24.437 电力电子正弦脉宽调制如图1所示，电压源逆变器的开关可以按要求打开和关闭。

用最简单的方法，顶部的开关打开，如果每个周期打开和关闭，则方波的波形结果只有一次。

但是如果改进谐波的数据则在个周期内可以实现多次打开关闭。

图1 简单的电压源逆变器 如图2所示，用最直接的执行方式，所期望的输出电压是通过比较预期的参考波形与高频率的三角载波(调制信号) 生成的，无论直流电压是正还是负，信号电压的输出只根据信号电压是否大于或小于载波波形，要注意的是，在此期间一个三角载波周期的平均电压即信号的振幅加到负载形成正比(假定不变)。

经过一段时间，三角载波的负荷是正比于幅值的信号，在这期间，由此产生的方波包含有在它低频元件所需波形的幅值，也具有较高频率分量在一个载波临近频率的幅值。

需要注意的是，由于PWM 使得总谐波不失真，均方根的平均交流电压波形幅值仍与直流电压相等。

谐波分量只是转移到了更高的平率范围，并由电感式交流系统自动过滤。

当正弦波调制信号的振幅为Am ，三角载波的振幅为Ac 时，它们的调制指数就是m=Am/ Ac 。

因此，控制调制指数控制着输出电压的幅值。

如图3所示，fc/fm=21 ，t=L/R=T/3，T 为基本周期，由于感性元件的存在，高频成分不能明显的传播到交流网络(或负载)，所以具有足够高的载波频率。

然而，由于具有较高的载波频率，从而导致在更多的功率损耗。

所以，在电力系统的应用中，通常认为使用2-15kHz 的开关频率最为合适。

此外，在三相系统中，建议使用)(,3N k k f f mc ∈=，使得三个波形对称。

图2 主要的脉宽调制图3 SPWM的fc/fm=48，L/R=T/3如图4所示，该过程是比较合适的，因为在该图中有三角载波，其中没有交集的载体作为信号周期。

然而，这种“超调”在一定量的范围内往往是允许获得更大的交流电压，使电压频谱呈现出差异。

需要注意的是，使用一个额外的比率形成一个反周期超过360°的对称波形。
