【精编推荐】CombineUserGuide船舶M站操作手册

INMARSAT-M(THRANE)站操作说明INMARSAT-M(THRANE)站操作说明一、打开 M站 HANDSET 电源开关按下①键即可。

（关机时应按住①键三秒）二、 选择洋区：按 2nd→ 1menu→ 用↑↓选择 Area →OK→用↑↓选择所需洋区 →OK →EXIT三、 选择岸站：摁 2nd→ 1menu→ 用↑↓选择 Default LES →OK →用↑↓选择所需岸站 →OK→EXIT四、电话拨号方法：　1.拿起话筒，听到长音。

　2.按*+岸站码+*+00+国家码+地区码+用户码和电话提示键结束，如果使用本机内设岸站，直 接拨 00+国家码+地区码+用户码和电话提示键结束。

3.听到拨号声后，表示电话接通。

　4.通话结束，放回话筒，液晶屏上将显示通话时间。

　五、发送传真　1.将所需发送的文件字面朝下放入传真机的送纸槽内。

2 在传真机上用数字键输入用户码和#号结束,START键发送；也可直接输入 00+国家码+地区 码+用户码和#，按 FAX/START键连通用户后自动发送传真。

3.注意观察 HANDSET液晶屏将依次显示SendingPage 1NegotiatingFax­LESconnectedFax­FaxConnectedFaxcalling4.接通用户后，传真机液晶屏上显示 send page xG3 等字样。

5. 文件全部发完后，显示窗显示 TRANSMITINGOK，传真发送完毕。

6.HANDSET 液晶屏上将显示发送时间。

　船舶设备操作规程 编号：0722-07-2146版次：03 卫通 M 站操作说明页次：17 附2 * 本传真在接受传真时无铃声提示，平时注意查看接受。

六、查看通讯记录：按 2nd→ 1menu→ 用↑↓选择 Call log →OK →用↑↓选择并查看记录 → EXIT七、查看通讯总时间:按 2nd→ 1menu→ 用↑↓选择 Calls total →OK →屏幕上将显示 Total time → EXIT。

GMDSS 实操手册NAVIGATION,IT IS AN ENTERPRISE OF BRAVE MAN!航海，是勇敢者的事业！SSB FS-5000 基本操作一、控制单元1.开关机1） 开机：按POWER 一秒以上2） 关机：同上2 屏幕亮度、对比度调整1） 亮度：DIMMER ，调整键盘照明；2） 对比度：CONSTRAST ，调整字符与背景的清晰度．3. 时间：按CLOCK 键，输入时间，按ＳＴＯＰ，再按一下ＣＬＯＣＫ键．4. 工作种类选择1) SSB ：电话通信2) TELEX ：电传 3）*CW ：人工莫尔斯报＊每按一次显示一种5. 经纬度显示：外接ＧＰＳ．6. 工作种类的中心频率1) FAX ：ＢＦＯ[１９００]2) TELEX ：ＢＦＯ[１７００]二、电台收发频率的设置（一）查看海岸电台表１、 Ｒ／Ｔ：无线电话频率１）看时间，找频率，查到的频率是接收频率，所以输入时要换成发射频率；AGC 开启开关 AGC 档位选择SLOW 、FAST２）查接收通波表：在表的下面最后一行，时间是Ｈ＋１０'，例１h10'、2h10''等２、ＲＡＤＩＯＴＥＬＥＸ：电传频率——同电话（二）船台频率的输入：发射频率（ＴＸ）≤接收频率（ＲＸ）１、直接输入法１）设置工作种类ＳＳＢ／ＴＥＬＥＸ２）查表后输入发射频率和接收频率ＴＸ键→输入频率→按ENTER 键ＲＸ键→输入频率→按ENTER 键２、调用国际信道法（ＩＴＵ）１）设置工作种类：ＳＳＢ／ＴＥＬＥＸ２）调用：ＩＴＵ键→信道号（例８１８）→按ENTER 键三、接收机的调整１.设置工作方式: SSB或TELEX1）电话通讯按：SSB单边带电话找H24（全天使用）2）电传通讯按：TELEX 中心频率1700 要知道BFO注意：船台发送频率小于接收频率TX<RX 操作如下：TX→频率→ENTERRX→频率→ENTER*TRAFFIC LIST(通播表) 里面的频率设在我台的接收频率上２.设置接收频率：直接输入法或ITU法３.通断扬声器：选择话筒或扬声器４.调节音量：按VOLUME的▲▼（刚开始时调大点，通信过程中调到适中）５. 调节灵敏度：按SENSITIVITY的▲▼（调到信号最佳，噪声最小,同时观察SEN表和S表）６. 设置AGC的参数：用于信号强度的均衡,增强弱信号,减弱强信号1)通常设：SLOW 2)远距离、信号弱时关闭：OFF（AGC） 3)双工通信、外干扰强时设：FAST７. 选择接收带宽(频带宽度)：SSB 3KHZ ； TELEX 0.3KHZ８. 静噪电路ＳＱ：用于抑制机内噪声，一般开启，信号弱时关闭９.消噪电路ＮＢ：用于抑制外部强脉冲干扰，平时可开可关，外界干扰大或双工时开启１０．接收频率４.５MHz以下的信号微调：只有在RX<4.5MHz时才有用。

国际航行船舶舱单申报系统用户操作手册广东电子口岸2017 年7 月目录第一篇前言 (4)第二篇使用需知 (5)第三篇舱单申报介绍 (6)功能简介 (6)术语定义 (6)重要提醒 (7)∙关于界面 (7)∙关于键盘操作 (7)第四篇进入系统 (9)第五篇通用功能 (10)∙折叠/展开菜单 (10)∙关闭选项卡 (10)∙必填数据与选填数据的标识 (10)∙日期、时间选择 (11)∙自动填充下拉选择框 (11)第六篇国际航行船舶舱单单证 (13)第一章原始舱单 (13)1.1原始舱单录入 (14)1.2原始舱单操作 (18)第二章预配舱单 (23)2.1 预配舱单录入 (23)2.2 预配舱单操作 (25)第三章理货报告 (26)3.1进口理货录入 (26)3.2进口理货操作 (27)3.3出口理货录入 (28)3.4出口理货操作 (30)第四章出口运抵 (31)4.1（集）出口运抵报文录入 (31)4.2（集）出口运抵报文操作 (32)4.3（散）出口运抵报文录入 (33)4.4（散）出口运抵报文操作 (34)第五章装载舱单 (34)5.1 装载舱单录入 (34)5.2 装载舱单操作 (36)第六章分拨/分流申请 (36)6.1分流申请录入 (36)6.2分流申请操作 (37)6.3分拨申请录入 (38)6.4分拨申请操作 (39)第七章分流/分拨运抵 (40)7.1（集）分流/分拨运抵录入 (40)7.2（集）分流/分拨运抵列表 (41)7.3（散）分流/分拨运抵录入 (42)7.4（散）分流/分拨运抵列表 (43)第八章直接/落装改配 (44)8.1直接改配录入 (44)8.2直接改配列表 (45)8.3落装申请录入 (46)8.4落装申请列表 (47)8.5落装改配录入 (48)8.6落装改配列表 (50)第九章进口改靠港 (51)9.1进口改靠港录入 (51)9.2进口改靠港列表 (52)第十章空箱调运 (53)10.1进口空箱调运录入 (53)10.2进口空箱调运列表 (54)10.3出口空箱调运录入 (55)10.4出口空箱调运列表 (56)第十一章国际转运 (56)11.1国际转运录入 (56)11.2国际转运列表 (57)第十二章系统管理 (58)第一篇前言为配合海关总署令第172号《中华人民共和国海关进出境运输工具舱单管理办法》（以下简称“舱单管理办法”）对进出口运输工具及其装载货物的管理要求，广东省电子口岸对广东国际贸易单一窗口系统进行了升级，增加了国际航行船舶舱单申报系统（以下简称“舱单系统”），舱单系统涵括了舱单管理办法中规定的全部内容，其中包括反映进出境船舶装载货物、物品的货物舱单模块和舱单相关数据模块，码头作业相关的运抵和理货模块，以及反映航行动态情况的运输工具管理模块。

船舶数据终端操作维护手册一、船舶数据终端概述CGSDT-9200船舶数据终端是由北京兴兴交通通信工程技术公司自主研发的基于VHF的内河水上数据通信的船舶终端产品。

船舶终端具备数字安全信息广播、船舶遇险报警、船舶动态轮询、船舶短信息、双向邮件传输、自动入退网等功能。

设备的各项控制功能和设置均在液晶显示器上以中文方式显示，操作简单、直观；本终端配置的行式热敏打印机，打印速度快、故障率低。

适用于各类船只自动接收并打印由电台播发的有关长江安全航行警告信息和专用信息。

全功能型船舶终端与PC机相连后，可以实现船岸之间的数据通信，如船与岸双向邮件业务，船与船双向短消息业务等。

还可通过船舶终端的客户端软件监控本船舶及周围船舶的航行动态，确保船舶航行的安全。

船舶数据终端有两部分组成，即终端显示控制单元与传输模块。

显示控制单元部分包括显示单元、打印单元、操作控制单元、GPS模块、外围接口电路等；传输单元包括VHF电台、电源模块、VHF天馈线。

地址：北京安外外馆后身一号1.1、 C GSDT-9200船舶数据终端前视图1.2 船舶数据终端显示单元前视图。

图1 船舶数据终端前视图地址：北京安外外馆后身一号1.3 CGSDT-9200船舶数据终端显示单元后视图船舶数据终端显示单元后视图1.4 按键功能介绍：按键布局图地址：北京安外外馆后身一号按键功能列表：按 键 含 义 功 能电 源 电源打开/关闭 按住电源键3秒，船舶数据电源打开/关闭 走 纸 进纸 打印机向前走纸，每按一次打印机走一行纸菜 单 功能菜单 进入船舶数据控制菜单功能状态或由子菜单返回主菜单选择/确认 激活/抑制 按此选择键可以交替进行激活和抑制的选择报警声关 消除报警 当接收到报警类信息及打印机缺纸时，发出音响报警，按消警键消除警报退出 退出 退出系统菜单报警1 报警组合键1 报警2 报警组合键2 同时按下报警组合键1和组合键2三秒钟，船舶数据终端自动发送遇险报警信息过闸申请 过闸业务申请键当船舶航行到系统设定的库区范围内，过闸申请键3秒钟，船舶数据终端自动发送过闸申请信息测试 自检 设备自身检测Δ▽上 移下 移在菜单功能下，上下翻看子菜单及功能选项 地址：北京安外外馆后身一号二、操作说明：2.1 开\关电源z关机状态下，持续按下数据终端 电 源键三秒，开启电源。

INMARSAT-C船舶地面站操作规程
INMARSAT船舶地面站操作规程
中/高频/SSB无线电装置操作规程
甚高频无线电装置操作规程
高频无线电装置操作规程
NVATEX航行警告接收机操作规程
气象传真机操作规程
AIS船用全球自动识别系统操作规程
回声测深仪操作规程
GPS接收机操作规程
自动操舵仪操作规程
电罗经操作规程
磁罗经操作规程
电磁记程仪操作规程
VDR船载航行数据记录仪操作规程
操作规程
注意事项备注
双向无线电话操作规程
SART 操作规程
EPIRB 操作规程
INMARSAT-F 操作规程
RADAR 雷达操作规程
RADAR雷达操作规程
雷达操作规程
舵机操作程序
1、通知机舱舵机供电。

2、打开舵机开关，选择舵机组。

3、选择操纵方式，随动方式。

4、转动舵轮试验舵角指示。

5、最后舵角指示回零。

6、舵机备好。

应急舵操作规程。

船舶配载系统使用说明书船舶配载系统使用说明书一、前言1.1 您好，感谢您使用船舶配载系统。

本系统为航运公司提供便捷高效的配载服务，节省了大量人力和物力成本，是目前航运行业一款非常优秀的系统。

1.2 本系统操作简单方便，但是在使用前，您需要进行帐号注册和登录操作。

二、系统注册和登录2.1 进入系统注册页面，填写相关信息，包括公司名称、公司地址、负责人姓名、联系电话、邮箱等信息，完成注册后，系统将审核账户信息并发送激活邮件到您的邮箱中，请按照邮件指示进行激活操作。

2.2 注册完成后，您需要进行登录操作，输入您的账户名和密码，点击登录即可进入系统的主界面。

三、系统主界面使用说明3.1 在系统主界面，您可以选择船公司、航线、港口、船舶等信息，进行配载操作。

3.2 系统支持智能配载，根据货物种类、重量等信息自动匹配最适合的船舶进行操作。

3.3 您可以根据货物种类、重量、航线等信息进行查询和修改操作，并随时了解到货物的配载情况和船舶运行状态。

3.4 配载操作完成后，您可以进行打印或者发送配载清单等操作。

四、系统维护和技术支持4.1 为保证系统的稳定运行，系统将定期进行维护和升级操作，请您在使用过程中保证网络畅通。

4.2 如果您在使用过程中遇到任何问题，请联系我们的客服人员进行解决，我们会提供快速的技术支持。

五、系统安全保障5.1 我们重视用户隐私和商业机密的保护，系统将采用专业的安全技术确保数据的安全性，同时展现高效可靠的配载服务。

5.2 建议用户在使用系统时，采取一定的保密措施，避免信息泄露和造成的经济损失。

以上就是船舶配载系统使用说明书的相关内容，希望对您使用该系统有所帮助，谢谢！。

1151 INTRODUCTIONIn the era of e ‐Navigation, the future VTS(Vessel Traffic Services) is anticipated to play an important role on the enhancement of maritime safety and the efficiency of maritime transport as a key stakeholder of e ‐Navigation. To enhance VTS services, VTS operator needs the advanced functions to support the VTS Services.In the IMO Resolution A.857(20), the three services for VTS are defined (IMO. 1997a), i.e., INformation Service(INS), Navigational Assistance Service(NAS), and Traffic Organization Service(TOS). Among them, the TOS concerns the operational management of traffic and the forward planning of vessel movements to prevent congestion and dangerous situations, and is particularly relevant in times of high traffic density or when the movement of special transports may effect the flow of other traffic. The TOS is a service to prevent the development of dangerous maritime traffic situations and to provide for the safe andefficient movement of vessel traffic within the declared VTS area. It also includes establishing priority of movements, allocating space, routes to be followed, speed limits to be observed or other appropriate measures which are considered necessary by the VTS authority (IALA. 2012a). Taking into the IALA VTS strategy paper account (IALA. 2012b), it is expected that the future VTS focuses on further development of TOS in its operation. In the 35th session of IALA VTS committee, the draft guideline on the provision of VTS Type of Service was finalised (IMO. 2012b). In contrast to a general definition of TOS in A.857 (20), the VTS draft guideline defines concrete services for TOS (IALA. 2012c). On the other hand, various roles of e ‐Navigation stakeholders are included in its architecture specification process (IMO. 2012b), i.e., the roles for master, pilot, and VTS. In this paper, the VTS functions to support its TOS are revisited, considering the reports of e ‐Navigation strategy and IALA VTS committee. Several functions to support the TOS are exemplified. Such functionsFunctional Requirements to Support Traffic Organization ServiceJ.S. Jeong & G.K. ParkDepartment of Maritime Transportation System, Mokpo National Maritime University, Mokpo City, Republic of KoreaABSTRACT: In the era of e ‐Navigation, the future VTS is anticipated to play an important role on the enhancement of maritime safety and the efficiency of maritime transport as a key stakeholder of e ‐Navigation. The VTS services need the advanced Traffic Organization Service(TOS). In this paper, the VTS functions for TOS is revisited from the reports of IMO e ‐Navigation Correspondence Group and IALA VTS Committee. In Korea, the research activities to enhance the existing VTS functions have been conducted. In terms of TOS, some VTS functions have been developed. In conclusion, all the past traffic data and real ‐time ship data are required to provide the advanced TOS. For this, the advanced functions to support TOS should be implemented on VTS console.http://www.transnav.euthe International Journal on Marine Navigationand Safety of Sea TransportationVolume 7Number 1March 2013DOI: 10.12716/1001.07.01.15need to be presented on the VTS console for an effective VTS operation.2TRAFFIC ORGANIZATION SERVICES FOR VTS 2.1Functions to be carried out in the era of e‐Navigation In e‐Navigation, a stakeholer – a person or an organization – may have several different responsibilities. All functions to fulfil the responsibilities may be carried out by persons or systems, or a combination of both (IMO. 2012b). The functions are sorted by stakeholders, i.e, master, pilot, tug service providers, shore organizations. Table 1 represents main functions to be conducted by a stakeholder (IMO. 2012b).Table 1. Functions to be conducted by a stakeholder._______________________________________________Stakeholders Functions_______________________________________________ Master Support and Control NavigationSafe NavigationManagement of InformationSupport to Incident Handling andEmergency ManagementSupport Maritime SecurityPilot Prepare PilotageConduct PilotageOn shore Fairway Utilization PlanningVessel Traffic ServicesPort Operation SupportEmergency Management_______________________________________________In Table 1, all the functions of stakeholders contain their sub‐functions. Several sub‐functions need to be supported by shore organization, such as VTS. For example, the function, Support and Control Navigation, requires to use shore‐based information services, i.e, Maritime Safety Information(MSI) Service, Routeing Information Service, Hydrographic Information Service, Ice Information Service, Port Authority Instruction, Meteorological Information Service and Warning so on.It is natural that each function is also interrelated to other function. The function, Vessel Traffic Services, includes ‘Monitor High Seas’, ‘Manage VTS’, ‘Manage Tracking Information’, ‘Operate Ship Reporting System’, ‘Exchange Information with Relevant Authorities’, ‘Exchange Information on Emergency’. The TOS is a crucial service for the effective management of VTS. In the era of e‐Navigation, the VTS require an intelligent TOS which contains the following sub‐functions:-Plan Traffic Flow-Plan Traffic Organization Criteria-Monitor Traffic Situation and Prediction -Decide on Priority – e.g. allocation of time slots2.2IALA VTS Traffic Organization ServicesIn the 35th session of IALA VTS committee, the draft guideline on the provision of VTS Type of Service was finalised and is supposed to be delivered to the IALA Council for approval (IALA. 2012d). As mentioned in the IALA VTS Strategy Paper (IALA. 2012b), the TOS will be further developed over the next 10 to 20 years. It is expected that the future VTS operation focuses on the delivery of the advanced TOS. The IMO Resolution A.857 (20) states that a VTS should at all times be capable of generating a comprehensive overview of the traffic in its service area combined with all traffic influencing factors. To respond the traffic situations developing in the VTS area and to determine appropriate actions, the acquired data should be processed and evaluated. As mentioned in Section 1, the TOS is a service to prevent the development of dangerous maritime traffic situations and to provide for the safe and efficient movement of vessel traffic within the declared VTS area. The draft guideline suggests the cases that the TOS should be provided as follows (IALA. 2012c).-vessel movements need to be planned or prioritised to prevent congestion or dangerous situations;-special transports or vessels with hazardous or polluting cargo may affect the flow of other traffic and need to be organised;-an operating system of traffic clearances or sailing plans, or both, has been established;-the allocation of space needs to be organised;-mandatory reporting of movements in the VTS area has been established;-special routes should be followed;-speed limits should be observed;-the VTS observes a developing situation and deems it necessary to interact and coordinate vessel traffic;-nautical activities (e.g. sailing regattas) or marine works in‐progress (such as dredging or submarine cable‐laying) may interfere with the flow of vessel movement.Here is an example of the TOS information with relation to waterway management (IALA. 2012c).-The use of one way traffic as an alternative of two way traffic, depending on the dimensions of ship or the weather conditions;-Organising other traffic when a vessel has passed point of no return;-Slot management to allocate ships in a time window;-Organising the traffic concerning vessel dimensions in comparison to fairway restrictions; -Instruct vessels when overtaking is not permitted; -Establish and organise ship safety zones in case of particular operations;-Establish and organise exclusion zones;-Instruct vessels to keep clear from special areas/positions;-Organising the traffic as regards to meteorological, hydrographical or other restrictions such as visibility, wind speed, current, sea state, and under keel clearance.1161173 VTS FUNCTIONS TO SUPPORT TOS 3.1 Examples of Functions for TOSTo provide the TOS, as mentioned in section 2.1 and 2.2, the VTS requires further information, which is obtainable by implementing the following functions. - Ship Reporting System(SRS), Sailing Plan (SP) and information transfer among authorities and ship. - Calculation of traffic congestion rate in the water ‐area of interest- Decision ‐making for collision avoidance - Monitoring of ship trajectories- Risk assessment in the water ‐area of interest.3.2 Ship Reporting System, Sailing Plan, andInformation TransferThe information which is collected from SRS contains ship particulars, ship’s draft, spatial and temporal information of ship movements, cargo type. Such information may be utilised to organise the ship or other ships in a fairway, to allocate the ships in a time window, and also to keep clear from special areas/positions so on. The SP may be used to provide various services belonging to TOS, i.e, wateway management and collision avoidance etc.3.3 Calculation of Traffic Congestion Rate in theWaterarea of interest Large part of the TOS may be conducted by predicting the direction of traffic flow and its volume. All information from SRS and/or SP may be used not only to predict such traffic flow prediction, but also to predict the area to be congested. The static and dynamic information from non ‐AIS ships should be combined with all the information from SRS and SP.Figure 1. Lateral distribution of Traffic along a fairway.The lateral distribution of traffic helps not only to understand traffic flow direction but also to mitigate the congestion by allocating traffic route. In addition to the spatial distribution of traffic, the speed distribution can be also used to calculate the traffic congestion rate in a time window as well as in the special area. The traffic congestion rate may be simply calculated from the ratio of the total ship bumper areas over the total waterarea in a fairway. However,the ship speed affects the number of ships in a fairway and the distance among ships. To obtain more practical congestion rate, it is realistic to consider the other parameters including ship particulars, ship dynamic conditions, courses, weather, sea state. The calculation of traffic congestion rate is open. Figure 1 shows the lateral distribution of traffic which is obtained from the data collected along a fairway. The lateral distribution in a fairway can be plotted at arbitrary gateline of interest. Figure 2 represents the distribution of ship speed at the observed area or a fairway. From the speed distribution, the average and standard deviation of speed are calculated. The standard deviation of speed will affect a navigational safety in waterarea. The speed distribution can use to determine the safe speed or the speed limit criteria.Figure 3 shows CPA distribution as TCPA varies with time at the waterarea of interest. The CPA is normalized by the major diameter of an elliptic model for ship bumper area (A.G. Frandsen. 1991). In Figure 3, the red dot line means the boundary of ship safe domain. If a vessel enters into the boundary of target vessel, the two vessels may be in danger.Figure 2. Ship Speed Distribution.Figure 3. CPA variation as a function TCPA.3.4 Risk Assessment and Decision ‐Making for CollisionAvoidance Several risk assessment models have been proposed to represent real ‐time collision risk among multiple encountered vessels in a water ‐area (Y.S. Park et.al.2012). The collision risk, which is calculated by method proposed in (Y.S. Park et.al. 2012, N.S. Nam & S.Y. Kim, 2012), may be used as a reference index to support decision‐making for collision avoidance in VTS or ship. On the other hand, the other models assess statistical risks by using the past ship movement data (Jun Min Mou. et al. 2010, Jakub Montewka. et al. 2010, J.S. Jeong. et.al. 2012). Figure 4 shows the variation of causation factor which is calculated by using AIS data for the last 72 hours (J.S. Jeong. et al. 2012) in WANDO waterway of Korean Southwestern coast. The causation factor is called the probability of failing to avoid a collision when the encountered vessels are on a collision course (Jakub Montewka. et al. 2010). In fact, it is difficult to assess the maritime risk by causation factor itself. The value of causation factor may be used as reference index for design of traffic lane, determination of speed limit and fairway width so on. The proper range of causation factor depends on natural environments including weather, geographical conditions.Figure 4. Variation of C P for 72 hours.4CONCLUSIONSIt is expected that the TOS plays an important role on the future VTS operation. Herein, the VTS functions in the e‐Navigation architecture and IALA draft guideline on the provision of VTS Type of Service were revisited. To support the advanced TOS and the decision‐making for effective and safe waterway management, several examples were illustrated. The information from ship reporting system and sailing plan may be utilized to organise the ship or other ships in a fairway, to allocate the ships in a time window, and also to keep clear from special areas/positions so on. The traffic congestion level is useful for the dynamic assignment of traffic lane and width, and even speed limit. The maritime risk index also helps to manage traffic effective and safely and to design traffic lane and capacity.To take a proactive measures for maritime safety and prevention of oil pollution, the advanced functions on VTS console should be implemented.ACKNOWLEDGMENTThis research was a part of the project titled “Development of the Intelligent Technology for Marine Accident Protection & Salvage” funded by the Ministry of Land, Transport and Maritime Affairs, Republic of Korea.REFERENCESIMO. 1997a. Guidelines for Vessel Traffic Services, Resolution A.857(20).IALA. 2012a. VTS Manual 2012 Ed.5: 50.IALA. 2012b. Strategy paper addressing the delivery of VTS in a rapidly changing world, VTS35/output/2.IALA. 2012c. Guideline on Provision of Vessel Traffic Services(INS, NAS, TOS), Ed.1.IMO. 2010b. Development of an e‐Navigation Strategy Implementation Plan, Report of the Working Group, NAV 56/WP.5.IALA. 2012d. Report of the 35th Session of the IALA VTS Committee.A.G.Frandsen. 1991. Evaluation of Minimum Bridge SpanOpenings – Applying Ship Domain Theory, Transport Research Record No.1313, Pub. No. 743B: pp.85‐86.Y.S. Park. J.S. Kim. J.Y. Jung. J.S. Jeong. & G.K. Park. 2012. A Study in the maritime safety model in Korea, ENC 2012, 25‐25 April, Gdansk, Poland.N.S. Son. S.Y. Kim. C.S. Lee. 2012. On the Monitoring System of Collision Risks among Multiple Ships, ENC 2012, 25‐25 April, Gdansk, Poland.Jun Min Mou. Ceesvander Tak. & HanLigteringen. 2010.Study on collision avoidance in busy waterways by using AIS data, Ocean Engineering (37): 483‐490.Jakub Montewka. Tomasz Hinz. Pentti Kujala. & Jerzy Matusiak. 2010. Probability modeling of vessel collisions, Reliability Engineering and System Safety (95): 573‐589.J.S. Jeong. K.I Kim. & G.K. Park. 2012. Risk Assessment Model of Maritime Traffic in Time‐Variant CPA Environments in Waterway, Journal of Advanced Computational Intelligence and Intelligent Informatics 16(7).118。

粤港澳航行船舶综合服务平台用户操作手册（运输工具申报篇）广东省电子口岸管理有限公司2021年9月粤港澳航行船舶综合服务平台用户操作手册（运输工具申报篇）目录第一篇前言 (1)第二篇使用须知 (2)系统环境 (2)第三篇运输工具申报介绍 (3)功能简介 (3)术语定义 (3)第四篇运输工具申报 (4)第一章船舶备案 (4)1.1船舶备案查询 (4)1.2船舶备案信息保存与申报 (7)第二章船舶出入境申报 (9)2.1入境(港)申报查询 (9)2.2入境(港)申报录入与暂存、申报 (12)第三章船舶动态 (15)3.1船舶动态时间查询 (15)3.2船舶动态查询 (15)3.3船舶动态信息录入与保存、申报 (18)第四章船舶证书 (20)第五章供退物料 (24)5.1供退物料查询 (24)5.2供退物料录入与保存、申报 (26)第六章删改申请 (28)6.1删改申请查询 (28)6.2删除申请录入与保存、申报 (30)第七章运输工具证书申报 (31)7.1卫生证书查询 (31)7.2卫生证书申报 (33)第八章移动端申报管理 (34)第一篇前言为贯彻落实《国务院关于印发优化口岸营商环境促进跨境贸易便利化工作方案的通知》（国发〔2018〕37号）和中共中央国务院印发《粤港澳大湾区发展规划纲要》，以及《广东省人民政府关于印发优化口岸营商环境促进跨境贸易便利化措施的通知》（粤府函〔2019〕31号）的要求，按照国际贸易“单一窗口”国家标准版建设的一系列决策部署，统筹推进中国（广东）国际贸易单一窗口建设，为企业提供集中受理进出口业务申报的通道，提高进出口货物流通速度，提升贸易便利化水平，营造良好的通关环境，推进全省各口岸相关管理单位之间信息互换、监管互认、执法互助。

依托中国国际贸易单一窗口，按照“明晰职责、归口管理、精简统一、高效运行”为基本原则，在全面梳理现有系统功能和业务需求的基础上，结合来往港澳小型船舶监管业务流程优化，建设中国（广东）国际贸易单一窗口“粤港澳航行船舶综合服务平台”。

·扬帆游艇俱乐部有限责任公司扬帆之星1高速客船操纵手册主管机关：海事局目录第一章船舶主要要素 (3)第二章船舶及其设备的说明 (4)第三章检查浮力舱完整的程序 (7)第四章船舶载荷程序与营运重量重心位置和载荷分配 (8)第五章主机及其推进系统的说明和操作 (8)第六章主、辅机及其电气设备说明及操作 (13)第七章无线电设备和导航设备的说明和操作 (14)第八章船舶维修及保养： (19)第九章损坏控制程序 (20)第十章船舶操纵资料及注意事项 (23)第十一章经主管机关特别批准的资料 (29)第十二章救生设备的说明和操作 (31)第十三章探火，灭火设备的说明及操作 (33)第十四章结构防火布罢图 (37)第十五章船舶航前检查及航前会议制度 (39)修改记录第一章船舶主要要素1、船旗国：中国2、航区：沿海航区3、船籍港：4、船舶所有人：扬帆游艇俱乐部有限责任公司5、建造厂：太阳鸟游艇制造股份6、船级： ccs7、船舶总长： 42.00m8、型宽： 10.00 m9、型深： 3.45m10、满载吃水： 1.50m11、满载排水量： 208.90t12、乘客定额： 288人13、总吨位： 452t14、净吨位： 226t15、空载状态距水面最大高度： 1.35m16、主机额定功率及数量： 2 ×373kw17、航速: 16kn18、燃油： 2×6000L19、续航力 : 48h20 船员: 10人第二章船舶及其设备的说明1、船体本船是一艘玻璃钢客船,船舶为双体型,其船体和上层建筑均采用高性能玻璃纤维增强塑料与木料纵横混合骨架结构，船型为消波型、乘客定额288名，限定在浦氏风力8级以下，距离不超过10海里，且目测波高不超过2m的海况下航行。

2、主机、齿轮箱、轴系本船船舶推进装置采用双机双桨间接转动，设有2台KTA-19-M 型船用柴油机,单机额定功率为373kw，额定转速1800，推进器2个铜质3叶螺旋桨，船舶满舵回转时，主机转速不准超过1200rpm。

第一章概述Chapter 1 Summarization本手册的编制目的是为了更好的帮助用户安全、正确的操作、使用船舶，让用户满意。

本手册向用户全面介绍了船上各部分设备、技术指标及维护保养措施等。

本手册的编制是基于随船完工图纸、各设备使用说明书及保养手册上完成的，其主要内容须参照完工图纸及各设备的使用说明书及保养手册查看。

Preparation of this manual is intended to help user safe and correct operate and use ship, to user satisfaction.This manual fully introduces the ship equipments, technical indicators and maintenance measures, etc to the user.Preparation of this manual is based on the completed with drawings, the equipment operation instruction and maintenance manual, its main contents shall refer to completed drawings and the equipment operation instruction and maintenance manual.请用户在使用船舶前认真参阅这份使用手册，且严格按照此手册使用、操作船舶，并将这本手册保存在安全的地方，以免遗失。

在需要的情况下，我们乐于提供这些资料的副本。

Please refer to the manual carefully before using the ship, and in strict accordance with the manual use and operating the ship, and keep this manual in a safe place, so as to avoid missing.In case of need, we are happy to provide a copy of the data.操作船舶，必须了解船舶的操纵性能，包括船舶的稳性、航速、舵效、船的风阻、船的航态及航向稳定性、倒车的制动距离、惯性等。

散杂货管理系统用户手册浙江电子口岸Zhejiang Electronic Port目录第一篇系统介绍及环境说明 (2)第一章系统简介及流程说明 (2)1.1.1系统简介 (2)1.1.2 申报基本流程 (3)第二章运行环境 (4)1.2.1硬件环境 (4)1.2.2软件环境 (4)1.2.3网络环境 (4)1.2.4支持软件 (4)第三章如何进入系统 (5)1.3.1用户注册 (5)1.3.2用户登录 (9)第二篇系统使用 (10)第一章散杂货申报子模块 (10)2.1.1卸货申请 (11)2.1.2到港信息录入 (13)2.1.3电子放行信息查询 (17)第三篇系统维护 (19)第一章出错处理和恢复 (19)3.1.1会话超时 (19)3.1.2页面JAVA脚本报错 (19)第二章联系我们 (20)3.2.1 关于我们 (20)第一篇系统介绍及环境说明第一章系统简介及流程说明1.1.1系统简介舟山是我国唯一以群岛建制的地级市，是我国重要的战略性大宗商品中转储运基地和船舶修造服务贸易口岸，在国家实施“海洋开发”、建设“上海国际航运中心”、浙江实施“发展海洋经济、建设港航强省”的战略中，发挥着日益重要的作用。

开发舟山海关综合监管业务平台，是舟山口岸监管综合改革工作中的一项支柱型任务。

该平台的设计目标是加强实际监管，以进出境船舶监管为主线，整合现行监管模式、监管制度、监管场所，形成与海关执法要求相配套、与舟山口岸特点相适应的通关监管模式。

该平台必将成为落实强化运用“风险控制、物流监控、信息监控”三个手段，确保实现对进出境运输工具和进出口货物的备案管理、进港监管、在港监管、离港监管、后续管理“五个到位”的重要技术基础。

船舶动态管理系统的建设属于舟山海关综合监管业务平台的一部分。

1.1.2 申报基本流程第二章运行环境1.2.1硬件环境系统将在浙江电子口岸平台上运行。

1、服务器：CPU双核3.0G 以上、内存4G以上、硬盘存储500G以上。

船端简易操作手册船舶管理系统用户操作手册（船端-简单版）documentidrevisionconfidential版本信息上次修改版本12022-8-302修改人曹晓嵩祁正胜修改内容创建新增二次开发内容备注二目录注意事项。

41.定期维护71.1如果维护年度计划............................................................................ .................................71.2如果填写月度计划与实绩............................................................................ .....................81.3如果填写定时设备工作卡............................................................................ .....................91.4如何填写工作实绩............................................................................ .............................111.5如何输入设备运行时间............................................................................ .......................122证书管理............................................................................ (14)2.0如何查询证书信息142.1如何维护证书信息153备件管理173.0如何申领备件............................................................................ .......................................173.1如何做备件入库............................................................................ ...................................183.2如何做备件出库............................................................................ ...................................203.3如何查看备件船存变化............................................................................ .......................211.物料管理............................................................................ .. (22)1.0如何申请材料221.1如何进行材料仓储231.2如何发放材料（即材料消耗）251.3如何检查船上材料的变化262。

船舶进出坞操作指南最新Ship docking and undocking operation guide:I. Preparation before docking1. Confirm that the ship meets the docking conditions, including draft depth, hull size, etc.2. Prepare mooring ropes and anti-collision equipment.3. Communicate with the dock duty personnel to understand the tidal, wind and other sea conditions information.4. Clean up the garbage and debris on the deck of the ship, and properly place the docking repair engineering tools and equipment.5. Hold a pre-shift meeting to clarify and implement the main operating procedures and necessary safety measures.6. Calibrate the ship's power equipment and operating instruments, inspect the winches and steel wire ropes, dock protection materials and other main tools to ensure safety and reliability.II. Docking operation1. Slowly enter the dock according to the instructions of the duty personnel.2. Pay attention to the distance between the two sides of the hull, control the speed of the ship, and avoid scratching the dock.3. Assign personnel to be ready to place mooring ropes.4. Adjust the ship's position according to the instructions to dock the hull correctly.III. During mooring1. Fix the mooring ropes and land to fix the wheel chocks.2. Monitor the tidal changes and adjust the mooring as necessary.3. Comply with the dock safety management regulations and maintain good order.4. Crew members should board and disembark in an orderly manner, avoiding violations such as excessive drinking and fighting.IV. Preparation for undocking1. Communicate with the duty personnel in advance about the undocking time.2. Inspect the condition of the machinery to ensure everything is normal.3. Untie the mooring ropes and remove the wheel chocks.4. Inform the crew to be ready for undocking.V. Undocking operation1. Slowly exit the dock, paying attention to avoid incoming ships.2. Maintain a safe speed and stay away from the dock area.3. Immediately inspect the ship's condition after undocking to ensure everything is normal.It should be noted that during the ship's docking and undocking process, it is necessary to comply with the regulations of the harbor supervision department, and hang the docking and undocking signal flags in advance, such as the D flag, RY flag, etc. At the same time, sufficient tugboats and guard boats must be equipped, and communication tools must be prepared. When necessary, cooperation with the harbor supervision department should be obtained. In the designated restricted water area, other ships are prohibited from coming and going to ensure the safety of the ship's docking and undocking.In conclusion, the docking and undocking operations of ships require strict compliance with relevant regulations and procedures to ensure safe and smooth operations.船舶进出坞操作指南：一、进坞前准备1. 确认船舶满足进坞条件，包括吃水深度、船体尺寸等。

船舶识别号管理系统⽤户⼿册船舶识别号管理系统⽤户⼿册⽬录1 引⾔ (1)编写⽬的 (1)2 申请流程 (2)3 系统⾸页 (4)4 快捷⽅式 (5)5 识别号管理 ................................................................................. 错误！未定义书签。

5.1. 申请填报 .......................................................................... 错误！未定义书签。

5.2. 申请进度查询 ................................................................... 错误！未定义书签。

6 船名管理..................................................................................... 错误！未定义书签。

6.1. 船名申请 .......................................................................... 错误！未定义书签。

6.2. 船名查询 .......................................................................... 错误！未定义书签。

1 引⾔编写⽬的本⽂描述外⽹《船舶识别号管理系统》的具体操作。

提供给船东（公司）⽤户参考。

2 申请流程如上图所⽰，识别号申请步骤：1. 申请预约描述：船东（公司）通过外⽹系统进⾏识别号申请预约。

适⽤⾓⾊：船东（公司）申请⽹址：中华⼈民共和国海事局⽹站——船舶——信息查询——船舶识别号管理系统即：http://114.251.210.58:8080/sbh/2. ⽹上受理申请描述：各地登记机关⽹上受理识别号申请。

AMOS M&P使用手册为了适应现代化船舶管理的发展，我公司开始安装并使用AMOS系统，利用该系统可以进行设备维修保养的跟踪管理，备件管理和采购以及进行船岸间的数据传输。

下面就简要介绍一下这几方面的功能：1．维修保养（Maintenance）船舶维修保养是轮机管理中必不可少的重要环节。

对设备进行合理、有效的维修保养，可以达到延长设备的使用寿命、保证设备的可靠运行，从而使船舶安全航行得以保证。

随着船舶轮机管理的发展，PMS计划保养系统的出现和轮机自动化程度的不断提高，对轮机管理人员来说，面对的工作量和需要处理的信息量越来走大。

AMOS系统是近年来出现的比较成功的轮机管理系统软件，它的出现对提高轮机管理效率，有很大帮助。

计划维修是目前船舶普遍采用的方法，即：通过厂家说明书推荐的保养周期以及多年的实践经验，再加上船级社的检验周期等，对该设备制订出相应的维修保养周期，制成表格，做成卡片，平时根据这些表格和卡片实施维修保养。

AMOS系统将上述工作做成电脑软件，日常需要做的维修保养工作很容易查到，具体操作步聚如下：1．1下发工作单（WOrk Ordr）打开AMOS系统，从File下拉菜单中的SwitchDeportment进人，或直接点工具图标进人，选择需要的部门（机舱选Engine Dopartmen 甲板选Deck）。

从 Maintenance下拉菜单中，点击 Work Order，或直接点击工具菜单。

在出现的查询窗口中，可选择：“工作负责人”、“具体设备”和“到期日’等，进行保养工作安排。

如果要选择一个时间段为到期日，可将鼠标移到 Due Between 处，双击左键选择日历，在选中的日期上点击一下即可，然后点击OK。

此时，所有到期的工作清单将呈现在荧屏上，只要翻动荧屏下半部分的滚动条，就可以逐一查看工作清单，荧屏上半部分是对应下半部分工作清单的详细说明。

按右键并选中Select All，或用鼠标点击各工作单号前面的确认方框，点击File下拉菜单中的Print，或直接点工具菜单中的打印机标志。
