacherw w w.i n f i n e o n.c o m。

Nigeria Omotoshi 4×9E Simple-Cycle Gas Turbine Power Plant ProjectSPEEDTRONIC™MARK VI TRAINING MANUALCONTENTS1. INTRODUCTION (2)1. 概述 (2)2. CONTROL SYSTEM HISTORY (3)2. 控制器的发展历史 (3)3. CONTROL SYSTEM FUNCTIONS (6)3. 控制系统功能 (6)4. Gas turbine GEN. set protective (20)4. 燃机发电机组的保护 (20)5. SPEEDTRONIC MARK VI ARCHITECTUR (23)5. SPEEDTRONIC MARK VI 配置 (23)6. Network (58)6. 网络 (58)1. INTRODUCTION1. 概述The SPEEDTRONIC TM Mark VI Gas Turbine Control System is the latest derivative in the highly successful SPEEDTRONIC TM series. Preceding systems were based on automated turbine control, protection and sequencing techniques dating back to the late 1940s. The main functions of the MARK VI turbine control system are as follows:SPEEDTRONIC TM Mark VI燃机控制系统是最新推出的、最成功的SPEEDTRONIC TM系列的过程控制系统。

该系统继承了GE公司自20世纪四十年代以来的燃机自动控制、保护和顺序控制技术。

HD74LS86Quadruple 2-input Exclusive-OR GatesREJ03D0422–0200Rev.2.00Feb.18.2005 Features• Ordering InformationPart Name Package Type Package Code(Previous Code)PackageAbbreviationTaping Abbreviation(Quantity)HD74LS86P DILP-14pin PRDP0014AB-B(DP-14AV)P —HD74LS86FPEL SOP-14 pin (JEITA) PRSP0014DF-B(FP-14DAV)FP EL (2,000 pcs/reel)HD74LS86RPEL SOP-14 pin (JEDEC) PRSP0014DE-A(FP-14DNV)RP EL (2,500 pcs/reel)Note: Please consult the sales office for the above package availability.Pin ArrangementFunction TableInputs OutputsA B YL L LL H HH L HH H LH; high level, L; low levelAbsolute Maximum RatingsItem Symbol Ratings UnitSupply voltage V CC 7 V Input voltage V IN 7 V Power dissipation P T 400 mW Storage temperature Tstg –65 to +150 °C Note: Voltage value, unless otherwise noted, are with respect to network ground terminal.Recommended Operating ConditionsItem Symbol Min Typ Max UnitSupply voltage V CC 4.75 5.00 5.25 VI OH — — –400 µAOutput currentI OL — — 8 mAOperating temperature Topr –20 25 75 °CElectrical Characteristics(Ta = –20 to +75 °C)ItemSymbol min. typ.* max. UnitConditionV IH 2.0 — — V Input voltageV IL — — 0.8 VV OH 2.7 — — VV CC = 4.75 V, V IH = 2 V, V IL = 0.8 V,I OH = –400 µA— — 0.4 I OL = 4 mA Output voltageV OL — — 0.5 VI OL = 8 mA V CC = 4.75 V, V IH = 2 V,V IL = 0.8 VI IH — — 40 µA V CC = 5.25 V, V I = 2.7 V I IL — — –0.8 mA V CC = 5.25 V, V I = 0.4 VInput current I I —— 0.2 mA V CC = 5.25 V, V I = 7 V Short-circuit outputcurrentI OS –20 — –100 mA V CC = 5.25 VSupply current** I CC — 6.1 10 mA V CC = 5.25 VInput clamp voltageV IK — — –1.5 V V CC = 4.75 V, I IN = –18 mANotes: * V CC = 5 V, Ta = 25°C** I CC is measured with all outputs open and all other inputs grounded.Switching Characteristics(V CC = 5 V, Ta = 25°C)Item Symbol Inputs min. typ. max. Unit Test Conditionst PLH — 12 23 nst PHL A or B— 10 17 ns Other inputs = 0 V t PLH — 20 30 nsPropagation delay timet PHL A or B— 13 22 nsC L = 15 pF,R L = 2 k Ω Other inputs = 4.5 VNote: Refer to Test Circuit and Waveform of the Common Item "TTL Common Matter (Document No.: REJ27D0005-0100)".Package Dimensions RENESAS SALES OFFICESRefer to "/en/network" for the latest and detailed information.Renesas Technology America, Inc.450 Holger Way, San Jose, CA 95134-1368, U.S.ATel: <1> (408) 382-7500, Fax: <1> (408) 382-7501Renesas Technology Europe LimitedDukes Meadow, Millboard Road, Bourne End, Buckinghamshire, SL8 5FH, U.K.Tel: <44> (1628) 585-100, Fax: <44> (1628) 585-900Renesas Technology Hong Kong Ltd.7th Floor, North Tower, World Finance Centre, Harbour City, 1 Canton Road, Tsimshatsui, Kowloon, Hong KongTel: <852> 2265-6688, Fax: <852> 2730-6071Renesas Technology Taiwan Co., Ltd.10th Floor, No.99, Fushing North Road, Taipei, TaiwanTel: <886> (2) 2715-2888, Fax: <886> (2) 2713-2999Renesas Technology (Shanghai) Co., Ltd.Unit2607 Ruijing Building, No.205 Maoming Road (S), Shanghai 200020, ChinaTel: <86> (21) 6472-1001, Fax: <86> (21) 6415-2952Renesas Technology Singapore Pte. Ltd.1 Harbour Front Avenue, #06-10, Keppel Bay Tower, Singapore 098632Tel: <65> 6213-0200, Fax: <65> 6278-8001。

December 2005 Rev. 41/12TS321Low Power Single Operational Amplifier■Large output voltage swing:■0 to 3.5V min. (@V CC = 5V)■Low supply current: 500µA ■Low input bias current: 20nA ■Low input offset voltage: 2mV max.■Wide power supply range:■Single supply: +3V to +30V ■Dual supplies: ±1.5V to ±15V ■Stable with high capacitive loadsDescriptionThe TS321 is intended for cost-sensitiveapplications where space saving is of great importance. This bipolar op-amp offers thebenefits of a reduced component size (SOT23-5 package), with specifications that match (or are better) industry standard devices (like the popular LM358A, LM324, etc.). The TS321 has an input common mode range (V icm ) that includes ground, and therefore can be employed in single supply applications.Order CodesPart Number TemperatureRangePackage Packaging Marking TS321IL T -40°C, +125°C SOT23-5L T ape & Reel K401TS321ID/IDT SO8Tube or Tape & Reel321I TS321AILT SOT23-5L T ape & Reel K402TS321AID/AIDT SO8Tube or Tape & Reel321AI TS321IYLT SOT23-5L (automotive grade level)T ape & ReelK406TS321AIYLT TS321IYD/IYDT SO-8 (automotive grade level)Tube or Tape & ReelTS321AIYD/AIYDTTypical Application Schematics TS321 1 Typical Application Schematics2/12TS321Absolute Maximum Ratings3/122Absolute Maximum RatingsTable 1.Key parameters and their absolute maximum ratingsSymbol ParameterValue Unit V CC Supply Voltage ±16 to 32V Vi Input Voltage-0.3 to +32V V idDifferential Input Voltage+32VOutput Short-circuit Duration - note (1)1.Short-circuits from the output to V CC can cause excessive heating if V CC > 15V. The maximum output current isapproximately 40mA independent of the magnitude of V CC .Infinite I inInput Current - note (2)2.This input current only exists when the voltage at any of the input leads is driven negative. It is due to the collector-basejunction of the input PNP transistor becoming forward biased and thereby acting as input diodes clamps. In addition to this diode action, there is also NPN parasitic action on the IC chip. This transistor action can cause the output voltages of the Op-amps to go to the V CC voltage level (or to ground for a large overdrive) for the time duration than an input is driven negative. This is not destructive and normal output will set up again for input voltage higher than -0.3V.50mA T oper Operating Free Air Temperature Range -40 to +125°C T stg Storage Temperature Range-65 to +150°C R thjaThermal Resistance Junction to Ambient (3)SOT23-5SO83.Short-circuits can cause excessive heating. Destructive dissipation can result from simultaneous short-circuit on allamplifiers. All values are typical.250125°C/W R thjcThermal Resistance Junction to Case SOT23-5SO88140°C/W ESDHBM: Human Body Model (4)4.Human body model, 100pF discharged through a 1.5k Ω resistor into pin of device.300V MM: Machine Model (5)5.Machine model ESD, a 200pF cap is charged to the specified voltage, then discharged directly into the IC with no externalseries resistor (internal resistor < 5Ω), into pin to pin of device.200V3 ElectricalCharacteristicsTable 2.V cc+ = +5V, V cc- = Ground, V o = 1.4V, T amb = +25°C (unless otherwise specified) Symbol Parameter Conditions Min.Typ.Max.UnitV io Input Offset Voltage (1)T amb = +25°CTS321AT min.≤ T amb≤ T max.TS321A0.54253mVI io Input Offset Current T amb = +25°CT min.≤ T amb≤ T max.23050nAI ib Input Bias Current (2)T amb = +25°CT min.≤ T amb≤ T max20150200nAA vd Large Signal VoltageGainV CC+ = +15V, R L = 2kΩ, Vo = 1.4V to 11.4VT amb = +25°CT min.≤ T amb≤ T max.5025100V/mVSVR Supply VoltageRejection RatioR s ≤ 10kΩV CC+ = 5 to 30VT amb = +25°C65110dBI CC Supply Current, no load T amb = +25°C, V CC = +5VV CC = +30VT min.≤ T amb≤ T max., V CC = +5VV CC = +305006006008009009001000µAV icm Common Mode InputVoltage Range (3)V CC = +30VT amb = +25°CT min.≤ T amb≤ T max.V CC -1.5V CC -2VCMR Common ModeRejection RatioR s ≤ 10kΩT amb = +25°C6585dBI source Output Current Source V id = +1VV CC = +15V, V o = +2V2040mAI sink Output Sink Current V id = -1VV CC = +15V, V o = +2VV CC = +15V, V o = +0.2V10122050mAµAI o Short Circuit to Ground V CC = +15V4060mAV OH High Level OutputVoltageV CC = +30VT amb = +25°C, R L = 2kΩT min.≤ T amb≤ T max.T amb = +25°C, R L = 10kΩT min.≤ T amb≤ T max.V CC = +5V, R L = 2kΩT amb = +25°CT min.≤ T amb≤ T max.2625.52726.53.532728VV OL Low Level OutputVoltageR L = 10kΩT amb = +25°CT min.≤ T amb≤ T max.51520mV4/12+-1.Vo = 1.4V, Rs = 0W, 5V < V CC+ < 30V, 0 < V ic < V CC+ - 1.5V2.The direction of the input current is out of the IC. This current is essentially constant, independent of the state of the outputso no loading change exists on the input lines.3.The input common-mode voltage of either input signal voltage should not be allowed to go negative by more than 0.3V.The upper end of the common-mode voltage range is V CC+ - 1.5V, but either or both inputs can go to +32V withoutdamage.5/126/12Figure 2.I CC = f(t)Figure 3.AC coupled inverting amplifierFigure 4.Non-inverting DC gainFigure 5.AC coupled non-inverting amplifierFigure 6.DC summing amplifierFR4TS321Macromodel 4 MacromodelNote:Please consider following remarks before using this macromodel:All models are a trade-off between accuracy and complexity (i.e. simulation time).Macromodels are not a substitute to breadboarding; rather, they confirm the validity of adesign approach and help to select surrounding component values.A macromodel emulates the NOMINAL performance of a TYPICAL device withinSPECIFIED OPERATING CONDITIONS (i.e. temperature, supply voltage, etc.). Thus themacromodel is often not as exhaustive as the datasheet, its goal is to illustrate the mainparameters of the product.Data issued from macromodels used outside of its specified conditions (Vcc, Temperature,etc) or even worse: outside of the device operating conditions (Vcc, Vicm, etc) are notreliable in any way.** Standard Linear Ics Macromodels, 1993.** CONNECTIONS :* 1 INVERTING INPUT* 2 NON-INVERTING INPUT* 3 OUTPUT* 4 POSITIVE POWER SUPPLY* 5 NEGATIVE POWER SUPPLY.SUBCKT TS321 1 2 3 4 5***************************.MODEL MDTH D IS=1E-8 KF=3.104131E-15 CJO=10F* INPUT STAGECIP 2 5 1.000000E-12CIN 1 5 1.000000E-12EIP 10 5 2 5 1EIN 16 5 1 5 1RIP 10 11 2.600000E+01RIN 15 16 2.600000E+01RIS 11 15 2.003862E+02DIP 11 12 MDTH 400E-12DIN 15 14 MDTH 400E-12VOFP 12 13 DC 0VOFN 13 14 DC 0IPOL 13 5 1.000000E-05CPS 11 15 3.783376E-09DINN 17 13 MDTH 400E-12VIN 17 5 0.000000e+00DINR 15 18 MDTH 400E-12VIP 4 18 2.000000E+00FCP 4 5 VOFP 3.400000E+01FCN 5 4 VOFN 3.400000E+01FIBP 2 5 VOFN 2.000000E-03FIBN 5 1 VOFP 2.000000E-03* AMPLIFYING STAGEFIP 5 19 VOFP 3.600000E+02FIN 5 19 VOFN 3.600000E+02RG1 19 5 3.652997E+06RG2 19 4 3.652997E+06CC 19 5 6.000000E-097/12Macromodel TS3218/12DOPM 19 22 MDTH 400E-12 DONM 21 19 MDTH 400E-12 HOPM 22 28 VOUT 7.500000E+03 VIPM 28 4 1.500000E+02HONM 21 27 VOUT 7.500000E+03 VINM 5 27 1.500000E+02EOUT 26 23 19 5 1VOUT 23 5 0ROUT 26 3 20COUT 3 5 1.000000E-12DOP 19 25 MDTH 400E-12VOP 4 25 2.242230E+00DON 24 19 MDTH 400E-12VON 24 5 7.922301E-01.ENDSTable 3.V CC+ = 3V, V CC- = 0V, R L, C L connected to V CC/2, T amb = 25°C (unless otherwise specified) Symbol Conditions Value Unit V io0mVA vd R L = 2kΩ100V/mVI CC No load, per operator300µAV icm0 to +3.5VV OH R L = 2kΩ+3.5VV OL R L = 2kΩ5mVI os V o = 0V40mAGBP R L = 2kΩ, C L = 100pF0.8MHzSR R L = 2kΩ, C L = 100pF0.4V/µs∅m R L = 2kΩ, C L = 100pF60DegreesTS321Macromodel9/12Figure 7.I CC = f(t)Figure 8.AC coupled inverting amplifierFigure 9.Non-inverting DC gainFigure 10.AC coupled non-inverting amplifierFigure 11.DC summing amplifierFR4Package Mechanical Data TS321 5 Package Mechanical DataIn order to meet environmental requirements, ST offers these devices in ECOPACK®packages. These packages have a Lead-free second level interconnect. The category ofsecond level interconnect is marked on the package and on the inner box label, incompliance with JEDEC Standard JESD97. The maximum ratings related to solderingconditions are also marked on the inner box label. ECOPACK is an ST trademark.ECOPACK specifications are available at: .10/12TS321Package Mechanical Data11/12Revision history TS32112/126 Revision historyInformation furnished is believed to be accurate and reliable. However, STMicroelectronics assumes no responsibility for the consequences of use of such information nor for any infringement of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of STMicroelectronics. Specifications mentioned in this publication are subject to change without notice. This publication supersedes and replaces all information previously supplied. STMicroelectronics products are not authorized for use as critical components in life support devices or systems without express written approval of STMicroelectronics.The ST logo is a registered trademark of STMicroelectronics.All other names are the property of their respective owners© 12 STMicroelectronics - All rights reserved STMicroelectronics group of companiesAustralia - Belgium - Brazil - Canada - China - Czech Republic - Finland - France - Germany - Hong Kong - India - Israel - Italy - Japan -Malaysia - Malta - Morocco - Singapore - Spain - Sweden - Switzerland - United Kingdom - United States of America。
