2-position, 6-way, soft shift, solenoid-operated directional spool valve Capacity:5 gpm (20 L/min.)Functional Group:Products : Cartridges : Directional : 6 Way : 2 Position, 6 Way Spool, Soft Shift, Solenoid OperatedModel: DNDYSProduct DescriptionThis solenoid-operated 6-way, 2-position cartridge is a direct-acting, balanced spool valve with a soft shift feature. The soft shift feature greatly reduces system shock due to valve actuation. The typical use for this valve is to select between two separate circuits. The de-energized condition connects P and T to the first circuit and when energized connects P and T to the second circuit.Technical FeaturesThe soft shift cartridge is interchangeable with the standard cartridge, however, the performance limits are lower. This valve is direct actuated and requires no minimum hydraulic pressure for operation.The soft shift feature can greatly reduce shock due to valve actuation but should not be counted upon in applications where timing is critical. If you need accurate ramping or timing control, consider Sun's electro-proportional valves. This valve utilizes a wet armature design. This means that the working fluid surrounds the armature and is exposed to the heat generated by the coil. This can be a factor if the coil is energized for long periods of time. Some fluids, notably water/glycol mixtures, break down at these temperatures over time and form varnishes that will affect the function of the cartridge.The soft shift feature results in significant increase in response time over Sun's standard solenoid. Response time is dependant on flow, pressure, coil voltage, oil viscosity and ambient temperature. Typical response time ranges from 150 ms to 300 ms. The solenoid's unique magnetic design results in a high efficiency solenoid, yielding high spool actuating force per Watt expended, leading to reliable valve shifting.For consistent soft shift performance, port 1 should be at a positive pressure. Coils are interchangeable with other Sun Series 1 solenoid products and can be mounted on the tube in either direction.This valve includes a push-type manual override control. Other manual control options such as T or D, cannot be ordered with the soft shift control but can be installed easily in the field. See Twist/Lock Manual Override link above for details. Please note: Manual override functionality is not compatible with weatherized coils. Coil connector options offer ratings up to IP69K. See individual coil product pages for details. Additional weatherized coils and kits are available for more complete environmental protection.The solenoid tube assembly is fatigue rated for 5000 psi (350 bar) service. Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.Special NotesPlease verify cartridge clearance when choosing a Sun manifold. Different valve controls and coils require different clearances.DownloadDNDY-SXN-*** $184.40Recommended List PriceSpool ConfigurationSeal MaterialCoilStandard OptionsX-+0.00Standard OptionsN Buna-N +0.00VViton+6.00*** See Coil Options Below Standard Coil Options (View All )DIN 43650 3 pin (Hirschman) SAE J858AAMP Junior TimerTwin LeadMetri-PackDeutsch DT04-2P*** no coil528 SAE J858A, 28 VDC, +25.30 814 Metri-Pack, 14 VDC, +27.70211DIN 43650 3 pin(Hirschman), 115 VAC, +36.40 536SAE J858A, 36 VDC, +22.50 814N Metri-Pack, 14 VDC, notransient voltagesuppression (TVS) diodes+27.20212DIN 43650 3 pin(Hirschman), 12 VDC,+20.40 612AMP Junior Timer, 12 VDC, +19.90 824Metri-Pack, 24 VDC, +24.90212N DIN 43650 3 pin(Hirschman), 12 VDC, notransient voltagesuppression (TVS) diodes +19.90 612N AMP Junior Timer, 12 VDC,no transient voltagesuppression (TVS) diodes+19.40 828Metri-Pack, 28 VDC, +27.70214DIN 43650 3 pin(Hirschman), 14 VDC,+23.20 614AMP Junior Timer, 14 VDC, +22.60 836Metri-Pack, 36 VDC, +27.70214N DIN 43650 3 pin(Hirschman), 14 VDC, notransient voltagesuppression (TVS) diodes+22.70 624AMP Junior Timer, 24 VDC, +19.90 848Metri-Pack, 48 VDC, +27.70223DIN 43650 3 pin(Hirschman), 230 VAC, +36.40 624N AMP Junior Timer, 24 VDC,no transient voltagesuppression (TVS) diodes+19.40 912Deutsch DT04-2P, 12 VDC, +26.20224DIN 43650 3 pin(Hirschman), 24 VDC, +20.40 628AMP Junior Timer, 28 VDC, +22.60 912N Deutsch DT04-2P, 12 VDC,no transient voltagesuppression (TVS) diodes+25.70224N DIN 43650 3 pin(Hirschman), 24 VDC, notransient voltagesuppression (TVS) diodes+19.90 636AMP Junior Timer, 36 VDC, +22.60 914Deutsch DT04-2P, 14 VDC, +29.10228DIN 43650 3 pin(Hirschman), 28 VDC, +23.20 712Twin Lead, 12 VDC, +22.50 914N Deutsch DT04-2P, 14 VDC,no transient voltagesuppression (TVS) diodes+28.60236DIN 43650 3 pin(Hirschman), 36 VDC, +23.20 712N Twin Lead, 12 VDC, notransient voltagesuppression (TVS) diodes+22.00 924Deutsch DT04-2P, 24 VDC, +26.20248DIN 43650 3 pin(Hirschman), 48 VDC, +23.20 724Twin Lead, 24 VDC, +22.50 924N Deutsch DT04-2P, 24 VDC,no transient voltagesuppression (TVS) diodes+25.70297DIN 43650 3 pin(Hirschman), 24 VAC, +48.80 724N Twin Lead, 24 VDC, notransient voltagesuppression (TVS) diodes+22.00 928Deutsch DT04-2P, 28 VDC, +29.10298DIN 43650 3 pin(Hirschman), 220 VDC,+48.80 728Twin Lead, 28 VDC, +25.30 936Deutsch DT04-2P, 36 VDC, +29.10299DIN 43650 3 pin(Hirschman), 127 VDC,+48.80 736Twin Lead, 36 VDC, +25.30 948Deutsch DT04-2P, 48 VDC, +29.10514SAE J858A, 14 VDC, +25.30 812Metri-Pack, 12 VDC, +24.90 HN24AA Hazardous environmentduty, 1/2 inch MPTmechanical conduit, 24VDC, 10 feet twin lead,ATEX Certification Ex mb IICT3 Gb.+852.00524SAE J858A, 24 VDC, +22.50 812N Metri-Pack, 12 VDC, notransient voltagesuppression (TVS) diodes +24.40 HN24AB Hazardous environmentduty, 1/2 inch MPTmechanical conduit, 24VDC, 10 feet twin lead, CSACertification+852.00Embedded Coil Options (Click Here)2E12V DIN 43650 3 pin(Hirschman), programmablevia IR link coil/power saver,12 VDC, 0-10V +172.90 4E12V Deutsch DT04-6P,programmable via IR linkcoil/power saver, 12 VDC, 0-10V+161.10 4E24V Deutsch DT04-6P,programmable via IR linkcoil/power saver, 24 VDC, 0-10V+161.102E24V DIN 43650 3 pin(Hirschman), programmablevia IR link coil/power saver,24 VDC, 0-10V+172.90 Additional Options (Click Here)Additional Coils512SAE J858A, 12 VDC, +22.50 71219Twin Lead, to DelphiWeather-Pack Connector, 9inch lead length, 12 VDC, +33.40 72419Twin Lead, to DelphiWeather-Pack Connector, 9inch lead length 24 VDC,+33.40548SAE J858A, 48 VDC, +22.50 71299Twin Lead, to Deutschconnector, 9 inch leadlength, +34.70 72499Twin Lead, to Deutschconnector, 9 inch leadlength,+34.70648AMP Junior Timer, 48 VDC, +22.60 714Twin Lead, 14 VDC, +25.30 748Twin Lead, 48 VDC, +25.30 Stainless options not available for this modelRelated ModelsDNDYCopyright © 2002-2013 Sun Hydraulics Corporation. All rights reserved.Terms and Conditions - ISO Certification - Statement of Privacy。

Return to Table of ContentsDESCRIPTIONA solenoid-operated, two-way, poppet-type, normally open, screw-in, hydraulic cartridge valve.OPERATIONWhen de-energized, the SV10-23 allows bidirectional flow from 2 to 1. With the sensor option, the neutral sensor will signal OFF or LOW.When energized, the valve’s poppet closes to block flow from 2 to 1. In this mode, the cartridge allows free reverse flow from 1 to 2 after overcoming the solenoid force (requires 3.4 to 10.3 bar / 50 to 150 psi). With the sensor option, the neutral sensor will signal ON or HIGH.Operation of Manual Override Option: To override, push and hold override button.FEATURES• Continuous-duty rated solenoid. • Manual override option.• Hardened seat for long life and low leakage. • Unitized, molded coil design.• Optional coil voltages and terminations. • Industry common cavity.• Efficient wet-armature construction.• Cartridges are voltage interchangeable.• Optional waterproof E-Coils rated up to IP69K.RATINGSOperating Pressure: 207 bar (3000 psi)Proof Pressure: 345 bar (5000 psi)Flow: See Performance ChartInternal Leakage: 0.15 cc/minute (3 drops/minute) max. at 207 bar (3000 psi)Temperature: with standard Buna N seals: -40 to 100°C (-40° to 212°F);with Fluorocarbon seals: -26 to 204°C (-15°F to 400°F);Sensor Option: -40°C to 110°C (-40°F to 230°F)Coil Duty Rating: Continuous from 85% to 115% of nominal voltageResponse Time: First indication of change of state with 100% voltage supplied at 80% of nominal flow rating: Energized: 80 msec.; De-energized: 30 msec.Response Time with Sensor: 158 ms pull-in, 57 ms drop-outInitial Coil Current Draw at 20°C: Standard Coil: 1.67 amps at 12 VDC; 0.18 amps at 115 VAC (full wave rectified).E-Coil: 1.7 amps at 12 VDC; 0.85 amps at 24 VDCMinimum Pull-in Voltage: 85% of nominal at 207 bar (3000 psi)Filtration: See page 9.010.1Fluids: Mineral-based or synthetics with lubricating properties at viscosities of7.4 to 420 cSt (50 to 2000 sus); See Temperature and Oil Viscosity, page 9.060.1Installation: No restrictions; See page 9.020.1Cavity: VC10-2; See page 9.110.1; Cavity Tool: CT10-2XX; See page 8.600.1Seal Kit: SK10-2X-T; See page 8.650.1Coil Nut: Part No. 7004420ISO:with Sensor:PERFORMANCE (Cartridge Only)SYMBOLS1.053.18.6/1256.9/1005.2/753.4/501.7/2511.4322.7634.1956.815FLOW lpm/gpmP R E S S U R E D R O P b a r /p s i45.41268.118 Port 2 to 1 De-energized ——Port 1 to 2 Energized - - - -32 cSt/150 sus oil at 40°CSOLENOID VALVES34.5/50027.6/40020.7/30013.8/2006.9/100FLOW lpm/gpmP R E S S U R E D R O P b a r /p s iSV10-23 with SensorPort 2 to 1 Energized - - - - -Port 1 to 2 Energized — - —Port 1 to 2 De-energized ——32 cSt/150 sus oil at 40°C11.4322.7634.1956.81545.41268.118VALVE SHIFT %F L O W VccS E N S O R O U T P U TTypical Sensor Output vs. Valve Shift0.3 lpm 0.08 gpm68.1 lpm18 gpm Hatched Area: Overlapping Stroke, Leakage FlowH YDRA F ORCE .comReturn to Table of ContentsDIMENSIONS1.053.2Dimensions will differ significantly with Sensor Option; see page 3.010.1.TO ORDERSV10-(P )23(A )__ - __ __ __ - __ - __ __ __ __ __ - __ __OptionNone (Blank) 152μ Screen S Manual Override P Manual Override KFor Manual Override options see page 1.001.1Cartridge: Weight: 0.16 kg. (0.35 lbs.); Weight with Sen-sor option: 0.45 kg. (1.0 lbs.); Steel with hardened worksurfaces. Zinc-plated exposed surfaces. Buna N O-rings and polyester elastomer back-up standard.Standard Ported Body:Weight: 0.16 kg. (0.35 lbs.); Anodized high-strength 6061 T6 aluminum alloy, rated to 207 bar (3000 psi). Ductile iron bodies available; dimensions may differ. See page 8.010.1.D-Coil: Weight: 0.27 kg. (0.60 lbs.); Unitized thermo-plastic encapsulated, Class H high temperature magnetwire. See page 3.200.1.E-Coil: Weight: 0.41 kg.(0.9 lbs.); Fully encapsulated with rugged external metal shell. Rated up to IP69K with integral connectors. See page 3.400.1.PortingCartridge Only 0SAE 6 6TSAE 8 8T 1/4 in. BSP* 2B 3/8 in. BSP* 3B1/2 in. BSP* 4B*BSP Body; U.K. Mfr. OnlyWith sensor option, use model code SV10-P23A . . .See page 3.010.1Without sensor option, use model code SV10-23 . . .Voltage Std. Coil 0 Less Coil** 10 10 VDC † 12 12 VDC 24 24 VDC 36 36 VDC 48 48 VDC 24 24 VAC 115 115 VAC 230 230 VAC**Includes D-Coil Nut†DS, DW or DLterminations onlyE-Coils: 10,12,20 or 24 VDC only.MATERIALSFor Coils with Zener Diode, add “/Z ” to option code. For example: “ER/Z ”. Not available on all models. See coil option info. on pages 3.200.1 & 3.400.1Coil Termination E-Coil D-Coil Deutsch DT04-2P ER (IP69K) DR (IP65)Metri-Pack ® 150 EY (IP69K) DY (IP65)Dual Lead Wires EL (IP69K) DL (IP65)Amp Jr. Timer EJ (IP67) —DIN 43650 EG (IP65) DG (IP65)Dual Spades — DS (IP65)Sensor Type 3 Dual Output, N.C./N.O.SealsN Buna N (Std.) V Fluorocarbon Sensor Option: See page 3.010.1Sensor/Connector N Neutral Sense/DT04-4P M Neutral Sense/M12-4P Mating Connectors :DT06-4S: Part No. 4001953M12-4S: available at or H YDRA F ORCEH YDRA F ORCE .com。

2-way, solenoid-operated directional spool valve with position switchCapacity:12 gpm (45 L/min.)Functional Group:Products : Cartridges : Solenoid Operated : 2-Way : Spool with Position Indicating SwitchModel: DLDAZProduct DescriptionThis solenoid-operated 2-way, 2-position cartridge is a direct-acting, balanced spool directional valve. The valve is available in either a normally open or normally closed configuration.The position switch provides confirmation that the valve is in the spring biased position.Technical FeaturesA coil must be ordered with this cartridge. This cartridge is supplied as a sealed, factory set unit and is not field serviceable. If the assembly requires changes or service it needs to be returned to the factory.Any tampering will violate the product warranty. This valve utilizes a wet armature design. This means that the working fluid surrounds the armature and is exposed to the heat generated by the coil. This can be a factor if the coil is energized for long periods of time. Some fluids, notably water/glycol mixtures, break down at these temperatures over time and form varnishes that will affect the function of the cartridge.Position switch is CE approved.A wide variety of coil termination and voltage options are available. When torquing this cartridge into its cavity, a crow's foot wrench or similar will be required since the position switch precludes the use of a deep socket wrench.The solenoid's unique magnetic design results in a high efficiencysolenoid, yielding high spool actuating force per Watt expended, leading to reliable valve shifting.The solenoid tube assembly is fatigue rated for 5000 psi (350 bar) service.Incorporates the Sun floating style construction to minimize thepossibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.This valve is direct actuated and requires no minimum hydraulic pressure for operation.C-Spool DownloadH-Spool DownloadDLDA-ZCN-224 $575.00Recommended List PriceSpool ConfigurationSeal MaterialCoilStandard Options C Normally Closed +0.00HNormally Open+0.00Standard OptionsN Buna-N +0.00VViton+3.50*** See Coil Options Below Standard Coil Options (View All )DIN 43650 3 pin (Hirschman)AMP Junior TimerTwin LeadMetri-PackDeutsch DT04-2P211DIN 43650 3 pin(Hirschman) 115 VAC +36.40 612 AMP Junior Timer 12 VDC +19.90 812NMetri-Pack 12 VDC no transient voltagesuppression (TVS) diodes +24.40212 DIN 43650 3 pin+20.40 612NAMP Junior Timer 12 VDC no+19.40 824Metri-Pack 24 VDC+24.90(Hirschman) 12 VDC transient voltagesuppression (TVS) diodes212N DIN 43650 3 pin(Hirschman) 12 VDC notransient voltagesuppression (TVS) diodes+19.90 624AMP Junior Timer 24 VDC +19.90 912Deutsch DT04-2P 12 VDC +26.20214N DIN 43650 3 pin(Hirschman) 14 VDC notransient voltagesuppression (TVS) diodes +22.70 624N AMP Junior Timer 24 VDC notransient voltagesuppression (TVS) diodes+19.40 912N Deutsch DT04-2P 12 VDC notransient voltagesuppression (TVS) diodes+25.70223DIN 43650 3 pin(Hirschman) 230 VAC +36.40 724N Twin Lead 24 VDC notransient voltagesuppression (TVS) diodes+22.00 924Deutsch DT04-2P 24 VDC +26.20224DIN 43650 3 pin(Hirschman) 24 VDC +20.40 812Metri-Pack 12 VDC +24.90 924N Deutsch DT04-2P 24 VDC notransient voltagesuppression (TVS) diodes+25.70224N DIN 43650 3 pin(Hirschman) 24 VDC notransient voltagesuppression (TVS) diodes+19.90Stainless options not available for this modelRelated ModelsDLDA DLDASCopyright © 2002-2013 Sun Hydraulics Corporation. All rights reserved.Terms and Conditions - ISO Certification - Statement of Privacy。

Return to Table of ContentsDESCRIPTIONdirectional control valve. It is well suited for use in specialized low-pressure pilot systems or power shift transmission control.OPERATIONWhen de-energized, the SV98-T40 allows flow from 3 to 2 and from 4 to 1. When energized, the cartridge’s spool shifts to allow flow from 2 to 1 and from 3 to 4. Pressure at 1 (tank) should not exceed 3.4 bar (50 psi).The coil is an integral part of the valve and is not serviceable.FEATURES• Economical drop-in style.• Integral waterproof coil standard.See page 3.400.1 for a description of tests conducted to verify coil waterproofing.• 12 or 24 VDC coils.• Several push-on termination options.RATINGSOperating Pressure: up to 30 bar (435 psi)Flow: 30 lpm (8 gpm)Internal Leakage: 70 ml/minute (4.3 cu. in./minute) maximum from inlet to tank at 30 bar (435 psi)Temperature: -40 to 120°CCoil Duty Rating: Continuous from 85% to 115% of nominal voltage Response Time: First indication of change of state with 100% voltage and flow rating: Pull-in: 50 ms; Drop-out: 30 ms.Initial Coil Current Draw at 20°C: 1.68 amps at 12 VDCMinimum Pull-in Voltage: 85% of nominal at 30 bar (435 psi)Filtration: See page 9.010.1Fluids: Mineral-based or synthetics with lubricating properties at viscosities of7.4 to 420 cSt (50 to 2000 sus); See Temperature and Oil Viscosity, page 9.060.1Installation: Flange MountFlange Mounting Screws: M5 x 8; Part No. 4000039 (not provided with valve)Cavity: VC-T004; See page 9.111.1Cavity Tool: CT-T004R0-x-G; See page 8.600.1Seal Kit:SK98-T4N-000; See page 8.650.1SYMBOLSUSASI/ISO:PERFORMANCE (Cartridge Only)1.704.1SOLENOID VALVES8.3/1209.7/14011.0/1606.9/1005.5/804.1/602.8/40P R E S S U R E D R O P b a r /p s iPressure Drop vs. Flow 32 cSt/150 sus oil at 40q C213FLOW lpm/gpm457681.4/20H YDRA F ORCE .comDIMENSIONS1.704.2OptionNone(Blank)233μ screen Son inlet portMATERIALSCartridge including Coil: Weight:0.26 kg. (0.57 lbs.) Steel withhardened work surfaces. Zinc-Nickel plated exposed surfaces.HNBR O-rings standard. Coil isencapsulated, class H high-temperature magnetwire, withzinc-nickel plated shell.Standard Ported Test Body:Weight: 0.11 kg. (0.25 lbs.)Anodized high-strength 6061 T6aluminum alloy, rated to 207 bar(3000 psi). See page 8.010.1.Mounting Screws: Must be orderedseparately: Part No. 4001015SV98-T40 __ - __ __ - __ __ - __ __TO ORDERVoltage12 12 VDC24 24 VDCTerminationDJ Amp Junior TimerY2A Metri-Pack® 150.2ADR Deutsch DT04-2PPortingC artridge Only 0SAE66TCoils with internaldiode are available.Consult factory.1.1629.5H YDRA F ORCEH YDRA F Return to Table of Contents。

Return to Table of ContentsDESCRIPTIONvalve.OPERATIONat 3. When energized, the spool shifts to allow flow between 1 and 3 while blocking flow at 2.While port 1 may be fully pressurized, it is not intended to be used as the inlet.FEATURES• Continuous-duty rated solenoid.• Hardened spool and cage for long life.• Optional coil voltages and terminations.• All ports may be fully pressurized.• Heavy-duty waterproof E-Coils rated up to IP69K.RATINGSOperating Pressure: 240 bar (3500 psi) max.Flow: See Performance ChartLeakage: 410 cc/minute (25 cu. in./minute) at 240 bar (3500 psi)Temperature: -40 to 120°C with Buna N seals Coil Duty Rating: See ChartResponse Time: Pull-In: 100 msec; Drop-Out: 100 msec Initial Coil Current Draw at 20°C: 2.8 amps at 12 VDC Filtration: See page 9.010.1Fluids: Mineral-based or synthetics with lubricating properties at viscosities of7.4 to 420 cSt (50 to 2000 sus); See Temperature and Oil Viscosity, page 9.060.1Installation: No restrictions; See page 9.020.1Cavity: VC12-3; See page 9.112.1Cavity Tool: CT12-3XX; See page 8.600.1Seal Kit: SK12-3X-MM; See page 8.650.1E-Coil Nut: Part No. 7085180USASI/ISO:PERFORMANCE (Cartridge Only)SYMBOLS1.369.113.8/20010.3/1506.9/1003.4/5037.91018.9556.815FLOW lpm/gpmP R E S S U R E D R O P b a r /p s i3 to 1 —— ; 2 to 1 - - - -32 cSt/150 sus oil at 40q C37.91018.9556.81575.820FLOW lpm/gpmP R E S S U R E b a r /p s iOPERATING LIMITSPull-In Current 85% of Nominal Drop-Out Current 5% of Nominal Inlet at 1: hatched; Inlet at 3: shaded32 cSt/150 sus oil at 40q C110120607050403020100-20-10-30-401008090706050% O F R A T E D V O L T A G EAMBIENT TEMPERATURE (q C)CONTINUOUS DUTY OPERATING RANGE Minimum Voltage at the Coil Required for Pull-In32 cSt/150 sus oil at 40q CSOLENOID VALVESH YDRA F ORCE .comReturn to Table of ContentsDIMENSIONS1.369.2Cartridge: Weight: 0.29 kg. (0.65 lbs.) Steel with hardened work surfaces. Zinc-plated exposed surfaces. Buna N O-rings and TFE back-ups standard.Standard Ported Body: Weight: 0.98 kg. (2.15 lbs.) Anodized high-strength 6061 T6 aluminum alloy, rated to 207 bar (3000 psi). Ductile iron bodies available; dimensions may differ. See page 8.012.1. E-Coil: Weight: 1.36 kg. (3.0 lbs.) Fully encapsulated with rugged external metal shell. Rated up to IP69K with integral connectors. See page 3.400.1.TO ORDERSV12-31 __ __ __ - __ - __ __ __ __ __Porting Cartridge Only 0 SAE 8 8T SAE 10 10T SAE 12 12T 1/2 in. BSP* 4B 3/4 in. BSP* 6B*BSP Body; U.K. Mfr. OnlySealsBuna N (Std.) N Fluorocarbon VVoltage 0 Less Coil 12 12 VDC 24 24 VDC 36 36 VDC 4848 VDCTerminations (VDC)EL Leadwires (2), IP65 Rated ES Dual Spades, IP65 Rated EG DIN 43650, IP65 Rated EW Leads w/Weather-Pack ® Connector, IP65 RatedEY Metri-Pack ® 150 Connector, IP69K RatedCoils with internal diode are available. Consult factory.Other coil voltages may be availablefor OEM applications. Consult factory.MATERIALSH YDRA F ORCEH YDRA F ORCE .com。

2-position, 6-way, soft shift, solenoid-operated directional spool valve Capacity:5 gpm (20 L/min.)Functional Group:Products : Cartridges : Directional : 6 Way : 2 Position, 6 Way Spool, Soft Shift, Solenoid OperatedModel: DNDYSProduct DescriptionThis solenoid-operated 6-way, 2-position cartridge is a direct-acting, balanced spool valve with a soft shift feature. The soft shift feature greatly reduces system shock due to valve actuation. The typical use for this valve is to select between two separate circuits. The de-energized condition connects P and T to the first circuit and when energized connects P and T to the second circuit.Technical FeaturesThe soft shift cartridge is interchangeable with the standard cartridge, however, the performance limits are lower. This valve is direct actuated and requires no minimum hydraulic pressure for operation.The soft shift feature can greatly reduce shock due to valve actuation but should not be counted upon in applications where timing is critical. If you need accurate ramping or timing control, consider Sun's electro-proportional valves. This valve utilizes a wet armature design. This means that the working fluid surrounds the armature and is exposed to the heat generated by the coil. This can be a factor if the coil is energized for long periods of time. Some fluids, notably water/glycol mixtures, break down at these temperatures over time and form varnishes that will affect the function of the cartridge.The soft shift feature results in significant increase in response time over Sun's standard solenoid. Response time is dependant on flow, pressure, coil voltage, oil viscosity and ambient temperature. Typical response time ranges from 150 ms to 300 ms. The solenoid's unique magnetic design results in a high efficiency solenoid, yielding high spool actuating force per Watt expended, leading to reliable valve shifting.For consistent soft shift performance, port 1 should be at a positive pressure. Coils are interchangeable with other Sun Series 1 solenoid products and can be mounted on the tube in either direction.This valve includes a push-type manual override control. Other manual control options such as T or D, cannot be ordered with the soft shift control but can be installed easily in the field. See Twist/Lock Manual Override link above for details. Please note: Manual override functionality is not compatible with weatherized coils. Coil connector options offer ratings up to IP69K. See individual coil product pages for details. Additional weatherized coils and kits are available for more complete environmental protection.The solenoid tube assembly is fatigue rated for 5000 psi (350 bar) service. Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.Special NotesPlease verify cartridge clearance when choosing a Sun manifold. Different valve controls and coils require different clearances.DownloadDNDY-SXN-*** $184.40Recommended List PriceSpool ConfigurationSeal MaterialCoilStandard OptionsX-+0.00Standard OptionsN Buna-N +0.00VViton+6.00*** See Coil Options Below Standard Coil Options (View All )DIN 43650 3 pin (Hirschman) SAE J858AAMP Junior TimerTwin LeadMetri-PackDeutsch DT04-2P*** no coil528 SAE J858A, 28 VDC, +25.30 814 Metri-Pack, 14 VDC, +27.70211DIN 43650 3 pin(Hirschman), 115 VAC, +36.40 536SAE J858A, 36 VDC, +22.50 814N Metri-Pack, 14 VDC, notransient voltagesuppression (TVS) diodes+27.20212DIN 43650 3 pin(Hirschman), 12 VDC,+20.40 612AMP Junior Timer, 12 VDC, +19.90 824Metri-Pack, 24 VDC, +24.90212N DIN 43650 3 pin(Hirschman), 12 VDC, notransient voltagesuppression (TVS) diodes +19.90 612N AMP Junior Timer, 12 VDC,no transient voltagesuppression (TVS) diodes+19.40 828Metri-Pack, 28 VDC, +27.70214DIN 43650 3 pin(Hirschman), 14 VDC,+23.20 614AMP Junior Timer, 14 VDC, +22.60 836Metri-Pack, 36 VDC, +27.70214N DIN 43650 3 pin(Hirschman), 14 VDC, notransient voltagesuppression (TVS) diodes+22.70 624AMP Junior Timer, 24 VDC, +19.90 848Metri-Pack, 48 VDC, +27.70223DIN 43650 3 pin(Hirschman), 230 VAC, +36.40 624N AMP Junior Timer, 24 VDC,no transient voltagesuppression (TVS) diodes+19.40 912Deutsch DT04-2P, 12 VDC, +26.20224DIN 43650 3 pin(Hirschman), 24 VDC, +20.40 628AMP Junior Timer, 28 VDC, +22.60 912N Deutsch DT04-2P, 12 VDC,no transient voltagesuppression (TVS) diodes+25.70224N DIN 43650 3 pin(Hirschman), 24 VDC, notransient voltagesuppression (TVS) diodes+19.90 636AMP Junior Timer, 36 VDC, +22.60 914Deutsch DT04-2P, 14 VDC, +29.10228DIN 43650 3 pin(Hirschman), 28 VDC, +23.20 712Twin Lead, 12 VDC, +22.50 914N Deutsch DT04-2P, 14 VDC,no transient voltagesuppression (TVS) diodes+28.60236DIN 43650 3 pin(Hirschman), 36 VDC, +23.20 712N Twin Lead, 12 VDC, notransient voltagesuppression (TVS) diodes+22.00 924Deutsch DT04-2P, 24 VDC, +26.20248DIN 43650 3 pin(Hirschman), 48 VDC, +23.20 724Twin Lead, 24 VDC, +22.50 924N Deutsch DT04-2P, 24 VDC,no transient voltagesuppression (TVS) diodes+25.70297DIN 43650 3 pin(Hirschman), 24 VAC, +48.80 724N Twin Lead, 24 VDC, notransient voltagesuppression (TVS) diodes+22.00 928Deutsch DT04-2P, 28 VDC, +29.10298DIN 43650 3 pin(Hirschman), 220 VDC,+48.80 728Twin Lead, 28 VDC, +25.30 936Deutsch DT04-2P, 36 VDC, +29.10299DIN 43650 3 pin(Hirschman), 127 VDC,+48.80 736Twin Lead, 36 VDC, +25.30 948Deutsch DT04-2P, 48 VDC, +29.10514SAE J858A, 14 VDC, +25.30 812Metri-Pack, 12 VDC, +24.90 HN24AA Hazardous environmentduty, 1/2 inch MPTmechanical conduit, 24VDC, 10 feet twin lead,ATEX Certification Ex mb IICT3 Gb.+852.00524SAE J858A, 24 VDC, +22.50 812N Metri-Pack, 12 VDC, notransient voltagesuppression (TVS) diodes +24.40 HN24AB Hazardous environmentduty, 1/2 inch MPTmechanical conduit, 24VDC, 10 feet twin lead, CSACertification+852.00Embedded Coil Options (Click Here)2E12V DIN 43650 3 pin(Hirschman), programmablevia IR link coil/power saver,12 VDC, 0-10V +172.90 4E12V Deutsch DT04-6P,programmable via IR linkcoil/power saver, 12 VDC, 0-10V+161.10 4E24V Deutsch DT04-6P,programmable via IR linkcoil/power saver, 24 VDC, 0-10V+161.102E24V DIN 43650 3 pin(Hirschman), programmablevia IR link coil/power saver,24 VDC, 0-10V+172.90 Additional Options (Click Here)Additional Coils512SAE J858A, 12 VDC, +22.50 71219Twin Lead, to DelphiWeather-Pack Connector, 9inch lead length, 12 VDC, +33.40 72419Twin Lead, to DelphiWeather-Pack Connector, 9inch lead length 24 VDC,+33.40548SAE J858A, 48 VDC, +22.50 71299Twin Lead, to Deutschconnector, 9 inch leadlength, +34.70 72499Twin Lead, to Deutschconnector, 9 inch leadlength,+34.70648AMP Junior Timer, 48 VDC, +22.60 714Twin Lead, 14 VDC, +25.30 748Twin Lead, 48 VDC, +25.30 Stainless options not available for this modelRelated ModelsDNDYCopyright © 2002-2013 Sun Hydraulics Corporation. All rights reserved.Terms and Conditions - ISO Certification - Statement of Privacy。

Return to Table of ContentsDESCRIPTIONvalve.OPERATIONat 3. When energized, the spool shifts to allow flow between 1 and 3 while blocking flow at 2.While port 1 may be fully pressurized, it is not intended to be used as the inlet.FEATURES• Continuous-duty rated solenoid.• Hardened spool and cage for long life.• Optional coil voltages and terminations.• All ports may be fully pressurized.• Heavy-duty waterproof E-Coils rated up to IP69K.RATINGSOperating Pressure: 240 bar (3500 psi) max.Flow: See Performance ChartLeakage: 410 cc/minute (25 cu. in./minute) at 240 bar (3500 psi)Temperature: -40 to 120°C with Buna N seals Coil Duty Rating: See ChartResponse Time: Pull-In: 100 msec; Drop-Out: 100 msec Initial Coil Current Draw at 20°C: 2.8 amps at 12 VDC Filtration: See page 9.010.1Fluids: Mineral-based or synthetics with lubricating properties at viscosities of7.4 to 420 cSt (50 to 2000 sus); See Temperature and Oil Viscosity, page 9.060.1Installation: No restrictions; See page 9.020.1Cavity: VC12-3; See page 9.112.1Cavity Tool: CT12-3XX; See page 8.600.1Seal Kit: SK12-3X-MM; See page 8.650.1E-Coil Nut: Part No. 7085180USASI/ISO:PERFORMANCE (Cartridge Only)SYMBOLS1.369.113.8/20010.3/1506.9/1003.4/5037.91018.9556.815FLOW lpm/gpmP R E S S U R E D R O P b a r /p s i3 to 1 —— ; 2 to 1 - - - -32 cSt/150 sus oil at 40q C37.91018.9556.81575.820FLOW lpm/gpmP R E S S U R E b a r /p s iOPERATING LIMITSPull-In Current 85% of Nominal Drop-Out Current 5% of Nominal Inlet at 1: hatched; Inlet at 3: shaded32 cSt/150 sus oil at 40q C110120607050403020100-20-10-30-401008090706050% O F R A T E D V O L T A G EAMBIENT TEMPERATURE (q C)CONTINUOUS DUTY OPERATING RANGE Minimum Voltage at the Coil Required for Pull-In32 cSt/150 sus oil at 40q CSOLENOID VALVESH YDRA F ORCE .comReturn to Table of ContentsDIMENSIONS1.369.2Cartridge: Weight: 0.29 kg. (0.65 lbs.) Steel with hardened work surfaces. Zinc-plated exposed surfaces. Buna N O-rings and TFE back-ups standard.Standard Ported Body: Weight: 0.98 kg. (2.15 lbs.) Anodized high-strength 6061 T6 aluminum alloy, rated to 207 bar (3000 psi). Ductile iron bodies available; dimensions may differ. See page 8.012.1. E-Coil: Weight: 1.36 kg. (3.0 lbs.) Fully encapsulated with rugged external metal shell. Rated up to IP69K with integral connectors. See page 3.400.1.TO ORDERSV12-31 __ __ __ - __ - __ __ __ __ __Porting Cartridge Only 0 SAE 8 8T SAE 10 10T SAE 12 12T 1/2 in. BSP* 4B 3/4 in. BSP* 6B*BSP Body; U.K. Mfr. OnlySealsBuna N (Std.) N Fluorocarbon VVoltage 0 Less Coil 12 12 VDC 24 24 VDC 36 36 VDC 4848 VDCTerminations (VDC)EL Leadwires (2), IP65 Rated ES Dual Spades, IP65 Rated EG DIN 43650, IP65 Rated EW Leads w/Weather-Pack ® Connector, IP65 RatedEY Metri-Pack ® 150 Connector, IP69K RatedCoils with internal diode are available. Consult factory.Other coil voltages may be availablefor OEM applications. Consult factory.MATERIALSH YDRA F ORCEH YDRA F ORCE .com。

电磁换向阀是用电磁铁推动阀芯，从而变换流体流动方向的控制阀。

电磁换向阀可直接用在液压系统中，控制油路的通断和切换；也可作先导阀，用来操纵其它阀。

型号说明：机能符号：电磁铁命名：技术参数：规格0203油口PAB31.5工作压力(Mpa)油口T10最大流量(L/min)80120工作介质矿物质液压油、磷酸酯介质温度范围(℃)-20~70介质粘度范围(mm2/s) 2.8~380重量(Kg)单电磁铁 1.45(直流) 1.4(交流) 5.1(直流) 4.3(交流)双电磁铁 1.95(直流) 1.9(交流) 6.7(直流) 5.1(交流)直流1224工作电压(V)交流110/50Hz220/50Hz110B220B开50~60(直流)15~25(交流)循环时间(ms)关50~70(直流)40~60(交流)切换频率(次/小时)15000(直流)7200(交流)绝缘等级IP6502规格D03特性曲线（试验条件：在υ=41mm2/s和t=50℃下测得）03规格D05特性曲线Performance curve（试验条件：在υ=41mm2/s和t=50℃下测得）7阀芯符号3C29处于切换位置A～B4阀芯符号3C6处于中位P～T带直流电磁铁阀:带交流电磁铁阀02直流插座式D0302直流线盒式D0302交流插座式D0302交流线盒式D03说明事项：1.产品可任意安装，优先考虑水平位置。

2.液压系统所用介质必须过滤，过滤精度至少20μm。

3.固定螺钉请按样本中所列参数选用。

4.与阀连接的表面，粗糙度要求Ra0.8，平面度要求0.01/100mm。

03直流插座式D0303交流插座式D05。

3-way, solenoid-operated directional spool valve - pilot capacityCapacity:.25 gpm (1 L/min.)Functional Group:Products : Cartridges : Directional : 3 Way : Solenoid Operated SpoolModel: DBAAProduct DescriptionThis solenoid-operated 3-way, 2-position cartridge is a direct-acting, balanced spool pilot valve used to pilot other full-flow valves. The valve is normally open between port 1 and port 2 or port 1 and port 3 and all flow paths are bidirectional.Technical FeaturesThe solenoid tube assembly is fatigue rated for 5000 psi (350 bar) service.This valve utilizes a wet armature design. This means that the working fluid surrounds the armature and is exposed to the heat generated by the coil. This can be a factor if the coil is energized for long periods of time. Some fluids, notably water/glycol mixtures, break down at these temperatures over time and form varnishes that will affect the function of the cartridge.This valve is direct actuated and requires no minimum hydraulic pressure for operation.A wide variety of coil termination and voltage options are available. Highly efficient tube design requires only 12 Watts to shift the valve. Coils are interchangeable with other Sun Series P pilot solenoid products and can be mounted on the tube in either direction.Valves exhibit extremely low leakage rates; less than 10 drops/min. @ 5000 psi (0,7 cc/min @ 350 bar).Incorporates the Sun floating style construction to minimize thepossibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.C-Spool Download H-Spool DownloadDBAA-MCN-***$112.20Recommended List PriceControl Spool Configuration Seal Material CoilStandard OptionsC Concealed ManualOverride+0.00M Manual Override +0.00Standard OptionsC Normally Open 1 to 3,Closed 1 to 2+0.00H Normally Open 1 to 2,Closed 1 to 3+0.00Standard OptionsN Buna-N +0.00V Viton +5.00***See Coil Options Below Standard Coil Options (View All)DIN 43650 3 pin(Hirschman)SAE J858A Twin Lead*** no coil 236DIN 43650 3 pin(Hirschman) 36 VDC+34.90 506SAE J858A 6 VDC +31.40206DIN 43650 3 pin(Hirschman) 6 VDC+34.90 248DIN 43650 3 pin(Hirschman) 48 VDC+34.90 512SAE J858A 12 VDC +31.40211DIN 43650 3 pin(Hirschman) 115 VAC+45.00 311NFPA 115 VAC +80.00 524SAE J858A 24 VDC +31.40212DIN 43650 3 pin(Hirschman) 12 VDC+34.90 323NFPA 230 VAC +85.10 712Twin Lead 12 VDC +31.40223DIN 43650 3 pin(Hirschman) 230 VAC+45.00 324NFPA 24 VDC +68.30 724Twin Lead 24 VDC +31.40224DIN 43650 3 pin+34.90(Hirschman) 24 VDCAdditional Options (Click Here)Additional Coils706Twin Lead 6 VDC +31.40Stainless options not available for this modelCopyright © 2002-2012 Sun Hydraulics Corporation. All rights reserved.Terms and Conditions - ISO Certification - Statement of Privacy。

Return to Table of ContentsDESCRIPTIONA solenoid-operated, three-way, direct-acting spool-type, screw-in hydraulic cartridge valve, intended as a bidirectional blocking valve.OPERATIONWhen de-energized, the SV12-33 allows flow between 3 and 1 while blocking flow at 2. When energized, the spool shifts to allow flow between 2 and 1 while blocking flow at 3.While port 1 may be fully pressurized, it is not intended to be used as the inlet.FEATURES• Continuous-duty rated solenoid.• Hardened spool and cage for long life.• Optional coil voltages and terminations.• All ports may be fully pressurized.• Heavy-duty waterproof E-Coils rated up to IP69K.RATINGSFlow: See Performance ChartLeakage: 410 cc/minute (25 cu. in./minute) at 240 bar (3500 psi)Temperature: -40 to 120°C with Buna N seals Coil Duty Rating: See ChartResponse Time: Pull-In: 100 msec; Drop-Out: 100 msec Initial Coil Current Draw at 20°C: 2.8 amps at 12 VDC Filtration: See page 9.010.1Fluids: Mineral-based or synthetics with lubricating properties at viscosities of7.4 to 420 cSt (50 to 2000 sus); See Temperature and Oil Viscosity, page 9.060.1Installation: No restrictions; See page 9.020.1Cavity: VC12-3; See page 9.112.1Cavity Tool: CT12-3XX; See page 8.600.1Seal Kit: SK12-3X-MM; See page 8.650.1E-Coil Nut: Part No. 7085180USASI/ISO:PERFORMANCE (Cartridge Only)SYMBOLS1.374.110.3/1506.9/1008.6/1255.2/753.4/501.7/2537.91018.9556.815FLOW lpm/gpmP R E S S U R E D R O P b a r /p s i3 to 1 or 2 to 132 cSt/150 ssu oil at 40C37.91018.9556.81575.820FLOW lpm/gpm P R E S S U R E b a r /p s iOPERATING LIMITSPull-In Current 85% of Nominal Drop-Out Current 5% of Nominal 110120607050403020100-20-10-30-401008090706050% O F R A T E D V O L T A G EAMBIENT TEMPERATURE (°C)CONTINUOUS DUTY OPERATING RANGE Minimum Voltage at the Coil Required for Pull-In32 cSt/150 sus oil at 40°CSOLENOID VALVESH YDRA F ORCE .comReturn to Table of ContentsDIMENSIONS1.374.2Cartridge: Weight: 0.29 kg. (0.65 lbs.) Steel with hardened work surfaces. Zinc-plated exposed surfaces. Buna N O-rings and TFE back-ups standard.Standard Ported Body: Weight: 0.98 kg. (2.15 lbs.) Anodized high-strength 6061 T6 aluminum alloy, rated to 207 bar (3000 psi). Ductile iron bodies available; dimensions may differ. See page 8.012.1. E-Coil: Weight: 1.36 kg. (3.0 lbs.) Fully encapsulated with rugged external metal shell. Rated up to IP69K with integral connectors. See page 3.400.1.TO ORDERSV12-33 __ __ __ - __ - __ __ __ __ __Porting Cartridge Only 0 SAE 8 8T SAE 10 10T SAE 12 12T 1/2 in. BSP* 4B 3/4 in. BSP* 6B*BSP Body; U.K. Mfr. OnlySealsBuna N (Std.) N Fluorocarbon VVoltage 0 Less Coil 12 12 VDC 24 24 VDC 36 36 VDC 4848 VDCTerminations (VDC)EL Leadwires (2), IP65 Rated ES Dual Spades, IP65 Rated EG DIN 43650, IP65 Rated EW Leads w/Weather-Pack ® Connector, IP65 RatedEY Metri-Pack ® 150 Connector, IP69K RatedCoils with internal diode are available. Consult factory.Other coil voltages may be availablefor OEM applications. Consult factory.MATERIALSH YDRA F ORCEH YDRA F ORCE .com。

电磁换向阀是用电磁铁推动阀芯，从而变换流体流动方向的控制阀。

电磁换向阀可直接用在液压系统中，控制油路的通断和切换；也可作先导阀，用来操纵其它阀。

电磁换向阀Electrical Operated Directional Control Valve功能说明Ｆｕｎｃｔｉｏｎ　ＩｎｓｔｒｕｃｔｉｏｎＥｌｅｃｔｒｉｃａｌ　ｏｐｅｒａｔｅｄ　ｄｉｒｅｃｔｉｏｎａｌ　ｃｏｎｔｒｏｌ　ｖａｌｖｅ　ｕｓｅｓ　ｓｏｌｅｎｏｉｄ　ｔｏ　ｐｕｌｌ　ｔｈｅ　ｓｐｏｏｌ　ａｎｄ　ｃｈａｎｇｅ　ｔｈｅ　ｄｉｒｅｃｔｉｏｎ　ｏｆ　ｔｈｅ　ｈｙｄｒａｕｌｉｃ　ｏｉｌ．　Ｅｌｅｃｔｒｉｃａｌ　ｏｐｅｒａｔｅｄ　ｄｉｒｅｃｔｉｏｎａｌ　ｃｏｎｔｒｏｌ　ｖａｌｖｅ　ｃａｎ　ｄｉｒｅｃｔｌｙ　ｃｏｎｔｒｏｌ　ｔｈｅ　ｆｌｏｗ　ｏｎ－ｏｆｆ　ａｎｄ　ｃｈａｎｇｅ．　Ｉｔ　ａｌｓｏ　ｃａｎ　ｂｅ　ｕｓｅｄ　ａｓ　ｔｈｅ　ｐｉｌｏｔ－ｏｐｅｒａｔｅｄ　ｖａｌｖｅ，　ｗｈｉｃｈ　ｃｏｕｌｄ　ｏｐｅｒａｔｅ　ｏｔｈｅｒ　ｖａｌｖｅｓ．型号说明 Ｍｏｄｅｌ　ｄｅｓｃｒｉｐｔｉｏｎ电磁换向阀Ｅｌｅｃｔｒｉｃａｌ　ｏｐｅｒａｔｅｄ　ｄｉｒｅｃｔｉｏｎａｌ　ｃｏｎｔｒｏｌ　ｖａｌｖｅ规格Ｓｐｅｃｉｆｉｃａｔｉｏｎ０２ ６通径 ＮＳ６０３ １０通径 ＮＳ１０接线形式Ｃｏｎｎｅｃｔ　ｔｙｐｅ省略 插座式Ｏｍｉｔ Ｐｌｕｇ　ｔｙｐｅＺ６ 线盒式Ｚ６ Ｗｉｒｅ　ｂｏｘ　ｔｙｐｅ 滑阀机能Ｆｕｎｃｔｉｏｎ　ｃｏｄｅ详见机能符号表Ｄｅｔａｉｌｓ　ａｓ　ｆｏｌｌｏｗｉｎｇ　ｓｙｍｂｏｌ　ｔａｂｌｅ工作电压Ｗｏｒｋｉｎｇ　ｖｏｌｔａｇｅＤ１２ ＤＣ１２ＶＤ２４ ＤＣ２４ＶＡ１１０ ＡＣ１１０ＶＡ２２０ ＡＣ２２０ＶＢ１１０ ＡＣ１１０Ｖ本整ＲｅｃｔｉｆｉｅｄＢ２２０ ＡＣ２２０Ｖ本整Ｒｅｃｔｉｆｉｅｄ附加说明Ｒｅｍａｒｋｓ系列号密封材料　Ｓｅａｌ　ｍａｔｅｒｉａｌ　省略 ＮＢＲ密封Ｏｍｉｔ　ＮＢＲｓｅａｌＶ ＦＰＭ密封 ｓｅａｌ省略 无阻尼Ｏｍｉｔ　Ｎｏ　ｄａｍｐ０８ ø０．８阻尼 Ｄａｍｐ１０ ø１．０阻尼 Ｄａｍｐ１２ ø１．２阻尼 Ｄａｍｐ省略 无应急推杆　Ｏｍｉｔ　ｗｉｔｈｏｕｔ　ｅｍｅｒｇｅｎｃｙ　ｐｕｓｈ　ｒｏｄＮ９ 带应急推杆Ｎ９ Ｗｉｔｈ　ｅｍｅｒｇｅｎｃｙ　ｐｕｓｈ　ｒｏｄＺ４ 方形插头Ｓｑｕａｒｅ　ｃｏｎｎｅｃｔｏｒ　Ｚ５ 方形大插头Ｌａｒｇｅ　ｓｑｕａｒｅ　ｃｏｎｎｅｃｔｏｒＺ５Ｌ 方形带灯插头Ｓｑｕａｒｅ　ｃｏｎｎｅｃｔｏｒ　ｗｉｔｈ　ｌｉｇｈｔＦＷ－× ×－×－× × ×　／　× × ５０ ＊　Ｓｅｒｉａｌ　ｎｕｍｂｅｒ５０ Ｒｅｘｒｏｔｈ　ｔｙｐｅ６０ Ｖｉｃｋｅｒｓ　ｔｙｐｅ７０ Ｙｕｋｅｎ　ｔｙｐｅ电磁铁命名 Ｎａｍｅ　ｏｆ　ｓｏｌｅｎｏｉｄ１．　ａ动作时Ｗｈｅｎ　ｍｏｖｅｍｅｎｔ　ａ，Ｐ→Ａ Ｂ→Ｔ２．　ｂ动作时Ｗｈｅｎ　ｍｏｖｅｍｅｎｔ　ｂ，Ｐ→Ｂ Ａ→Ｔ３．　３Ｃ５，３Ｃ６油液流通状况与上述方向相反 Ｏｉｌ　ｆｌｏｗ　ｉｎ　ｔｈｅ　ｏｐｐｏｓｉｔｅ　ｄｉｒｅｃｔｉｏｎ　ｗｉｔｈ　ｔｈｅ　ａｂｏｖｅ－ｍｅｎｔｉｏｎｅｄ　ｍｏｖｅｍｅｎｔ　ｆｏｒ ３Ｃ５、３Ｃ６　ｓｙｍ６０Ｌ ｖａｌｌｅ．A B P abA B P bA BP a机能符号 Ｃｏｄｅ　ｓｙｍｂｏｌ由于阻塞的原因，阀的切换性能取决于过滤。
