松下内部特殊继电器

©2009上海松下微波炉有限公司版权所有。

未经允许，私自翻印散发均属违法。

PHAMOS0906036C3微波炉NN-GF559X NN-GF559M NN-GF559SNN-GF549H NN-GF539W NN-GF539HXPE（中国）目录页数页数1特性表-------------------------------------------3 2控制板-------------------------------------------3 3原理图-------------------------------------------4 4操作顺序说明-------------------------------------5 5检修时注意事项-----------------------------------6 6元部件拆卸和更换的步骤---------------------------77元件测试步骤-------------------------------------12 8测量与调整---------------------------------------14 9检修指南 ----------------------------------------15 10分解图和零部件表---------------------------------18 11数据电路-----------------------------------------251特性表2控制板3原理图4操作顺序说明4.1.可变功率烹调控制当微波炉的功率选择设置在高功率以外的任一功率位置时，继电器RY1即由数据程序电路周期供能。

数据程序电路通过对RY1 触点的ON/OFF时间进行控制以改变微波炉从“低”功率到“高”功率的输出功率。

继电器RY1 ON/OFF的一次完整循环时间为22秒钟。

下表中给出的是设定的火力和微波输出之间的关系。

修理实例Repair Manual现象描述： 红灯闪一下的故障，故障部位有两个：一是P 板各路电源有的没有输出造成A 板总线没有电源。

二是A 板故障，通常是因为各IC 之间通讯不通造成的。

原因分析： 测量P 板输出排插，发现有待机5V 、待机15V 输出，但没有15VcVDA 、VSUS 输出。

P 板电路原理分析：该机的P 板电路比效简单，有三个开关电源电路：1、待机电源电路由IC201、T200组成。

输出待机5V 、15V 。

2、PFC 电路由IC100、T100组成。

产生390V 电源。

3、VSUS 、VDA 、15V 电源由同一个开关电源产生：IC301、T301、T300。

上述三个开关电源工作的前后时间顺序是有严格的规定的：通电后待机电源先工作，不论面板上的电源开关是否闭合，只要接通220V 市电，待机电源就工作。

产生并输出待机5V 、15V 电压。

待机电源开始工作后，在待机电源变压器T200：1—2绕组间产生的脉冲电压经D209整流C210滤波，产生24V 电源电压，经开关管Q100加到两个三端稳压器输入端：经IC101输出20V 电源，经IC102输出15V 电源。

其中20V 电源是给IC301供电的，用于产生VSUS 、VDA 、15V 电源，IC102输出的15V 电源给IC100供电，用于产生PFC 电源。

由此看出：只有待机电源先工作，PFC 电源振荡IC 才能得电工作。

产生PFC 电源电压后，将此PFC 电源加给Q304、Q305、Q306、Q307。

VSUS 、VDA 、15V 电源才能随后工作。

这是PDP 电视机P 板工作的重要一环。

待机电源电路：IC201是单片开关电源专用IC ，只有三个引脚，外围电路最为简单。

其中2脚是IC 内大功率MOS 管的S 极，接地。

3脚是D 极，接开关电源变压器T200初级绕组。

1脚是稳压控制输入端。

电视机电源插头输入220V 市电后，经D200整流，C201滤波，产生300V 电压，加到T200初级绕组，并经T200：7、D204加到IC201的D 极，IC201开始振荡， T200初级流过脉冲电流，在次级产生脉冲电压，其中13—10绕组产生的脉冲电压经整流产生5V 待机电源。

MID系列变频器操作手册1．布线时的注意事项主电路1）如果把电源输入端子（R、S、T）和电机用输出端子（U、V、W）接反了，则变频器会受到损伤，绝对不可这样接线。

2）请不要让电机输出用端子（图）（U、V、W）接地。

3）请不要让电机输出用端子（U、V、W）之间短路。

4）在开动变频器时，请按照标准接线图使用熔丝断路器和热敏继电器。

请参照5—3“布线用机器的选定”。

5）地线端子（E）为变频器的框架地线（FG），请按第三种接地（100Ω以下，¢1.6mm 以上）的标准接地。

6）请务必将已设置电机的进相电容器取下来。

7）对主电路端子（R、S、T、U、V、W）请务必用绝缘外皮的压焊端子。

控制电路1）加在输出端子（01、COM）上的电流请不要超过DC24V、50MA，也不要加反极性电压。

2）输入端子（11—14）的内部结构是：以大约2.5千兆由大约8V拉制而成，可用接点或敞开式调整器进行控制，请不要由外部加压。

3）请不要把设定频率用电源端子（5V）和控制用地线端子（G）短路。

2854）当用输出端子（01 COM）直接驱动继电器时，请插入续流二极管（FD）。

5）接在控制电路上的电线请用胶合线或屏蔽线。

ERA15-01ERB15-01请注意二极管的极性6）请把屏蔽线的屏蔽部分接地。

7）接在控制电路上的电线要与动力线分离。

8）关于电线的固定，要用螺丝刀垂直对准接线柱加以固定。

2 安全注意事项2-1 MID***W**的情况电源三相/单相单相AC100V50/60Hz单相输入的请接在R、T上正转/反转/286进行外部频率设定的情况* 电机在以最高频率运转，由于外部频率设定标度盘的位置，设定频率用电流接线端子（5V）和控制用地线端子（G）会短路。

因此，请务必把短路棒去掉之后再布线。

* 关于外部频率的设定，请将电位器面板向左旋转到最大限度后再进行。

电源三相/单相单相AC100V50/60Hz单相输入的请接在R、TH标度盘特性正转/反转/2-2 布线用器件的选定（1）熔丝断路器、电磁接触器、热敏继电器（以上为松下电工的商品型号）和电线的选定变频器型号适用电机（KW）熔丝断路器(额定电流值)电磁接触器*1(接点的构成)热敏继电器*1(电流调整范围)电线*2(mm2)MID011A1X 0.1 BBP25 (5A)BMF61824(3P+1a) BMF902E(0.95~1.45A)2.0MID021A1X 0.2 BBP25(5A) BMF61842(3P+1a) BMF904E(1.7~2.6A)2.0MID041A1X 0.4 BBP25(10A) BMF61842(3P+1a) BMF907E(0.98~4.2A)2.02 MID01 *1× 30.1 BBP25(5A)BMF61842(3P+1a)BMF901E(0.5~0.75A)2.02 MID02 *1×0.2 BBP25(5A)BMF61842(3P+1a)BMF902E(0.95~1.45E)2.02873 2MID04 *1× 3 0.4 BBP25(5A) BMF61842 (3P+1a) BMF904E(1.7~2.6A) 2.02MID08 *1× 30.75 BBP25(10A) BMF61842 (3P+1a) BMF907E (2.8~4.2E)2.02 MID15 *1× 31.5 BBP25(15A) BMF61842 (3P+1a) BMF915E(5.0~8.0A) 2.0注）端子盘螺丝钉尺寸 控制电路端子 M3螺丝钉 主电路端子/地线端（E ） M4螺丝钉 （2）继电器的选定 为防止接触不良，用于控制输入端子（“11—14”）等控制电路的继电器请使用小信号用的（最低保证电流在1MA 以下） （参考例）松下电工：DS 形 NK 形 HC 形 欧姆龙： G2A 形 （3）控制电路用开关的选定当用开关代替继电器时，为防止接触不良，请使用微弱电流用的（参考例）日本开关：M-2012J-G注：*1 当有几台机器同时运转时，请结合电机选用电磁接触器和热敏继电器。

ORDERING INFORMATION10A PC board type10A TM type60A Screw terminal type80A Connector type300A Connector typeFEATURES1. High-voltage, high-current controlcapable400V DC high-voltage switching cutoffhas been achieved thanks to a sealedconstruction with mixed hydrogen gasand the magnetic arc motion through useof a permanent magnet.2. Compact & Low Operating SoundBy using a capsule contact mechanismthat is enclosed with hydrogen gas, high-capacity cutoff is possible even with a tinycontact gap. There is little operatingsound, which does not change evenwhen large currents are cut off.3. Arc space unnecessaryThe enclosure box can be made smallerthanks to an arc-space-free constructionfrom which the arc will not get out.4. SafetySince the contacts are enclosed in asealed capsule structure, the arc will notget out, which ensures safety.5. High contact reliabilityThe contact part is hermetically sealedwith H2 mixed gas, hence the contactresistance remains stable regardless ofthe ambient conditions.6. Mounting direction is not specifiedThe weight of the movable parts is light,and also the restoring force is large,hence the relay is relatively unaffected bygravity.7. Wide selection of models available.T ypes include PC board type, TM type(10A), screw terminal type (60A), andconnector type (80A and 300A).8. Standard complianceThe 60A type is UL and C-UL standardcertified.TYPICAL APPLICATIONS1. Cogeneration systems2. Battery inspection and testingequipment (charge and dischargecontrol)3. Construction machinery4. AGV (Automatic guided vehicle)(Unmanned transport carts)5. Welding equipment6. Inverter control7. Solar power generation systems8. Elevator, etc.EP RelayContact arrangement1: 1 Form A3: 1 Form A PC board type*5: 1 Form A TM type*AEP0Contact rating1: 10A6: 60A8: 80A9: 300ACoil voltage12:24:48:X0:12V DC24V DC48V DC*100V DC*Note: *10A type onlyEPTYPESNotes:* One female connector lead wire for connecting is packaged with the 80A and 300A connector types.-Specifications: Housing: Y azaki 7283-1020 (light gray); Lead wire: 0.5 mm 2 dia. and 300±10 mm length Lead wire coating color: Pin No. 1: white; Pin No. 2: greenRATING1. Coil data*When using a DC power supply use one that has a leeway of at least 150% current capacity.TtpeNominal coil voltageContact arrangementPart No.Packing quantityCarton Case 10A PC board type 12V DC1 Form AAEP3101225pcs.100pcs.10A TM type AEP5101225pcs.100pcs.60AAEP160121pc.20pcs.80A Connector type*AEP180121pc.20pcs.300A Connector type*AEP190121pc.5pcs.10A PC board type 24V DCAEP3102425pcs.100pcs.10A TM type AEP5102425pcs.100pcs.60AAEP160241pc.20pcs.80A Connector type*AEP180241pc.20pcs.300A Connector type*AEP190241pc.5pcs.10A PC board type 48V DC AEP3104825pcs.100pcs.10A TM typeAEP5104825pcs.100pcs.10A PC board type 100V DCAEP310X025pcs.100pcs.10A TM typeAEP510X025pcs.100pcs.T ype Nominal coil voltagePick-up voltage (at 20°C 68°F )Drop-out voltage (at 20°C 68°F )Nominal coil current [±10%] (at 20°C 68°F )Nominal operating power (Nominal voltage applied to the coil, at 20°C 68°F )Max. allowablevoltage10A 12V DC 75%V or less of nominal voltage(Initial)8%V or more of nominal voltage(Initial)0.103A Max.1.4W130%V of nominal voltage60A 0.415A Max. 5W 80A 0.375A Max. 5W300A 3.3A (during peak)When input: 40 W max. (0.1 sec. from time of input) When retained: 4 W max.10A 24V DC0.052A Max.1.4W 60A 0.208A Max. 5W 80A 0.188A Max. 5W300A 1.85A (during peak)When input: 45 W max. (0.1 sec. from time of input) When retained: 4 W max.10A 48V DC 0.026A Max.1.4W10A100V DC0.012AEP*3Condition: Switches rated number of 10 cycles each time there is a 2,500A cutoff.REFERENCE DATA1.-(1) Ambient temperature characteristics (10A type)T ested sample: 10A type EP relay, 3pcs1.-(2) Ambient temperature characteristics (60A type)T ested sample: 60A type EP relay, 3pcs1.-(3) Ambient temperature characteristics (80A type)T ested sample: 80A type EP relay, 3pcsEP1.-(4) Ambient temperature characteristics (300A type)T ested sample: 300A type EP relay, 3pcs 2.-(1) Max. value for switching capacity(10A and 60A types)2.-(2) Max. value for switching capacity(80A and 300A types)ontactcurrent,Aontactcurrent,A3.-(1) Switching life curve (10A type) 3.-(2) Switching life curve (60A type) 3.-(3) Switching life curve (80A type)ife(cycle)ife(×13cycle)ife(cycle)3.-(4) Switching life curve (300A type)4. Cut-off curve (forward direction)5.-(1) Carrying performance curve (80°C)(10A and 60A types)ife(cycle)Cut-off current, Aife(cycle)1010ime,sec5.-(2) Carrying performance curve (80°C)(80A and 300A types)1010ime,secEPDIMENSIONS (Unit: mm inch )1. 10A PC board type2. 10A TM typeExternal dimensionsSchematic (Bottom view)PC board pattern (Bottom view)Notes:1.We recommend through-hole plating withland on both sides.2.Be careful of the insulation distancebetween land patterns with regards to the circuit voltage you will use.2Load sides have polarities (+) and (–).After doing through-hole plating+0.1+.004General tolerance:Max. 10 .394 ±0.3 ±.01210 .394 to 50 1.969 ±0.6 ±.024Min. 50 1.969 ±1.0 ±.039External dimensions.016Schematic (T op view)Panel cut-off5:CoilLoad sides have polarities (+) and (–).6:CoilMounting hole 2-4.2±0.1 dia.General tolerance:Max. 10 .394 ±0.3 ±.01210 .394 to 50 1.969 ±0.6 ±.024Min. 50 1.969 ±1.0 ±.039EP3. 60A type4. 80A typeExternal dimensionsSchematic (T op view)Panel cut-off6: Coil 5: Coil2–1+Load side has polarities (+) and (–).General tolerance:Max. 10 .394 ±0.3 ±.01210 .394 to 50 1.969 ±0.6 ±.024Min. 50 1.969 ±1.0 ±.039External dimensions57.9Schematic (T op view)Panel cut-off*Accessories (included)General tolerance:Max. 10 .394: ±0.3 ±.01210 .394 to 50 1.969: ±0.6 ±.024Min. 50 1.969: ±1.0±.039−1Load sides have polarities (+) and (−).EP5. 300A typeExternal dimensionsSchematic (T op view)Panel cut-off*Accessories (included)General tolerance:Max. 10 .394: ±0.3 ±.01210 .394 to 50 1.969: ±0.6 ±.024Min. 50 1.969: ±1.0 ±.039+)−1Input and load sides have polarities (+) and (−).EPNOTESFor Cautions for Use, see Relay Technical Information.1. When installing the relay, always use washers to prevent the screws from loosening.Tighten each screw within the rated range given below. Exceeding themaximum torque may result in breakage. Mounting is possible in either direction.•M5 screw (60A, 80A and 300A main unit mounting section): 3 to 4N·m •M3.5 screw (60A input terminal): 0.84 to 1.2 N·m•M4 screw (10A PC board type main unit mounting section): 0.98 to 1.2N·m (10A TM type main unit mounting section): 1.8 to 2.7N·mRecommended securing torque on load side terminals•60A/M5 screw: 2.5 to 3.6 N·m •80A/M5 bolt: 3.5 to 6.5 N·m •300A/M8 bolt: 10 to 12 N·m2. The contacts of the relay arepolarized. Please follow instructions in the connection schematic when connecting the contacts.We recommend installing a surgeprotector varistor (ZNR) for the 10A , 60A and 80A types. Avoid using a diode as this may result in decreased cut-off capability.3. Do not use a relay if it has been dropped.4. Avoid mounting the relay in strong magnetic fields (near a transformer or magnet) or close to an object that radiates heat.5. Electrical lifeThis relay is a high-voltage direct-current switch. In its final breakdown mode, it may lose the ability to provide the proper cut-off. Therefore, do not exceed the indicated switching capacity and life. (Please treat the relay as a product with limited life and replace it when necessary.)In the event that the relay loses cut-off ability, there is a possibility that burning may spread to surrounding parts, so configure the layout so that the power is turned off within one second and from the point of view of safety, consider installing a failsafe circuit in the device.Also, in order to avoid increased contact resistance, do not operate when there is no switching load.6. Permeation life of internal gasThis relay uses a hermetically encased contact (capsule contact) with gas inside. The gas has a permeation life that is affected by the temperature inside thecapsule contact (ambient temperature + temperature rise due to flow of electrical current). For this reason, make sure the ambient operating temperature isbetween –40 and 80°C –40 and +176°F , and the ambient storage temperature is between –40 and 85°C –40 and +185°F .7. Do not disassemble the relay.Please note that disassembling the relay will invalidate the warranty.8. If the power is turned off and then immediately on after applying the rated voltage (current) continuously to therelay’s coil and contact, the resistance of the coil will increase due to a rise in the coil temperature. This causes the pick-up voltage to rise, and possibly exceed the rated pick-up voltage. In thesecircumstances, take measures such as reducing the load current, limiting the duration of current flow, and applying a coil voltage higher than the rated operating voltage.9. Coil operating powerPure DC current should be applied to the coil. The wave form should berectangular. If it includes ripple, the ripple factor should be less than 5%. However, check the actual circuit since thecharacteristics may be slightly different.The power supply waveform supplied to the coil should be rectangular.10. Don’t exceed maximum coil voltage. Exceeding maximumallowable coil voltage on continuous basis will damage the relay and could case failure.11. Ensure that the rated contacts voltage and current values are not exceeded.12. The rated control capacity and life are given as general guides.The contact life is heavily influenced by the type of load and other related conditions, and these factors must be kept in consideration when using the relay.13. Main contact ratings in the ratings apply to when there is a resistive load. If you are using an inductive load (L load) such that L/R > 1 ms, add surge protection in parallel with theinductive load. If this is not done, the electrical life will decrease and cut-off failure may occur.14. Be careful that foreign matter and oils and fats kind don’t stick to the main terminal parts because it is likely to cause terminal parts to give offunusual heat. Also, please use the following materials for connected harnesses and bus bars.•10A TM type: Faston terminal for #187 tab terminal, 0.5 mm board thickness (JIS C2809-1992 compliant, flat type connection terminal)Harness nominal cross-sectional area Load input terminal: min. 2.0 mm 2Coil input terminal: min. 0.3 mm 2•60A and 80A types: Min. 14mm 2 nominal cross sectional area•300A type: Min. 100mm 2 nominal cross sectional area15. Use 40N to 70N of force as a guide to fasten the terminal connected to the 10A TM type. Please use caution when inserting or removing the terminal as the relay tab terminal may cause injuly.16. Place the PC board mount type (10A PC board type) securely by hand soldering after attaching it using M4 screw. Don’t submerge assembled board in cleaning solvent or water. Also, be careful not let flux overflow up from the PC board or adhere to the base of the relay.Recommended hand soldering conditions• Soldering iron: 30 to 60 W • Tip temperature: 400°C 752°F• Solder time: within approx. 5 seconds 17. Make sure the power is turned off when wiring.18. Incorrect wiring may causeunexpected malfunction and failure.19. Regarding AC cutoff, although there is no contact polarity, generally it is thought that the electrical life will shorten due to cutoff in the reverse direction, compared to DC cutoff. Confirm electrical life using actual load. In the case of DC cut-off, please note the contact polarity.20. Lead-free solder (tin, silver and copper) is used as pre-solder for the terminals of the PC board mount type (10A PC board type).21. The warranted tensile strength of the female connector lead wire used for connection that comes with the 80A and 300A connector type when attaching it to the relay body is 100N. Avoid excessive tension as this is a cause of broken wires and damage. Also, insert the female connectordeeply and make sure the connection is secure.。

松下电焊机维修指南目录第一章KR 系列CO2 气体保护焊机典型故障及排除方法 (1)第二章YM-500CL4 焊机典型故障分析 (15)第三章YC—300TSP 焊机典型故障及排除方法 (18)第四章YC—300WP4 焊机典型故障及排除方法 (22)第五章YE-150TM 工作原理简述及典型故障分析 (28)第六章直流弧焊机典型故障分析 (30)第七章YP—060PS 切割机工作原理简述及典型故障分析 (32)第八章YC—315TR5HGE 逆变氩弧焊机故障排除方法 (41)第一章KR 系列CO2 气保焊机典型故障及排除方法一. 焊机故障原因KR 系列CO2 气体保护焊机以其先进的控制技术、良好的焊接性能以及高可靠性得到了众多用户的认可。

众所周知, 电焊机不同于家电，大多都处在比较差的环境下工作，因此从客观上讲，电焊机在使用过程中出现一些故障是在所难免的。

究其产生故障的原因，从维修的角度看不外乎以下三种：1。

内部原因2。

外部原因3. 人为原因具体来说造成电焊机故障的内部原因主要是：1。

P 板上的元器件损坏。

2. 晶闸管模块损坏。

3。

接触器、控变损坏。

4。

主变、电抗器等器件损坏。

5。

电流互感器损坏。

6。

输入组件损坏.造成电焊机故障的外部原因主要是：1。

外电波动较大,其波动范围超过了焊机正常工作所允许电压范围380V±10% 。

2. 送丝机控制电缆损伤。

3. 输入、输出电缆连接不牢固。

4。

CO2 气体不纯。

5。

环境条件恶劣（露天无防护措施使用，在粉尘、油烟较大或有腐蚀性气体场所使用）.6。

动物（蛇、老鼠等）进入机内。

7。

其它金属异物进入机内。

造成电焊机故障的人为原因主要是：1. 运输中损坏(特别是流动作业的用户经常搬运电焊机）.2。

使用、保养不当（如操作者或其他人用手拽电缆的方式移动送丝机，导电嘴没拧紧等）.3. 修理中P 板上的电位器调乱，或将保险插错位置。

对维修人员来说，在着手检修电焊机时，首先应根据电焊机的故障现象判断故障的起因是在焊机的内部还是外部，然后通过现场观察,向操作者了解和亲自动手检查以便迅速准确地找到故障点。

松下波轮洗衣机故障代码松下全自动洗衣机显示故障代码H59 风扇电机异常H01 水位(压力)感应异常U11 (较常见)排水异常，一般是排水口堵塞，也可能是掉硬币进去了H27 机盖锁定开关异常H43 洗衣桶内部漏水U54 貌似没有这个故障代码的H09 通讯线断线的异常松下洗衣机维修故障代码021-松下洗衣机维修Ed.门未关，检查机门是否打开。
